Dake LAGUNA 14CX User manual

14CX METAL & WOOD VERTICAL BANDSAW
INSTRUCTIONAL MANUAL
WARNING! Read and understand all instructions and responsibilities before operating.
Failure to follow safety instructions and labels could result in serious injury.

14CX 2 REV#072023
Table of Contents
RETURN & WARRANTY POLICY .......................................................................................................3
SPECIFICATIONS................................................................................................................................5
SAFETY................................................................................................................................................6
UNPACKING ......................................................................................................................................10
MACHINE ASSEMBLY ......................................................................................................................11
Before First Time Start ....................................................................................................................12
Testing the Saw...............................................................................................................................13
Blade Installation .............................................................................................................................14
Tensioning the Blade.......................................................................................................................14
Blade Tracking / Top Idler Wheel Camber Adjustment....................................................................15
Blade Guide Adjustment..................................................................................................................15
FIRST TIME OPERATION..................................................................................................................15
First Run Checks:............................................................................................................................15
High to Low Setting & FPM setting:.................................................................................................16
Blade Speed Chart ..........................................................................................................................17
ADJUSTMENTS .................................................................................................................................17
Adjusting Fence for Drift..................................................................................................................17
Blade Guidepost Adjustment:..........................................................................................................17
Squaring Table to Blade..................................................................................................................18
Adjusting Table Tilt:.........................................................................................................................18
Fence Assembly Adjustment:..........................................................................................................18
OPTIONAL LIGHT KIT INSTALLATION............................................................................................19
BLADE SELECTION ..........................................................................................................................20
Tell-tale Metal Chips........................................................................................................................20
Material Hardness & Pitch...............................................................................................................20
Causes of Blade Breakage..............................................................................................................20
Causes of Blade Dulling ..................................................................................................................21
TROUBLESHOOTING .......................................................................................................................21
MAINTENANCE .................................................................................................................................23
Tire Maintenance.............................................................................................................................24
Replacing the Drive Belt..................................................................................................................25
Adjusting the Brake .........................................................................................................................25
WIRING DIAGRAMS: .........................................................................................................................26
PARTS LIST .......................................................................................................................................28
Upper Wheel Assembly:..................................................................................................................28
Lower Wheel & Motor Assembly: ....................................................................................................31
Table and Fence Assembly.............................................................................................................34
Upper & Lower Blade Guides Assembly..........................................................................................36
ORDERING INFORMATION ..............................................................................................................37

14CX 3 REV#072023
RETURN & WARRANTY POLICY
All requested warranty claims must be communicated to the distributor or representative
responsible for the sale.
New wood/metal working saws sold by Laguna Tools carry a one-year warranty that is effective from
purchase date. the date of shipping. Machines sold through dealers must be registered with Laguna
Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new
machines sold are free of manufacturers’ defective workmanship, parts, and materials.
We will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a
manufacturer’s defect. We require that the defective item/part be returned to Laguna Tools with the
complaint. The end-user must request an RMA (return material authorization) number from Customer
Service and include the (RMA) number with any and all returned parts/components requesting
warranty coverage.
In the event the item/part is determined to be damaged due to lack of maintenance, cleaning, and/or
misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related
shipping charges.
This limited warranty does not apply to natural disasters, acts of terrorism, normal wear and tear,
product failure due to lack of maintenance or cleaning, damage caused by accident, neglect, lack of
or inadequate dust collection, and/or misuse/abuse or damage caused where repair or alterations
have been made or attempted by others.
All items being returned to Laguna Tools must have a return merchandise authorization number
(RMA) issued by the Customer Service Department. Products must be returned within 30 days from
the delivery date. No merchandise shall be returned without an RMA number.
Any machines returned to Laguna Tools must be returned with packaging in the same manner in
which it was received. If a part or blade is being returned it must have adequate packaging to ensure
no damage is received during shipping.
Unapproved returns are subject to a 25% stocking fee plus round-trip shipping charges. Laguna
Tools, Inc. is not responsible for additional tools or modifications sold or performed (other than
from/by Laguna Tools, Inc.) on any Laguna Tools, Inc. woodworking machine. Warranty may be
voided upon the addition of such described tools and/or modifications, determined on a case-by-case
basis by Laguna Tools, Inc.
Normal user alignment, adjustment, tuning, and machine settings are not covered by this warranty. It
is the responsibility of the user to understand basic woodworking machinery settings and procedures
and to properly maintain the equipment in accordance with the standards provided by the

