Daikin RXS-L Instruction manual

Air Conditioning
Technical Data
EEDEN14-100
RXS-L

• Split - Sky Air • RXS-L 1
• Outdoor Unit • RXS-L
TABLE OF CONTENTS
RXS-L
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cooling/Heating Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6 Centre of gravity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
8 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Sound Pressure Spectrum - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Sound Pressure Spectrum - Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
10 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

• Outdoor Unit • RXS-L
1
• Split - Sky Air • RXS-L
2
1 Features
OutdoorUni Split-Sk RXS-L • Optimised heating solution for your home
• Energy saving during standby mode: reduces current consumption
by about 80% when operating In standby. If no people are detected
for more than 20 minutes, the system will automatically switch to the
current-saving mode.
• Outdoor unit silent operation: "silent" button on the remote control
lowers the operation sound of the outdoor unit by 3dBA to ensure a
quiet environment for the neighbourhood.
• Outdoor units for pair application
• Daikin outdoor units are neat, sturdy and can easily be mounted on a
roof or terrace or simply placed against an outside wall
• Outdoorunitsarefitted withaswing compressor,renownedforits low
noise and high energy efficiency
• Anti-corrosion treated outdoor heat exchanger fin
Inverter Energy saving
during standby
mode
Powerful mode Auto cooling-
heating
changeover
Outdoor unit
silent operation

3
2
• Split - Sky Air • RXS-L 3
• Outdoor Unit • RXS-L
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
(2) 220V
(3) 230V
(4) 240V
2-1 Nominal Capacity And Nominal Input FTXS20K/RXS20L FTXS25K/RXS25L FTXS35K/RXS35L FTXS42K/RXS42L FTXS50K/RXS50L
Coolingcapacity Min. kW 1.3 1.4 1.7
Btu/h 4,400 4,800 5,800
kcal/h 1,120 1,200 1,460
Nom. kW 2.00 2.5 3.5 4.20 5.00
Btu/h 6,800 8,500 11,900 14,300 17,100
kcal/h 1,720 2,150 3,010 3,610 4,300
Max. kW2.83.24.05.05.3
Btu/h 9,600 10,900 13,600 17,100 18,100
kcal/h 2,410 2,750 3,440 4,300 4,560
Heating capacity Min. kW 1.3 1.4 1.7
Btu/h 4,400 4,800 5,800
kcal/h 1,120 1,200 1,460
Nom. kW 2.5 2.8 4.00 5.40 5.80
Btu/h 8,500 9,600 13,600 18,400 19,800
kcal/h 2,150 2,410 3,440 4,640 4,990
Max. kW4.34.75.26.06.5
Btu/h 14,700 16,000 17,700 20,500 22,200
kcal/h 3,700 4,040 4,470 5,160 5,590
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A++
Pdesign kW 2.00 2.50 3.50 4.20 5.00
SEER 7.40 7.90 7.47 6.80
Annual energy
consumption kWh 95 111 164 216 257
Heating (Average
climate) Energy label A++ A+
Pdesign kW 2.30 2.50 3.60 4.00 4.60
SCOP 4.77 4.78 4.85 4.20
Annual energy
consumption kWh 675 732 1,039 1,334 1,535
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 4.65 4.39 4.07 3.56 3.55
COP 4.72 4.67 4.76 4.12 4.00
Annual energy consumption kWh 215 285 430 590 705
Energy label Cooling A
Heating A
Piping connections Liquid OD mm 6
Gas OD mm 9.5 12.7
Drain OD mm 18
Heat insulation Both liquid and gas pipes
Current Nominal running
current(RLA)-50Hz Cooling A 2.4 (2) / 2.3 (3) / 2.2 (4) 3.2 (2) / 3.1 (3) / 3.0(4) 4.3 (2) / 4.1 (3) / 3.9 (4) 6.0 (2) / 5.7 (3) / 5.5 (4) 6.6 (2) / 6.3 (3) / 6.0 (4)
Heating A 2.8 (2) / 2.7 (3) /
2.6 (4) 3.3 (2) / 3.2 (3) / 3.1(4) 4.3 (2) / 4.1 (3) / 3.9 (4) 6.6 (2) / 6.3 (3) / 6.0 (4) 6.8 (2) / 6.5 (3) / 6.2 (4)
2-2 Nominal Capacity And Nominal Input FTXS60G/RXS60L
Cooling capacity Min. kW 1.7
Btu/h 5,800
kcal/h 1,460
Nom. kW 6.0
Btu/h 20,500
kcal/h 5,160
Max. kW 6.7
Btu/h 22,900
kcal/h 5,760

