1 Specifications
IndoorUnit VRVSystems FXMQ-PVEConcealedC
1-1 TECHNICAL SPECIFICATIONS FXMQ40PVE FXMQ50PVE FXMQ63PVE FXMQ80PVE FXMQ100PVE FXMQ125PVE
Capacity Cooling kW 4.5 5.6 7.1 9.0 11.2 14.0
Heating kW 5.0 6.3 8.0 10.0 12.5 16.0
Power Input Cooling kW 0.194 (1)
0.193 (2)
0.215 (1)
0.214 (2)
0.230 (1)
0.229 (2)
0.298 (1)
0.297 (2)
0.376 (1)
0.375 (2)
0.461 (1)
0.460 (2)
Heating kW 0.182 0.203 0.218 0.286 0.364 0.449
Casing Material Galvanised steel plate
Dimensions Unit Height mm 300 300 300 300 300 300
Width mm 700 1,000 1,000 1,000 1,400 1,400
Depth mm 700 700 700 700 700 700
Weight Unit kg 28 36 36 36 46 46
Heat
Exchanger
DimensionsNrofRows 333333
Fin Pitch mm 1.75 1.75 1.75 1.75 1.75 1.75
Face
Area
m² 0.148 0.249 0.249 0.249 0.383 0.383
Nr of Stages 16 16 16 16 16 16
Fan Type Sirocco fan
Air Flow Rate Cooling High high m³/min 16 18 19.5 25 32 39
High m³/min 13 16.5 17.5 22.5 27 33
Low m³/min 11 15 16 20 23 28
Fan External static
pressure
High Pa 160 200 200 200 200 200
Standard Pa 100 100 100 100 100 100
Low Pa 30 50 50 50 50 50
Motor Output
(high)
W 140 350 350 350 350 350
Drive Direct drive
Piping
connections
Liquid (OD) Type Flare connection
Diameter mm 6.35 9.52 9.52 9.52 9.52 9.52
Gas Type Flare connection
Diameter mm 12.7 15.9 15.9 15.9 15.9 15.9
Drain Diameter mm VP25 (I.D. 32/O.D. 25)
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices Fuse
Fan driver overload protector
Standard
Accessories
Standard Accessories Operation manual
Installation manual
Drain hose
Sealing pads
Clamps
Washer
Screws
Insulation for fitting
Clamp metal
Air discharge flange
Air suction flange
Legend (1) 50Hz, 220-240V
(2) 60Hz, 220V
Notes Nominal cooling capacities are based on following conditions: return air temperature: 27°CDB/19°CWB; outdoor
temperature: 35°CDB; standard external static pressure: 100Pa; equivalent refrigerant piping: 7.5m (horizontal)
Nominal heating capacities are based on following conditions: return air temperature: 20°CDB; outdoor temperature:
7°CDB/6°CWB; standard external static pressure: 100Pa; equivalent refrigerant piping: 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
External static pressure is changeable in 13 or 14 stages within the ( ) range by the remote control.
Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its colorimetric
method(gravity method) 50% or more.

•VRV
®Systems • Indoor Units 133
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
1 Specifications
1-2 ELECTRICAL SPECIFICATIONS FXMQ40PVE FXMQ50PVE FXMQ63PVE FXMQ80PVE FXMQ100PVE FXMQ125PVE
Power Supply Name VE
Phase 1~
Frequency Hz 50/60
Voltage V 220-240/220
Current Minimum circuit amps
(MCA)
A 1.4 1.6 1.8 2.3 2.9 3.4
Maximum fuse amps (MFA) A 16 16 16 16 16 16
Full load amps (FLA) A 1.1 1.3 1.4 1.8 2.3 2.7
Voltage range Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below
or above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 16A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
134
2 Safety device settings
3 Options
FXMQ-P
3D034597E
Safety devices 40 50 63 80 100 125
FXMQ-PVE
PC boad fuse 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A
PC boad fuse (Fan driver) 250V 5A 250V 6.3A 250V 6.3A 250V 6.3A 250V 6.3A 250V 6.3A
Drain pump thermal fuse 145 145 145 145 145 145
FXMQ-P
3D060443
NOTE
1 See the latest for the modification marks
Model DUCT TYPE
Item FXMQ40PVE FXMQ50PVE FXMQ63PVE FXMQ80PVE FXMQ100PVE FXMQ125PVE
High efficiency filter 65% KAF372AA56 KAF372AA80 KAF372AA160
90% KAF373AA56 KAF373AA80 KAF373AA160
Filter chamber KDDF37AA56 KDDF37AA80 KDDF37AA160
long life replacement filter KAF371AA56 KAF371AA80 KAF371AA160
Long life replacement filter chamber kit KAF375AA56 KAF375AA80 KAF375AA160
Service panel KTBJ25K56W KTBJ25K80W KTBJ25K160W
KTBJ25K56F KTBJ25K80F KTBJ25K160F
KTBJ25K56T KTBJ25K80T KTBJ25K160T
Air discharge adapter KDAJ25K56A KDAJ25K80A KDAJ25K160A

•VRV
®Systems • Indoor Units 135
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
4 Control systems
FXMQ-P
3D060455
No.
Type
Item
FXMQ~PVE
1 Remote control Wireless H/P
C/O
BRC4C65
BRC4C66
Wired BRC1D52
2 Simplified remote control BRC2C51
3 Remote control for hotel use BRC3A61
4 Adaptor for wiring KRP1C64
5-1 Wiring adaptor for electrical appendices (1) KRP2A61
5-1 Wiring adaptor for electrical appendices (2) KRP4AA51
6 Remote sensor KRCS01-1B
7 Mounting plate for adapter PCB Note 2, 3
KRP4A96
8 Central remote control DCS302CA61
8-1 Electrical box with earth terminal (3 blocks) KJB311AA
9 Unified on/off control DSC301BA61
9-1 Electrical box with earth terminal (2 blocks) KJB212AA
9-2 Noise filter
(for electromagnetic interface use only) KEK26-1A
10 Schedule timer DST301BA61
11 External control adaptor for outdoor unit
(Must be installed on indoor units) DTA104A61
NOTES
1 Mounting plate (No.7) is necessary for each adapter marked  .
2 Up to 2 adapters can be fixed for each mounting plate.
3 Only one mounting plate can be installed for each indoor unit.

