Daikin DCS601C51 User manual

Operation Manual
Use smart and save smart
• Thank you for purchasing intelligent Touch Controller.
• This operation manual contains notes for safe use of the
product.
For correct use, be sure to read this manual carefully
before use.
• When you have read this manual, be sure to store it in a
place where the operator can conveniently refer to at
anytime.
In case of personnel change, be sure to give the manual
to the new operator.
Model
DCS601C51
intelligent Touch Controller
Maintenance
Precautions................................................ 83
Maintenance
LCD Maintenance...................................... 84
When Leaving the Product
Turned OFF for a Long Time ..................... 84
Troubleshooting ......................................... 85
Maintenance
For Your Information
Before useOperation
Before use
Safety Considerations
Be sure to follow the instructions below .....1
System Overview......................................... 3
Features and Functions...............................4
Part Names and Functions.......................... 5
Part Names on the Monitoring
Screen and the Functions
List............................................................... 7
Icon.............................................................. 9
Operation
Operation
Quick Reference........................................13
Air Conditioner Operation.......................... 15
Monitoring Operation of Air Conditioner ... 26
System Setup Menu ..................................... 32
For Your Information
Options ...................................................... 93
Specification .............................................. 94
After-sales Service .....................................95
EM04A055A

Operation Manual
Use smart and save smart
• Thank you for purchasing intelligent Touch Controller.
• This operation manual contains notes for safe use of the
product.
For correct use, be sure to read this manual carefully
before use.
• When you have read this manual, be sure to store it in a
place where the operator can conveniently refer to at
anytime.
In case of personnel change, be sure to give the manual
to the new operator.
Model
DCS601C51
intelligent Touch Controller
Maintenance
Precautions................................................ 83
Maintenance
LCD Maintenance...................................... 84
When Leaving the Product
Turned OFF for a Long Time ..................... 84
Troubleshooting ......................................... 85
Maintenance
For Your Information
Before useOperation
Before use
Safety Considerations
Be sure to follow the instructions below .....1
System Overview......................................... 3
Features and Functions...............................4
Part Names and Functions.......................... 5
Part Names on the Monitoring
Screen and the Functions
List............................................................... 7
Icon.............................................................. 9
Operation
Operation
Quick Reference........................................13
Air Conditioner Operation.......................... 15
Monitoring Operation of Air Conditioner ... 26
System Setup Menu ..................................... 32
For Your Information
Options ...................................................... 93
Specification .............................................. 94
After-sales Service .....................................95

Warning
Warning
caution
Note
Safety Considerations
Please read these “SAFETY CONSIDERATIONS”
carefully before installing air conditioning equipment
and be sure to install it correctly.
After completing the installation, make sure that the
unit operates properly during the start-up operation.
Please instruct the customer on how to operate the
unit and keep it maintained.
Also, inform customers that they should store this
installation manual along with the operation manual
for future reference.
This air conditioner comes under the term “appliances
not accessible to the general public”.
Meaning of warning, caution and note symbols.
Indicates a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
It may also be used to alert against
unsafe practices.
Indicates situation that may result
in equipment or property-damage-
only accidents.
Keep these warning sheets handy so that you can
refer to them if needed.
Also, if this equipment is transferred to a new user,
make sure to hand over this operation manual to the
new user.
In order to avoid electric shock, fire or injury, or if you
detect any abnormality such as smell of fire, turn off
power and call your dealer for instructions.
Ask your dealer for installation of the air
conditioner.
Incomplete installation performed by yourself may
result in a water leakage, electric shock, and fire.
Ask your dealer for improvement, repair, and
maintenance.
Incomplete improvement, repair, and maintenance
may result in a water leakage, electric shock, and fire.
Improper installation or attachment of equipment
or accessories could result in electric shock,
short-circuit, leaks, fire or other damage to the
equipment. Be sure only to use accessories made
by Daikin which are specifically designed for use
with the equipment and have them installed by a
professional.
Ask your dealer to move and reinstall the air
con-ditioner or the remote controller.
Incomplete installation may result in a water leakage,
electric shock, and fire.
Never let the indoor unit or the remote controller
get wet.
It may cause an electric shock or a fire.
Never use flammable spray such as hair spray,
lacquer or paint near the unit.
It may cause a fire.
Never replace a fuse with that of wrong ampere
ratings or other wires when a fuse blows out.
Use of wire or copper wire may cause the unit to
break down or cause a fire.
Never inspect or service the unit by yourself.
Ask a qualified service person to perform this work.
Cut off all electric waves before maintenance.
Do not wash the air conditioner or the remote
controller with excessive water.
Electric shock or fire may result.
Do not install the air conditioner or the remote
controller at any place where flammable gas may leak
out.
If the gas leaks out and stays around the air
condi-tioner, a fire may break out.
Do not touch the switch with wet fingers.
Touching a switch with wet fingers can cause electric
shock.
CISPR 22 Class A Warning:
This is a class A product. In a domestic environment
this prod-uct may cause radio interference in which
case the user may be required to take adequate
measures.
1

