1English
FXAQ20MAVE
FXAQ25MAVE
FXAQ32MAVE
FXAQ40MAVE
FXAQ50MAVE
FXAQ63MAVE
VRV SYSTEM
Inverter Air Conditioners
Installation manual
CONTENTS
1. SAFETY CONSIDERATIONS........................................................................................ 1
2. BEFORE INSTALLATION .............................................................................................. 2
3. SELECTING INSTALLATION SITE ............................................................................... 4
4. INDOOR UNIT INSTALLATION..................................................................................... 5
5. REFRIGERANT PIPING WORK .................................................................................... 9
6. DRAIN PIPING WORK................................................................................................. 11
7. ELECTRIC WIRING WORK......................................................................................... 12
8. HOW TO CONNECT WIRINGS AND WIRING EXAMPLE .......................................... 13
9. FIELD SETTINGS ........................................................................................................ 16
10. TEST OPERATION ...................................................................................................... 18
1. SAFETY CONSIDERATIONS
Please read these “SAFETY CONSIDERATIONS” carefully before installing air conditioning equipment and
be sure to install it correctly. After completing the installation, make sure that the unit operates properly during
the start-up operation. Please instruct the customer on how to operate the unit and keep it maintained.
Also, inform customers that they should store this installation manual along with the operation manual for
future reference.
This air conditioner comes under the term “appliances not accesible to the general public”.
Meaning of warning and caution symbols.
WARNING ........Failure to observe a warning may result in death or serious injury.
CAUTION ..........Failure to observe a caution may result in injury or damage to the equipment.
WARNING
•
Ask your dealer or qualified personnel to carry out installation work. Do not try to install the machine yourself.
Improper installation may result in water leakage, electric shocks or fire.
•Perform installation work in accordance with this installation manual.
Improper installation may result in water leakage, electric shocks or fire.
•When installing the unit in a small room, take measures against to keep refrigerant concentration from
exceeding allowable safety limits in the event of refrigerant leakage. Contact the place of purchase for more
information. Excessive refrigerant in a closed ambient can lead to oxygen deficiency.
•Be sure to use only the specified accessories and parts for installation work.
Failure to use the specified parts may result in water leakage, electric shocks, fire or the unit falling.
•Install the air conditioner on a foundation strong enough to withstand the weight of the unit.
A foundation of insufficient strength may result in the equipment falling and causing injuries.
•Carry out the specified installation work after taking into account strong winds, typhoons or earthquakes.
Improper installation work may result in the equipment falling and causing accidents.
•Make sure that a separate power supply circuit is provided for this unit and that all electrical work is carried
out by qualified personnel according to local laws and regulations and this installation manual.
An insufficient power supply capacity or improper electrical construction may lead to electric shocks or fire.
01_EN_3P156215-10P.fm Page 1 Wednesday, April 2, 2008 11:47 AM

English 2
•Make sure that all wiring is secured, the specified wires are used, and no external forces act on the terminal
connections or wires.
Improper connections or installation may result in fire.
•When wiring the power supply and connecting the wiring between the indoor and outdoor units, position the
wires so that the control box cover can be securely fastened.
Improper positioning of the control box cover may result in electric shocks, fire or the terminals
overheating.
•If the refrigerant gas leaks during installation, ventilate the area immediately.
Toxic gas may be produced if the refrigerant gas comes into contact with fire.
•After completing the installation work, check that the refrigerant gas does not leak.
Toxic gas may be produced if the refrigerant gas leaks into the room and comes into contact with a source
of fire, such as a fan heater, stove or cooker.
•Before touching electrical parts, turn off the unit.
•Be sure to establish an earth.
Do not earth the unit to a utility pipe, arrester, or telephone earth.
Incomplete earth may cause electrical shock, or fire.
A high surge current from lightning or other sources may cause damage to the air conditioner.
•Be sure to install an earth leakage breaker.
Failure to install an earth leakage breaker may result in electric shocks, or fire.
CAUTION
•While following the instructions in this installation manual, install drain piping in order to ensure proper
drainage and insulate piping in order to prevent condensation.
Improper drain piping may result in water leakage and property damage.
•Install the indoor and outdoor units, power cord and connecting wires at least 1 meter away from televisions
or radios in order to prevent image interference or noise.
(Depending on the radio waves, a distance of 1 meter may not be sufficient enough to eliminate the noise.)
•Remote controller (wireless kit) transmitting distance can result shorter than expected in rooms with
electronic fluorescent lamps. (inverter or rapid start types)
Install the indoor unit as far away from fluorescent lamps as possible.
•Do not install the air conditioner in the following locations:
(a) where a mineral oil mist or an oil spray or vapor is produced, for example in a kitchen
Plastic parts may deteriorate and fall off or result in water leakage.
(b) where corrosive gas, such as sulfurous acid gas, is produced
Corroding copper pipes or soldered parts may result in refrigerant leakage.
(c) near machinery emitting electromagnetic waves
Electromagnetic waves may disturb the operation of the control system and result in a malfunction of
the equipment.
(d) where flammable gases may leak, where there are carbon fiber or ignitable dust suspensions in the air,
or where volatile flammables such as thinner or gasoline are handled.
Operating the unit in such conditions may result in fire.
2. BEFORE INSTALLATION
Do not exert pressure on the resin parts when opening the unit or when moving it after opening.
Before rigging tubes, check which type of refrigerant is used. Proper operation is not possible if the
types of refrigerant are not the same.
•Be careful not to bend any of the plastic parts when moving the unit when taking it out of the packing case or
afterwards.
•Decide upon a line of transport.
•When transporting, transport to the installation location without taking it out of the packing case.
If you have to remove the unit from the packing case when transporting it, be sure not to damage it.
•Refer to the installation manual of the outdoor unit for items not described in this manual.
•Do not dispose of any parts necessary for installation until the installation is complete.
01_EN_3P156215-10P.fm Page 2 Wednesday, April 2, 2008 11:47 AM

