Daikin Modular T User manual

Modular T
Traduzione delle istruzioni originali
Installation manual
Digital Node
Modular T
REV 00
DATE December 2022
REPLACES
D-EIMOC2009-27_00EN
Modular T Smart ABT
Traduzione delle istruzioni originali
Manuale di installazione
uso e manutenzione
Modular T Smart ATB

2
The pictogram shows a situation of immediate danger or a dangerous situation that might cause injuries or death.
The pictogram shows that it is necessary to adopt suitable behaviour in order to avoid jeopardising sta safety and
cause damages to the equipment.
The pictogram shows particularly important technical information that should be taken into consideration by the
people installing or using the equipment.
Important warnings
1
Read this manual carefully before installation and keep it for any further future consultation by the vari-
ous operators. Do not remove, tear out or rewrite any part of this manual.
Failure to follow these instructions may cause damage and injuries, even fatal, voids
the warranty and relieves the Manufacturer of any liability.
All installation, assembly, electrical connections to the mains and ordinary/extraordinary
maintenancemustbeperformedonlybytechnicianscomplyingwiththelegalrequirements,
after turning o the unit and using personal protective equipment (i.e. gloves, protective goggles,
etc.), in compliance with the regulations in force in the country the equipment is to be used in and
the laws on safety in the workplace.
Installation, use or maintenance other than those specied in the manual may cause damage,
injury or death, invalidate the warranty and relieve the Manufacturer of all liability.
Use protective clothing and suitable equipment while handling or installing the equipment, in
order to prevent accidents and safeguard your own and other people’s safety. Individuals not
assigned to installation or maintenance are NOT allowed to stand or pass through the work area
while the unit is assembled.
Before carrying out any installation, disconnect the equipment from the power supply
and wait at least 120 seconds before carrying out any operation.
It is the responsibility of the user/installer to check the static and dynamic stability relative to the
installation and to arrange environments so that people who are not competent or authorised
DO NOT have access to the unit or to its controls.

AB
C
D
A
B
C
D
3
air ducts
(not supplied)
DIGITAL NODE
Right Handling
VERSION MACHINES
ATB**R**
Left handling
VERSION MACHINES
ATB**L**
1Box Digital Node position
Installation
2
DUCT
AExhaust air
BFresh air
CReturn air
DSupply air

Component Q.ty
ATE00PDUA
Digital Node 1
ATE00PDUA
Connector bus
+ power supply digital PCB QE 1
ATE00PDUA
Metal plate 1
ATE00PDUA
Washer
5x15x1.5 2
ATE00PDUA
8.8 Zinc plated full thread cap screw 2
ATE00PDUA
4,8x13
Drilling screw, round head with H recessed head 4
4
Components

ATE00PDUA
1
2
5
2
3
Remove Box Digital Node cap
Mounting metal plate and Box Digital Node
Box Digital Node mounting

Not
provided
123
62 61 63 64 65 66
4
5
6
4Connect Box Digital Node
Connect according to
the wiring diagram
Association of cables
with terminal blocks:
red-61
black - 62
white - 63
brown-64
green - 65
black (shielding) - 66
6

BUS-IN BUS-OUT
Position of pressure
transducer P1 and P2
7
5Connect Box Digital Node

2
1
1
LED1 = green ON
LED2 = red Hardware error, replace the board
LED3 = yellow I/O error, incorrect wiring indicated by the controller
LED4 = blue communication OK
LED5 = yellow communication timeout with the controller
LED6 = red unit in alarm state
Perform accessory wiring,
if required
8
6
7
Repositioning Box Digital Node cap
Status LED
