Daikin FTYN25DV3B ATY20DV2 User manual

SiBE01 - 503
SPLIT Pair
D-Series
[Applied Models]
zNon-Inverter Pair : Heat Pump

SiBE01-503
Table of Contents i
Non Inverter Pair
D-Series
zHeat Pump
Indoor Unit
FTYN25DV3B ATY20DV2
FTYN35DV3B ATY25DV2
ATY35DV2
Outdoor Unit
RYN25DV3B ARY20DV2
RYN35DV3B ARY25DV2
ARY35DV2

SiBE01-503
ii Table of Contents
1. Introduction .............................................................................................v
1.1 Safety Cautions ........................................................................................v
Part 1 List of Function .................................................................. 1
1. Functions.................................................................................................2
Part 2 Specifications .................................................................... 5
1. Specifications ..........................................................................................6
Part 3 Printed Circuit Board Connector Wiring Diagram ............. 9
1. Printed Circuit Board Connector Wiring Diagram..................................10
1.1 Indoor Unit..............................................................................................10
Part 4 Functions and Control...................................................... 13
1. Functions...............................................................................................14
1.1 Power-Airflow Dual Flaps, Wide-Angle Louvers and Auto-Swing ..........14
1.2 Fan Speed Control for Indoor Units........................................................15
1.3 Thermostat Control.................................................................................16
1.4 Automatic Operation...............................................................................17
1.5 Programme Dry Function .......................................................................18
1.6 Night Set Mode.......................................................................................19
1.7 POWERFUL Operation ..........................................................................20
1.8 Other Functions......................................................................................21
2. Function of Thermistor ..........................................................................22
3. Control Specification .............................................................................23
3.1 Four Way Valve Switching .....................................................................23
3.2 3-Minutes Standby .................................................................................23
3.3 Compressor Protection Function............................................................23
3.4 Fan OFF Delay.......................................................................................23
3.5 Freeze-up Protection Control .................................................................23
3.6 Heating Peak-cut Control .......................................................................24
3.7 Liquid Compression Protection Function................................................24
3.8 Defrost Control .......................................................................................25
Part 5 System Configuration....................................................... 27
1. System Configuration............................................................................28
2. Instructions............................................................................................29
2.1 Safety Precautions .................................................................................29
2.2 Names of Parts.......................................................................................31
2.3 Preparation before Operation.................................................................34
2.4 AUTO • DRY • COOL • HEAT • FAN Operation .....................................37
2.5 Adjusting the Air Flow Direction .............................................................39
2.6 POWERFUL Operation ..........................................................................40
2.7 TIMER Operation ...................................................................................41
2.8 Care and Cleaning .................................................................................43
2.9 Troubleshooting......................................................................................46

