Daikin FXZQ-M Series Dimension Guide

EDUS 39 - 800 - F9_a
AMERICAS
FXZQ-M
4 Way Ceiling Mounted Cassette Unit
(2' × 2')

EDUS39-800-F9_a
FXZQ-M 1
FXZQ-M
4 Way Ceiling Mounted
Cassette Unit
(2’ × 2’)
1. External Appearance...................................................................................2
2. Specifications ..............................................................................................3
3. Dimensions .................................................................................................5
4. Piping Diagrams..........................................................................................7
5. Wiring Diagrams..........................................................................................8
6. Electric Characteristics................................................................................9
7. Capacity Tables ........................................................................................10
7.1 Cooling Capacity ........................................................................................ 10
7.2 Heating Capacity ........................................................................................ 11
8. Air Velocity and Temperature Distributions
(Reference Data).......................................................................................12
9. Sound Levels ............................................................................................18
10.Installation and Operation .........................................................................19
10.1 Center of Gravity ........................................................................................ 19
10.2 Installation Manual / Indoor Unit................................................................. 20
10.3 Installation Manual / Decoration Panel....................................................... 35
11.Accessories...............................................................................................37

External Appearance EDUS39-800-F9_a
2FXZQ-M
1. External Appearance
FXZQ07~18M

EDUS39-800-F9_a Specifications
FXZQ-M 3
2. Specifications
4 Way Ceiling Mounted Cassette Unit (2’ × 2’)
Notes:
1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB, 67°FWB
Outdoor temperature: 95°FDB
Equivalent ref. piping length: 25ft (Horizontal)
2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB.
Outdoor temperature: 47°FDB, 43°FWB
Equivalent ref. piping length: 25ft (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
5 Refer to page 9 for Power Input.
Model FXZQ07M7VJU FXZQ09M7VJU FXZQ12M7VJU
1 Cooling Capacity Btu/h 7,500 9,500 12,000
2 Heating Capacity Btu/h 8,700 11,100 14,000
Casing / Color Galvanized Steel / Non Painted Galvanized Steel / Non Painted Galvanized Steel / Non Painted
Dimensions: (H×W×D) in 10.24 (11.26) ×22.64 ×22.64
( ): include El. Compo box
10.24 (11.26) ×22.64 ×22.64
( ): include El. Compo box
10.24 (11.26) ×22.64 ×22.64
( ): include El. Compo box
Coil (Cross
Fin Coil)
Rows×Stages×FPI 2 ×10 ×17 2 ×10 ×17 2 ×10 ×17
Face Area ft² 2.9 2.9 2.9
Fan
Model QST32C15M QST32C15M QST32C15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output (High) W 55 55 55
Air Flow Rate (H/L) cfm 320/247 335/265 495/353
Drive Direct Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Air Filter Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Piping
Connections
Liquid Pipes in φ1/4 (Flare Connection) φ1/4 (Flare Connection) φ1/4 (Flare Connection)
Gas Pipes in φ1/2 (Flare Connection) φ1/2 (Flare Connection) φ1/2 (Flare Connection)
Drain Pipe in
VP20
External Dia. 1.02
Internal Dia. 0.79
VP20
External Dia. 1.02
Internal Dia. 0.79
VP20
External Dia. 1.02
Internal Dia. 0.79
Machine Weight (Mass) Lbs 42 42 42
4 Sound Level (H/L) dBA 31/29 33/29 41/34
Safety Devices Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A Series R-410A Series R-410A Series
Decoration
Panels
(Option)
Model BYFQ60BU BYFQ60BU BYFQ60BU
Color White (RAL 9010) White (RAL 9010) White (RAL 9010)
Dimensions: (H×W×D) in 2.17 ×27.56 ×27.56 2.17 ×27.56 ×27.56 2.17 ×27.56 ×27.56
Weight Lbs 6 6 6
Standard Accessories
Installation and Operation manual,
Paper pattern for installation, Drain
hose, Clamp metal, Washer fixing plate,
Sealing pads, Clamps, Screws, Washer
for hanger bracket, Insulation for fitting.
Installation and Operation manual,
Paper pattern for installation, Drain
hose, Clamp metal, Washer fixing plate,
Sealing pads, Clamps, Screws, Washer
for hanger bracket, Insulation for fitting.
Installation and Operation manual,
Paper pattern for installation, Drain
hose, Clamp metal, Washer fixing plate,
Sealing pads, Clamps, Screws, Washer
for hanger bracket, Insulation for fitting.
Drawing No. C:3TW30721-1
(
)
(
)
(
)

