Daikin BRC1E72 User manual

English
Français
Español
On/Off
Mode
Fan
Speed
Cancel
Menu
OK
MODEL BRC1E72
WIRED REMOTE
CONTROLLER
OPERATION MANUAL
Thank you for purchasing the wired remote controller.●
This manual describes safety consideration which should be observed●
during the use of the product.
Read this manual carefully and be sure you understand the
information provided before attempting to use the product.
Keep this manual where it is readily accessible after reading it through.
If another user operates the product in the future, be sure to hand over
this manual to the new user.
Proper Use for Effective Energy Savings
00_CV_3P243520-3E.indd 100_CV_3P243520-3E.indd 1 9/12/2012 9:49:14 AM9/12/2012 9:49:14 AM

Nous vous remercions pour votre achat de la télécommande câblée.●
Ce manuel décrit les précautions de sécurité à respecter lors de●
l’utilisation du produit.
Lisez soigneusement ce manuel et veillez à bien comprendre
les renseignements fournis avant d’utiliser le produit.
Gardez ce manuel dans un endroit facile à accéder après l’avoir lu
complètement.
Si un autre utilisateur doit faire fonctionner le produit par la suite, veillez à
remettre ce manuel au nouvel utilisateur.
Utilisation Correcte pour des Économies d’Énergie Efficaces
Gracias por su compra del control remoto alámbrico.●
Este manual describe las consideraciones de seguridad que deben ser●
observadas durante el uso del producto.
Lea cuidadosamente este manual y asegúrese de
comprender la información provista antes de intentar usar el
producto.
Guarde este manual en un lugar fácilmente accesible después de leerlo
completamente.
Si otro usuario opera el producto en el futuro, asegúrese de entregar
este manual al nuevo usuario.
Uso apropiado para ahorro de energía efectivo
00_CV_3P243520-3E.indd 200_CV_3P243520-3E.indd 2 9/12/2012 9:49:15 AM9/12/2012 9:49:15 AM

English 1
Notices
Safety Considerations Items to be Strictly Observed ...... 2
Button Locations and Descriptions ........................... 4
Basic Operation Cool/Heat/Auto/Fan Operation ..............................
10
Dry Mode ............................................................... 12
Setback .................................................................. 14
Ventilation Mode .................................................... 15
Setting the Cool / Heat Changeover Master........... 16
Key Lock ............................................................... 18
Quick Reference Main Menu Items ...................................................
20
Menu Options Moving Within the Main Menu Screen ...................
22
Airflow Direction ..................................................... 23
Ventilation .............................................................. 26
Schedule ................................................................ 28
Off Timer ................................................................ 33
Maintenance Information ....................................... 35
Configuration .......................................................... 36
Current Settings ..................................................... 39
Clock & Calendar ................................................... 39
Daylight Saving Time ............................................. 42
Language ............................................................... 45
Maintenance Reset Filter Indicator ..............................................
45
Maintaining the Unit and LCD Display ................... 46
Reference Information Error Code Display .................................................
47
After-sale Service ................................................... 48
Contents
01_EN_3P243520-3E.indd 101_EN_3P243520-3E.indd 1 9/11/2012 4:12:34 PM9/11/2012 4:12:34 PM

2 English
Safety Considerations
Read these SAFETY CONSIDERATIONS carefully before operating the remote controller.
Train the customer to operate and maintain the remote controller.
Inform customers that they should store this Operations Manual with the Installation Manual for
future reference.
Meanings of WARNING and CAUTION Symbols:
WARNING Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
It may also be used to alert against unsafe practices.
NOTE Indicates situations that may result in equipment or property-damage
accidents only.
The following pictograms are used in this manual.●
Never do. Always follow the instructions given.
Keep water and moisture away. Keep wet hands away.
WARNING
Do not modify or repair the remote controller.●
Consult your Daikin dealer for any modification or for repairs.
Do not relocate or reinstall the remote controller by yourself.●
Improper installation may result in electric shocks or fire.
Consult your Daikin dealer to relocate or for any reinstallation.
Do not use flammable materials (e.g., hairspray or insecticide) near the●
remote controller.
Do not clean the product with organic solvents such as paint thinner.
The use of organic solvents may cause cracking, damaging the product, causing electric
shocks, or fire.
Consult the dealer if the remote controller was submerged under water●
due to a natural disaster, such as a flood or hurricane.
Do not operate the remote controller at this time or a malfunction, electric
shock, or fire can occur.
01_EN_3P243520-3E.indd 201_EN_3P243520-3E.indd 2 9/11/2012 4:12:35 PM9/11/2012 4:12:35 PM