3English
2-1 PRECAUTIONS
•Be sure to read this manual before installing the indoor unit.
•Entrust installation to the place of purchase or a qualified serviceman.Improper installation could lead to
leaks and, in worse cases, electric shock of fire.
•Use only parts provided with the unit or parts satisfing required specifications. Unspecified parts could
cause the unit to fall out of place, or could lead to leaks and, in worse cases, electric shock or fire.
•Do not install or operate the unit in rooms mentioned below.
• Laden with mineral oil, or filled with oil vapor or spray like in kitchens. (Plastic parts may
deteriorate which could eventually cause the unit to fall out of place, or could lead to leaks.)
• Where corrosive gas like sulfurous gas exists. (Copper tubing and brazed spots may corrode,
which could eventually lead to refrigerant leaks.)
• Where volatile flammable gas like thinner or gasoline is used.
• Where exposed to combustible gases and where voltatile flammable gas like thinner or gasoline
is used. (Gas in the vicinity of the unit could ignite.)
• Where machines can generate electromagnetic waves. (Control system may malfunction.)
• Where the air contains high levels of salt such as that near the ocean and where voltage
fluctuates greatly such as that in factories. Also in vehicles or vessels.
•When selecting installation site, refer to the installation pattern.
•This unit, both indoor and outdoor, is suitable for installation in a commercial and light industrial
environment. If installed as a household appliance it could cause electromagnetic interference.
2-2 ACCESSORIES
Check the following accessories are included with your unit.
2-3 OPTIONAL ACCESSORIES
•These are two types of remote controllers: wired and wireless. Select a remote controller according to
customer request and install in an appropriate place.
•If the customer wishes to use a remote controller that is not listed above, select a suitable remote
controller after consulting catalogs and technical materials.
Name (1) Installation
panel
(2) Attachment screws
for the installation panel
(3) Paper pattern
for installation (4) Insulating tape
Quantity 1 set 8 pcs. → FXA(Q)20,25,32 type
9 pcs. → FXA(Q)40,50,63 type 1 pc. 1 pc.
Shape
M4 × 25L
Name (5) Clamp (6) Securing screws
(Other)
• Operation manual
• Installation manual
Quantity 1 large 3 small 2 pcs.
Shape
M4 × 12L
Remote controller type Model
Wired type BRC1C51
BRC1A61
Wireless type
Heat pump type BRC7E618
Cooling only
type BRC7E619
01_EN_3P156215-10P.fm Page 3 Wednesday, April 2, 2008 11:47 AM

English 4
FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND
CHECK AFTER INSTALLATION IS FINISHED.
1. Items to be checked after completion of work
2. Items to be checked at time of delivery
* Also review the “SAFETY CONSIDERATIONS”
Points for explanation about operations
2-4 NOTE TO THE INSTALLER
Be sure to instruct customers how to properly operate the unit (especially cleaning filters, operating different
functions, and adjusting the temperature) by having them carry out operations themselves while looking at the
manual.
3. SELECTING INSTALLATION SITE
(1) Select an installation site where the following conditions are fulfilled and that meets with your
customer’s approval.
•In the upper space (including the back of the ceiling) of the indoor unit where there is no possible
dripping of water from the refrigerant pipe, drain pipe, water pipe, etc.
•Where the wall is strong enough to bear the indoor unit weight.
•Where sufficient clearance for installation and maintenance can be ensured.
(Refer to Fig. 1 and Fig. 2)
Items to be checked If not properly done, what is likely to occur Check
Are the indoor and outdoor unit fixed
firmly? The units may drop, vibrate or make noise.
Is the gas leak test finished? It may result in insufficient cooling.
Is the unit fully insulated? Condensate water may drip.
Does drainage flow smoothly? Condensate water may drip.
Does the power supply voltage correspond
to that shown on the name plate?
The unit may malfunction or the
components burn out.
Are wiring and piping correct? The unit may malfunction or the
components burn out.
Is the unit safely grounded? Dangerous at electric leakage.
Is wiring size according to specifications? The unit may malfunction or the
components burn out.
Is something blocking the air outlet or inlet
of either the indoor or outdoor units? It may result in insufficient cooling.
Are refrigerant piping length and additional
refrigerant charge noted down?
The refrigerant charge in the system is not
clear.
Items to be checked Check
Did you explain about operations while showing the operation manual to your customer?
Did you hand the operation manual over to your customer?
The items with WARNING and CAUTION marks in the instruction manual are the items
pertaining to possibilities for bodily injury and material damage in addition to the general usage of
the product. Accordingly, it is necessary that you make a full explanation about the described
contents and also ask your customers to read the instruction manual.
01_EN_3P156215-10P.fm Page 4 Wednesday, April 2, 2008 11:47 AM