After a long use, check the unit stand and fitting
for damage.
If they are left in a damaged condition, the unit may
fall and result in injury.
Do not allow a child to mount on the unit or avoid
placing any object on it.
Falling or tumbling may result in injury.
Do not let children play on and around the unit.
If they touch the unit carelessly, it may result in injury.
Do not place a flower vase and anything contain-
ing water.
Water may enter the unit, causing an electric shock or
fire.
Never touch the internal parts of the controller.
Do not remove the front panel. Some parts inside are
dan-gerous to touch, and a machine trouble may
happen.
For checking and adjusting the internal parts, contact
your dealer.
Avoid placing the controller in a spot splashed
with water.
Water coming inside the machine may cause an
electric leak or may damage the internal electronic
parts.
Do not operate the air conditioner when using a
room fumigation - type insecticide.
Failure to observe could cause the chemicals to
become deposited in the unit, which could endanger
the health of those who are hypersensitive to
chemicals.
Safely dispose of the packing materials.
Packing materials, such as nails and other metal or
wooden parts, may cause stabs or other injuries.
Tear apart and throw away plastic packaging bags so
that children will not play with them. If children play
with a plastic bag which was not torn apart, they face
the risk of suffocation.
Do not turn off the power immediately after stop-
ping operation.
Always wait at least five minutes before turning off the
power. Otherwise, water leakage and trouble may
occur.
The appliance is not intended for use by young
children or infirm persons without supervision.
The remote controller should be installed in such
away that children cannot play with it.
Never press the button of the remote controller
with a hard, pointed object.
The remote controller may be damaged.
Never pull or twist the electric wire of the remote
controller.
It may cause the unit to malfunction.
Do not place the controller exposed to direct
sunlight.
The LCD display may get discolored, failing to dis-
play the data.
Do not wipe the controller operation panel with
benzine, thinner, chemical dustcloth, etc.
The panel may get discolored or the coating peeled
off. If it is heavily dirty, soak a cloth in water-diluted
neutral detergent, squeeze it well and wipe the panel
clean. And wipe it with another dry cloth.
Dismantling of the unit, treatment of the refriger-
ant, oil and eventual other parts, should be done
in accordance with the relevant local and national
regulations.
2
CAUTION NOTE

3
System Overview
This intelligent Touch Controller is capable of controlling / monitoring up to 64 groups of indoor units (hereafter
“groups”).
The main functions of the intelligent Touch Controller include :
1. Collective starting / stopping of operation of the indoor units connected to the intelligent Touch Controller.
2. Starting / stopping of operation, temperature setting, switching between temperature control modes and
enabling / disabling of operation with the hand-held remote control by zone or group .
3. Scheduling by zone or group .
4. Monitoring of the operation status by zone or group .
5. Display of the air conditioner operation history.
6. Compulsory contact stop input from the central monitoring panel (non-voltage, normally-open contact).
7. Power distribution of the air conditioners. (With the optional DCS002A51)
∗A group of indoor units include :
∗Zone control with the intelligent Touch Controller
1 One indoor unit without a remote control.
3 Up to 16 indoor units controlled with one or two remote controls.
2 One indoor unit controlled with one or two remote controls.
intelligent Touch Controller
Zone 1
Up to 16 units Up to 16 unitsTwo remote controlsRemote control
No remote control Remote control Remote control
or
Indoor unit
Zone 5
Zone 2 Zone 3 Zone 4
∗Zone control, which allows collective settings for more than one group, is available with the intelligent Touch
Controller, which facilitates the setting operations.
• One setting makes the same setting for all of the units in one zone.
• Up to 128 zones can be set with one intelligent Touch Controller.
(The maximum number of groups in one zone is 64.)
• Groups can be zoned at will with the intelligent Touch Controller.
• Units in one group can be divided into more than one zone.