14CX 4 REV#072023
manufacturer. Parts, under warranty, are shipped at Laguna Tools, Inc.’s cost either by common
carrier, FEDEX ground service, or a similar method.
Technical support to install replacement parts is primarily provided by phone, fax, e-mail, or Laguna
Tools Customer Support Website. The labor required to install replacement parts is the responsibility
of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other
circumstances not in our control.
All claims for loss or damaged goods must be notified to Laguna Tools within twenty-four hours of
delivery. Please contact our Customer Service Department for more information. Only new machines
sold to the original owner are covered by this warranty. For warranty repair information, contact
respective company subsidiary the saw was purchased from. When a return merchandise
authorization number (RMA) is issued, the customer has 30 days to return the part; otherwise, that
number is canceled and the return will not be accepted. No merchandise shall be returned without an
RMA number.
IMPORTANT – PLEASE READ
Replacement parts/ accessories/ machines are sent free of charge providing the item being replaced
is RETURNED to Laguna Tools Inc., within 30 days. Please KEEP ALL the packaging materials to
repack the parts/accessories/machine being replaced. If the item is a small item a return label will be
enclosed in your package. DO NOT THROW THIS AWAY.
Please package the item and write both INSIDE and OUTSIDE of the box the RMA number which
was provided through an email and or verbally at the time of the request. In the event that the item
(machine) is not returned to Laguna Tools Inc., YOU WILL BE responsible for the cost of the item.
Your credit card will be charged and or your account will be billed. NO SERVICE will be given until
this balance is PAID or the item returned in good condition.

14CX 5 REV#072023
SPECIFICATIONS
14CX Bandsaw
Motor voltage/HP
166VDC / 1 3/4 HP
Supply Voltage
110V Single Phase
Throat
13 5/8"(346mm)
Table, cast iron
16" x 21 1/2" (406.4mm x 546mm)
Table tilt
- 7 degrees + 45 degrees
Miter slot
3/8" x 3/4" (9.525mm x 19.05mm)
Table height
38" (965mm)
Blade Speed Range High
160 – 4400 FT/MIN
Blade Speed Range Low
60 – 1600 FT/MIN
Fly wheel
Cast iron
Resaw capacity
13" (330.2mm)
Minimum blade length
114 3/4" (2,914mm)
Maximum blade length
116" (2,946mm)
Maximum blade width
3/4" (19mm)
Minimum blade width
1/8" (3mm)
Guides
Laguna ceramic
Height
70 1/2" (1,790mm)
Machine Dimensions (W x D)
Base Footprint
29-3/4" x 28" (755mm x 712mm)
22-11/16" x 17-9/16" (576mmx446mm)
Machine Dimensions with mobility kit (W x D)
Base Footprint with mobility kit
36 5/8" x 28" (930mm x 712mm)
33" x 20 1/2" (838mm x 521mm)
Weight, gross
286 lbs. (130 kg)
Weight, net
264 lbs. (120 kg)
Package size (W x D x H)
73 1/8" x 26 1/2" x 24 5/16"
(1857mm x 673mm x 618mm)
Mobility kit
Optional “MBA14/12 Wheel System”
Industrial work light
Optional
In the space provided, record the serial number and model number of the machine. This information
is only found on the black Dake tag. If contacting Dake this information must be provided to assist in
identifying the specific machine.