5English
•Where optimum air distribution can be ensured.
•Where nothing blocks the air passage.
•Where condensate can be properly drained.
•Where the wall is not significantly tilted.
•Where not exposed to combustible gases.
•Where pipe between indoor and outdoor units is possible within the allowable limit.
(Refer to the installation manual of the outdoor unit.)
•Install the indoor and outdoor units, power cable and transmission wiring, at least 1 m from TVs and
radios, to prevent distorted pictures and static. (Depending on the type and source of the electrical
waves, static may be heard even when more than 1 m away.)
•Install the indoor unit no less than 2.5 m above the floor. Where unavoidably lower, take what measures
are necessary to keep hands out of the air inlet.
•Where the cool (warm) air reaches all across the room.
(2) Consider whether the place where the unit will be installed can support the full weight of the unit,
and reinforce it with boards and beams, etc. if needed before proceeding with the installation.
Also, reinforce the place to prevent vibration and noise before installing.
(The installation pitch can be found on the paper pattern for installation (3), so refer to it when con-
sidering the necessity for reinforcing the location.)
(3) The indoor unit may not be directly installed on the wall. Use the attached installation panel (1)
before installing the unit.
4. INDOOR UNIT INSTALLATION
•Use only accessories and parts which are of the designated specification when installing.
CAUTION
•Install so that the unit does not tilt to either side or forward.
•Do not hold the unit by the horizontal flaps when lifting it. (This may damage the horizontal flaps.)
(1) Open the piping through-hole.
•The refrigerant pipe and drain pipe can be passed out in one of 6 directions: left, bottom-left, back-left,
right, bottom-right, and back-right. (Refer to Fig. 3)
Fig. 1
≥ 50 ≥ 50
[ Space required for installation (mm) ]
≥ 90
≥ 30
Floor
Fig. 2
Obstruction
≤ 120
≥ 2500 (from floor)
For installation
in high places.
01_EN_3P156215-10P.fm Page 5 Wednesday, April 2, 2008 11:47 AM

English 6
•Using the paper pattern for installation (3), choose where to pass the piping out and open a through-hole
(φ80) in the wall.
Open the hole so that there is a downward slope for the drain piping. (See “ 6.DRAIN PIPING WORK ”)
(2) Remove the installation panel (1) from the unit and attach to the wall.
(The installation panel is temporarily attached to the unit with screw. (In case of 20-32 type))
(Refer to Fig. 3)
(a) Check the location for the hole using the included paper pattern for installation (3).
•Choose a location so that there is at least a 90 mm gap between the ceiling and the main unit.
(b) Temporarily attach the installation panel (1) at the temporary-securing position on the paper pattern for
installation (3) and use a level to make sure the drain hose is either level or tilted slightly downward.
(c) Secure the installation panel (1) to the wall using either screws or bolts.
•If using the attachment screws for the installation panel (2), attach using at least 4 screws on either
side (for a total of 8 screws (20-32 type), 9 screws (40-63 type)) of the recommended installation
cleat position on the included paper pattern for installation (3).
•If using bolts, attach using a M8 - M10 bolt (for a total of 2 bolts) on either side.
•If dealing with concrete, use commercially available foundation bolts (M8 - M10).
(3) If using the left, bottom-left, right, or bottom-right positions for the piping, cut out the through-hole
for the piping in the front grill. (Refer to Fig. 4)
(4) Remove the front panel and the service lid. (Refer to Fig. 5)
< How to remove the front panel and service lid >
(1) Open the front panel to the point where it stops.
(2)
Push the axes on either side of the front panel towards the center of the main unit and remove. (You can
also remove it by sliding the front panel either to the left or right and pulling it forward.)
(3) Remove the screw from the service lid and pull the handle forward.
Installation panel (1)
Temporary screw
(In case of 20-32 type)
Right pipe
Left pipe
Back-left pipe
Back-right pipe
Bottom-left pipe
Bottom-right pipe
Front grill
Cut out along
the groove.
Cut away
Fig. 3 Fig. 4
Axis Axis
Axis
Fig. 5
Handle
Screw
Service lid
Front panel
(1)
(2) (2)
(3)
01_EN_3P156215-10P.fm Page 6 Wednesday, April 2, 2008 11:47 AM

7English
(5) Point the pipe in the direction it will be passed out.
For right, bottom-right, and back-right piping (Refer to Fig. 6)
•
Wrap the drain hose and the refrigerant piping together with the insulat-
ing tape (4) so that the drain hose is below the refrigerant piping.
For left, bottom-left, and left-back piping
•Remove the front grill. (Refer to Fig. 7)
< How to remove the front grill >
Remove the front grill as described below when securing the indoor
unit with screws or when attaching Optional Accessories (wireless
remote controller, adapter PC board, etc.).
(1) Remove the front panel.
(2) Remove the screws (2 places in case of FXA(Q)20,25,32 type/3 places in case of FXA(Q)40,50,63
type) securing the front grill.
(3) Remove the tabs (3 places) securing the front grill by pushing them in the direction of the arrows.
(4)
Making sure not to catch the horizontal flaps, remove the front grill by pulling in the direction of the arrow.
•Remove the drain plug, the insulation tubing, and the drain hose from the drain pan and replace.
(Refer to Fig. 8)
•Connect the local refrigerant piping ahead of time, matching it to the liquid pipe and gas pipe marks
engraved on the installation panel (1).
< Replacing the drain hose and drain plug >
(1) Remove the drain plug and insulation tubing.
(2) Remove the drain hose and replace onto the left side.
(3) Replace the drain plug and the insulation tubing onto the right side.
Insulating tape (4)
Drain hose
Fig. 6
Refrigerant piping
Tab position Tab position
Front grill
Fig. 7
Ta b
(2) (2) (2)
(3) (3)
(4)
(3)
Screw position
Screw position (In case of FXA(Q)40,50,63 type)
Drain plug
Insulating tube
Fig. 8
Do not place lubricant (refrigerant oil) when inserting.
This may cause deterioration and water leaks.
Insert using a hexagon wrench (4mm).
Make sure
there are
no gaps.
01_EN_3P156215-10P.fm Page 7 Wednesday, April 2, 2008 11:47 AM