4
Features and Functions
■ Operation Menu
intelligent Touch Controller is capable of starting / stopping of the operation by
the group or zone. Collective starting / stopping is also available.
■ Air Conditioner Detail Setup
Temperature setting, switching between temperature control modes, switching of
speed and direction of wind and remote control mode setting are available by the
group, by the zone or collectively.
■ Monitoring of Various Information on Indoor Units
Information on operation such as the operation mode and temperature setting of
the indoor units, maintenance information including the filter or element cleaning
sign, troubleshooting information such as error codes can be displayed by the
group or the zone.
■ Zone Control Simplifying Complicated Setting Operations
Up to 64 groups can be controlled with the intelligent Touch Controller.
More than one group can be consolidated into a zone, which can be registered, to
allow the following settings by the zone. This eliminates the need for repeating the
same setting operation for each group. Function to allow collective setting for all
groups is also available.
■ Detailed Scheduled Operation Control
The intelligent Touch Controller allows detailed scheduled operation by the group,
by the zone or collectively. Up to 8 options for annual schedule can be set. Each
schedule can include four types of plans : for Weekdays, Holidays, Special days 1
and Special days 2. Each of the plans allows setting of up to 16 operations.
■ Diversified Operation Modes
Operation can be controlled both with the main unit and the remote control to
provide diversified operation management. Setting with the main unit allows the
following remote control settings by the group, by the zone or collectively:
1. Start/Stop 2. Operation Mode 3.Temperature Setting
: (Remote control) Inhibited : (Remote control) Inhibited : (Remote control) Inhibited
: (Remote control) Permitted : (Remote control) Permitted : (Remote control) Permitted
: Priority
• Start / stop
• Temperature setting
• Switching between operation modes
• Setting of direction and fan speed
• Disabling / enabling the remote control
See pages
15 17
to
See pages
18 22
to
See pages
26 29
to
See page
22
See pages
15 29
to
33
See pages
35 36
to
See pages
37 46
to
■ Handy Automated Control
The Intelligent Touch Controller can do the following.
• Change Over Settings : automatically switches between cooling and heating
according to the room temperature.
• Temperature Limit Settings : prevents the temperature from rising too high or
too low in unmanned rooms.
• Heating Optimization Settings : stops uncomfortable hot air from blowing when
the heating thermo is off.

Be sure to use the touch pen for
operation of the touch panel of
the intelligent Touch Controller.
Operating with an object other
than the touch pen provided may
cause damage and failure.
Part Names and Functions
Color LCD with Touch Panel
Provides a display for monitoring
and operation.
Be sure to use the touch pen
provided for operation.
PCMCIA Card Slot
Used when using the optional
Power Proportional Distribution
(DCS002C51) or updating the
intelligent Touch Controller
software to a newer version.
Touch Pen
5
Use the touch pen for operation.
Be sure to use the touch pen for
operation.
Use caution not to lose the touch
pen.
When the pen is lost, contact the
dealer you purchased the
product from.
Front and Side View
Note

Terminals on the Back of intelligent Touch Controller
Using DIII-NET Plus adapter
being sold as an accessory,
you can increase the number
of indoor units to be controlled.
RS232-C connector for
DIII-NET Plus adapter
When using AIRNET service,
connect it to the telephone line.
Modem connector for AIRNET
This is used when distributing the power supply to indoor
units using optional Power Proportional Distribution software
sold separately and when stopping the indoor units
compulsorily by contact input.
The size of terminal block is M3.5.
Terminal block for watt hour meter and force stop input
of indoor units
When monitoring and operating
the indoor units using the optional
Web and E-mail function software
sold separately, connect to LAN
via Ethernet cable.
Ethernet connector for web
Securely connect the earth wire.
Terminal size is M4.
Earth terminal block
Connect to AC100-240V power supply.
Terminal size is M4.
Terminal block for power supply
The terminal size of the terminal
block for communication with
indoor units is M3.5.
Terminal block for DIII-NET
communication
LINE
COM L0Dil Pi3 COM Pi2 Pi1 F2 F1 N L
PHONE
RS-232C LAN
6

