Daintree GE Current WOS2-RM User manual

(WOS2-RM)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save these instructions for future use.
1Installation Process
Installation Guide
WOS2-RM |DT107
Risk of electrical shock. Disconnect power before servicing or
installing product.
Install in accordance with National Electric Code and local codes.
WARNING
Risk of injury. Wear safety glasses and gloves during installation and
servicing.
CAUTION
The Daintree Networked Recess Mounted Wireless Occupancy
Sensor (WOS2-RM) is a battery-powered occupancy sensor
using passive infrared (PIR) sensing technology detect movement.
Using open, standards based ZigBee wireless communications,
the WOS2-RM reports real-time occupancy events to the control
system for various functions such as turning on lights or keeping
them on when movement is detected, and turning off lights
when a space is left vacant. The sensor’s off-delay timer is user-
congurable from any location using the Daintree Controls
Software (DCS) web-based control application, eliminating
the need for on-site, manual sensor adjustment.
The WOS2-RM-S provides the standard coverage area, 500sf
with a 360 degree (lateral) coverage. The WOS2-RM-E provides
an extended coverage area of up to 1000sf.
• Keep the sensor lens clean. Avoid touching the sensor lens.
• After rst-time installation or reinstallation of a new
battery, allow up to three minutes for initialization.
• CAUTION: the WOS2-RM is not intended for air handling
applications.
1. Determine the mounting location for the sensor based
on the desired occupancy coverage. See Sensor Placement.
2. Remove the sensor from the recessed box by twisting it.
Locate the sensor’s IEEE address on the label inside the
box. Record the IEEE address in the sensor’s location on
the facility oor plan or relay schedule.
3. Cut a 4-inch diameter (100mm) hole in the ceiling for the
recessed box.
Daintree®Wireless Occupancy
Sensor, Recess Mount
Occupancy
Sensor
Lens
Network LED
(green)
Infrared Detection
& Test Mode LED
(red)
Utility
Button
Recessed Box

Installation GuideDaintree®Wireless Occupancy Sensor, Recess Mount (WOS2-RM)
2
2LED Operation
1Installation Process (continued)
4. Rotate the mounting feet in and insert the box into
the hole.
5. Tighten the Phillips head screws until the box is secure.
Note: Do not overtighten screws. Ceiling access is not
necessary for installation. Be sure the label is visible after
mounting the recessed box.
6. Install the batteries in the orientation (+ -) shown on the
bottom of the battery compartments.
7. Secure the sensor to the ceiling by twisting it onto the base.
8. After the batteries have been installed for at least
3 minutes, initiate the Installation Test Mode: Momentarily
press the Utility button. The green LED ashes once then
the red LED ashes each time the sensor detects motion.
(The test mode times out after 5 minutes).
A. Walk test the sensor. Walk outside the coverage
area and wait for the red LED to stop ashing.
Step inside the desired coverage area and observe
the red LED.
B. Repeat from various positions in the coverage area.
C. If necessary, adjust the sensor as described in
PIR Sensitivity Adjustment. Repeat the walk test.
D. If you do not observe the proper behavior,
see Troubleshooting.
9. Exit Installation Test Mode. Momentarily press the Utility
button again, or wait 5 minutes for the mode to time out.
10. Complete the installation by resetting the device: press and
hold the Utility button for 5 seconds. Release the button when
the Network LED begins to ash rapidly. The sensor attempts
to join a ZigBee network for up to 30 seconds.
See LED Operation and Joining the ZigBee Network.
Rapid ash (12 times
per second) for up to 30
seconds
Solid for 10 seconds
Flashes once
Flashes twice
On for 2 seconds every
30 seconds
Device is trying to join ZigBee
network. If it fails to join, it will
retry after 15 minutes.*
Device successfully joined a ZigBee
network.
Utility button was pressed to initiate
Installation Test Mode.
Utility button was pressed for
2 seconds and the device is currently
joined to a network.
The batteries are low; replace the
batteries. Will also generate low
battery warning within CSM.
Green LED:
Network Indicator
Description
While unit is in
Installation Test Mode,
Flashes
Off
The red LED ashes each time sensor
detects occupancy. Test mode times
out after 5 minutes.
Normal operation: either not
detecting occupancy, or detected
occupancy and in Off Delay. LED
turns on with initial occupancy.
Red LED: Installation
Test Mode, Motion
Description