Specifications EDUS39-800-F9_a
4FXZQ-M
4 Way Ceiling Mounted Cassette Unit (2’ × 2’)
Notes:
1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB, 67°FWB
Outdoor temperature: 95°FDB
Equivalent ref. piping length: 25ft (Horizontal)
2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB.
Outdoor temperature: 47°FDB, 43°FWB
Equivalent ref. piping length: 25ft (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
5 Refer to page 9 for Power Input.
Model FXZQ18M7VJU
1 Cooling Capacity Btu/h 18,000
2 Heating Capacity Btu/h 21,000
Casing / Color Galvanized Steel / Non Painted
Dimensions: (H×W×D) in 10.24 (11.26) ×22.64 ×22.64
Coil (Cross
Fin Coil)
Rows×Stages×FPI 2×10 ×17
Face Area ft² 2.9
Fan
Model QST32C15M
Type Turbo Fan
Motor Output (High) W 55
Air Flow Rate (H/L) cfm 495/353
Drive Direct Drive
Temperature Control Microprocessor Thermostat for Cooling and Heating
Air Filter Resin Net
(with Mold Resistant)
Piping
Connections
Liquid Pipes in φ1/4 (Flare Connection)
Gas Pipes in φ1/2 (Flare Connection)
Drain Pipe in
VP20
External Dia. 1.02
Internal Dia. 0.79
Machine Weight (Mass) Lbs 42
4 Sound Level (H/L) dBA 41/34
Safety Devices Fuse
Refrigerant Control Electronic Expansion Valve
Connectable outdoor unit R-410A Series
Decoration
Panels
(Option)
Model BYFQ60BU
Color White (RAL 9010)
Dimensions: (H×W×D) in 2.17 ×27.56 ×27.56
Weight Lbs 6
Standard Accessories Installation and Operation manual, Paper pattern for installation, Drain hose, Clamp metal, Washer fixing plate, Sealing pads,
Clamps, Screws, Washer for hanger bracket, Insulation for fitting.
Drawing No. C:3TW30721-1
(
)

EDUS39-800-F9_a Dimensions
FXZQ-M 5
3. Dimensions
FXZQ07M7VJU
FXZQ09M7VJU
FXZQ12M7VJU
FXZQ18M7VJU
3TW30724-2

Dimensions EDUS39-800-F9_a
6FXZQ-M
3TW30724-3
FXZQ07~18M7VJU+ BYFQ60B8W1
BYFQ60B8W1U

EDUS39-800-F9_a Piping Diagrams
FXZQ-M 7
4. Piping Diagrams
R1T : Thermistor for suction air temperature
R2T : Thermistor for liquid line temperature
R3T : Thermistor for gas line temperature
Capacity GAS Liquid
07/09/12/18M φ1/2 φ1/4
C:4D040157
Heat exchanger Gas piping connection port
Liquid piping connection port
Fan
R3T
R1T
Electronic
expansion valve
Filter Filter
R2T