Contents of the List Currently Displayed
• When Group List is displayed
“Zone : Zone Name”
• When Zone List is displayed
“Zone List”
Display Mode Selection
Press the button and display
change between Zone and Group.
System Condition Displayed Domain
Domain displaying system
condition (Compulsory Stop etc.)
Zone / Group Name
Set the names in the Group
Registration or Zone Registration
in the System Setup Mode.
Filter / Element Sign
Displayed when there is any air
conditioner showing a filter or
element sign in the zone or the
group.
Target of Automatic Control
Displayed when there is any air
conditioner with the registration of
scheduled in the zone or in the
group.
Monitoring Screen Legend
Pressing the “?” button shows
more detailed legend.
Button to Switch to the System Setup Mode
Use this button for settings
including the time, group, zone
and schedule.
7
Part Names on the Monitoring Screen and the Functions
List
Zone / Group Currently Displayed
The name of the zone / group
currently selected is highlighted
in light-blue.

8
List
Display for Collective Monitoring of Air
Conditioners Connected to intelligent Touch Controller
When operation is normal and any air
conditioner is in operation :
Red / Normal
When operation is normal and all air
conditioners are in stoppage :
Green / Normal
When there is any air conditioner
generating an error :
Yellow / Abnormal
When there is any air conditioner with
communication error :
Blue / Abnormal
Change in color of Start/Stop is
possible by Iconcolor Settings in
System Settings.
Start All Button
Button to collectively start all the
air conditioners connected to
intelligent Touch Controller.
Stop All Button
Button to collectively stop all the
air conditioners connected to
intelligent Touch Controller.
Display Mode Selection
Select the mode among icon / list /
detailed icon.
Displayed in List in the right figure.
Icon display is P9, 10.
Detailed icon display is P11, 12.
Group / Zone Start Button
Button to start operation of the
group / zone selected.
Group / Zone Stop Button
Button to stop operation of the
group / zone selected.
Group / Zone Set Button
Makes settings (temperature
setting, temperature control mode,
etc.) and display of the group /
zone selected.
Current Time Display
Shows the current date and time.
Group / Zone Prop Button
Detailed display of the group /
zone selected
Lock Setting / Cancel Button
Displays possibititiy of monitor
operation.
Expresses detailed information in
P31, 32.
Scroll Buttons
Up / Down scroll button used
when monitoring zone / group
which are not currently displayed.
Left/Right scroll button used
when monitoring temperature
and errors etc.
Which are not currently
displayed.

Contents of the List Currently Displayed
• When Group List is displayed
“Zone : Zone Name”
• When Zone List is displayed
“Zone List Display”
Display Mode Selection
Select between Zone and Group.
Generally, the temperature setting
and the operation mode are
displayed. If any error occurs in the
air conditioner, the error code is
displayed.
Blue triangular mark shows
communication abnormality in air
conditioner.
Yellow triangular mark shows
abnormality in air conditioner.
Zone / Group Currently Displayed
The name of the zone / group currently
selected is highlighted in blue flame.
Zone / Group Name
Set the names in the Group
Registration or Zone Registration
in the System Setup Mode.
Filter / Element Sign
Displayed when there is any air
conditioner showing a filter or
element sign in the zone or the
group.
Target of Automatic Control
Displayed when there is any air
conditioner with the registration of
scheduled in the zone or in the
group.
Monitoring Screen Legend
Pressing the “?” button shows
more detailed legend.
Use this button for settings
including the time, group, zone
and schedule.
Description of Zone / Group
Set the names in the Group
Registration or Zone Registration
in the System Setup Mode.
9
Icon
System Condition Displayed Domain
Domain displaying system
condition (Compulsory Stop etc.)
Information on Zone / Group
Currently Displayed
Displayed Abnormality in Air
Conditioner or Communication
Button to Switch to the
System Setup Mode