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
136
5 Capacity tables
5 - 1 Cooling capacity tables
FXMQ-P
CA08A050
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit
size
Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
40 4.5 10.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.4 3.9 5.7 4.0
12.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.4 3.9 5.6 4.0
14.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.4 3.9 5.5 4.0
16.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.4 3.9 5.5 3.9
18.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.3 3.9 5.4 3.9
20.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.2 3.8 5.3 3.9
21.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.2 3.8 5.3 3.8
23.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.1 3.8 5.2 3.8
25.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.0 3.7 5.1 3.8
27.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 5.0 3.7 5.1 3.7
29.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.8 3.8 4.9 3.7 5.0 3.7
31.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.7 3.8 4.8 3.6 4.9 3.6
33.0 3.0 2.9 3.6 3.4 4.2 3.8 4.5 3.8 4.6 3.7 4.7 3.6 4.8 3.6
35.0 3.0 2.9 3.6 3.4 4.2 3.2 4.5 3.8 4.6 3.7 4.7 3.5 4.8 3.6
37.0 3.0 2.9 3.6 3.4 4.2 3.2 4.4 3.8 4.5 3.6 4.6 3.5 4.7 3.5
39.0 3.0 2.9 3.6 3.4 4.2 3.2 4.4 3.7 4.4 3.6 4.5 3.4 4.6 3.5
50 5.6 10.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.7 4.8 7.1 4.3
12.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.7 4.8 7.0 4.3
14.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.7 4.8 6.9 4.2
16.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.7 4.8 6.8 4.1
18.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.6 4.7 6.7 4.1
20.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.5 4.7 6.6 4.0
21.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.4 4.6 6.6 4.0
23.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.4 4.6 6.5 4.0
25.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.3 4.5 6.4 3.9
27.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 6.0 4.6 6.2 4.5 6.3 3.8
29.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 5.9 4.6 6.1 4.4 6.2 3.8
31.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 5.9 4.6 6.0 4.4 6.1 3.7
33.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 5.8 4.5 5.9 4.3 6.0 3.7
35.0 3.8 3.6 4.5 4.1 5.2 4.5 5.6 4.6 5.7 4.5 5.8 4.3 5.9 3.6
37.0 3.8 3.6 4.5 4.1 5.2 4.5 5.5 4.6 5.6 4.4 5.7 4.2 5.8 3.6
39.0 3.8 3.6 4.5 4.1 5.2 4.5 5.4 4.5 5.5 4.4 5.6 4.2 5.8 3.5
63 7.1 10.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 9.0 6.4
12.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 8.9 6.3
14.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 8.7 6.3
16.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 8.6 6.3
18.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.3 5.8 8.5 6.2
20.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.2 5.7 8.4 6.2
21.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.2 5.7 8.3 6.2
23.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 8.1 5.6 8.2 6.1
25.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 7.9 5.6 8.1 6.1
27.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.6 5.6 7.8 5.5 8.0 6.1
29.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.5 5.6 7.7 5.4 7.9 6.0
31.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.4 5.5 7.6 5.4 7.8 6.0
33.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.3 5.5 7.5 5.3 7.6 5.9
35.0 4.8 4.2 5.7 4.9 6.6 5.4 7.1 5.5 7.2 5.4 7.4 5.3 7.5 5.9
37.0 4.8 4.2 5.7 4.9 6.6 5.4 7.0 5.5 7.1 5.4 7.2 5.2 7.4 5.9
39.0 4.8 4.2 5.7 4.9 6.6 5.4 6.9 5.4 7.0 5.3 7.1 5.1 7.3 5.8
80 9.0 10.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.8 7.4 11.4 7.4
12.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.8 7.4 11.2 7.4
14.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.8 7.4 11.1 7.3
16.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.7 7.4 10.9 7.2
18.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.6 7.3 10.8 7.2
20.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.4 7.2 10.6 7.1
21.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.4 7.2 10.6 7.1
23.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.2 7.1 10.4 7.0
25.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 10.1 7.0 10.3 6.9
27.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.6 7.1 9.9 7.0 10.1 6.9
29.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.5 7.1 9.8 6.9 10.0 6.8
31.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.4 7.0 9.6 6.8 9.8 6.7
33.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.3 7.0 9.5 6.7 9.7 6.7
35.0 6.1 5.3 7.2 6.1 8.4 6.9 9.0 7.0 9.1 6.9 9.3 6.6 9.5 6.6
37.0 6.1 5.3 7.2 6.1 8.4 6.9 8.9 6.9 9.0 6.8 9.2 6.6 9.4 6.5
39.0 6.1 5.3 7.2 6.1 8.4 6.9 8.7 6.8 8.8 6.7 9.0 6.5 9.3 6.5

•VRV
®Systems • Indoor Units 137
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
5 Capacity tables
5 - 1 Cooling capacity tables
FXMQ-P
CA08A050
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit
size
Nominal
capacity
Outdoor
air temp.
Indoor air temperature
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
100 11.2 10.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 13.4 9.0 14.2 8.9
12.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 13.4 9.0 14.0 8.9
14.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 13.4 9.0 13.8 8.8
16.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 13.3 9.0 13.6 8.7
18.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 13.2 8.9 13.4 8.6
20.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 13.0 8.8 13.2 8.5
21.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 12.9 8.8 13.2 8.5
23.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 12.7 8.7 13.0 8.4
25.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 12.5 8.6 12.8 8.3
27.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.7 12.3 8.5 12.6 8.2
29.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.9 8.6 12.2 8.4 12.4 8.1
31.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.7 8.5 12.0 8.3 12.2 8.0
33.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.5 8.5 11.8 8.2 12.1 7.9
35.0 7.6 6.4 9.0 7.3 10.5 8.3 11.2 8.5 11.3 8.4 11.6 8.1 11.9 7.8
37.0 7.6 6.4 9.0 7.3 10.5 8.3 11.0 8.4 11.2 8.3 11.4 8.0 11.7 7.7
39.0 7.6 6.4 9.0 7.3 10.5 8.3 10.8 8.3 11.0 8.2 11.2 7.9 11.5 7.6
125 14.0 10.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.7 11.1 17.7 11.1
12.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.7 11.1 17.5 11.0
14.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.7 11.1 17.2 10.9
16.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.7 11.1 17.0 10.8
18.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.4 11.0 16.8 10.7
20.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.2 10.9 16.6 10.6
21.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 16.1 10.9 16.4 10.5
23.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 15.9 10.8 16.2 10.4
25.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 15.6 10.6 16.0 10.3
27.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.8 15.4 10.5 15.8 10.2
29.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.9 10.7 15.2 10.4 15.5 10.1
31.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.6 10.6 15.0 10.3 15.3 10.0
33.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.4 10.5 14.7 10.2 15.1 9.8
35.0 9.4 8.0 11.3 9.2 13.1 10.3 14.0 10.5 14.2 10.4 14.5 10.1 14.9 9.7
37.0 9.4 8.0 11.3 9.2 13.1 10.3 13.8 10.4 13.9 10.3 14.3 10.0 14.6 9.6
39.0 9.4 8.0 11.3 9.2 13.1 10.3 13.5 10.3 13.7 10.2 14.1 9.9 14.4 9.5