SiBE01-503
Table of Contents iii
Part 6 Service Diagnosis............................................................. 51
1. Caution for Diagnosis............................................................................52
2. Problem Symptoms and Measures .......................................................53
3. Service Check Function ........................................................................54
4. Troubleshooting ....................................................................................57
4.1 Error Codes and Description ..................................................................57
4.2 Indoor Unit PCB Abnormality .................................................................58
4.3 Freeze-up Protection Control or High Pressure Control.........................59
4.4 Fan Motor or Related Abnormality (AC motor).......................................61
4.5 Thermistor or Related Abnormality (Indoor Unit)....................................62
4.6 High Pressure Control in Cooling ...........................................................63
4.7 Thermistor or Related Abnormality (Outdoor Unit).................................65
5. Check ....................................................................................................67
5.1 Thermistor Resistance Check ................................................................67
5.2 Installation Condition Check...................................................................68
5.3 Outdoor Unit Fan System Check............................................................69
5.4 Hall IC Check .........................................................................................69
Part 7 Removal Procedure .......................................................... 71
1. Indoor Unit.............................................................................................72
1.1 Removal of Air Filter...............................................................................72
1.2 Removal of Front Grille ..........................................................................75
1.3 Removal of Horizontal Blades / Vertical Blades .....................................78
1.4 Removal of Electrical Parts Box / PCB / Swing Motor............................80
1.5 Removal of Heat Exchanger ..................................................................86
1.6 Install of Drain Plug ................................................................................89
1.7 Removal of Fan Rotor / Fan Motor.........................................................90
2. Outdoor Unit..........................................................................................94
2.1 Removal of Panels .................................................................................94
2.2 Removal of Bellmouth and Left Side Plate.............................................96
2.3 Removal of Electrical Device Mounting Plate.........................................97
2.4 Removal of Propeller Fan and Fan Motor ..............................................98
2.5 Removal of Sound Blanket.....................................................................99
2.6 Removal of Partition Plate....................................................................101
2.7 Removal of Compressor.......................................................................103
Part 8 Others ............................................................................. 105
1. Others .................................................................................................106
1.1 Trial Operation and Testing..................................................................106
1.2 Pump Down Operation .........................................................................106
1.3 Jumper Settings ...................................................................................107
Part 9 Appendix......................................................................... 109
1. Piping Diagrams..................................................................................110
1.1 Indoor Units ..........................................................................................110
1.2 Outdoor Units .......................................................................................111
2. Wiring Diagrams..................................................................................113
2.1 Indoor Units ..........................................................................................113
2.2 Outdoor Units .......................................................................................113

SiBE01-503
iv Table of Contents
Index ............................................................................................. i
Drawings & Flow Charts ............................................................... iii

SiBE01-503 Introduction
v
1. Introduction
1.1 Safety Cautions
Cautions and
Warnings
Be sure to read the following safety cautions before conducting repair work.
The caution items are classified into “ Warning” and “ Caution”. The “ Warning”
items are especially important since they can lead to death or serious injury if they are not
followed closely. The “ Caution” items can also lead to serious accidents under some
conditions if they are not followed. Therefore, be sure to observe all the safety caution items
described below.
About the pictograms
This symbol indicates an item for which caution must be exercised.
The pictogram shows the item to which attention must be paid.
This symbol indicates a prohibited action.
The prohibited item or action is shown inside or near the symbol.
This symbol indicates an action that must be taken, or an instruction.
The instruction is shown inside or near the symbol.
After the repair work is complete, be sure to conduct a test operation to ensure that the
equipment operates normally, and explain the cautions for operating the product to the
customer.
1.1.1 Caution in Repair
Warning
Be sure to disconnect the power cable plug from the plug socket before
disassembling the equipment for a repair.
Working on the equipment that is connected to a power supply can cause an
electrical shook.
If it is necessary to supply power to the equipment to conduct the repair or
inspecting the circuits, do not touch any electrically charged sections of the
equipment.
If the refrigerant gas discharges during the repair work, do not touch the
discharging refrigerant gas.
The refrigerant gas can cause frostbite.
When disconnecting the suction or discharge pipe of the compressor at the
welded section, release the refrigerant gas completely at a well-ventilated
place first.
If there is a gas remaining inside the compressor, the refrigerant gas or
refrigerating machine oil discharges when the pipe is disconnected, and it can
cause injury.
If the refrigerant gas leaks during the repair work, ventilate the area. The
refrigerant gas can generate toxic gases when it contacts flames.
The step-up capacitor supplies high-voltage electricity to the electrical
components of the outdoor unit.
Be sure to discharge the capacitor completely before conducting repair work.
A charged capacitor can cause an electrical shock.
Do not start or stop the air conditioner operation by plugging or unplugging the
power cable plug.
Plugging or unplugging the power cable plug to operate the equipment can
cause an electrical shock or fire.