• Outdoor Unit • RXS-L
2
• Split - Sky Air • RXS-L
4
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
(2) 220V
(3) 230V
(4) 240V
Heating capacity Min. kW 1.7
Btu/h 5,800
kcal/h 1,460
Nom. kW 7.0
Btu/h 23,900
kcal/h 6,020
Max. kW 8.0
Btu/h 27,300
kcal/h 6,880
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A
Pdesign kW 6.00
SEER 5.58
Annual energy
consumption kWh 376
Heating (Average
climate) Energy label A
Pdesign kW 4.80
SCOP 3.89
Annual energy
consumption kWh 1,728
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.02
COP 3.43
Annual energy consumption kWh 995
Energy label Cooling B
Heating B
Piping connections Liquid OD mm 6
Gas OD mm 12.7
Drain OD mm 18
Heat insulation Both liquid and gas pipes
Current Nominal running
current(RLA)-50Hz Cooling A 9.2 (2) / 8.8 (3) / 8.4 (4)
Heating A 9.4 (2) / 9.0 (3) / 8.6 (4)
2-3 Nominal Capacity And Nominal Input FVXS25F/RXS25L FVXS35F/RXS35L FVXS50F/RXS50L
Cooling capacity Min. kW 1.3 1.4
Btu/h 4,400 4,800
kcal/h 1,120 1,200
Nom. kW 2.5 3.5 5.0
Btu/h 8,500 11,900 17,100
kcal/h 2,150 3,010 4,300
Max. kW 3.0 3.8 5.6
Btu/h 10,200 13,000 19,100.0
kcal/h 2,580 3,270 4,820.0
Heating capacity Min. kW 1.3 1.4
Btu/h 4,400 4,800
kcal/h 1,120 1,200
Nom. kW 3.4 4.5 5.8
Btu/h 11,600 15,400 19,800
kcal/h 2,920 3,870 4,990
Max. kW 4.5 5.0 8.1
Btu/h 15,400 17,100 27,600
kcal/h 3,870 4,300 6,970
2-2 Nominal Capacity And Nominal Input FTXS60G/RXS60L