English 8
(6) Hook the indoor unit onto the installation panel. (Refer to Fig. 9)
•Placing buffering material between the wall and the indoor unit at this time will make work easier.
For right, bottom-right, and back-right piping
•Pass the drain hose and the refrigerant piping to the wall.
(7) Pass power supply wiring, transmission wiring, ground wiring, and remote controller wiring
through the wiring guide in through the back of the indoor unit and to the front.
(8) Connect the piping. (See “5.REFRIGERANT PIPING WORK” and Fig. 10)
•
To avoid the influence of noise from the power supply line on the transmission wiring and the remote
controller wiring, these wirings must be kept as far as possible from the power/ground wirings. As shown in the
figure, keep the power supply wiring and the ground wiring together. Keep the transmission and remote con-
troller wirings together and route them maintaining a good distance from the power supply/ground wirings
(that is, on the other side of the power supply/ground wirings). Then, fix them securely on the refrigerant pipe.
•Seal the piping through-hole with putty corking material.
(9) Push on both bottom edges of the indoor unit using both hands and hook the tab on the back of
the indoor unit onto the installation panel (1). (Refer to Fig. 9)
•At this time remove the buffering material placed in step (6).
Refrigerant piping
Be sure to pass all wires through
the wiring guide.
Ta b
(There are 2 places.)
Wiring (locally procured)
Power supply wiring, Transmission wiring, Ground wiring,
Remote controller wiring
Wall
Installation panel
(accessory) (1)
Front panel Front grill
Service lid
Place buffering material
Hook the indoor unit hook onto the installation panel (1).
Fig. 9
Secure with
vinyl tape.
Wrap the insulating tape overlapping at least half the width with
each wrap.
Wrap the insulating tape all the way to the L-shaped bend.
Seal with putty corking
material.
Drain hose
Wiring
Fig. 10
Refrigerant piping
A
Aarrow view
Power supply wiring and
ground wiring
Refrigerant piping
Transmission wiring and
remote controller wiring
01_EN_3P156215-10P.fm Page 8 Wednesday, April 2, 2008 11:47 AM

9English
•Make sure power supply wiring, transmission wiring, ground wiring and remote controller wiring are not
caught inside the indoor unit.
■When screwing in the indoor unit
•Remove the front grill. (Refer to Fig. 7)
•Secure the indoor unit to the installation panel (1) with the securing
screws (6). (Refer to Fig. 11)
5. REFRIGERANT PIPING WORK
〈For refrigerant piping of outdoor units, see the installation manual attached to the outdoor unit.〉
〈Execute heat insulation work completely on both sides of the gas piping and the liquid piping.
Otherwise, a water leakage can result sometimes.〉
(When using a heat pump, the temperature of the gas piping can reach up to approximately 120°C, so use
insulation which is sufficiently resistant.)
〈Also, in cases where the temperature and humidity of the refrigerant piping sections might exceed
30°C or RH80 %, reinforce the refrigerant insulation. (20 mm or thicker) Condensation may form on the
surface of the insulating material.〉
〈Before refrigerant piping work, check which type of refrigerant is used. Proper operation is not pos-
sible if the types of refrigerant are not the same.〉
CAUTION
• Use a pipe cutter and flare suitable for the type of refrigerant.
• Apply ester oil or ether oil around the flare section before connecting.
• To prevent dust, moisture or other foreign matter from infiltrating the tube, either pinch the end
or cover it with tape.
• Do not allow anything other than the designated refrigerant to get mixed into the refrigerant
circuit, such as air, etc. If any refrigerant gas leaks while working on the unit, ventilate the room
thoroughly right away.
•The outdoor unit is charged with refrigerant.
•Use copper alloy seamless pipes (ISO 1337)
•Be sure to use both a spanner and torque wrench together, as shown
in the drawing, when connecting or disconnecting pipes to/from the
unit. (Refer to Fig. 12)
•Refer to “Table 1” for the dimensions of flare nut spaces.
•When connecting the flare nut, coat the flare section (both inside and
outside) with ester oil or ether oil, rotate three or four times first, then
screw in. (Refer to Fig. 13)
CAUTION
•Over-tightening may cause the flare nuts to crack or the refrigerant
to leak.
•Use the flare nut included with the unit main body.
Installation panel
(accessory) (1)
Refrigerant piping
Insulating tape
(accessory) (4)
M4 × 12L
(accessory) (6)
Fig. 11
Ester oil or ether oil
Fig. 13
Torque wrench
Spanner
Piping union
Flare nut
Fig. 12
01_EN_3P156215-10P.fm Page 9 Wednesday, April 2, 2008 11:47 AM