Introduction SiBE01-503
vi
1.1.2 Cautions Regarding Products after Repair
Caution
Do not repair the electrical components with wet hands.
Working on the equipment with wet hands can cause an electrical shock.
Do not clean the air conditioner by splashing water.
Washing the unit with water can cause an electrical shock.
Be sure to provide the grounding when repairing the equipment in a humid or
wet place, to avoid electrical shocks.
Be sure to turn off the power switch and unplug the power cable when cleaning
the equipment.
The internal fan rotates at a high speed, and cause injury.
Do not tilt the unit when removing it.
The water inside the unit can spill and wet the furniture and floor.
Be sure to check that the refrigerating cycle section has cooled down
sufficiently before conducting repair work.
Working on the unit when the refrigerating cycle section is hot can cause burns.
Use the welder in a well-ventilated place.
Using the welder in an enclosed room can cause oxygen deficiency.
Warning
Be sure to use parts listed in the service parts list of the applicable model and
appropriate tools to conduct repair work. Never attempt to modify the
equipment.
The use of inappropriate parts or tools can cause an electrical shock,
excessive heat generation or fire.
When relocating the equipment, make sure that the new installation site has
sufficient strength to withstand the weight of the equipment.
If the installation site does not have sufficient strength and if the installation
work is not conducted securely, the equipment can fall and cause injury.
Be sure to install the product correctly by using the provided standard
installation frame.
Incorrect use of the installation frame and improper installation can cause the
equipment to fall, resulting in injury.
For integral units
only
Be sure to install the product securely in the installation frame mounted on a
window frame.
If the unit is not securely mounted, it can fall and cause injury.
For integral units
only
Be sure to use an exclusive power circuit for the equipment, and follow the
technical standards related to the electrical equipment, the internal wiring
regulations and the instruction manual for installation when conducting
electrical work.
Insufficient power circuit capacity and improper electrical work can cause an
electrical shock or fire.

SiBE01-503 Introduction
vii
1.1.3 Inspection after Repair
Be sure to use the specified cable to connect between the indoor and outdoor
units. Make the connections securely and route the cable properly so that there
is no force pulling the cable at the connection terminals.
Improper connections can cause excessive heat generation or fire.
When connecting the cable between the indoor and outdoor units, make sure
that the terminal cover does not lift off or dismount because of the cable.
If the cover is not mounted properly, the terminal connection section can cause
an electrical shock, excessive heat generation or fire.
Do not damage or modify the power cable.
Damaged or modified power cable can cause an electrical shock or fire.
Placing heavy items on the power cable, and heating or pulling the power cable
can damage the cable.
Do not mix air or gas other than the specified refrigerant (R410A / R22) in the
refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
If the refrigerant gas leaks, be sure to locate the leak and repair it before
charging the refrigerant. After charging refrigerant, make sure that there is no
refrigerant leak.
If the leak cannot be located and the repair work must be stopped, be sure to
perform pump-down and close the service valve, to prevent the refrigerant gas
from leaking into the room. The refrigerant gas itself is harmless, but it can
generate toxic gases when it contacts flames, such as fan and other heaters,
stoves and ranges.
When replacing the coin battery in the remote controller, be sure to disposed
of the old battery to prevent children from swallowing it.
If a child swallows the coin battery, see a doctor immediately.
Warning
Caution
Installation of a leakage breaker is necessary in some cases depending on the
conditions of the installation site, to prevent electrical shocks.
Do not install the equipment in a place where there is a possibility of
combustible gas leaks.
If a combustible gas leaks and remains around the unit, it can cause a fire.
Be sure to install the packing and seal on the installation frame properly.
If the packing and seal are not installed properly, water can enter the room and
wet the furniture and floor.
For integral units
only
Warning
Check to make sure that the power cable plug is not dirty or loose, then insert
the plug into a power outlet all the way.
If the plug has dust or loose connection, it can cause an electrical shock or fire.
If the power cable and lead wires have scratches or deteriorated, be sure to
replace them.
Damaged cable and wires can cause an electrical shock, excessive heat
generation or fire.