3
2
• Split - Sky Air • RXS-L 5
• Outdoor Unit • RXS-L
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
(2) 220V
(3) 230V
(4) 240V
(5) Cooling: indoor temp. 27°CDB, 19.0°CWB; outdoor temp. 35°CDB, 24°CWB; equivalent piping length: 5m
(6) Heating: indoor temp. 20°CDB; outdoor temp. 7°CDB, 6°CWB; equivalent refrigerant piping: 5m
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A+
Pdesign kW 2.50 3.50 5.00
SEER 5.74 5.60 5.89
Annual energy
consumption kWh 152 219 297
Heating (Average
climate) Energy label A+ A
Pdesign kW 2.60 2.90 4.20
SCOP 4.56 3.93 3.80
Annual energy
consumption kWh 798 1,033 1,546
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 4.39 3.43 3.23
COP 4.42 3.78 3.63
Annual energy consumption kWh 285 510 775
Energy label Cooling A
Heating A
Piping connections Liquid OD mm 6 6.35
Gas OD mm 9.5 12.7
Drain OD mm 20
Heat insulation Both liquid and gas pipes
Current Nominal running
current(RLA)-50Hz Cooling A 3.5 (2) / 3.3 (3) / 3.2 (4) 4.9 (2) / 4.7 (3) / 4.5 (4) 7.2 (2) / 6.8 (3) / 6.6 (4)
Heating A 4.5 (2) / 4.3 (3) / 4.1 (4) 5.9 (2) / 5.6 (3) / 5.4 (4) 7.3 (2) / 7.0 (3) / 6.7 (4)
2-4 Nominal Capacity And Nominal Input FLXS25B/RXS25L FLXS50B/RXS50L
Cooling capacity Min. kW 1.2 0.9
Btu/h 4,100 3,070
kcal/h 1,030 770
Nom. kW 2.5 4.9
Btu/h 8,500 16,730
kcal/h 2,150 4,210
Max. kW 3.0 5.3
Btu/h 10,200 18,090
kcal/h 2,580 4,560
Heating capacity Min. kW 1.2 0.9
Btu/h 4,100 3,070
kcal/h 1,030 770
Nom. kW 3.4 6.1
Btu/h 11,600 20,830
kcal/h 2,920 5,250
Max. kW 4.5 7.5
Btu/h 15,400 18,090
kcal/h 3,870 6,450
2-3 Nominal Capacity And Nominal Input FVXS25F/RXS25L FVXS35F/RXS35L FVXS50F/RXS50L

• Outdoor Unit • RXS-L
2
• Split - Sky Air • RXS-L
6
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
(2) 220V
(3) 230V
(4) 240V
(5) Cooling: indoor temp. 27°CDB, 19.0°CWB; outdoor temp. 35°CDB, 24°CWB; equivalent piping length: 5m
(6) Heating: indoor temp. 20°CDB; outdoor temp. 7°CDB, 6°CWB; equivalent refrigerant piping: 5m
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A
Pdesign kW 2.50 4.90
SEER 5.19 5.25
Annual energy
consumption kWh 169 326
Heating (Average
climate) Energy label A
Pdesign kW 2.50 4.20
SCOP 3.80
Annual energy
consumption kWh 921 1,546
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.85 2.85
COP 3.54 3.35
Annual energy consumption kWh 325 860
Energy label Cooling A C
Heating B C
Piping connections Liquid OD mm 6.35
Gas OD mm 9.5 12.7
Drain OD mm 18.0 20
Heat insulation Both liquid and gas pipes
Current Nominal running
current(RLA)-50Hz Cooling A 3.7 (2) / 3.6 (3) / 3.4 (4) 8.0 (2) / 7.6 (3) / 7.3 (4)
Heating A 4.7 (2) / 4.5 (3) / 4.3 (4) 8.4 (2) / 8.0 (3) / 7.7 (4)
2-5 Nominal Capacity And Nominal Input FLXS35B9/RXS35L
Cooling capacity Min. kW 1.2
Btu/h 4,100
kcal/h 1,030
Nom. kW 3.5
Btu/h 11,900
kcal/h 3,010
Max. kW 3.8
Btu/h 13,000
kcal/h 3,270
Heating capacity Min. kW 1.4
Btu/h 4,100
kcal/h 1,030
Nom. kW 4.0
Btu/h 13,600
kcal/h 3,440
Max. kW 5.0
Btu/h 17,100
kcal/h 4,300
2-4 Nominal Capacity And Nominal Input FLXS25B/RXS25L FLXS50B/RXS50L