English 3
―― Items to be Strictly Observed――
CAUTION
Do not allow children to play with the remote controller to avoid causing●
damage to the product.
Never disassemble the remote controller.●
Touching the interior parts may result in electric shocks or fire.
Consult your Daikin dealer for internal inspections and adjustments.
Do not touch the remote controller buttons with wet fingers.●
Touching the buttons with wet fingers can cause an electric shock.
Do not wash the remote controller.●
Doing so may cause electric leakage and result in electric shocks or fire.
Never let the remote controller to get wet.●
Water can cause damage to the remote controller, and may cause an electric shock or
fire.
NOTE
Never press the button of the remote controller with a hard, pointed●
object.
The remote controller may be damaged.
Never pull or twist the electric wire of the remote controller.●
It may cause the unit to malfunction.
Do not wipe the remote controller with benzine, thinner, chemical●
dustcloth, etc.
The remote controller may get discolored or the coating peeled off. If it is heavily dirty,
soak a cloth in water-diluted neutral detergent, squeeze it well and wipe the remote
controller clean. And wipe it with another dry cloth.
01_EN_3P243520-3E.indd 301_EN_3P243520-3E.indd 3 9/11/2012 4:12:35 PM9/11/2012 4:12:35 PM

4 English
On/Off
Mode
Fan
Speed
Cancel
Menu
OK
Button Locations and Descriptions
Functions other than basic operation items (i.e., On/Off, Operation
Mode, Fan Speed, and Setpoint) are set from the menu screen.
NOTE
Do not install the remote controller in places exposed to direct sunlight, the LCD●
will be damaged.
Do not pull or twist the remote controller cord, the remote controller may be●
damaged.
Do not use objects with sharp ends to press the buttons on the remote controller●
damage may result.
2. Fan speed control
button
3. Menu/OK button
8. On/Off button
10. Cancel button
9. Operation lamp
11. LCD (with backlight)
4. Up button
5. Down button
6. Right button
7. Left button
1. Operation mode
selector button
01_EN_3P243520-3E.indd 401_EN_3P243520-3E.indd 4 9/11/2012 4:12:36 PM9/11/2012 4:12:36 PM

English 5
Operation mode selector button1.
Press this button to select the operation●
mode of your preference. (See page 10.)
Available modes vary with the indoor unit*
model.
Fan speed control button2.
Press this button to select the fan speed of●
your preference. (See page 11.)
Available fan speeds vary with the indoor*
unit model.
Menu/OK button3.
Used to indicate the main menu.●
(See page 20 for the menu items.)
Used to enter the selected item.●
Up button4.
Used to raise the setpoint.●
The item above the current selection will be●
highlighted.
(The highlighted items will be scrolled
continuously when the button is
continuously pressed.)
Used to change the selected item.●
Down button5.
Used to lower the setpoint.●
The item below the current selection will be●
highlighted.
(The highlighted items will be scrolled
continuously when the button is
continuously pressed.)
Used to change the selected item.●
Right button6.
Used to highlight the next items on the●
right-hand side.
Each screen is scrolled in the right-hand●
direction.
Left button7.
Used to highlight the next items on the●
left-hand side.
Each screen is scrolled in the left-hand●
direction.
On/Off button8.
Press this button and system will start.●
Press this button again to stop the system.●
Operation lamp (Green)9.
This lamp illuminates solid during normal●
operation.
This lamp blinks if a error occurs.●
Cancel button10.
Used to return to the previous screen.●
LCD (with backlight)11.
The backlight will be illuminated for●
approximately 30 seconds by pressing any
button.
If two remote controllers are used to control●
a single indoor unit, only the controller to
be accessed first will have backlight
functionality.
01_EN_3P243520-3E.indd 501_EN_3P243520-3E.indd 5 9/11/2012 4:12:37 PM9/11/2012 4:12:37 PM