Wiring Diagrams EDUS39-800-F9_a
8FXZQ-M
5. Wiring Diagrams
FXZQ07M/09M/12M/18M7VJU
THERMISTOR (COIL-LIQUID)
MOTOR (DRAIN PUMP) LIGHT EMITTING DIODE (DEFROST-ORANGE) TRIAC CONNECTOR (WIRING ADAPTOR FOR ELECTORICAL APPENDICES)
THERMAL PROTECTOR (M1F EMBEDDED) MOTOR (SWING FLAP) TERMINAL BLOCK CONNECTOR (ADAPTOR FOR WIRING) LIGHT EMITTING DIODE (ON-RED) ELECTRONIC EXPANSION VALVE
CONNECTOR FOR OPTIONAL PARTS
PRINTED CIRCUIT BOARD MOTOR (INDOOR FAN) THERMISTOR (AIR)
PUSH BUTTON (ON/OFF)
PRINTED CIRCUIT BOARD SELECTOR SWITCH (WIRELESS ADDRESS SET) LIGHT EMITTING DIODE (TIMER-GREEN) THERMISTOR (COIL-GAS)
SELECTOR SWITCH (MAIN/SUB) LIGHT EMITTING DIODE (SERVICE MONITOR GREEN) FLOAT SWITCH THERMISTOR (AIR)
PRINTED CIRCUIT BOARD FUSE ( B , 5A, 250V) CAPACITOR (M1F)
WIRELESS REMOTE CONTROLLER (RECEIVER/DISPLAY UNIT)
MAGNETIC RELAY (M1P) LIGHT EMITTING DIODE (FILTER SIGN-RED)
WIRED REMOTE CONTROLLER
TERMINAL BLOCK SELECTOR SWITCH (MAIN/SUB)
F1U R1T Y1E V1TR X1M X2M X16A H4P HAP H1P Q1M A4P X18A M1F BS1 SS1 H2P
A1P R1T H3P T1R S1L M1S A3P M1P KPR SS2 R2T C1 SS1 R3T
TRANSFORMER (208-230V/22V)
WHT
X25A
X13A
X7A
WHT
CONTROL BOX
X1M
A1P
X2M
T1R
C1
C1
X2M
V1TR
X1M
L1
L2
X18A
A1P
X12A
RED
L2
M
~
t˚
t˚
t˚ t˚
X30A
NOTE) 4
INPUT FROM OUTSIDE
BLK
Q1M
KPR
X3A
X4A
P2
HAP
YLW
RED
GRN/YLW
R3T
WHT
X28A
M
YLW
WIRED REMOTE CONTROLLER
YLW
SS1
NOTE) 2
TRANSMISSION WIRING
CENTRAL REMOTE CONTROLLER
BS1
X16A
BLK
X8A
T2 F1 T1
P2
F2
P1
X11A
R2TR1T
M1F
SS1
PNK
YLW
R1T
S1L
BLU
M1P
SS2
M
X31A
MSW
L1
Y1E
F1U
ORG
M1S
P1
H1P H4P H3P
NOTE) 3
X23A
A3P
X1A
A4P
RECEIVER/DISPLAY UNIT
X1A
H2P
X2A
A1P
X1A
X23A
NOTE) 3
T1R
POWER SUPPLY
208-230V
~
60Hz
NOTES) 1. : TERMINAL , : CONNECTOR : FIELD WIRING 2. IN CASE USING CENTRAL REMOTE CONTROLLER, CONNECT IT TO THE UNIT IN ACCORDANCE WITH THE ATTACHED
INSTALLATION MANUAL.
3. X23A IS CONNECTED WHEN THE WIRELESS REMOTE CONTROLLER KIT IS BEING USED. 4. WHEN CONNECTING THE INPUT WIRES FROM OUTSIDE, FORCED OFF OR ON/OFF CONTROL OPERATION CAN BE
SELECTED BY REMOTE CONTROLLER. IN DETAILS, REFER TO THE INSTALLATION MANUAL ATTACHED THE UNIT.
5. REMOTE CONTROLLER MODEL VARIES ACCORDING TO THE COMBINATION SYSTEM, CONFIRM ENGINEERING
MATERIALS AND CATALOGS, ETC. BEFORE CONNECTING.
6. SYMBOLS SHOW AS FOLLOWS: RED : RED BLK : BLACK WHT : WHITE YLW : YELLOW PNK : PINK ORG : ORANGE
GRN : GREEN BLU : BLUE
C:3D059263 C:3TW30726-1