10
Icon
Display for Collective Monitoring of Air
Conditioners Connected to intelligent Touch Controller
When operation is normal and any air
conditioner is in operation :
Red / Normal
When operation is normal and all air
conditioners are in stoppage :
Green / Normal
When there is any air conditioner
generating an error :
Yellow / Abnormal
When there is any air conditioner with
communication error :
Blue / Abnormal
Change in color of Start / Stop is
possible by Iconcolor Settings in
System Settings.
Start All Button
Button to collectively start all the
air conditioners connected to
intelligent Touch Controller.
Stop All Button
Button to collectively stop all the
air conditioners connected to
intelligent Touch Controller.
Display Mode Selection
Select the mode among icon / list /
detailed icon.
Displayed is List in the right figure.
List display in P7, 8.
Detailed icon display is P11, 12.
Group / Zone Start Button
Button to start operation of the
group / zone selected.
Group / Zone Stop Button
Button to stop operation of the
group / zone selected.
Group / Zone Set Button
Makes settings (temperature
setting, temperature control mode,
etc.) and display of the group /
zone selected.
Current Time Display
Shows the current date and time.
Group / Zone Prop Button
Detailed display of the group /
zone selected
Lock Setting / Cancel Button
Displays possibititiy of monitor
operation.
Expresses detailed information in
P31, 32.
Scroll Buttons
Up / Down scroll button used
when monitoring zone / group
which are not currently
displayed.
Left / Right scroll button used
when monitoring temperature
and errors etc.
Which are not currently
displayed.

11
Icon
Contents of the List Currently Displayed
• When Group List is displayed
“Zone : Zone Name”
• When Zone List is displayed
“Zone List Display”
Display Mode Selection
Press the button ana display
change between Zone and Group.
Blue triangular mark shows
communication abnormality in air
conditioner.
Yellow triangular mark shows
abnormality in air conditioner.
Zone / Group Currently Displayed
The name of the zone / group currently
selected is highlighted in blue frame.
Zone / Group Name
Set the names in the Group
Registration or Zone Registration
in the System Setup Mode.
Filter / Element Sign
Displayed when there is any air
conditioner showing a filter or
element sign in the zone or the
group.
Target of Automatic Control
Displayed when there is any air
conditioner with the registration of
scheduled in the zone or in the
group.
Monitoring Screen Legend
Pressing the “?” button shows
more detailed legend.
Button to Switch to the System Setup Mode
Use this button for settings
including the time, group, zone
and schedule.
System Condition Displayed Domain
Domain displaying system
condition (Compulsory Stop etc.).
Displayed Abnormality in Air
Conditioner or Communication

12
Display for Collective Monitoring of Air
Conditioners Connected to intelligent Touch Controller
When operation is normal and any air
conditioner is in operation :
Red / Normal
When operation is normal and all air
conditioners are in stoppage :
Green / Normal
When there is any air conditioner
generating an error :
Yellow / Abnormal
When there is any air conditioner with
communication error :
Blue / Abnormal
Change in color of Start / Stop is
possible by Iconcolor Settings in
System Settings.
Start All Button
Button to collectively start all the
air conditioners connected to
intelligent Touch Controller.
Stop All Button
Button to collectively stop all the
air conditioners connected to
intelligent Touch Controller.
Display Mode Selection
Select the mode among icon / list /
detailed icon.
Displayed in List in the right figure.
List display is P7, 8.
Icon display is P9, 10.
Group / Zone Start Button
Button to start operation of the
group / zone selected.
Group / Zone Stop Button
Button to stop operation of the
group / zone selected.
Group / Zone Set Button
Makes settings (temperature
setting, temperature control mode,
etc.) and display of the group /
zone selected.
Current Time Display
Shows the current date and time.
Group / Zone Prop Button
Detailed display of the group /
zone selected
Lock Setting / Cancel Button
Displays possibititiy of monitor
operation.
Expresses detailed information in
P31, 32.
Scroll Buttons
Up / Down scroll button used
when monitoring zone/group
which are not currently displayed.
Left/Right scroll button used
when monitoring temperature
and errors etc.
Which are not currently
displayed.
Icon

13
Quick Reference
15
16
17
18
19
20
21
22
23
24
25
26 27
28 29
30
31
Air Conditioner Operation
■ To collectively start / stop the operation of all devices connected
to the intelligent Touch Controller
■ To start / stop the operation of devices by zone
■ To start / stop the operation of devices by group
■ To change the operation mode
■ To change the temperature setting
■ To change the direction or fan speed
■ To change the range of operation allowed with remote control
■ To change the ventilation mode
■ To change the ventilation volume
■ To permit / prohibit the remote control at hand for ventilation
Air Conditioner Operation Monitoring
■ To monitor by zone or by group
■ To monitor detailed information
■ To monitor the operation condition for ventilation
■ To set / release the lock of screen operation
■ To reset the filter or element sign
See page
See page
See page
See page
See page
See page
See page
See page
See page
See pages to
See pages to
See page
See page
See page
See page