6 English
Liquid Crystal Display
Three types of liquid crystal display (LCD) are available. The standard display is set by default. ●
Detailed and Simple displays can be selected in the main menu. ● (See page 37.)
The displayed contents of the screen vary with the operation mode of the indoor unit model. (The ●
following display will appear when the indoor unit is in Auto mode.)
Standard display
Set to
Cool
Heat
74F
70F
Auto
Cool
This function is not available
<Standard display example>
6.Ventilation
2.Fan Speed
1.Operation mode
11.Setback
7.( ) display
3.Setpoint display
4.
Stand by for Defrost/
Hot start
5.Message
10.Changeover controlled by
the master indoor unit
9.Under centralized
control 8.( ) display
AUTO
ERV AIR PURIFY
CENTRAL
CONTROL MASTER CONTROLLED
SETBACK
STANDBY
Detailed Display
The airflow direction, clock, and selectable item appear on the detailed 
display screen in addition to the items appearing on the standard display.
Cool
Heat74
F
70 F
Room
Fri
11:03A
Set to
74
F
Return Setting
Auto
Cool
14. Selectable Display
Item
12. Airflow Direction
(Displayed only when
the indoor unit is in
operation.)
13.Current Day/time
(12/24 hour time
display)
<Detailed display example 1>
AUTO
ERV AIR PURIFY
CENTRAL
CONTROL MASTER CONTROLLED
SETBACK
STANDBY
Return Setting
Auto
Cool
<Detailed display example 2>
No Airflow
Direction display
(with no airflow direction
settings)
No Fan speed display
(with no fan speed
control function)
No Selectable Display
Item display
(with no selectable
display item selected)
No Clock display
(when the clock has
not been set)
15. ( ) display
--
:
--
CENTRAL
CONTROL MASTER CONTROLLED
SETBACK
AUTO
ERV AIR PURIFY
STANDBY
Names and Functions
01_EN_3P243520-3E.indd 601_EN_3P243520-3E.indd 6 9/11/2012 4:12:37 PM9/11/2012 4:12:37 PM

English 7
Simple Display
70F74F 74F
Auto
Cool
Room
STANDBY
Set to
Heat Cool
SETBACK
<Simple display example>
2.Fan speed
3.Setpoint display
1.Operation mode 14.Selectable Display
item
11.Setback
4.
Stand by for Defrost/
Hot start
Common precautions for all display modes
Depending on the field settings, while the indoor unit is stopped, OFF may be displayed instead of●
the operation mode and/or the setpoint may not be displayed.
01_EN_3P243520-3E.indd 701_EN_3P243520-3E.indd 7 9/11/2012 4:12:38 PM9/11/2012 4:12:38 PM

8 English
Names and Functions
Operation mode1.
Used to display the current operation●
mode: Cool, Heat, Vent, Fan, Dry or Auto.
In Auto mode, the actual operation mode●
(Cool or Heat) will be also displayed.
Operation mode cannot be changed when●
OFF is displayed.
Operation mode can be changed after
starting operation.
Fan Speed2.
Used to display the fan speed that is set for●
the indoor unit.
The fan speed will not be displayed if the●
connected model does not have fan speed
control functionality.
Setpoint display3.
Used to display the setpoint for the indoor●
unit.
Use the Celsius/Fahrenheit item in the●
main menu to select the temperature unit
(Celsius or Fahrenheit).
Stand by for Defrost/Hot start4.
“
STANDBY
” (See page 12.)
If ventilation icon is displayed in this field:
Indicates that an energy recovery ventilator●
is connected.
For details, refer to the Operation Manual
of the ERV.
Message5.
The following messages may be
displayed.
“This function is not available”
Displayed for a few seconds when an●
Operation button is pressed and the indoor
unit does not provide the corresponding
function.
In a remote control group, the message will●
not appear if at least one of the indoor units
provides the corresponding function.
“Error: Push Menu button”
“Warning: Push Menu button”
Displayed if an error or warning is detected●
(see page 47).
“Time to clean filter”
“Time to clean element”
“Time to clean filter & element”
Displayed as a reminder when it is time to●
clean the filter or element (see page 45).
Ventilation6.
Displayed when a energy recovery●
ventilator is connected.
Ventilation Mode icon.“●AUTO
ERV
ERV BYPASS
”
These icons indicate the current ventilation
mode (ERV only) (AUTO, ERV, BYPASS).
Air Purify ICON “●AIR
PURIFY
”
This icon indicates that the air purifying unit
(option) in operation.
7. display (See page 18.)
Displayed when the key lock is set.●
8. display (See page 28.)
Displayed if the Schedule or Off timer is●
enabled.
Under Centralized control “9.
CENTRAL
CONTROL
”
Displayed if the system is under the●
management of a multi-zone controller
(option) and the operation of the system
through the remote controller is limited.
Changeover controlled by the10.
master indoor unit “
MASTER
CONTROLLED
”
(VRV only)
Displayed when another indoor unit on the●
system has the authority to change the
operation mode between cool and heat.
01_EN_3P243520-3E.indd 801_EN_3P243520-3E.indd 8 9/11/2012 4:12:38 PM9/11/2012 4:12:38 PM