Installation GuideDaintree®Wireless Occupancy Sensor, Recess Mount (WOS2-RM)
3
PIR Sensitivity Adjustments
4
Sensor Placement
Installation Height
Detection Angle
Detection Radius
10’ (3m) from oor
120°
up to 17’ (5.2m)
Coverage Pattern, WOS2-CM-E, Extended Coverage
The PIR sensor can only be installed indoors. It is extremely
important to select the appropriate installation location to
avoid false occupancy reporting while obtaining the best
sensitivity. A proper installation should meet the following
conditions:
• The PIR sensor is typically mounted 6.5’ to 10’ (2m to 3m)
from the oor. The height affects the coverage area.
• The PIR sensor must be 4’ to 6’ away from hot or cold sources
such as heat or air conditioner vents, refrigerators, stoves, etc.
The PIR sensor should not be installed in places with
strong airows.
• The PIR sensor must have clear line of sight to the coverage area.
It may not detect a human body if it is blocked by furniture,
xtures, large plants, glass, curtains, etc.
TA trimpot next to the battery compartment is used to
adjust the PIR motion sensor sensitivity.
Use caution when adjusting the trimpots.
• Do not use excess force, as this will damage the unit.
• Stop turning the trimpot when you feel resistance.
3
Minimum
(counter-
clockwise)
Clockwise to increase
sensitivity
Counter-Clockwise to
decrease sensitivity
Maximum
(clockwise)
Installation Height
Detection Angle
Detection Radius
10’ (3m) from oor
100°
up to 13’ (3.9m)
Coverage Pattern, WOS2-RM-S, Standard Coverage

Installation GuideDaintree®Wireless Occupancy Sensor, Recess Mount (WOS2-RM)
4
5
Joining the ZigBee Network
After successfully completing the Installation Test the
occupancy sensor is ready to communicate with the
Daintree Wireless Area Controller (WAC).
* A network join can be retriggered manually at any
time using one of the following methods:
• Reset to factory defaults: This causes the device to
leave any network to which it is currently joined.
Following the reset, the device attempts to join a
network. Press and hold the Utility button for
5 seconds. Release the button when the Network
LED begins to ash rapidly.
• Activate device: Press and hold the Utility button
for 2 seconds. If the device is already joined to a
network, the Network LED ashes twice. If the
device is not joined to a network, the Network
LED ashes rapidly and the device will attempt
to join a network.
For more information about conguring the lighting
control network, see the instructions and on-line help
provided with the Daintree Controls Software (DCS)
web application.
6
Troubleshooting
No LEDs turn on when I press the Utility button.
• Check battery installation.
•Make sure batteries are oriented (+ -) correctly.
The red Infrared Detection LED does not activate when walking
through the coverage area while in Installation Test mode.
• Make sure that the lens is not obstructed and there is no
debris on the lens.
• Check to see if the red LED turns on when you
wave your hand directly in front of the lens.
– If the red LED turns on, adjust the PIR Sensitivity trimpot
clockwise to increase sensitivity. Check for objects or barriers
obstructing the sensor’s view of the coverage area.
– If the red LED does not turn on, the Installation Test mode
may have timed out. Restart the Installation Test mode by
momentarily pressing the Utility button. The green LED turns
on, then the red LED ashes with each detection. Installation
Test mode times out in 5 minutes.
The red LED ashes when nobody is moving in the
coverage area.
•Adjust the PIR sensitivity trimpot counter-clockwise to
reduce sensitivity. Repeat the walk test.
• Check for sources of hot airow in the coverage area.
•Review the Placement guidelines and eliminate false
trigger sources.
If lights do not turn Off after the WOS2-CM has Joined the
ZigBee network:
• Check the “Off delay” for the zone in the Daintree
Controls Software.
• Check for other DCS scheduled events or manual overrides
that may be keeping the lights On.
4
Sensor Placement (continued)

These instructions do not purport to cover all details or variations in equipment nor to provide for every possible contingency to be met in connection with installation, operation
or maintenance. Should further information be desired or should particular problems arise which are not covered sufciently for the purchaser’s purposes, the matter should be
referred to GE Current, a Daintree company.
www.gecurrent.com
© 2021 Current Lighting Solutions, LLC. All rights reserved. GE and the GE monogram are trademarks of the
General Electric Company and are used under license. Information provided is subject to change without notice.
All values are design or typical values when measured under laboratory conditions.
DT107 (Rev. 03/29/2021
Installation GuideDaintree®Wireless Occupancy Sensor, Recess Mount (WOS2-RM)
Questions:
Web: products.gecurrent.com
Phone: [phone]
Power Supply (2) Lithium-thionyl chloride batteries
(Li-SOCl2) AA 3.6V (included)
Battery Life 5 years (normal operation)
Radio Properties 2.4 GHz, +7dBm transmit power
Sensor Coverage 360°, 500 sq. ft (WOS2-RM-S)
(maximum) 360°, 1000 sq. ft (WOS2-RM-E)
Off-Delay TImer 30 seconds (xed), additional delay
time congurable in CSM
Operating 14°F to +122°F (-10°C to 50°C)
Environment Indoor use only
Compliance FCC Part 15B, FCC ID: NRH-ZB-Z100B ICES/
NMB-003 Class B, IC: 8984A-Z100B
Mounting Recess ceiling mount (2 screws) Maximum
Ceiling Thickness: 1”
Dimensions Diameter x Depth: 4.6” x 2.6”
117mm x 67mm)
Weight (without battery): 2.85 oz. (81g)
Specications
CAUTION
RISK OF EXPOSURE IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSAL OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
WOS2-RM
8Industry Canada (IC) Warning Message
Product complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and radiates radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encourage to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and receiver;
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected;
• Consult the dealer or an experienced radio/TV technician
for help.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference;
2. This device must accept any interference received, including
interference that may cause undesired operation.
7FCC Warning Message