14
33
33
35 36
37 41
42 44
45 46
55
55
34
34
34
34
92
47
50 54
49
See pages to
System Setup Menu
■ To change the name of a group
■ To change the zone setup
■ To change the schedule setup
■ To calibrate the touch panel
■ To adjust the contrast of the screen
■ To set the e-mail
■ To review the history of errors
■ To set the locale
■ To set the icon color
■ To set the network
■ To set the license key
■ To change the change over settings
■ To change the temperature limit settings
■ To change the heating optimization settings
See page
See page
See pages to
See pages to
See pages to
See pages to
See pages to
See page
See page
See page
See page
See page
See page
See page
■ To xxxx

15
Air Conditioner Operation
Starting / Stopping Operation Collectively
1 2
3
Screen 1 Monitoring
Screen 2 Confirm
To start / stop the operation
of all devices connected
1.
2.
Screen 2 Confirm appears. Press the
[OK] button 3 .
To exit without activating collective
start or stop, press the [Cancel] button.
Start or stop collectively the operation of
devices connected.
On the Monitoring screen, operation is
allowed with either Zone or Group as the
display mode and with either Icon or List as
the display type. In the example on the left,
the display mode is Group in the collective
mode and the display type is Icon.
[Procedure]
On Screen 1 Monitoring, press the [Start
All] button 1 or [Stop All] button 2 .

16
Screen 1 Monitoring
To start / stop the operation
of devices by group
1.
On Screen 1 Monitoring, select a zone
from the button 1 .
Start or stop the operation of air conditioners
by group.
The example on the left shows the
screen for starting / stopping the
operation of Group Name : 1F North
registered for Zone Name : Canteen.
2.
Select a zone that includes the group of
which the operation is to be started or
stopped 2 .
3.
4.
Select a group to be started or stopped
as in 3 and press the [Start] button 4
or [Stop] button 5 .
Starting / Stopping Operation by the Group
Screen 2 Monitoring (Group)
1
2
3
4
5
Zone Name
Canteen
[Procedure]
Air conditioner
group to be
started or
stopped
1F North
1F West
1F South
1F East
2F North
2F West
2F South
2F East
3F North
Select a group from the button 1 .
Screen 2 Monitoring (Group) appears.

17
Collective Zone
Zone Name
Screen 1 Monitoring
To start / stop the operation
of devices by group
1.
On Screen 1 Monitoring, select a zone
from the button 1 .
2.
Starting / Stopping Operation by the Zone
1
3
4
2
Select the zone of which the operation is
to be started / stopped as shown in 2 .
3.
Press the [Start] button 3 or [Stop]
button 4 .
Start or stop by zone the operation of groups
of air conditioners set in zones.
The example on the left shows a screen for
starting or stopping the operation of air
conditioners in the canteen.
[Procedure]
Office
Canteen
Meeting
1F
2F
3F
Air conditioner
group to be
started or
stopped

18
Screen 1 Monitoring
1.
On Screen 1 Monitoring, select a zone
or a group from the button 1 .
Switch the operation mode of the air
conditioner.
On the Monitoring screen, operation is
allowed with either Icon or List as the display
type.
The operation mode can be switched by
zone or by group.
Selecting a zone and switching the operation
mode switches the mode of
all air conditioners in the zone.
Selecting a group and switching the
operation mode switches the mode of air
conditioners in the group selected.
Ex.: For the following zone setting, the
operation modes available are Fan,
Cool, Heat and Auto.
If Cool/Heat option is not available for
any air conditioner in the zone, Fan and
Set Point are the available operation
modes.
2.
Select with 2 a zone or a group of
which the operation mode is to be
switched.
3.
Press the [Set] button 3 .
Screen 2 Operation appears.
4.
Select the operation mode to be set
from the pull down menu 4 .
5.
Switching the Operation Mode
Screen 2 Operation
3
2
5
1
4
To cancel the setting, press the
Cancel button.
On the menu, operation modes
available for air conditioners in the
zone are displayed if the switching
is to be made by zone. See the
example below.
Press the [OK] button 5 .
Zone name Group name Operation modes available
Canteen 1F North
1F West
[Procedure]
“Cool” “Heat”
“Auto” “Air”
“Cool” “Air”