3
2
• Split - Sky Air • RXS-L 7
• Outdoor Unit • RXS-L
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
(2) 220V
(3) 230V
(4) 240V
(5) Cooling: indoor temp. 27°CDB, 19.0°CWB; outdoor temp. 35°CDB, 24°CWB; equivalent piping length: 5m
(6) Heating: indoor temp. 20°CDB; outdoor temp. 7°CDB, 6°CWB; equivalent refrigerant piping: 5m
Seasonal efficiency
(according to
EN14825)
Cooling Energy label B
Pdesign kW 3.50
SEER 4.87
Annual energy
consumption kWh 252
Heating (Average
climate) Energy label A
Pdesign kW 2.90
SCOP 3.80
Annual energy
consumption kWh 1,068
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.10
COP 3.57
Annual energy consumption kWh 565
Energy label Cooling B
Heating B
Piping connections Liquid OD mm 6.35
Gas OD mm 9.5
Drain OD mm 18.0
Heatinsulation Both liquid andgas pipes
Current Nominal running
current(RLA)-50Hz Cooling A 5.3 (2) / 5.1 (3) / 4.9 (4)
Heating A 5.6 (2) / 5.3 (3) / 5.1 (4)
2-6 Nominal Capacity And Nominal Input FDXS25F/RXS25L FDXS35F/RXS35L FDXS60F/RXS60L
Coolingcapacity Min. kW 1.3 1.4 1.7
Btu/h 4,400 4,800 5,800
kcal/h 1,110 1,200 1,460
Nom. kW 2.4 3.4 6.0
Btu/h 8,150 11,500 20,500
kcal/h 2,060 2,920 5,160
Max. kW 3.0 3.8 6.5
Btu/h 10,200 13,000 22,200
kcal/h 2,580 3,260 5,590
Heating capacity Min. kW 1.3 1.4 1.7
Btu/h 4,400 4,800 5,800
kcal/h 1,110 1,200 1,460
Nom. kW 3.2 4.0 7.0
Btu/h 10,900 13,600 23,900
kcal/h 2,750 3,440 6,020
Max. kW 4.5 5.0 8.0
Btu/h 15,350 17,100 27,300
kcal/h 3,870 4,300 6,880
2-5 Nominal Capacity And Nominal Input FLXS35B9/RXS35L

• Outdoor Unit • RXS-L
2
• Split - Sky Air • RXS-L
8
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
(2) 230V
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A+ A
Pdesign kW 2.40 3.40 6.00
SEER 5.63 5.21 5.51
Annual energy
consumption kWh 149 228 381
Heating (Average
climate) Energy label A+ A
Pdesign kW 2.60 2.90 4.60
SCOP 4.24 3.88 3.80
Annual energy
consumption kWh 858 1,047 1,693
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.69 3.21 2.91
COP 4.00 3.48 3.21
Annual energy consumption kWh 325 530 1,030
Energy label Cooling A C
Heating A B C
Piping connections Liquid OD mm 6.35
Gas OD mm 9.5 12.7
Drain OD mm VP20 (External dia.26 / Internal dia. 20)
Heat insulation Both liquid and gas pipes
Current Nominal running
current(RLA)-50Hz Cooling A 3.9 (2) 4.9 (2) 9.2 (2)
Heating A 4.2 (2) 5.4 (2) 10.0 (2)
2-7 Nominal Capacity And Nominal Input FDXS50F9/RXS50L
Cooling capacity Min. kW 1.7
Btu/h 5,800
kcal/h 1,460
Nom. kW 5.0
Btu/h 17,100
kcal/h 4,300
Max. kW 5.3
Btu/h 18,100
kcal/h 4,560
Heating capacity Min. kW 1.7
Btu/h 5,800
kcal/h 1,460
Nom. kW 5.8
Btu/h 19,800
kcal/h 4,990
Max. kW 6.0
Btu/h 20,500
kcal/h 5,160
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A+
Pdesign kW 5.00
SEER 5.72
Annual energy
consumption kWh 306
Heating (Average
climate) Energy label A
Pdesign kW 4.00
SCOP 3.93
Annual energy
consumption kWh 1,425
2-6 Nominal Capacity And Nominal Input FDXS25F/RXS25L FDXS35F/RXS35L FDXS60F/RXS60L