EDUS39-800-F9_a Electric Characteristics
FXZQ-M 9
6. Electric Characteristics
Units Power supply IFM Input (W)
Model Hz Volts Voltage range MCA MFA kW FLA Cooling Heating
FXZQ07M7VJU
60 208-230 MAX. 253
MIN. 187
0.8 15 0.055 0.6 75 69
FXZQ09M7VJU 0.8 15 0.055 0.6 75 69
FXZQ12M7VJU 0.8 15 0.055 0.6 80 73
FXZQ18M7VJU 0.9 15 0.055 0.7 128 122

Capacity Tables EDUS39-800-F9_a
10 FXZQ-M
7. Capacity Tables
7.1 Cooling Capacity
FXZQ-M
C: 3TW30722-1
TC : Total capacity ; MBH
SHC : Sensible heat capacity ; MBH
Refer to Outdoor Unit Capacity Tables : for the actual performance data of each indoor and outdoor unit combination.
Unit size
Outdoor
air temp.
°FDB
Indoor Air Temp. °FWB
61 64 67 70 72 75
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
MBHMBHMBHMBHMBHMBHMBHMBHMBHMBHMBHMBH
07
75 5.9 5.0 6.7 5.5 7.5 5.9 8.3 6.1 8.8 6.0 8.9 5.4
79 5.9 5.0 6.7 5.5 7.5 5.9 8.3 6.1 8.6 5.9 8.8 5.3
83 5.9 5.0 6.7 5.5 7.5 5.9 8.3 6.1 8.5 5.8 8.6 5.2
87 5.9 5.0 6.7 5.5 7.5 5.9 8.2 6.1 8.3 5.7 8.5 5.1
91 5.9 5.0 6.7 5.5 7.5 5.9 8.1 6.0 8.2 5.6 8.4 5.0
95 5.9 5.0 6.7 5.5 7.5 5.9 8.0 5.9 8.1 5.5 8.2 4.9
99 5.9 5.0 6.7 5.5 7.5 5.9 7.8 5.8 7.9 5.4 8.1 4.8
103 5.9 5.0 6.7 5.5 7.5 5.9 7.7 5.7 7.8 5.3 7.9 4.8
09
75 7.5 6.0 8.5 6.5 9.5 6.7 10.5 7.0 11.1 6.9 11.3 6.4
79 7.5 6.0 8.5 6.5 9.5 6.7 10.5 7.0 10.9 6.8 11.1 6.3
83 7.5 6.0 8.5 6.5 9.5 6.7 10.5 7.0 10.7 6.7 10.9 6.2
87 7.5 6.0 8.5 6.5 9.5 6.7 10.4 7.0 10.6 6.6 10.9 6.2
91 7.5 6.0 8.5 6.5 9.5 6.7 10.3 6.9 10.4 6.4 10.6 6.0
95 7.5 6.0 8.5 6.5 9.5 6.7 10.1 6.8 10.2 6.3 10.4 5.9
99 7.5 6.0 8.5 6.5 9.5 6.7 9.9 6.6 10.0 6.2 10.2 5.8
103 7.5 6.0 8.5 6.5 9.5 6.7 9.7 6.5 9.9 6.1 10.0 5.7
12
75 9.5 6.8 10.7 7.6 12.0 8.0 13.3 8.2 14.0 8.1 14.3 7.8
79 9.5 6.8 10.7 7.6 12.0 8.0 13.3 8.2 13.8 8.0 14.0 7.7
83 9.5 6.8 10.7 7.6 12.0 8.0 13.3 8.2 13.6 7.9 13.8 7.6
87 9.5 6.8 10.7 7.6 12.0 8.0 13.2 8.2 13.3 7.7 13.6 7.5
91 9.5 6.8 10.7 7.6 12.0 8.0 13.0 8.0 13.1 7.6 13.4 7.4
95 9.5 6.8 10.7 7.6 12.0 8.0 12.7 7.9 12.9 7.5 13.1 7.2
99 9.5 6.8 10.7 7.6 12.0 8.0 12.5 7.8 12.7 7.3 12.9 7.1
103 9.5 6.8 10.7 7.6 12.0 8.0 12.3 7.6 12.4 7.2 12.7 7.0
18
75 14.2 11.4 16.1 12.2 18.0 13.0 19.9 13.7 21.0 13.9 21.4 12.8
79 14.2 11.4 16.1 12.2 18.0 13.0 19.9 13.7 20.7 13.7 21.1 12.6
83 14.2 11.4 16.1 12.2 18.0 13.0 19.9 13.7 20.4 13.4 20.7 12.4
87 14.2 11.4 16.1 12.2 18.0 13.0 19.8 13.6 20.0 13.2 20.4 12.2
91 14.2 11.4 16.1 12.2 18.0 13.0 19.4 13.4 19.7 13.0 20.1 12.0
95 14.2 11.4 16.1 12.2 18.0 13.0 19.1 13.2 19.3 12.8 19.7 11.8
99 14.2 11.4 16.1 12.2 18.0 13.0 18.8 12.9 19.0 12.5 19.4 11.6
103 14.2 11.4 16.1 12.2 18.0 13.0 18.4 12.7 18.7 12.3 19.0 11.4