English 10
•Refer to Table 1 for tightening torque.
Ta b l e 1
Not recommendable but in case of emergency
You must use a torque wrench but if you are obliged to install the unit without a torque wrench, you may
follow the installation method mentioned below.
After the work is finished, make sure to check that there is no gas leak.
When you keep on tightening the flare nut with a spanner, there is a point where the tightening torque
suddenly increases. From that position, further tighten the flare nut the angle shown below:
Ta b l e 2
CAUTION
CAUTION TO BE TAKEN WHEN BRAZING REFRIGERANT PIPING
“Do not use flux when brazing refrigerant piping. Therefore, use the phosphor copper brazing filler metal
(BCuP-2: JIS Z 3264/B-Cu93P-710/795: ISO 3677) which does not require flux.”
(Flux has extremely harmful influence on refrigerant piping systems. For instance, if the chlorine based flux is
used, it will cause pipe corrosion or, in particular, if the flux contains fluorine, it will damage the refrigerant oil.)
•When brazing the refrigerant piping, only begin brazing after having carried out nitrogen substitution
(NOTE 1) or while inserting nitrogen into the refrigerant piping (NOTE 2). Once this is done, connect the
indoor unit with a flared or a flanged connection.
NOTES
1. Refer to the “Manual for Multi Installation for Buildings” for directions on how to carry out nitrogen
substitution. (Inquire with your dealer.)
2. Nitrogen should be set to 0.02 MPa with a pressure-reducing valve if brazing while inserting nitrogen into
the piping. (Refer to Fig. 14)
CAUTION
Be sure to insulate any field piping all the way to the piping connection inside the unit. Any exposed piping
may cause condensation or burns if touched.
Pipe size Tightening torque Flare dimensions A (mm) Flare
FXA–LVE(C) FXAQ–M(A)VE
φ 6.4 (1/4”) 14.2 – 17.2N·m 8.6 – 9.0 8.7 – 9.1
φ 9.5 (3/8”) 32.7 – 39.9N·m 12.6 – 13.0 12.8 – 13.2
φ 12.7 (1/2”) 49.5 – 60.3N·m 15.8 – 16.2 16.2 – 16.6
φ 15.9 (5/8”) 61.8 – 75.4N·m 19.0 – 19.4 19.3 – 19.7
Pipe size Further tightening angle Recommended arm length of tool
φ6.4 (1/4”) 60 to 90 degrees Approx. 150mm
φ9.5 (3/8”) 60 to 90 degrees Approx. 200mm
φ12.7 (1/2”) 30 to 60 degrees Approx. 250mm
φ15.9 (5/8”) 30 to 60 degrees Approx. 300mm
R0.4-0.8
A
90
0
±2
0
45
0
±2
0
Refrigerant piping
Part to be
brazed
Taping
Pressure-reducing valve
hands valve
Nitrogen Fig. 14
Nitrogen
01_EN_3P156215-10P.fm Page 10 Wednesday, April 2, 2008 11:47 AM

11 English
•After checking for gas leaks, be sure to insulate the pipe connections using the supplementary piping
insulation tubing and insulating tape (4). The insulating tape (4) should be wrapped from the L-shaped bend
all the way to the end inside the unit. (Refer to Fig. 15)
6. DRAIN PIPING WORK
(1) Install the drain piping. (Refer to Fig. 16)
•The drain pipe should be short with a downward slope and should prevent air pockets from forming.
•Watch out for the points in the figure 16 when performing drain work.
•When extending the drain hose, use a commercially available drain extension hose, and be sure to
insulate the extended section of the drain hose which is indoors. (Refer to Fig. 17)
•Make sure the diameter of the piping is the same as the piping (hard vinyl chloride, nominal diameter
13mm) or bigger.
•When directly connecting a hard vinyl chloride pipe joint (nominal diameter 13mm) to the drain hose
connected to the indoor unit (i.e. for embedded piping, etc.), use a commercially available hard vinyl
chloride pipe joint (nominal diameter 13mm). (Refer to Fig. 18)
Insulating tubing tape
Insulating tubing tape
Local piping
Indoor unit piping
Indoor unit piping insulation tubing
Clamping material large
(accessory) (5)
Insulating tape (accessory) (4)
L-shaped
bend
Start wrapping
See “ 4.INDOOR UNIT
INSTALLATION ”
Indoor unit piping insulation tubing
Insulating tubing tape
Insulation tubing seam
Attach the insulation tubing
tape so that there are no gaps
in the insulation tubing seam.
Fig. 15
Fig. 16
Make sure the drain
hose is at a downward
slope.
Make sure the tip does
not go underwater even
when water is added.
Drain hose Drain hose
(Downward
slope)
Indoor unit drain hose
Extension drain piping
(commercially available)
Insulating tube
(commercially available) Insulating tape (accessory) (4)
( See “4.INDOOR UNIT INSTALLATION” )
Fig. 17
Drain hose connected
to the indoor unit
Commercially available
hard vinyl chloride pipe
joint (nominal diameter 13mm)
Commercially available
hard vinyl chloride pipe
(nominal diameter 13mm)
Fig. 18
01_EN_3P156215-10P.fm Page 11 Wednesday, April 2, 2008 11:47 AM