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
138
5 Capacity tables
5 - 2 Heating capacity tables
FXMQ-P
CA08A056
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size
Nominal
capacity
Outdoor air temp.
Indoor air temperature
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWBKWKWKWKWKWKW
40 5.0 -19.8 -20.0 3.0 2.9 2.9 2.9 2.9 2.9
-18.8 -19.0 3.0 3.0 3.0 3.0 3.0 3.0
-16.7 -17.0 3.2 3.2 3.2 3.2 3.2 3.2
-14.7 -15.0 3.4 3.4 3.4 3.4 3.4 3.4
-12.6 -13.0 3.6 3.6 3.6 3.5 3.5 3.5
-10.5 -11.0 3.7 3.7 3.7 3.7 3.7 3.7
-9.5 -10.0 3.8 3.8 3.8 3.8 3.8 3.8
-8.5 -9.1 3.9 3.9 3.9 3.9 3.9 3.9
-7.0 -7.6 4.0 4.0 4.0 4.0 4.0 4.0
-5.0 -5.6 4.2 4.2 4.2 4.2 4.2 4.2
-3.0 -3.7 4.4 4.4 4.4 4.4 4.4 4.4
0.0 -0.7 4.7 4.6 4.6 4.6 4.6 4.4
3.0 2.2 4.9 4.9 4.9 4.8 4.7 4.4
5.0 4.1 5.1 5.1 5.0 4.8 4.7 4.4
7.0 6.0 5.2 5.2 5.0 4.8 4.7 4.4
9.0 7.9 5.4 5.3 5.0 4.8 4.7 4.4
11.0 9.8 5.6 5.3 5.0 4.8 4.7 4.4
13.0 11.8 5.6 5.3 5.0 4.8 4.7 4.4
15.0 13.7 5.6 5.3 5.0 4.8 4.7 4.4
50 6.3 -19.8 -20.0 3.7 3.7 3.7 3.7 3.7 3.7
-18.8 -19.0 3.8 3.8 3.8 3.8 3.8 3.8
-16.7 -17.0 4.1 4.0 4.0 4.0 4.0 4.0
-14.7 -15.0 4.3 4.3 4.3 4.2 4.2 4.2
-12.6 -13.0 4.5 4.5 4.5 4.5 4.5 4.5
-10.5 -11.0 4.7 4.7 4.7 4.7 4.7 4.7
-9.5 -10.0 4.8 4.8 4.8 4.8 4.8 4.8
-8.5 -9.1 4.9 4.9 4.9 4.9 4.9 4.9
-7.0 -7.6 5.1 5.1 5.1 5.1 5.1 5.1
-5.0 -5.6 5.3 5.3 5.3 5.3 5.3 5.3
-3.0 -3.7 5.5 5.5 5.5 5.5 5.5 5.5
0.0 -0.7 5.9 5.9 5.8 5.8 5.8 5.5
3.0 2.2 6.2 6.2 6.2 6.1 5.9 5.5
5.0 4.1 6.4 6.4 6.3 6.1 5.9 5.5
7.0 6.0 6.6 6.6 6.3 6.1 5.9 5.5
9.0 7.9 6.8 6.7 6.3 6.1 5.9 5.5
11.0 9.8 7.0 6.7 6.3 6.1 5.9 5.5
13.0 11.8 7.1 6.7 6.3 6.1 5.9 5.5
15.0 13.7 7.1 6.7 6.3 6.1 5.9 5.5
63 8.0 -19.8 -20.0 4.7 4.7 4.7 4.7 4.7 4.7
-18.8 -19.0 4.9 4.9 4.8 4.8 4.8 4.8
-16.7 -17.0 5.1 5.1 5.1 5.1 5.1 5.1
-14.7 -15.0 5.4 5.4 5.4 5.4 5.4 5.4
-12.6 -13.0 5.7 5.7 5.7 5.7 5.7 5.7
-10.5 -11.0 6.0 6.0 6.0 6.0 6.0 5.9
-9.5 -10.0 6.1 6.1 6.1 6.1 6.1 6.1
-8.5 -9.1 6.3 6.3 6.2 6.2 6.2 6.2
-7.0 -7.6 6.5 6.5 6.4 6.4 6.4 6.4
-5.0 -5.6 6.8 6.7 6.7 6.7 6.7 6.7
-3.0 -3.7 7.0 7.0 7.0 7.0 7.0 7.0
0.0 -0.7 7.5 7.4 7.4 7.4 7.4 7.0
3.0 2.2 7.9 7.8 7.8 7.7 7.5 7.0
5.0 4.1 8.1 8.1 8.0 7.7 7.5 7.0
7.0 6.0 8.4 8.4 8.0 7.7 7.5 7.0
9.0 7.9 8.7 8.5 8.0 7.7 7.5 7.0
11.0 9.8 8.9 8.5 8.0 7.7 7.5 7.0
13.0 11.8 9.0 8.5 8.0 7.7 7.5 7.0
15.0 13.7 9.0 8.5 8.0 7.7 7.5 7.0
80 10.0 -19.8 -20.0 5.9 5.9 5.9 5.9 5.9 5.8
-18.8 -19.0 6.1 6.1 6.0 6.0 6.0 6.0
-16.7 -17.0 6.4 6.4 6.4 6.4 6.4 6.4
-14.7 -15.0 6.8 6.8 6.8 6.7 6.7 6.7
-12.6 -13.0 7.1 7.1 7.1 7.1 7.1 7.1
-10.5 -11.0 7.5 7.5 7.5 7.5 7.4 7.4
-9.5 -10.0 7.7 7.7 7.6 7.6 7.6 7.6
-8.5 -9.1 7.8 7.8 7.8 7.8 7.8 7.8
-7.0 -7.6 8.1 8.1 8.1 8.1 8.0 8.0
-5.0 -5.6 8.4 8.4 8.4 8.4 8.4 8.4
-3.0 -3.7 8.8 8.8 8.7 8.7 8.7 8.7
0.0 -0.7 9.3 9.3 9.3 9.3 9.3 8.7
3.0 2.2 9.8 9.8 9.8 9.7 9.4 8.7
5.0 4.1 10.2 10.1 10.0 9.7 9.4 8.7
7.0 6.0 10.5 10.5 10.0 9.7 9.4 8.7
9.0 7.9 10.8 10.6 10.0 9.7 9.4 8.7
11.0 9.8 11.2 10.6 10.0 9.7 9.4 8.7
13.0 11.8 11.3 10.6 10.0 9.7 9.4 8.7
15.0 13.7 11.3 10.6 10.0 9.7 9.4 8.7