EDUS39-800-F9_a Capacity Tables
FXZQ-M 11
7.2 Heating Capacity
FXZQ-M
c: 3TW30722-2
TC : Total capacity ; MBH
Refer to Outdoor Unit Capacity Tables : for the actual performance data of each indoor and outdoor unit combination.
Unit
size
Outdoor Air
Temp.
Indoor Air Temp. °FDB
Unit
size
Outdoor Air
Temp.
Indoor Air Temp. °FDB
62 65 68 70 72 75 62 65 68 70 72 75
°FDB °FWB TC TC TC TC TC TC °FDB °FWB TC TC TC TC TC TC
MBHMBHMBHMBHMBHMBH MBHMBHMBHMBHMBHMBH
07
22.0 20.0 7.3 7.3 7.3 7.3 7.3 7.2
12
22.0 20.0 11.7 11.7 11.6 11.6 11.6 11.6
26.0 24.0 7.6 7.6 7.6 7.6 7.6 7.6 26.0 24.0 12.2 12.2 12.2 12.2 12.2 12.1
30.0 28.0 8.0 8.0 8.0 8.0 7.9 7.7 30.0 28.0 12.8 12.8 12.7 12.7 12.7 12.3
35.0 32.0 8.3 8.3 8.3 8.3 8.1 7.7 35.0 32.0 13.3 13.3 13.3 13.3 13.0 12.3
39.0 36.0 8.7 8.7 8.7 8.4 8.1 7.7 39.0 36.0 13.9 13.9 13.9 13.5 13.0 12.3
44.0 40.0 9.0 9.0 8.7 8.5 8.1 7.7 44.0 40.0 14.5 14.4 14.0 13.5 13.0 12.3
47.0 43.0 9.3 9.2 8.7 8.5 8.1 7.7 47.0 43.0 14.9 14.7 14.0 13.5 13.0 12.3
51.0 47.0 9.6 9.2 8.7 8.5 8.1 7.7 51.0 47.0 15.4 14.7 14.0 13.5 13.0 12.3
54.0 50.0 9.7 9.2 8.7 8.5 8.1 7.7 54.0 50.0 15.5 14.7 14.0 13.5 13.0 12.3
57.0 53.0 9.7 9.2 8.7 8.5 8.1 7.7 57.0 53.0 15.5 14.7 14.0 13.5 13.0 12.3
60.0 56.0 9.7 9.2 8.7 8.5 8.1 7.7 60.0 56.0 15.5 14.7 14.0 13.5 13.0 12.3
09
22.0 20.0 9.2 9.2 9.2 9.2 9.2 9.2
18
22.0 20.0 17.5 17.5 17.4 17.4 17.4 17.4
26.0 24.0 9.7 9.7 9.6 9.6 9.6 9.6 26.0 24.0 18.3 18.3 18.3 18.3 18.2 18.2
30.0 28.0 10.1 10.1 10.1 10.1 10.1 9.7 30.0 28.0 19.2 19.1 19.1 19.1 19.1 18.4
35.0 32.0 10.6 10.5 10.5 10.5 10.3 9.7 35.0 32.0 20.0 20.0 19.9 19.9 19.5 18.4
39.0 36.0 11.0 11.0 11.0 10.5 10.3 9.7 39.0 36.0 20.8 20.8 20.8 20.0 19.5 18.4
44.0 40.0 11.4 11.4 11.1 10.5 10.3 9.7 44.0 40.0 21.7 21.6 21.0 20.0 19.5 18.4
47.0 43.0 11.8 11.7 11.1 10.5 10.3 9.7 47.0 43.0 22.3 22.1 21.0 20.0 19.5 18.4
51.0 47.0 12.2 11.7 11.1 10.5 10.3 9.7 51.0 47.0 23.1 22.1 21.0 20.0 19.5 18.4
54.0 50.0 12.3 11.7 11.1 10.5 10.3 9.7 54.0 50.0 23.2 22.1 21.0 20.0 19.5 18.4
57.0 53.0 12.3 11.7 11.1 10.5 10.3 9.7 57.0 53.0 23.2 22.1 21.0 20.0 19.5 18.4
60.0 56.0 12.3 11.7 11.1 10.5 10.3 9.7 60.0 56.0 23.2 22.1 21.0 20.0 19.5 18.4