English 12
(2) Make sure the drain works properly.
•After drain work is complete, perform a drain
check by opening the front panel, removing
the air filter, pouring water into the drain pan,
and making sure water flows smoothly out of
the drain hose. (Refer to Fig. 19)
CAUTION
Drain piping connections
Do not connect the drain piping directly to sewage pipes that smell of ammonia. The ammonia in the
sewage might enter the indoor unit through the drain pipes and corrode the heat exchanger.
Keep in mind that it will become the cause of getting drain pipe blocked if water collects on drain pipe.
7. ELECTRIC WIRING WORK
7-1 GENERAL INSTRUCTIONS
•All field supplied parts and materials and electric works must conform to local codes.
•Use copper wire only.
•For electric wiring work, refer to also “WIRING DIAGRAM” attached to the unit body.
•For remote controller wiring details, refer to the installation manual attached to the remote controller.
•All wiring must be performed by an authorized electrician.
•This system consists of multiple indoor units. Mark each indoor unit as unit A, unit B..., and be sure the
terminal board wiring to the outdoor unit and BS unit are properly matched. If wiring and piping between the
outdoor unit and an indoor unit are mismatched, the system may cause a malfunction.
•A circuit breaker capable of shutting down power supply to the entire system must be installed.
•Refer to the installation manual attached to the outdoor unit for the size of power supply wiring connected
to the outdoor unit, the capacity of the circuit breaker and switch, and wiring instructions.
•Be sure to ground the air conditioner.
•Do not connect the ground wire to gas pipes, water pipes, lightning rods, or telephone ground wires.
•Gas pipes: might cause explosions or fire if gas leaks.
•Water pipes: no grounding effect if hard vinyl piping is used.
•Telephone ground wires or lightning rods: might cause abnormally high electric potential in the ground
during lighting storms.
7-2 ELECTRICAL CHARACTERISTICS
MCA: Min. Circuit Amps (A); MFA: Max. Fuse Amps (A)
kW: Fan Motor Rated Output (kW); FLA: Full Load Amps (A)
Units Power supply Fan motor
Model Hz Volts Voltage range MCA MFA kW FLA
FXA(Q)20LVE(M(A)VE)
50 220 - 240 Max. 264
Min. 198
0.3 15 0.04 0.2
FXA(Q)25LVE(M(A)VE) 0.4 15 0.04 0.3
FXA(Q)32LVE(M(A)VE) 0.4 15 0.04 0.3
FXA(Q)40LVE(M(A)VE) 0.4 15 0.043 0.3
FXA(Q)50LVE(M(A)VE) 0.4 15 0.043 0.3
FXA(Q)63LVE(M(A)VE) 0.6 15 0.043 0.5
FXA(Q)20LVE(M(A)VE)
60 220 Max. 242
Min. 198
0.3 15 0.04 0.2
FXA(Q)25LVE(M(A)VE) 0.3 15 0.04 0.2
FXA(Q)32LVE(M(A)VE) 0.4 15 0.04 0.3
FXA(Q)40LVE(M(A)VE) 0.4 15 0.043 0.3
FXA(Q)50LVE(M(A)VE) 0.4 15 0.043 0.3
FXA(Q)63LVE(M(A)VE) 0.6 15 0.043 0.5
Plastic container
for pouring
Drain pan
Make sure not to splash the water.
Fig. 19
01_EN_3P156215-10P.fm Page 12 Wednesday, April 2, 2008 11:47 AM

13 English
7-3 SPECIFICATIONS FOR FIELD SUPPLIED FUSES AND WIRE
Allowable length of transmission wirings and remote controller wiring are as follows.
(1) Outdoor unit - Indoor unit: Max. 1000m (Max. wiring length: 2000m)
(2) Indoor unit - Remote controller: Max. 500m
8. HOW TO CONNECT WIRINGS AND WIRING EXAMPLE
8-1 HOW TO CONNECT WIRINGS
Methods of wiring power supply, units and connecting remote controller wiring
•Power supply wiring
Unscrew and remove the service lid.
Connect the power supply wiring and ground wiring to the power supply terminal block (3P).
When doing this, tie the power supply wiring and the ground wiring using the included clamp (small) (5) and
then firmly secure using the included clamp (small) (5) according to the figure.
(Refer to Fig. 20)
•Transmission wiring and remote controller wiring
Unscrew and remove the service lid.
Connect the remote controller wiring and the transmission wiring to the terminal block (6P).
When doing this, tie the remote controller wiring and the transmission wiring using the included clamp (small)
(5) and then firmly secure using the included clamp (small) (5) according to the figure.
(Refer to Fig. 20)
Model
Power supply wiring Remote controller wiring
Transmission wiring
Field fuses Wire Size Wire Size
FXA(Q)20LVE(M(A)VE)
15A H05VV - U3G
Wire size must
comply with
local codes.
Vinyl cord with
sheath or cable
(2 wire)
0.75 - 1.25 mm
2
FXA(Q)25LVE(M(A)VE)
FXA(Q)32LVE(M(A)VE)
FXA(Q)40LVE(M(A)VE)
FXA(Q)50LVE(M(A)VE)
FXA(Q)63LVE(M(A)VE)
REMOTE
CNTRL FORCED OFF
TRANSMISSION
WIRING
F1 F2 T1 T2P1 P2
LN
Terminal block (6P)
Ground terminal
Ground wiring
Power supply wiring
Power supply
terminal block (3P)
In case of using the power
supply terminal together with
the other connecting wirings
Make sure to process
the insulation at the wire
terminal part properly so that
the terminals do not get in
contact each other.
Fig. 20
Remote
controller wiring
LN
Ground wiring
Power supply wiring
Transmission wiring
Transmission
wiring
< Wiring clamp method >
Clamp small
(accessory) (5)
Clamp small
(accessory) (5)
Clamp small
(accessory) (5)
Clamp after tying the
wiring between the units
and the ground
wiring .
Remote controller
wiring
(3 places)
Cut off any excess
material after tightening.
01_EN_3P156215-10P.fm Page 13 Wednesday, April 2, 2008 11:47 AM