•VRV
®Systems • Indoor Units 139
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
5 Capacity tables
5 - 2 Heating capacity tables
FXMQ-P
CA08A056
TC: Total capacity;kW – SHC: Sensible capacity;kW
Unit size
Nominal
capacity
Outdoor air temp.
Indoor air temperature
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWBKWKWKWKWKWKW
100 12.5 -19.8 -20.0 7.4 7.4 7.3 7.3 7.3 7.3
-18.8 -19.0 7.6 7.6 7.6 7.5 7.5 7.5
-16.7 -17.0 8.0 8.0 8.0 8.0 8.0 8.0
-14.7 -15.0 8.5 8.5 8.4 8.4 8.4 8.4
-12.6 -13.0 8.9 8.9 8.9 8.9 8.9 8.8
-10.5 -11.0 9.4 9.3 9.3 9.3 9.3 9.3
-9.5 -10.0 9.6 9.6 9.5 9.5 9.5 9.5
-8.5 -9.1 9.8 9.8 9.7 9.7 9.7 9.7
-7.0 -7.6 10.1 10.1 10.1 10.1 10.1 10.0
-5.0 -5.6 10.6 10.5 10.5 10.5 10.5 10.5
-3.0 -3.7 11.0 11.0 10.9 10.9 10.9 10.9
0.0 -0.7 11.6 11.6 11.6 11.6 11.6 10.9
3.0 2.2 12.3 12.3 12.2 12.1 11.7 10.9
5.0 4.1 12.7 12.7 12.5 12.1 11.7 10.9
7.0 6.0 13.1 13.1
12.5 12.1 11.7 10.9
9.0 7.9 13.5 13.3 12.5 12.1 11.7 10.9
11.0 9.8 14.0 13.3 12.5 12.1 11.7 10.9
13.0 11.8 14.1 13.3 12.5 12.1 11.7 10.9
15.0 13.7 14.1 13.3 12.5 12.1 11.7 10.9
125 16.0 -19.8 -20.0 9.4 9.4 9.4 9.4 9.4 9.3
-18.8 -19.0 9.7 9.7 9.7 9.7 9.6 9.6
-16.7 -17.0 10.3 10.3 10.2 10.2 10.2 10.2
-14.7 -15.0 10.9 10.8 10.8 10.8 10.8 10.7
-12.6 -13.0 11.4 11.4 11.4 11.4 11.3 11.3
-10.5 -11.0 12.0 12.0 11.9 11.9 11.9 11.9
-9.5 -10.0 12.3 12.2 12.2 12.2 12.2 12.2
-8.5 -9.1 12.5 12.5 12.5 12.5 12.4 12.4
-7.0 -7.6 13.0 12.9 12.9 12.9 12.9 12.8
-5.0 -5.6 13.5 13.5 13.5 13.4 13.4 13.4
-3.0 -3.7 14.1 14.0 14.0 14.0 14.0 13.9
0.0 -0.7 14.9 14.9 14.8 14.8 14.8 13.9
3.0 2.2 15.7 15.7 15.7 15.5 15.0 13.9
5.0 4.1 16.3 16.2 16.0 15.5 15.0 13.9
7.0 6.0 16.8 16.8
16.0 15.5 15.0 13.9
9.0 7.9 17.3 17.0 16.0 15.5 15.0 13.9
11.0 9.8 17.9 17.0 16.0 15.5 15.0 13.9
13.0 11.8 18.1 17.0 16.0 15.5 15.0 13.9
15.0 13.7 18.1 17.0 16.0 15.5 15.0 13.9

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
140
6 Dimensional drawing & centre of gravity
6 - 1 Dimensional drawing
FXMQ40P
3D060160
12 Drain hose (accessory) O.D. ø 32 (outlet)
11 Socket (for maintenance)
VP25 (O.D. ø 32 /I.D. ø 25)
10 Hook For M10
9 Air suction flange
8 Air discharge flange
7 Power supply connection
6 Interunit wiring connection
5 Control box (inside)
4 Ground terminal (in control box) M4
3 Drain pipe connection
VP25 (O.D. ø 32 /I.D. ø 25)
2 Gas pipe connection ø 12.7 flale connection
1 Liquid pipe connection ø 6.4 flale connection
ITEM PART NAME REMARK
20-ø 4.7 hole
(All around) (Suspention bolt position)
Air Outlet
26-ø 4.7 hole
(All around)
or less
Air Inlet
12 - 8x12 oblong hole
(All around)
450 or more
(service space)
700 or more
(service space)
View
(From the Air Outlet)
Inspection hatch 450 or more
700 or more
Adjustable
(467 or less)
Air outlet
Ceiling Floor surface
300 or more
Air Inlet
(Note 2)
(Note 4)
(A case without the
ceiling)
14 - 8x12 oblong hole
(All around)
(From the air inlet)
300 or less
Fig. A
View B-1 View B-2
Inspection hatch 2
Air
outlet
Air
inlet
Control box
<Inspection hatch>
(Ceiling opening)
Control box
Inspection hatch Ceiling
Inspection hatch
Ceiling
Inspection hatch (450mmx450mm)
Inspection hatch (°450)
Control box Control box
Control box
Inspection hatch 3
or more
or lessor more
or more
NOTES
1 Location of MANUFACTURE’S LABEL: Control box
surface
2 Mount the air filter at the suction side.
(Select its colorimethod (gravity method) 50% or more)
3 Do not locate things should not be wet under the indoor
unit.
Dews may droop when humidity reaches over 80%, or a
drain gets stuck, or air filters are not clean.
4 Space for Service Works
1) One inspection hatch (450x450) on the control box side and a space of 300mm or
more under the unit. (Fig.A)
2) One inspection hatch (450x450) on the control box side and 2 (two) inspection
hatches under the unit (Arrow view B-1)
3) 3 (three) inspection hatches under the unit and the control box. (Arrow view B-2)
According to any one of below 1) - 3), secure a space for service works, such
as, checking and maintenance of control box and drain pumps, etc.
FXMQ50,63,80P
3D060161
12 Drain hose (accessory) O.D. ø 32 (outlet)
11 Socket (for maintenance)
VP25 (O.D. ø 32 /I.D. ø 25)
10 Hook For M10
9 Air suction flange
8 Air discharge flange
7 Power supply connection
6 Interunit wiring connection
5 Control box (inside)
4 Ground terminal (in control box) M4
3 Drain pipe connection
VP25 (O.D. ø 32 /I.D. ø 25)
2 Gas pipe connection ø 15.9 flale connection
1 Liquid pipe connection ø 9.5 flale connection
ITEM PART NAME REMARK
30-ø 4.7 hole
(All around) (Suspention bolt position)
Air Outlet
36-ø 4.7 hole
(All around)
or less
Air Inlet
16 - 8x12 oblong hole
(All around)
450 or more
(service space)
700 or more
(service space)
View
(From the Air Outlet)
Inspection hatch 450 or more
700 or Less
Adjustable
(467 or more)
Air outlet
Ceiling Floor surface
300 or more
Air Inlet
(Note 2)
(Note 4)
2500 or more
(A case without the
ceiling)
18 - 8x12 oblong hole
(All around)
(From the air inlet)
300 or less
Fig. A
View B-1 View B-2
Inspection hatch 2
Air
outlet Air
inlet
Control box
<Inspection hatch>
(Ceiling opening)
Control box
Inspection hatch Ceiling
Inspection hatch
Ceiling
Inspection hatch (450mmx450mm)
Inspection hatch (°450)
Control box Control box
Control box
Inspection hatch 3
or more
or lessor more
or more
NOTES
1 Location of MANUFACTURE’S LABEL: Control box
surface
2 Mount the air filter at the suction side.
(Select its colorimethod (gravity method) 50% or
more)
3 Do not locate things should not be wet under the
indoor unit.
Dews may droop when humidity reaches over 80%,
or a drain gets stuck, or air filters are not clean.
4 Space for Service Works
According to any one of below 1) - 3), secure a space for service works, such
as, checking and maintenance of control box and drain pumps, etc.
1) One inspection hatch (450x450) on the control box side and a space of
300mm or more under the unit. (Fig.A)
2) One inspection hatch (450x450) on the control box side and 2 (two)
inspection hatches under the unit (Arrow view B-1)
3)
3 (three) inspection hatches under the unit and the control box. (Arrow view B-2)