English 9
Setback “11.
SETBACK
” (See page 14.)
The setback icon flashes when the unit is●
turned on under the setback control.
Airflow Direction “12. ”
Displayed when the airflow direction and●
swing are set (see page 23).
If the connected indoor unit model does not●
include oscillating louvers this item will not
be displayed.
Current Day/Time (12/24 hour13.
time display)
Displayed if the clock is set●(see page 39).
If the clock is not set, “ -- : -- ” will be●
displayed.
12 hour time format is displayed by default.●
Select 12/24 hour time display option in the●
main menu under “Clock & Calendar”.
Selectable Display Item14.
Displayed if the selectable display item is●
selected (see page 38).
Room temperature is selected by default.●
15. display
Displayed when the clock needs to be set.●
The schedule function will not work unless●
the clock is set.
01_EN_3P243520-3E.indd 901_EN_3P243520-3E.indd 9 9/11/2012 4:12:39 PM9/11/2012 4:12:39 PM

10 English
Basic Operation
Cool/Heat/Auto/Fan Operation (SkyAir and VRV)
Operation
1
2
●Display the main menu screen.
(See page 22.)
●Before setting the schedule , the
clock must be set.
●The date & time screen will appear.
●Set the current year, month, day, and
time. (See clock settings on page 39.)
●
If the clock has not been set, a screen
like the one on the left will appear.
Press buttons to select Yes and
press Menu/OK button.
●Press buttons to select
Schedule the main menu screen.
Press Menu/OK button to display
the timer screen.
Setting
Clock has not been set.
Would you like to set it now?
Schedule
Yes No
Setting
Date & Time
Year 2012
Month 1
Day 1
Sunday
12:00A
Operation screen
display
Describes screens that
will be displayed on the
remote controller in
operation.
Operation procedure
Explains the sequence of
operation for the remote controller.
Operate the buttons according to
the procedure.
Operation button
display
Displays the location of
buttons to be operated.
How to follow the operation manual
Setting
Main Menu
Airflow Direction
Ventilation
Schedule
Off Timer
Celsius / Fahrenheit
Maintenance Information
1/2
Preparation
For mechanical protection purposes, apply power to the outdoor units at least six hours●
before starting the operation of the system.
Operation
1 Cool
Return Setting
Set to
74F
Press the●Mode button several times
until the desired mode Cool, Heat, Fan,
or Auto mode is selected.
Unavailable operation modes are not displayed.*
Note
Before changing the mode, confirm that the display does not●
indicate master controlled status. Both heat and cool mode may
not be selected if the unit is master controlled. See page 16 if
MASTER CONTROLLED icon blinks.
01_EN_3P243520-3E.indd 1001_EN_3P243520-3E.indd 10 9/11/2012 4:12:39 PM9/11/2012 4:12:39 PM

English 11
2
On/Off
n
u
K
Press●On/Off button.
The Operation lamp (green) will
illuminate and the system will start
operating.
3 Cool
Return Setting
Set to
74F
The setpoint will increase by●
1°F (or 1°C) when button is pressed
and decrease by 1°F (or 1°C) when
button is pressed.
Setpoint is not available in fan or dry mode.*
4 Cool
Return Setting
Set to
74F
Low Medium
High
Auto
A
To change the fan speed, press the●Fan
speed control button and select the
desired fan speed from Low, Medium,
High, or Auto.
Depending on the type of indoor unit, the adjustment levels may*
be two levels of “Low” and “High” or three levels of “Low”,
“Medium”, and “High”.
The system may be in automatic fan speed control for equipment*
protection purposes.
The system may be in automatic fan speed control according to*
the room temperature. It is normal for the fan to intermittently stop
operating.
It is normal for a delay to occur when changing the fan speed.*
In auto mode setting, the fan speed setting is adjusted*
automatically according to setpoint and indoor temperature. In
Fan mode, the fan speed setting is always at High.
5 Adjust Airflow Direction from the main menu●
(see page 23).
If the connected indoor unit model does not include oscillating*
louvers this function will not be available.
01_EN_3P243520-3E.indd 1101_EN_3P243520-3E.indd 11 9/11/2012 4:12:40 PM9/11/2012 4:12:40 PM