14CX 6 REV#072023
SAFETY
Failure to comply with all warnings could lead to serious injury or death.
Employer is responsible to perform a hazard/PPE assessment before work activity.
English
French
WARNING: For your own safety, read instruction manual
before operating bandsaw
1.
Wear eye protection.
2.
Do not remove jammed cut off pieces until blade has
stopped.
3.
Maintain proper adjustment of blade tension, blade
guides and thrust bearings.
4.
Adjust upper guide to just clear workpiece.
5.
Hold workpiece firmly against table.
6.
ALWAYS USE A PUSH STICK. Never allow your
hands/ fingers to come close to the bandsaw blade.
AVERTISSEMENT: Pour votre securite, lisez le manuel
d'instruction attentivement avant d'utiliser la scie a ruban.
1. Portez des lunettes de protection .
2. Ne tentez pas d'enlever une piece coincee avant
l'arret complet de la lame.
3. Assurez-vous que les guides et la tension sur la lame
soient toujours correctement ajustes.
4. Ajustez la hauteur du guide superieur de fa on a
passer juste au-dessus de la piece .
5. Tenez la piece fermement sur la table.
6. UTILISEZ TOUJOURS UN POUSSOIR - N'approchez
jamais vos doigts, ou vos main, de la lame .
Safety Rules
1.
KEEP GUARDS IN PLACE and in working order.
2.
REMOVE ADJUSTING KEYS AND WRENCHES. Form a
habit of checking to see that the keys and adjusting
wrenches are removed from tool before turning it on.
3.
KEEP WORK AREA CLEAN. Cluttered areas and
benches invite accidents.
4.
DON'T USE IN DANGEROUS ENVIRONM ENT. Do not use
power tools in damp or wet locations or expose them
to rain. Keep work area well lighted.
5.
KEEP CHILDREN AWAY. All visitors should be kept
safe distance from work area.
6.
MAKE WORKSHOP KID PROOF with padlocks,
master switches or by removing starter keys.
7.
DON'T FORCE TOOL. It will do the job better and
safer at the rate for which it was designed.
8.
USE RIGHT TOOL. Do not force tool or attachment
to do a job for which it was not designed.
9.
USE PROPER EXTENSION CORD. Make sure your
extension cord is in good condition. When using an
extension cord, be sure to use one heavy enough to
carry the current your product will draw. An
undersized cord will cause a drop in line voltage,
resulting in loss of power and overheating. Table A
shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use
the next heavier gage. The smaller the gage
number, the heavier the cord.
10.
WEAR PROPER APPAREL. Do not wear loose
clothing, gloves, neckties, rings, bracelets, or
other jewelry that may get caught in moving parts.
Nonslip footwear is recommended. Wear
protective hair covering to contain long hair.
11.
ALWAYS USE SAFETY GLASSES. Also use face or
dust mask if cutting operation is dusty. Everyday
eyeglasses only have impact-resistant lenses; they
are NOT safety glasses.
1. CONSERVEZ TOUSLES DISPOSITIFS DE PROTECTION EN
PLACE et en bon etat de fonct ionnement .
2.
ENLEVEZ LES CLES ET OUTILS. Prenez l'habitude de
verifier si les cles et autres outils ne sont pas trop
pres de la machine avant de la demarrer.
3.
CONSERVEZ LA SURFACE DE TRAVAIL PROPRE ET
LIBRE D'ENTRAVES. Les endroits encombres
augmentent le risque d'accident.
4.
NE PAS UTILISER DANS LES ENVIRONNEMENTS
DANGEREUX. N'utilisez pas d'outils electriques dans
les endroits humides, detrempes, ou sous la pluie.
Conservez l'espace de travail bien eclaire.
5.
TENEZ LES ENFANTS A L'ECART. Tousles visiteurs
doivent etre tenus a une distance securitaire de
l'aire de travail.
6.
RENDEZ L'ATELIER A L'EPREUVE DES ENFANTS avec des
verrous, des interrupteurs principaux ou en enlevant
les cles de demarrage sur les outils.
7.
NE FORCEZ PAS L'OUTIL. L'outil effectuera un
meilleur travail et de fa on securitaire s'il est utilise
au rythme pour lequel ii a ete con u.
8.
UTILISEZ L'OUTIL APPROPRIE. Ne forcez pas un
outil ou un accessoire pour effectuer un travail pour
lequel ii n'a pas ete con u.
9.
UTILISEZ UNE RALLONGE ELECTRIQUE
APPROPRIEE. Assurez-vous que votre rallonge
electrique est en bon etat et que le calibre du filage
soit adequat pour transporter le courant que la
machine a besoin. Une rallonge de trop faible calibre
induira une perte d'intensite du voltage, ce
qui
provoquera une surchauffe et une perte de puissance .
Le tableau A indique le bon calibre a
utiliser en
fonction de la longueur de la rallonge et de la
demande en intensite du moteur. En cas de doute,
utilisez la rallonge de calibre plus fort . Plus le
numero est petit , plus la rallonge est de fort calibre .
10.
PORTEZ DES VETEMENTS APPROPRIES. Ne portez pas
de vetements ampies, des gants, des colliers, des