•VRV
®Systems • Indoor Units 141
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
6 Dimensional drawing & centre of gravity
6 - 1 Dimensional drawing
FXMQ100,125P
3D060162
12 Drain hose (accessory) O.D. ø 32 (outlet)
11 Socket (for maintenance)
VP25 (O.D. ø 32 /I.D. ø 25)
10 Hook For M10
9 Air suction flange
8 Air discharge flange
7 Power supply connection
6 Interunit wiring connection
5 Control box (inside)
4 Ground terminal (in control box) M4
3 Drain pipe connection
VP25 (O.D. ø 32 /I.D. ø 25)
2 Gas pipe connection ø 15.9 flale connection
1 Liquid pipe connection ø 9.5 flale connection
ITEM PART NAME REMARK
40-ø 4.7 hole
(All around) (Suspention bolt position)
Air Outlet
48-ø 4.7 hole
(All around)
or less
Air Inlet
20 - 8x12 oblong hole
(All around)
450 or more
(service space)
700 or more
(service space) View
(From the Air Outlet)
Inspection hatch 450 or more
700 or Less
Adjustable
(467 or more)
Air outlet
Ceiling Floor surface
300 or more
Air Inlet
(Note 2)
(Note 4)
2500 or more
(A case without the
ceiling)
20 - 8x12 oblong hole
(All around)
(From the air inlet)
300 or less
Fig. A
View B-1 View B-2
Inspection hatch 2
Air
outlet Air
inlet
Control box
<Inspection hatch>
(Ceiling opening)
Control box
Inspection hatch Ceiling
Inspection hatch
Ceiling
Inspection hatch (450mmx450mm)
Inspection hatch (°450)
Control box Control box
Control box
Inspection hatch 3
or more
or lessor more
or more
NOTES
1 Location of MANUFACTURE’S LABEL:
Control box surface
2 Mount the air filter at the suction side.
(Select its colorimethod (gravity method) 50% or
more)
3 Do not locate things should not be wet under the
indoor unit.
Dews may droop when humidity reaches over 80%,
or a drain gets stuck, or air filters are not clean.
4 Space for Service Works
According to any one of below 1) - 3), secure a space for service works, such
as, checking and maintenance of control box and drain pumps, etc.
1) One inspection hatch (450x450) on the control box side and a space of
300mm or more under the unit. (Fig.A)
2) One inspection hatch (450x450) on the control box side and 2 (two)
inspection hatches under the unit (Arrow view B-1)
3)
3 (three) inspection hatches under the unit and the control box. (Arrow view B-2)
FXMQ100,125P
3D060162
12 Drain hose (accessory) O.D. ø 32 (outlet)
11 Socket (for maintenance)
VP25 (O.D. ø 32 /I.D. ø 25)
10 Hook For M10
9 Air suction flange
8 Air discharge flange
7 Power supply connection
6 Interunit wiring connection
5 Control box (inside)
4 Ground terminal (in control box) M4
3 Drain pipe connection
VP25 (O.D. ø 32 /I.D. ø 25)
2 Gas pipe connection ø 15.9 flale connection
1 Liquid pipe connection ø 9.5 flale connection
ITEM PART NAME REMARK
40-ø 4.7 hole
(All around) (Suspention bolt position)
Air Outlet
48-ø 4.7 hole
(All around)
or less
Air Inlet
20 - 8x12 oblong hole
(All around)
450 or more
(service space)
700 or more
(service space) View
(From the Air Outlet)
Inspection hatch 450 or more
700 or Less
Adjustable
(467 or more)
Air outlet
Ceiling Floor surface
300 or more
Air Inlet
(Note 2)
(Note 4)
2500 or more
(A case without the
ceiling)
20 - 8x12 oblong hole
(All around)
(From the air inlet)
300 or less
Fig. A
View B-1 View B-2
Inspection hatch 2
Air
outlet Air
inlet
Control box
<Inspection hatch>
(Ceiling opening)
Control box
Inspection hatch Ceiling
Inspection hatch
Ceiling
Inspection hatch (450mmx450mm)
Inspection hatch (°450)
Control box Control box
Control box
Inspection hatch 3
or more
or lessor more
or more
NOTES
1 Location of MANUFACTURE’S LABEL:
Control box surface
2 Mount the air filter at the suction side.
(Select its colorimethod (gravity method) 50% or
more)
3 Do not locate things should not be wet under the
indoor unit.
Dews may droop when humidity reaches over 80%,
or a drain gets stuck, or air filters are not clean.
4 Space for Service Works
According to any one of below 1) - 3), secure a space for service works, such
as, checking and maintenance of control box and drain pumps, etc.
1) One inspection hatch (450x450) on the control box side and a space of
300mm or more under the unit. (Fig.A)
2) One inspection hatch (450x450) on the control box side and 2 (two)
inspection hatches under the unit (Arrow view B-1)
3)
3 (three) inspection hatches under the unit and the control box. (Arrow view B-2)
FXMQ-P
3D028952
Cord oulet hole
Staple
EXPOSED BODY, EXPOSED CORD
Remote control
• REMOTE CONTROL DIMENSIONS
• INSTALLATION METHOD
NOTE
1 Remote control cord and staple are not attached. They are field
supplied parts.
• Specifications of cord
For Australia For other countries
Type
Shield wire
(insulated thickness: 1mm or more)
Vinyl cord with sheath or cable
(insulated thickness: 1mm or more)
Size 0.75~1.25mm²
Total
length 500m
EXPOSED BODY, EMBEDDED CORD EXPOSED BODY, EMBEDDED CODE
Remote control
(Between
remote control
and control box)
Control box
Remote control
Through hole
Conduit