12 English
Basic Operation
6
On/Off
n
u
K
When the●On/Off button is pressed
again, the system will stop operating
and the operation lamp will turn off.
When the system is stopped while in the heating*
mode, the fan will continue to operate for
approximately one minute to remove residual
heat from the indoor unit.
Note
To prevent water damage or system failure, do not immediately●
remove power from the indoor unit following system operation.
Wait at least five minutes for the condensate pump to finish
draining residual water from the unit.
Characteristics of Heat Mode
The system automatically controls the following operating modes to
prevent the reduction of heating capacity and space comfort.
Defrost operation The system will automatically go into defrost operation to prevent frost●
accumulation at the outdoor unit and loss of heating capacity.
The indoor unit fan will stop, and “●
STANDBY
” (Defrost/Hot start) will be
displayed on the remote controller.
The system will return to normal operation usually within six to eight●
minutes (but not more than 10 minutes).
Hot start When the system goes into heat mode, the indoor unit fan will stop in●
order to prevent a cold draft.
(In that case, “
STANDBY
” (Defrost/Hot start) will be displayed on the
remote controller.)
Dry Mode
Preparation
For equipment protection purposes, apply power to the outdoor units at least six hours before●
starting the operation of the system.
The dry mode may not be selected if the remote controller is master controlled and the●
system is not already in the cooling mode of operation. (see page 17 for details)
01_EN_3P243520-3E.indd 1201_EN_3P243520-3E.indd 12 9/11/2012 4:12:41 PM9/11/2012 4:12:41 PM

English 13
Operation
1 Dry
Return Setting
Press●Mode button several times until
the Dry mode is selected.
The dry mode may not be available depending on the type of*
indoor unit.
2
On/Off
n
u
K
Press●On/Off button.
The Operation lamp (green) will
illuminate and the system will start
operating.
In Dry mode, the system maintains automatic temperature and*
fan speed control. Therefore, temperature setpoint or fan speed
settings are not available while the indoor unit is in the Dry
mode.
3 Adjust Airflow Direction from the main menu●
(see page 23).
If the connected indoor unit model does not include oscillating*
louvers this function will not be available.
4
On/Off
n
u
K
When the●On/Off button is pressed
again, the system will stop operating
and the operation lamp will turn off.
Note
To prevent water damage or system failure, do not immediately●
remove power from the indoor unit following system operation.
Wait at least five minutes for the condensate pump to finish
draining residual water from the unit.
01_EN_3P243520-3E.indd 1301_EN_3P243520-3E.indd 13 9/11/2012 4:12:41 PM9/11/2012 4:12:41 PM

14 English
Basic Operation
Characteristic of Dry mode
The Dry mode dehumidifies the space at reduced cooling capacity to
prevent the room temperature from dropping to uncomfortable
levels.
Setback
The Setback feature will maintain the space temperature in a specific range during unoccupied
periods.
Note
This function will temporarily start an indoor unit that was previously turned off by the user or●
turned off from a schedule event / off timer.
This function must be enabled by the system installer.●
Operation
1 Cool
Return Setting
Setback
Cool
84F
Setback
Cool
84F
Cool
Return Setting
SETBACK
The setback icon flashes when the unit●
is turned on under the setback control.
01_EN_3P243520-3E.indd 1401_EN_3P243520-3E.indd 14 9/11/2012 4:12:42 PM9/11/2012 4:12:42 PM

English 15
Ventilation Mode When the Indoor Unit is Interlocked with Energy Recovery Ventilator
Preparation
For equipment protection purposes, apply power to the outdoor units at least six hours before●
starting the operation of the system.
Operation
1 Vent
Return Setting
AUTO
ERV
When operating the energy recovery●
ventilator (ERV) between seasons
without the air conditioner, set the
control to ventilation mode.
2 Changes to the ventilation mode are made from the●
main menu.
Ventilation Mode: Auto, ERV, and Bypass*
3 Changes to the ventilation rate are made from the●
main menu.
Ventilation Rate: Low or High*
4
On/Off
n
u
K
Press●On/Off button.
The Operation lamp (green) will
illuminate and the system will start
operating.
5
On/Off
n
u
K
When the●On/Off button is pressed
again, the system will stop operating
and the operation lamp will turn off.
01_EN_3P243520-3E.indd 1501_EN_3P243520-3E.indd 15 9/11/2012 4:12:43 PM9/11/2012 4:12:43 PM