Air Velocity and Temperature Distributions (Reference Data) EDUS39-800-F9_a
12 FXZQ-M
8. Air Velocity and Temperature Distributions
(Reference Data)
FXZQ07, 09M <Cooling mode>

EDUS39-800-F9_a Air Velocity and Temperature Distributions (Reference Data)
FXZQ-M 13
FXZQ07, 09M <Heating mode>

Air Velocity and Temperature Distributions (Reference Data) EDUS39-800-F9_a
14 FXZQ-M
FXZQ12M <Cooling mode>

EDUS39-800-F9_a Air Velocity and Temperature Distributions (Reference Data)
FXZQ-M 15
FXZQ12M <Heating mode>

Air Velocity and Temperature Distributions (Reference Data) EDUS39-800-F9_a
16 FXZQ-M
FXZQ18M <Cooling mode>

EDUS39-800-F9_a Air Velocity and Temperature Distributions (Reference Data)
FXZQ-M 17
FXZQ18M <Heating mode>

Sound Levels EDUS39-800-F9_a
18 FXZQ-M
9. Sound Levels
Overall
Octave Band Level
208V~230V
4 Way Ceiling Mounted Cassette Unit Notes:
Operation noise differs with operation and ambient
conditions.
dBA
Model 208~230V, 60Hz
HL
FXZQ07M7VJU 32 29
FXZQ09M7VJU 32 29
FXZQ12M7VJU 33 29
FXZQ18M7VJU 41 34
FXZQ07/09M7VJU FXZQ12M7VJU FXZQ18M7VJU
OCTAVE BAND SOUND PRESSURE LEVEL dB (0dB=0.0002μbar)
OCTAVE BAND CENTER FREQUENCY (Hz)
APPROXIMATE
THRESHOLD
HEARING FOR
CONTINUOUS NOISE
70
60
50
40
30
20
63 125 250 500 1000 2000 4000 8000
HI
LOW
4TW30727-1
NC-60
NC-50
NC-40
NC-30
NC-20
OCTAVE BAND SOUND PRESSURE LEVEL dB (0dB=0.0002μbar)
OCTAVE BAND CENTER FREQUENCY (Hz)
APPROXIMATE
THRESHOLD
HEARING FOR
CONTINUOUS NOISE
70
60
50
40
30
20
63 125 250 500 1000 2000 4000 8000
HI
LOW
4TW30747-1
NC-60
NC-50
NC-40
NC-30
NC-20
OCTAVE BAND SOUND PRESSURE LEVEL dB (0dB=0.0002μbar)
OCTAVE BAND CENTER FREQUENCY (Hz)
APPROXIMATE
THRESHOLD
HEARING FOR
CONTINUOUS NOISE
70
60
50
40
30
20
63 125 250 500 1000 2000 4000 8000
HI
LOW
4TW30757-1
NC-60
NC-50
NC-40
NC-30
NC-20

EDUS39-800-F9_a Installation and Operation
FXZQ-M 19
10.Installation and Operation
10.1 Center of Gravity