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
142
6 Dimensional drawing & centre of gravity
6 - 1 Dimensional drawing
FXMQ100,125P
3D060162
12 Drain hose (accessory) O.D. ø 32 (outlet)
11 Socket (for maintenance)
VP25 (O.D. ø 32 /I.D. ø 25)
10 Hook For M10
9 Air suction flange
8 Air discharge flange
7 Power supply connection
6 Interunit wiring connection
5 Control box (inside)
4 Ground terminal (in control box) M4
3 Drain pipe connection
VP25 (O.D. ø 32 /I.D. ø 25)
2 Gas pipe connection ø 15.9 flale connection
1 Liquid pipe connection ø 9.5 flale connection
ITEM PART NAME REMARK
40-ø 4.7 hole
(All around) (Suspention bolt position)
Air Outlet
48-ø 4.7 hole
(All around)
or less
Air Inlet
20 - 8x12 oblong hole
(All around)
450 or more
(service space)
700 or more
(service space) View
(From the Air Outlet)
Inspection hatch 450 or more
700 or Less
Adjustable
(467 or more)
Air outlet
Ceiling Floor surface
300 or more
Air Inlet
(Note 2)
(Note 4)
2500 or more
(A case without the
ceiling)
20 - 8x12 oblong hole
(All around)
(From the air inlet)
300 or less
Fig. A
View B-1 View B-2
Inspection hatch 2
Air
outlet Air
inlet
Control box
<Inspection hatch>
(Ceiling opening)
Control box
Inspection hatch Ceiling
Inspection hatch
Ceiling
Inspection hatch (450mmx450mm)
Inspection hatch (°450)
Control box Control box
Control box
Inspection hatch 3
or more
or lessor more
or more
NOTES
1 Location of MANUFACTURE’S LABEL:
Control box surface
2 Mount the air filter at the suction side.
(Select its colorimethod (gravity method) 50% or
more)
3 Do not locate things should not be wet under the
indoor unit.
Dews may droop when humidity reaches over 80%,
or a drain gets stuck, or air filters are not clean.
4 Space for Service Works
According to any one of below 1) - 3), secure a space for service works, such
as, checking and maintenance of control box and drain pumps, etc.
1) One inspection hatch (450x450) on the control box side and a space of
300mm or more under the unit. (Fig.A)
2) One inspection hatch (450x450) on the control box side and 2 (two)
inspection hatches under the unit (Arrow view B-1)
3)
3 (three) inspection hatches under the unit and the control box. (Arrow view B-2)
FXMQ-P
3D007898B
79
Transmitting part
Switch box
(Field supplied parts)
2 - 5x9 Slot
(Ceiling opening)
• Service space for ceiling installation
Liquid crystal remote
control (wireless)
Remote control holder
(Ceiling opening)
more than 90
(Service space)
• REMOTE CONTROL DIMENSIONS • RECEIVER DETAIL
• REMOTE CONTROL HOLDER
INSTALLATION PROCEDURE
(INSTALLATION TO WALL SURFACE)
NOTE
1 Do not install more than 3 receivers in the vicinity of one another.
With 4 or more units, there is always the possibility of malfunction.

•VRV
®Systems • Indoor Units 143
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
6 Dimensional drawing & centre of gravity
6 - 2 Centre of gravity
FXMQ-P
4D060438
MODEL NAME
FXMQ40P
FXMQ50•63•80P
FXMQ100•125P

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
144
7 Piping diagram
FXMQ-P
4D034245C
Heat exchanger
Fan
Gas pipe connection port
Liquid pipe connection port
Filter Filter
Electronic expansion valve

•VRV
®Systems • Indoor Units 145
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
8 Wiring diagram
8 - 1 Wiring diagram
FXMQ-P
3D058783
NOTES
1 In case of using central remote control, connect it to the unit in accordance with the attached installation manual.
2 When connecting the input wires from outside, forced off or on/off control operation can be selected by remote control.
In details, refer to the installation manual attached the unit.
Indoor unit Connector optional accessory
A1P Printed circuit board R1 Resistor (current limiting) X28A Connector (power supply for wiring)
A2P Printed circuit board (Fan) R2 Current sensing device X33A Connector (for wiring)
A3P Printed circuit board (Capacitor) R3, R4 Resistor (electric discharge) X35A Connector (adapter)
C1,C2,C3 Capacitor R1T Thermistor (suction air)
F1U Fuse (T, 3,15A, 250V) R2T Thermistor (liquid) Wired remote control
F2U Fuse (T, 5A, 250V) R3T Thermistor (gas) R1T Thermistor (air)
F3U Fuse (T, 6,3A, 250V) R4T Thermistor (discharge air) SS1 Selector switch (main/sub)
F4U Fuse (T, 6,3A, 250V) S1L Float switch
HAP
Light emitting diode (service monitor-green) (A1P, A2P) V1R Diode bridge
KPR Magnetic relay V2R Power module
K1R Magnetic relay X1M Terminal strip (power supply)
L1R Reactor X2M Terminal strip (control)
M1F Motor (fan) Y1E Electronic expansion valve
M1P Motor (drain pump) Z1C,Z2C Noise filter (ferrite core)
PS Switching power supply (A1P, A2P) Z1F Noise filter
: Terminal Colors: RED: Red BRN: Brown ORG: Orange
: Connector BLK: Black GRY: Gray GRN: Green
: Field wiring WHT: White BLU: Blue
YLW: Yellow PNK: Pink
WIRING DIAGRAM
Wired remote control
(optional accessory)
Power
supply
For FXMQ50PVE • 63PVE • 80PVE • 100PVE • 125PVE
Input from outside
Note 2.
Transmission wiring
central remote
control
Note 1.
EL. COMPO. BOX (INDOOR)
❈ Only FXMQ50PVE • 63PVE • 80PVE • 100PVE • 125PVE
For FXMQ20PVE • 25PVE •320PVE •40PVE
To X1M
To X70A(A1P)

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
146
9 Sound data
9 - 1 Sound pressure spectrum
4D060446
NOTES
1 Over All (dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling - Return air temperature: 27°C DB, 19°C WB
Outdoor temperature: 35°C DB, 24°C WB
• Heating - Return air temperature: 20°C DB, 15°C WB
Outdoor temperature: 7°C DB, 6°C WB
• External static Pressure: 100Pa
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operation noise differs with operation and ambient options
Octave band sound pressure level dB(0dB=0.0002μ bar)
Octave band center frequency (Hz)
Approximate
threshold hearing
for continuous
noise
FXMQ40P
Scale Air flow rate
HH H L
A 39.0 37.0 35.0
C 45.0 42.0 41.0
Discharge Suction
1m2m
DuctDuct
1,5m
Microphone
4D060428
NOTES
1 Over All (dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling - Return air temperature: 27°C DB, 19°C WB
Outdoor temperature: 35°C DB, 24°C WB
• Heating - Return air temperature: 20°C DB, 15°C WB
Outdoor temperature: 7°C DB, 6°C WB
• External static Pressure: 100Pa
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operation noise differs with operation and ambient conditions.
Octave band sound pressure level dB(0dB=0.0002μ bar)
Octave band center frequency (Hz)
Approximate
threshold hearing
for continuous
noise
FXMQ50P
Scale Air flow rate
HH H L
A 41.0 39.0 37.0
C 46.0 44.0 42.0
Discharge Suction
1m2m
DuctDuct
1,5m
Microphone
4D060447
NOTES
1 Over All (dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB
Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB
Outdoor temperature: 7°C DB, 6°C WB
• External static Pressure: 100Pa
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operation noise differs with operation and ambient conditions.
Octave band sound pressure level dB(0dB=0.0002μ bar)
Octave band center frequency (Hz)
Approximate
threshold hearing
for continuous
noise
FXMQ63P
Scale Air flow rate
HH H L
A 42.0 40.0 38.0
C 48.0 46.0 44.0
Discharge Suction
1m2m
DuctDuct
1,5m
Microphone
4D060429
NOTES
1 Over All (dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB
Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB
Outdoor temperature: 7°C DB, 6°C WB
• External static Pressure: 100Pa
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operation noise differs with operation and ambient conditions.
Octave band sound pressure level dB(0dB=0.0002μ bar)
Octave band center frequency (Hz)
Approximate
threshold hearing
for continuous
noise
FXMQ80P
Scale Air flow rate
HH H L
A 43.0 41.0 39.0
C 49.0 47.0 45.0
Discharge Suction
1m2m
DuctDuct
1,5m
Microphone