Introduction SiBE01-503
viii
1.1.4 Using Icons
Icons are used to attract the attention of the reader to specific information. The meaning of each
icon is described in the table below:
1.1.5 Using Icons List
Do not use a joined power cable or extension cable, or share the same power
outlet with other electrical appliances, since it can cause an electrical shock,
excessive heat generation or fire.
Warning
Caution
Check to see if the parts and wires are mounted and connected properly, and
if the connections at the soldered or crimped terminals are secure.
Improper installation and connections can cause excessive heat generation,
fire or an electrical shock.
If the installation platform or frame has corroded, replace it.
Corroded installation platform or frame can cause the unit to fall, resulting in
injury.
Check the grounding, and repair it if the equipment is not properly grounded.
Improper grounding can cause an electrical shock.
Be sure to measure the insulation resistance after the repair, and make sure
that the resistance is 1 Mohm or higher.
Faulty insulation can cause an electrical shock.
Be sure to check the drainage of the indoor unit after the repair.
Faulty drainage can cause the water to enter the room and wet the furniture
and floor.
Icon Type of
Information
Description
Note:
Note A “note” provides information that is not indispensable, but may
nevertheless be valuable to the reader, such as tips and tricks.
Caution
Caution A “caution” is used when there is danger that the reader, through
incorrect manipulation, may damage equipment, loose data, get
an unexpected result or has to restart (part of) a procedure.
Warning
Warning A “warning” is used when there is danger of personal injury.
Reference A “reference” guides the reader to other places in this binder or
in this manual, where he/she will find additional information on a
specific topic.

SiBE01-503
List of Function 1
Part 1
List of Function
1. Functions.................................................................................................2

Functions SiBE01-503
2List of Function
1. Functions
Category Functions
FTYN25-35DV3B RYN25-35DV3B
Category Functions
FTYN25-35DV3B RYN25-35DV3B
Basic Function
Inverter (with Inverter Power Control) —
Health & Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions —
Operation Limit for Cooling (°CDB) 15
~46 Photocatalytic Deodorizing Filter —
Operation Limit for Heating (°CWB) –10
~15
Air Purifying Filter with Photocatalytic
Deodorizing Function —
PAM Control — Titanium Apatite Photocatalytic
Air-Purifying Filter {
Compressor
Oval Scroll Compressor — Longlife Filter —
Swing Compressor — Mold Proof Air Filter {
Rotary Compressor {Wipe-clean Flat Panel {
Reluctance DC Motor — Washable Grille —
Comfortable
Airflow
Power-Airflow Flap — Mold Proof Operation —
Power-Airflow Dual Flaps {Heating Dry Operation —
Power-Airflow Diffuser — Good-Sleep Cooling Operation —
Wide-Angle Louvers {
Timer Count up-down Timer {
Vertical Auto-Swing (Up and Down) {Night Set Mode {
Horizontal Auto-Swing (Right and Left) —
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {
3-D Airflow — Self-Diagnosis (Digital, LED) Display {
1
Comfort Airflow Mode — Wiring Error Check —
3-Step Airflow (H/P Only) — Anticorrosion Treatment of Outdoor Heat
Exchanger {
Comfort Control
Auto Fan Speed {
Indoor Unit Silent Operation —
Flexibility
Multi-Split / Split Type Compatible Indoor
Unit —
Night Quiet Mode (Automatic) —
Outdoor Unit Silent Operation (Manual) — Flexible Voltage Correspondence —
Intelligent Eye — High Ceiling Application —
Quick Warming Function — Chargeless 2
Hot-Start Function {Either Side Drain (Right or Left) {
Automatic Defrosting {Power Selection —
Operation
Automatic Operation {
Remote Control
5-Rooms Centralized Controller (Option) —
Programme Dry Function {Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) —
Fan Only {
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) {Remote Control Adaptor
(Normal Open Contact)(Option) —
Inverter Powerful Operation —
Priority-Room Setting — DIII-NET Compatible (Adaptor)(Option) —
Cooling / Heating Mode Lock — Remote
Controller
Wireless {
Home Leave Operation — Wired —
ECONO Mode —
Indoor Unit On/Off Switch {
Signal Reception Indicator {
Temperature Display —
Another Room Operation —
Note: {: Holding Functions
— : No Functions
1:
2:
Digital Only
7.5m(25 class), 10m(35 class)