English 14
CAUTION
Be sure to attach the sealing material and putty (field supplied) to hole of wiring to prevent the infiltration
of water as well as any insects and other small creatures from outside. Otherwise a short-circuit may
occur inside the electric parts box.
When clamping the wirings, be sure no pressure is applied to the wire connections by using the included
clamp to make appropriate clamps. Also, when wiring, make sure the lid on the control box fits snugly by
arranging the wirings neatly and attaching the service lid firmly. When attaching the service lid, make sure
no wirings get caught in the edges. Pass wiring through the wiring through holes to prevent damage to
them.
Make sure the remote controller wiring, and transmission wire the wiring between the units, and other elec-
trical wiring do not pass through the same locations outside the machine, separating them by at least
50mm, otherwise electrical noise (external static) could cause mistaken operation or breakage.
Use only specified wire and tightly connect wires to terminals. Be careful wires do not place external stress
on terminals. Keep wiring in neat order and so as not to obstruct other equipment such as popping open the
service cover. Make sure the cover closes tight. Incomplete connections could result in overheating, and in
worse case, electric shock or fire.
[ PRECAUTIONS ]
1. Use round crimp-style terminals for connecting wires to the power supply terminal board.
(Refer to Fig. 21)
If unavailable, observe the following points when wiring.
•Do not connect wires of different gauge to the same power supply terminal.
(Looseness in the connection may cause overheating.)
•When connecting wires of the same gauge, connect them according to Fig. 22.
•Use the specified electric wire. Connect the wire securely to the terminal. Lock the wire down without
applying excessive force to the terminal. (Tightening torque: 131N·cm ±10 %)
2. Tightening torque for the terminal screws.
•Use the correct screwdriver for tightening the terminal screws. If the blade of screwdriver is too small, the
head of the screw might be damaged, and the screw will not be properly tightened.
•If the terminal screws are tightened too hard, screws might be damaged.
•Refer to the table below for the tightening torque of the terminal screws.
3. Do not connect wires of different gauge to the same ground terminal. Looseness in the connection may
deteriorate protection.
4. Keep transmission wiring at least 50mm away from power supply wiring. The equipment may malfunction
if subjected to electrical (external) noise.
5. For remote controller wiring, refer to the “INSTALLATION MANUAL OF REMOTE CONTROLLER”
attached to the remote controller.
6. Never connect power supply wiring to the terminal block for remote controller. A mistake of the
sort could damage the entire system.
Terminal Size Tightening torque
Remote controller, Transmission wiring and
Forced off terminal block (6P) M3.5 0.79 – 0.97N·m
Power supply and Ground terminal block (3P) M4 1.18 – 1.44N·m
Electric wire
Round crimp-style terminal
Attach insulation sleeve
Fig. 21
01_EN_3P156215-10P.fm Page 14 Wednesday, April 2, 2008 11:47 AM

15 English
8-2 WIRING EXAMPLE
•Fit the power supply wiring of each unit with a switch and fuse as shown in the drawing.
COMPLETE SYSTEM EXAMPLE (3 systems)
1. When using 1 remote controller for 1 indoor unit. (Normal operation)
2. For group control or use with 2 remote controllers
Power supply wiring
Transmission and remote controller wiring
Switch
Fuse
Fig. 22
Power supply
Main
switch
Remote controller
Indoor unit
Outdoor unit
BS unit
(Only for Heat
recovery system)
LN LN
IN/D OUT/D
F1F2F1F2
Control box
LN
LN P 1 P 2
P 1 P 2
F 1 F 2 T 1 T 2 P 1 P 2
P 1 P 2
F 1 F 2 T 1 T 2LN P 1 P 2
P 1 P 2
F 1 F 2 T 1 T 2LN LN P 1 P 2
P 1 P 2
F 1 F 2 T 1 T 2
LN
Outdoor unit
No. 1
System
Indoor
unit A
Indoor
unit B
Indoor
unit C
Most
downstream
Indoor unit
Power supply
220-240V
50Hz
or
220V
60Hz
Power supply
220-240V
50Hz
or
220V
60Hz
Power supply
220-240V
50Hz
or
220V
60Hz
Power supply
220-240V
50Hz
or
220V
60Hz
Fig. 23
IN/D OUT/D
F1F2F1F2
Control box
LN P 1 P 2
P 1 P 2
F 1 F 2 T 1 T 2LN P 1 P 2 F 1 F 2 T 1 T 2LN P 1 P 2 F 1 F 2 T 1 T 2LN P 1 P 2 F 1 F 2 T 1 T 2
P 1 P 2 P 1 P 2
LN
Outdoor unit
No. 2
System
Indoor
unit A
Indoor
unit B
Indoor
unit C Most downstream
indoor unit
Fig. 24
For use with 2
remote controllers
Power supply
220-240V
50Hz
or
220V
60Hz
Note: It is not necessary to designate indoor unit
address when using group control.
The address is automatically set when power is
activated.
01_EN_3P156215-10P.fm Page 15 Wednesday, April 2, 2008 11:47 AM