•VRV
®Systems • Indoor Units 147
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
9 Sound data
9 - 1 Sound pressure spectrum
4D060448
NOTES
1 Over All (dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB
Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB
Outdoor temperature: 7°C DB, 6°C WB
• External static Pressure: 100Pa
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operation noise differs with operation and ambient conditions.
Octave band sound pressure level dB(0dB=0.0002μ bar)
Octave band center frequency (Hz)
Approximate
threshold hearing
for continuous
noise
FXMQ100P
Scale Air flow rate
HH H L
A 43.0 41.0 39.0
C 49.0 46.0 44.0
Discharge Suction
1m2m
DuctDuct
1,5m
Microphone
4D060449
NOTES
1 Over All (dB):
(B, G, N is already rectified)
2 Operating conditons:
• Power source: 220-240V 50Hz / 220V 60Hz
• Cooling: Return air temperature: 27°C DB, 19°C WB
Outdoor temperature: 35°C DB, 24°C WB
• Heating: Return air temperature: 20°C DB, 15°C WB
Outdoor temperature: 7°C DB, 6°C WB
• External static Pressure: 100Pa
3 Measuring place: Anechoic chamber
4 Location of microphone
5 Operation noise differs with operation and ambient conditions.
Octave band sound pressure level dB(0dB=0.0002μ bar)
Octave band center frequency (Hz)
Approximate
threshold hearing
for continuous
noise
FXMQ125P
Scale Air flow rate
HH H L
A 44.0 42.0 40.0
C 50.0 48.0 45.0
Discharge Suction
1m2m
DuctDuct
1,5m
Microphone

• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
•VRV
®Systems • Indoor Units
148
10 Fan characteristics
FXMQ40P
3D060456
External static pressure
Air flow (m3/min)
LowerlimitofESP
(ratingESP)
External static pressure
Air flow (m3/min)
(mmH
2
O) (Pa) (mmH
2
O) (mmH
2
O) (Pa) (mmH
2
O)
Fan characteristics Fan characteristics
(For local setting of remote control)
HH
(max ESP)
H
(max ESP)
HH
(min ESP)
L
(max ESP)
H
(rating ESP)
(note7)
max ESP
min EPS
Lower limitof ESP
(max ESP)
UpperlimitofESP(Note6)
(maxESP)
UpperlimitofESP
(ratingESP)
LowerlimitofESP
(minESP)
UpperlimitofESP
(minESP)
L(rating ESP)
H (min ESP)
L (min ESP)
NOTES
1 As for this machine, setting is possible
by 13 position of ESP
2 Fan characteristics cshows a fan
characteristic at the time of the
“maximum ESP” “rating ESP”
“minimum ESP” as a representative.
3 Fan characteristics d(for field setting
of remote control) shows a fan
characteristic of each ESP of field
setting possible air flow “HH”.
4 Please choose ESP setting by using
fan characteristics cand fan
characteristics dby the resistance of
a connect duct.
5 The remote control can be used to
change “HH” “H” and “L”.
6 ESP: External Static Pressure
7 The value in this figure shows ESP in
rating air flow.
Range of available air flow rate in ªHH¼
rating EPS
HH
(rating ESP)
(mmH
2
O) (mmH
2
O) (mmH
2
O) (mmH
2
O)
FXMQ50P
3D060457
External static pressure
Air flow (m3/min)
LowerlimitofESP
(ratingESP)
External static pressure
Air flow (m3/min)
(mmH
2
O) (Pa) (mmH
2
O) (mmH
2
O) (Pa) (mmH
2
O)
Fan characteristics Fan characteristics
(For local setting of remote control)
(note7)
max ESP
min EPS
LowerlimitofESP
(maxESP)
UpperlimitofESP(Note6)
(maxESP)
UpperlimitofESP
(ratingESP)
LowerlimitofESP
(minESP)
UpperlimitofESP
(minESP)
NOTES
1 As for this machine, setting is possible
by 14 position of ESP
2 Fan characteristics cshows a fan
characteristic at the time of the
“maximum ESP” “rating ESP”
“minimum ESP” as a representative.
3 Fan characteristics d(for field setting
of remote control) shows a fan
characteristic of each ESP of field
setting possible air flow “HH”.
4 Please choose ESP setting by using
fan characteristics cand fan
characteristics dby the resistance of
a connect duct.
5 The remote control can be used to
change “HH” “H” and “L”.
6 ESP: External Static Pressure
7 The value in this figure shows ESP in
rating air flow.
Range of available air flow rate in ªHH¼
rating EPS
HH
(max ESP)
H
(max ESP)
H
(min ESP)
L
(max ESP)
H
(rating ESP)
HH
(rating ESP)
L
(rating ESP)
HH
(min ESP)
L
(min ESP)
(note7)
max ESP
(mmH
2
O) (mmH
2
O) (mmH
2
O) (mmH
2
O)
FXMQ63P
3D060458
External static pressure
Air flow (m3/min)
Lowerlimit of ESP
(rating ESP)
External static pressure
Air flow (m3/min)
(mmH
2
O) (Pa) (mmH
2
O) (mmH
2
O) (Pa) (mmH
2
O)
Fan characteristics Fan characteristics
(For local setting of remote control)
HH
(max ESP)
H
(max ESP)
H
(min ESP)
L
(max ESP)
H
(rating ESP)
(note7)
max ESP
min EPS
LowerlimitofESP
(maxESP)
UpperlimitofESP(Note6)
(maxESP)
Upper limito
fES
P
(rating ESP)
Lower limito
fESP
(minESP)
UpperlimitofESP
(minESP)
NOTES
1 As for this machine, setting is possible
by 14 position of ESP
2 Fan characteristics cshows a fan
characteristic at the time of the
“maximum ESP” “rating ESP”
“minimum ESP” as a representative.
3 Fan characteristics d(for field setting
of remote control) shows a fan
characteristic of each ESP of field
setting possible air flow “HH”.
4 Please choose ESP setting by using
fan characteristics cand fan
characteristics dby the resistance of
a connect duct.
5 The remote control can be used to
change “HH” “H” and “L”.
6 ESP: External Static Pressure
7 The value in this figure shows ESP in
rating air flow.
Range of available air flow rate in ªHH¼
rating EPS
HH
(rating ESP)
L
(rating ESP)
HH
(min ESP)
L
(min ESP)
(mmH
2
O) (mmH
2
O) (mmH
2
O) (mmH
2
O)
FXMQ80P
3D060459
External static pressure
Air flow (m3/min)
LowerlimitofESP
(ratingESP)
External static pressure
Air flow (m3/min)
(mmH
2
O) (Pa) (mmH
2
O) (mmH
2
O) (Pa) (mmH
2
O)
Fan characteristics Fan characteristics
(For local setting of remote control)
HH
(max ESP)
H
(max ESP)
HH
(min ESP)
L
(max ESP)
H
(rating ESP)
(note7)
max ESP
min EPS
LowerlimitofESP
(maxESP)
UpperlimitofESP(Note6)
(maxESP)
UpperlimitofESP
(ratingESP)
LowerlimitofESP
(minESP)
UpperlimitofESP
(minESP)
L (min ESP)
NOTES
1 As for this machine, setting is possible
by 14 position of ESP
2 Fan characteristics cshows a fan
characteristic at the time of the
“maximum ESP” “rating ESP”
“minimum ESP” as a representative.
3 Fan characteristics d(for field setting
of remote control) shows a fan
characteristic of each ESP of field
setting possible air flow “HH”.
4 Please choose ESP setting by using
fan characteristics cand fan
characteristics dby the resistance of
a connect duct.
5 The remote control can be used to
change “HH” “H” and “L”.
6 ESP: External Static Pressure
7 The value in this figure shows ESP in
rating air flow.
Range of available air flow rate in ªHH¼
rating EPS
HH
(rating ESP)
(mmH
2
O) (mmH
2
O) (mmH
2
O) (mmH
2
O)
FXMQ100P
3D060460
External static pressure
Air flow (m3/min)
Lowerlimit of ESP
(ratingESP)
External static pressure
Air flow (m3/min)
(mmH
2
O) (Pa) (mmH
2
O) (mmH
2
O) (Pa) (mmH
2
O)
Fan characteristics Fan characteristics
(For local setting of remote control)
HH
(max ESP)
H
(max ESP)
HH
(min ESP)
L
(max ESP)
H
(rating ESP)
(note7)
max ESP
min EPS
LowerlimitofESP
(maxESP)
UpperlimitofESP(Note6)
(maxESP)
Upper limit of ESP
(rating ESP)
Lower limitofESP
(minESP)
UpperlimitofESP
(minESP)
L(rating ESP)
H (min ESP)
L (min ESP)
NOTES
1 As for this machine, setting is possible
by 14 position of ESP
2 Fan characteristics cshows a fan
characteristic at the time of the
“maximum ESP” “rating ESP”
“minimum ESP” as a representative.
3 Fan characteristics d(for field setting
of remote control) shows a fan
characteristic of each ESP of field
setting possible air flow “HH”.
4 Please choose ESP setting by using
fan characteristics cand fan
characteristics dby the resistance of
a connect duct.
5 The remote control can be used to
change “HH” “H” and “L”.
6 ESP: External Static Pressure
7 The value in this figure shows ESP in
rating air flow.
Range of available air flow rate in ªHH¼
rating EPS
HH
(rating ESP)
(mmH
2
O) (mmH
2
O) (mmH
2
O) (mmH
2
O)
FXMQ125P
3D060461
External static pressure
Air flow (m3/min)
Lowerlimit of ESP
(ratingESP)
External static pressure
Air flow (m3/min)
(mmH
2
O) (Pa) (mmH
2
O) (mmH
2
O) (Pa) (mmH
2
O)
Fan characteristics Fan characteristics
(For local setting of remote control)
HH
(max ESP)
H
(max ESP)
HH
(min ESP)
L
(max ESP)
H
(rating ESP)
(note7)
max ESP
min EPS
LowerlimitofESP
(maxESP)
UpperlimitofESP(Note6)
(maxESP)
Upperl
imito
fES
P
(rating ESP)
Lower limitof ESP
(minESP)
UpperlimitofESP
(minESP)
L(rating ESP)
H (min ESP)
L (min ESP)
NOTES
1 As for this machine, setting is possible
by 14 position of ESP
2 Fan characteristics cshows a fan
characteristic at the time of the
“maximum ESP” “rating ESP”
“minimum ESP” as a representative.
3 Fan characteristics d(for field setting
of remote control) shows a fan
characteristic of each ESP of field
setting possible air flow “HH”.
4 Please choose ESP setting by using
fan characteristics cand fan
characteristics dby the resistance of
a connect duct.
5 The remote control can be used to
change “HH” “H” and “L”.
6 ESP: External Static Pressure
7 The value in this figure shows ESP in
rating air flow.
Range of available air flow rate in ªHH¼
rating EPS
(mmH
2
O) (mmH
2
O) (mmH
2
O) (mmH
2
O)

2e
ÈEEDEN08-204aËÍ
Daikin Europe N.V. is approved by LRQA for its
Quality Management System in accordance with the
ISO9001 standard. ISO9001 pertains to quality
assurance regarding design, development,
manufacturing as well as to services related to the
product.
Daikin units comply with the European
regulations that guarantee the safety of
the product.
EEDEN08-204 • 01/2008 • Copyright ©Daikin Prepared in Belgium by Lannoo (www.lannooprint.be), a company whose concern for the environmont is set in the EMAS and ISO 14001 systems. Responsible Editor: Daikin Europe N.V., Zandvoordestraat 300, B- 8400 Oostende
The present publication is drawn up by way of information only and
does not constitute an offer binding upon Daikin Europe N.V.. Daikin
Europe N.V. has compiled the content of this publication to the best
of its knowledge. No express or implied warranty is given for the
completeness, accuracy, reliability or fitness for particular purpose of
its content and the products and services presented therein.
Specifications are subject to change without prior notice. Daikin
Europe N.V. explicitly rejects any liability for any direct or indirect
damage, In the broadest sense, arising from or related to the use
and/or interpretation of this publication. All content is copyrighted
by Daikin Europe N.V..
VRV®products are not within the scope of the
Eurovent certification programme.
Naamloze Vennootschap
Zandvoordestraat 300
B-8400 Oostende, Belgium
www.daikin.eu
BTW: BE 0412 120 336
RPR Oostende
Daikin’s unique position as a manufacturer of air
conditioning equipment, compressors and
refrigerants has led to its close involvement in
environmental issues. For several years Daikin
has had the intension to become a leader in the
provision of products that have limited impact
on the environment. This challenge demands
the eco design and development of a wide
range of products and an energy management
system, resulting in energy conservation and a
reduction of waste. ISO14001 assures an effective environmental
management system in order to help protect human
health and the environment from the potential
impact of our activities, products and services and to
assist in maintaining and improving the quality of the
environment.