16 English
Basic Operation
Setting the Cool / Heat Changeover Master
(VRV only)
Settin
g
Chan
g
es
See page 18 for an explanation of the cool/heat changeover master indoor unit.
1 Cool
Return Setting
Set to
74F
Cool
Return Setting
Set to
MASTER
CONTROLLED
74F
Press the●Mode button on the remote
controller of the changeover master
indoor unit for at least four seconds
while the backlight is illuminated.
The “ ●
MASTER
CONTROLLED
” icon on each remote controller for the
indoor units connected to the same outdoor unit or
Branch Selector unit will start flashing.
Vent mode setting changes are possible regardless of the cool/*
heat changeover master indoor unit.
If cool/heat mode is configured for control from the outdoor unit,*
all remote controllers serving the associated indoor units will
display its “
MASTER
CONTROLLED
” icon.
Set the cool/heat changeover master indoor unit as ●
outlined below.
The icon “ ” will flash on all remote controllers when the power is turned ON for the first time.
Selection Settin
g
s
MASTER
CONTROLLED
2 Cool
Return Setting
Set to
MASTER
CONTROLLED
74F
Cool
Return Setting
Set to
74F
Press the ● Mode button on the remote
controller of the indoor unit which is to
serve as the cool/heat changeover
master.
The remote controller for the changeover
master indoor unit is established and the
MASTER
CONTROLLED
icon is no longer displayed.
Other remote controllers in the system
(indoor units served by the same outdoor
unit or indoor units served by the same
branch selector unit) will now display the
MASTER
CONTROLLED
icon.
01_EN_3P243520-3E.indd 1601_EN_3P243520-3E.indd 16 9/11/2012 4:12:44 PM9/11/2012 4:12:44 PM

English 17
3 Cool
Return Setting
Set to
74F
Press the●Mode button on the remote
controller of the indoor unit designated
as the cool/heat changeover master (the
remote controller not displaying the
MASTER
CONTROLLED
icon) repeatedly until the desired
mode is selected. The display will
change to Fan, Dry, Auto, Cool, Heat
each time the button is pressed.
Simultaneously, the other indoor units on ●
the system will follow suit and change
modes to reflect the new mode selected
at the changeover master remote
controller.
Cool / Heat Mode Selection Availability
“Cool”, “Heat”, and “Auto” are all only available for selection on the cool/heat changeover master●
indoor unit. The following table indicates the available operating modes of the other indoor units
on the system based upon the selected mode of the master indoor unit.
When the master indoor
unit is set to
The other indoor units in the system can be set to
Cool Dry Heat Fan
Cool mode
Dry mode
Heat mode
Fan mode
Auto mode (Cooling operation)
Auto mode (Heating operation)
01_EN_3P243520-3E.indd 1701_EN_3P243520-3E.indd 17 9/11/2012 4:12:45 PM9/11/2012 4:12:45 PM

18 English
Basic Operation
Precautions for Selecting the Cool / Heat Changeover Master Indoor Unit
The cool/heat changeover master must be set for a single indoor unit in the following applications●
(2-Pipe Heat Pump System) (3-Pipe Heat Recovery System)
Indoor unit Indoor unit
A number of indoor units are
connected to a single outdoor unit.
Set any one of the indoor units as the
cool/heat changeover master.
A number of indoor units are connected
to a single Branch Selector unit.
Set any one of the indoor units as the
cool/heat changeover master.
Branch Selector unit:
The Branch Seletor unit is used for
cooling or heat mode selection.
Key Lock
Operation Confirm and cancel Key Lock settings in the basic display screen.
1 Cool
Return Setting
Set to
74F
Basic screen
Press the ● Menu/OK button for at least
four seconds while the backlight is
illuminated.
2 Cool
Return Setting
Set to
74F
“●” is displayed.
All buttons are disabled when the keys
are locked.
To cancel the key lock mode, continue●
pressing Menu/OK button for at least
four seconds while the backlight is
illuminated.
01_EN_3P243520-3E.indd 1801_EN_3P243520-3E.indd 18 9/11/2012 4:12:48 PM9/11/2012 4:12:48 PM