SiBE01-503 Functions
List of Function 3
Category Functions
ATY20-35DV2 ARY20-35DV2
Category Functions
ATY20-35DV2 ARY20-35DV2
Basic Function
Inverter (with Inverter Power Control) —
Health & Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions —
Operation Limit for Cooling (°CDB) 10
~46
Operation Limit for Heating (°CWB) –10
~15 Photocatalytic Deodorizing Filter —
PAM Control — Air Purifying Filter with Photocatalytic
Deodorizing Function —
Compressor
Oval Scroll Compressor — Titanium Apatite Photocatalytic
Air-Purifying Filter {
Swing Compressor —
Rotary Compressor {Longlife Filter —
Reluctance DC Motor — Mold Proof Air Filter {
Comfortable
Airflow
Power-Airflow Flap — Wipe-clean Flat Panel {
Power-Airflow Dual Flaps {Washable Grille —
Power-Airflow Diffuser — Mold Proof Operation —
Wide-Angle Louvers {Heating Dry Operation —
Vertical Auto-Swing (Up and Down) {Good-Sleep Cooling Operation —
Horizontal Auto-Swing (Right and Left) — Timer Count Up-down Timer {
3-D Airflow — Night Set Mode {
Comfort Airflow Mode —
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {
3-Step Airflow (H/P Only) — Self-Diagnosis (Digital, LED) Display {

Comfort Control
Auto Fan Speed {Wiring Error Check —
Indoor Unit Silent Operation — Anticorrosion Treatment of Outdoor Heat
Exchanger {
Night Quiet Mode (Automatic) —
Outdoor Unit Silent Operation (Manual) —
Flexibility
Multi-Split / Split Type Compatible Indoor
Unit —
Intelligent Eye —
Quick Warming Function — Flexible Voltage Correspondence —
Hot-Start Function {High Ceiling Application —
Automatic Defrosting {Chargeless 5m
Operation
Automatic Operation {Either Side Drain (Right or Left) {
Programme Dry Function {Power Selection —
Fan Only {
Remote Control
5-Rooms Centralized Controller (Option) —
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) {Remote Control Adaptor
(Normal Open-Pulse Contact)(Option) —
Inverter Powerful Operation —
Priority-Room Setting — Remote Control Adaptor
(Normal Open Contact)(Option) —
Cooling / Heating Mode Lock —
Home Leave Operation — DIII-NET Compatible (Adaptor)(Option) —
ECONO Mode — Remote
Controller
Wireless {
Indoor Unit On/Off Switch {Wired —
Signal Reception Indicator {
Temperature Display —
Another Room Operation —
Note: {
: Holding Functions
— : No Functions
: Digital Only

Functions SiBE01-503
4List of Function

SiBE01-503
Specifications 5
Part 2
Specifications
1. Specifications ..........................................................................................6