English 16
3. When including BS unit
[ PRECAUTIONS ]
1. A single switch can be used to supply power to units on the same system. However, branch switches and
branch circuit breakers must be selected carefully.
2. Do not ground the equipment on gas pipes, water pipes or lightning rods, or crossground with telephones.
Improper grounding could result in electric shock.
9. FIELD SETTINGS
(1) Make sure the service lids are closed on the indoor and outdoor units.
(2)
Field settings must be made from the remote controller and in accordance with installation conditions.
•Settings can be made by changing the “Mode No.”, “FIRST CODE NO.” and “SECOND CODE NO.”.
•The “Field Settings” included with the remote control lists the order of the settings and method of operation.
*Setting is made in all units in a group. To set for individual indoor units or to check the setting, use the mode
Nos. (with “2” in upper digit) in parentheses ( ).
9-1 SETTING AIR FILTER SIGN
•Remoto controllers are equiped with liquid crystal display air filter sighs to display the time to clean air
filters.
•Change the SECOND CODE NO. according to Table 3 depending on the amount of dirt or dust in the room.
(SECOND CODE NO. is factory set to “01” for air filter contamination-light)
Ta b l e 3
9-2 SETTING AIR FLOWRATE INCREASE MODE
•It is possible to raise set air flow (HIGH and LOW) from the field. Change the SECOND CODE NO. as
shown in Table 4 to suit your needs.
(SECOND CODE NO. is factory set to “01” for Standard.)
Ta b l e 4
Setting Spacing time of display
air filter sign Mode No. FIRST CODE NO. SECOND CODE NO.
Air filter
contamination-light Approx. 200 hrs
10 (20) 0
01
Air filter
contamination-heavy Approx. 100 hrs 02
Setting Mode No. FIRST CODE NO.
SECOND CODE NO.
Standard
13 (23) 0
01
A little increase 02
Increase 03
IN/D OUT/D
F1F2F1F2
IN/DOUT/D
F1F2F1F2
LN
P 1 P 2
LN P 1 P 2 F 1 F 2 T 1 T 2
BS unit
No. 3
System
Outdoor unit
Power supply
220-240V
50Hz
or
220V
60Hz
Indoor
unit A
Fig. 25
Control box
Control box
IN/DOUT/D
F1F2F1F2
BS unit
Control box
01_EN_3P156215-10P.fm Page 16 Wednesday, April 2, 2008 11:47 AM

17 English
〈When using wireless remote controllers〉
•When using wireless remote controllers, wireless remote controller address setting is necessary. Refer to
the installation manual attached to the wireless remote controller for setting instructions.
9-3 CONTROL BY 2 REMOTE CONTROLLERS (CONTROLLING 1 INDOOR UNIT BY
2 REMOTE CONTROLLERS)
•When using 2 remote controllers, one must be set to “MAIN” and the other to “SUB”.
MAIN/SUB CHANGEOVER
(1) Insert a screwdriver into the recess between the
upper and lower part of remote controller and,
working from the 2 positions, pry off the upper part.
The remote controller PC board is attached to the upper
part of the remote controller. (Refer to Fig. 26)
(2) Turn the main/sub changeover switch on one of the
two remote controller PC boards to “S”.
(Leave the switch of the other remote controller set to
“M”.) (Refer to Fig. 27)
Wiring Method (See ‘‘7.ELECTRIC WIRING WORK’’)
(3) Remove the service lid.
(4) Add remote control 2 (slave) to the terminal block
(6P) for remote controller (P1, P2) in the control box.
(There is no polarity.) (Refer to Fig. 24 and section
7-3 for the wiring size.)
9-4 COMPUTERISED CONTROL (FORCED OFF AND ON/OFF OPERATION)
(1) Wire specifications and how to perform wiring
•Connect the input from outside to terminals T1 and T2 of the terminal block (6P).
(2) Actuation
•The following table explains FORCED OFF and ON/OFF OPERATIONS in response to Input A.
Wire specification Sheathed vinyl cord or cable (2 wire)
Gauge 0.75 - 1.25 mm
2
Length Max. 100 m
External terminal Contact that can ensure the minimum
applicable load of 15V DC, 10 mA.
FORCED OFF ON/OFF OPERATION
Input “ON” stops operation (impossible by remote controllers). Input OFF → ON turns ON unit.
Input OFF enables control by remote controller. Input ON → OFF turns OFF unit.
Upper part of
remote controller
Lower part of
remote controller
Insert the screwdriver here
and gently work off the
upper part of the remote controller.
Fig. 26
S
M
S
S
M
Remote
controller
PC board
(Factory setting)
(Only one remote
controller needs
to be changed if
factory settings
have remained
untoched.)
Fig. 27
Input A
Fig. 28
F2 T1 T2
FORCED
OFF
01_EN_3P156215-10P.fm Page 17 Wednesday, April 2, 2008 11:47 AM