Specifications SiBE01-503
6Specifications
1. Specifications
50Hz 230V
Note: MAX. interunit piping length: 15m
MAX. interunit height difference: 10m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 7.5m(25 class), 10m(35class)
The data are based on the conditions shown in the table below.
Models
Indoor Units FTYN25DV3B FTYN35DV3B
Outdoor Units RYN25DV3B RYN35DV3B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 3 3.15 3.85
Btu/h 8,550 10,260 10,770 13,160
kcal/h 2,150 2,580 2,710 3,310
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 4.0 4.0 5.4 5.8
Power Consumption
Rated (Min.~Max.) W 830 880 1,200 1,290
PowerFactor %90969797
COP (Rated) W/W 3.01 3.41 2.63 2.98
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTYN25DV3B FTYN35DV3B
Front Panel Color White White
Air Flow Rate m³/min
(cfm)
H 7.5 (265) 7.8 (275) 7.5 (265) 7.8 (275)
M 6.0 (212) 6.3 (222) 6.1 (215) 6.4 (226)
L 4.6 (162) 4.8 (169) 4.9 (173) 5.2 (184)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 3 Steps, Powerful, Auto 3 Steps, Powerful, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19 0.19 0.19 0.19
Power Consumption (Rated) W 40 40 40 40
PowerFactor %92929292
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 260×840×330 260×840×330
Weight kg 9 9
Gross Weight kg 11 11
Operation
Sound H/M/L dBA 39 / 33 / 27 39 / 33 / 27 39 / 34 / 29 39 / 34 / 29
Sound Power H dBA 57 57 57 57
Outdoor Units RYN25DV3B RYN35DV3B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model 5PS112DAH21 5KS150DBK21
Motor Output W 750 1,100
Refrigerant
Oil
Type FV50S FV50S
Charge L 0.35 0.43
Refrigerant Type R410A R410A
Charge kg 0.9 1.0
Air Flow Rate m³/min 28 25.2 28 25.2
cfm 988 890 988 890
Fan Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.81 3.81 5.21 5.61
Power Consumption (Rated) W 790 840 1,160 1,250
PowerFactor %90969797
Starting Current A 18.6 23.1
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (H×W×D) mm 607×824×337 607×824×337
Weight kg 31 36
Gross Weight kg 35 40
Operation
Sound H dBA 47 49 48 49
Sound Power H dBA 62 64 63 64
Drawing No. 3D048831 3D048830
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB/6°CWB 7.5m

SiBE01-503 Specifications
Specifications 7
50Hz 220V
Note: MIN. interunit piping length: 3m
MAX. interunit piping length: 12m
MAX. interunit height difference: 10m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 5m
The data are based on the conditions shown in the table below.
Models
Indoor Units ATY20DV2 ATY25DV2
Outdoor Units ARY20DV2 ARY25DV2
Cooling Heating Cooling Heating
Capacity
kW 1.95 2.3 2.5 2.8
Btu/h 6,700 7,900 8,500 9,600
kcal/h 1,680 1,980 2,150 2,410
Moisture Removal L/h 0.8 — 1.2 —
Running Current A 3.6 3.2 4.0 3.6
Power Consumption W 680 600 840 770
PowerFactor %86859597
COP W/W 2.87 3.83 2.98 3.64
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units ATY20DV2 ATY25DV2
Front Panel Color White White
Air Flow Rate m³/min
(cfm)
H 7.2 (254) 7.5 (265) 7.5 (265) 7.8 (275)
M 5.9 (208) 6.2 (219) 6.0 (212) 6.3 (222)
L 4.6 (162) 4.8 (169) 4.6 (162) 4.8 (169)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 3 Steps, Powerful, Auto 3 Steps, Powerful, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current A 0.19 0.19 0.19 0.19
Power Consumption W 40 40 40 40
PowerFactor %96969696
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 260×840×330 260×840×330
Weight kg 9 9
Gross Weight kg 11 11
Operation
Sound H/M/L dBA 38 / 33 / 27 38 / 33 / 27 39 / 33 / 27 39 / 33 / 27
Outdoor Units ARY20DV2 ARY25DV2
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model 2R13C225BSA 2P16C225ANF
Motor Output W 600 750
Refrigerant
Oil
Type ATMOS M60 or SUNISO 4GDID ATMOS M60 or SUNISO 4GDID
Charge L 0.3 0.35
Refrigerant Type R22 R22
Charge kg 0.75 0.75
Air Flow Rate m³/min 28 25.2 28 25.2
cfm 988 890 988 890
Fan Type Propeller Propeller
Motor Output W 23 23
Running Current A 3.41 3.01 3.81 3.41
Power Consumption W 640 560 800 730
PowerFactor %85859597
Starting Current A 14 15.6
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (H×W×D) mm 607×824×337 607×824×337
Weight kg 26 28
Gross Weight kg 28 31
Operation Sound dBA 46 47 46 47
Drawing No. 3D048822 3D048821
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB/6°CWB 5m

Specifications SiBE01-503
8Specifications
50Hz 220V
Note: MIN. interunit piping length: 3m
MAX. interunit piping length: 12m
MAX. interunit height difference: 10m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 5m
The data are based on the conditions shown in the table below.
Models
Indoor Units ATY35DV2
Outdoor Units ARY35DV2
Cooling Heating
Capacity
kW 3.3 3.8
Btu/h 11,300 13,000
kcal/h 2,840 3,270
Moisture Removal L/h 1.9 —
Running Current A 5.4 5.6
Power Consumption W 1,110 1,180
Power Factor % 93 96
COP W/W 2.97 3.22
Piping
Connections
Liquid mm φ 6.4
Gas mm φ12.7
Drain mm φ18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Units ATY35DV2
Front Panel Color White
Air Flow Rate m³/min
(cfm)
H 7.5 (265) 7.8 (275)
M 6.1 (215) 6.4 (226)
L 4.9 (173) 5.2 (184)
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 3 Steps, Powerful, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current A 0.19 0.19
Power Consumption W 40 40
Power Factor % 96 96
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195
Packaged Dimensions (H×W×D) mm 260×840×330
Weight kg 9
Gross Weight kg 11
Operation
Sound H/M/L dBA 39 / 34 / 29 39 / 34 / 29
Outdoor Units ARY35DV2
Casing Color Ivory White
Compressor
Type Hermetically Sealed Rotary Type
Model 2K22C225EUE
Motor Output W 1,100
Refrigerant
Oil
Type ATMOS M60 or SUNISO 4GDID
Charge L 0.41
Refrigerant Type R22
Charge kg 0.95
Air Flow Rate m³/min 28 25.2
cfm 988 890
Fan Type Propeller
Motor Output W 23
Running Current A 5.21 5.41
Power Consumption W 1,070 1,140
Power Factor % 93 96
Starting Current A 22.8
Dimensions (H×W×D) mm 560×695×265
Packaged Dimensions (H×W×D) mm 607×824×337
Weight kg 36
Gross Weight kg 40
Operation Sound dBA 47 48
Drawing No. 3D048820
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB/6°CWB 5m

SiBE01-503
Printed Circuit Board Connector Wiring Diagram 9
Part 3
Printed Circuit Board
Connector Wiring Diagram
1. Printed Circuit Board Connector Wiring Diagram..................................10
1.1 Indoor Unit..............................................................................................10

Printed Circuit Board Connector Wiring Diagram SiBE01-503
10 Printed Circuit Board Connector Wiring Diagram
1. Printed Circuit Board Connector Wiring Diagram
1.1 Indoor Unit
Connectors
Note: Other designations
1) S1 Connector for fan motor
2) S2, S4 Connector for transformer
3) S5 Connector for thermal fuse
4) S6 Connector for swing motor (horizontal blades)
5) S7 Connector for fan motor (Hall IC)
6) S26 Connector for control PCB
7) S27 Connector for signal receiver PCB
8) S32 Connector for indoor heat exchanger thermistor
9) S33 Connector for outdoor heat exchanger thermistor
10) H1 Connector for compressor (outdoor unit)
11) H2, H4 Connector for four way valve (outdoor unit)
12) H3 Connector for fan motor (outdoor unit)
13) H5 Connector for power supply (outdoor unit)
1) V1, V2 Varistor
2) JA Address setting jumper
JC Power failure recovery function (auto restart)
∗Refer to page 107 for detail.
3) SW1 Forced operation ON/OFF switch
4) LED1 LED for operation (green)
5) LED2 LED for timer (yellow)
6) LED A LED for service monitor (green)
7) FU1 Fuse (3.15A)
8) RTH Room temperature thermistor

SiBE01-503 Printed Circuit Board Connector Wiring Diagram
Printed Circuit Board Connector Wiring Diagram 11
Control PCB
Signal Receiver PCB
S4
S5
S27 LED A J30 JC JA
S32
(R4670)
S33
S6
S7
H5
H4
H3
V2
S1
H2
S2V1FU1
H1
LED1
SW1
LED2 S26 RTH
(R4671)