14CX 7 REV#072023
12. SECURE WORK. Use clamps or a vise to hold
work when practical. It is safer than using your
hand, and it frees both hands to operate tool.
13.
DON'T OVERREAC H. always Keep proper
footing and balance.
14.
MAINTAIN TOOLS WITH CARE. Keep tools
sharp and clean for best and safest
performance. Follow instructions for lubricating
and changing accessories.
15.
DISCONNECT TOOLS before servicing, when
changing accessories such as blades, bits, and
cutters.
16.
REDUCE THE RISK OF UNINTENTIONAL
STARTING. Make sure switch is in off position
before plugging in.
17.
USE RECOMMENDED ACCESSORIES.
Consult the owner's manual for recommended
accessories. The use of improper accessories
may cause risk of injury to persons.
18.
NEVER STAND ON TOOL Serious injury could
occur if the tool is tipped or if the cutting tool is
unintentionally contacted.
19.
CHECK DAMAGED PARTS. Before further use
of the tool, a guard or other part that is
damaged should be carefully checked to
determine that it will operate properly and
perform its intended function - check for
alignment of moving parts, binding of moving
parts, breakage of parts, mounting and any
other conditions that may affect its operation. A
guard or other part that is damaged should be
properly repaired or replaced.
20.
DIRECTION OF FEED. Feed work into a blade
or cutter against the direction of rotation of the
blade or cutter only.
21.
NEVER LEAVE TOOL RUNNING
UNATTENDED TURN POWER OFF. Do not
leave tool until it comes to a complete stop.
bracelets, ou tout autre bijou ou accessoire qui pourrait
etre entra1ne par des pieces mobiles . Des souliers a
semelle antiderapante sont egalement recommandes .
Attachez les cheveux longs et portez un bonnet pour
contenir la chevelure trop abondante.
11.
PORTEZ DES LUNETTES DE PROTECTION. Portez
egalement un masque contre la poussiere si le
travail execute degage de la poussiere. Veuillez
prendre note que les lunettes de prescription
ordinaire ne resistent pas aux impacts et qu'elles ne
sont pas homologuees a titre de lunettes de securite.
12.
IMMOBILISEZ VOTRE TRAVAIL. Utilisez des serres ou
un etau pour immobiliser votre travail lorsque c'est
possible. C'est plus securitaire que d'utiliser votre
main, et <;:a permet de liberer vos deux mains pour
operer l'outil confortablement.
13.
NE VOUS ETIREZ PAS AU-DESSUS DE LA M ACHINE.
Demeurez solidement en equilibre sur vos pieds en tout
temps.
14.
ENTRETENEZ LES OUTILS AVEC SOIN. Gardez les outils
de coupe tranchants et propres pour en tirer les
meilleures performances. Suivez les instructions du
fabricant pour la lubrification et l'entretien des
accessoires .
15.
DEBRANCHEZ LES OUTILS avant d'en effectuer
l'entretien ou lors du changement d'accessoires
tels que lames ou couteaux.
16.
REDUISEZ LES RISQUES DE DEMARRAGE NON
INTENTIONNEL. Assurez-vous que l'interrupteur est en
position fermee avant le branchement d'un outil.
17.
UTILISEZ LES ACCESSOIRES RECOMMANDES.
Consultez le manuel d'instruction pour conna1tre les
accessoires recommandes. L'utilisation d'accessoires
inappropries pose des risques de blessures aux
utilisateurs .
18.
NE VOUS TENEZ JAMAIS DEBOUT SUR UNE
MACHINE. Des blessures graves pourraient
survenir si la machine bascule ou si les outils
coupants sont touches accidentellement .
19.
VERIFIEZ LES PIECES ENDOM M AGEES. Avant de
poursuivre !'utilisation d'un outil, tout dispositif de
protection ou toute piece endommagee devra etre
inspecte pour determiner si elle peut fonctionner
correctement et selon !'utilisation qui en est prevue
. Verifiez l'alignement des pieces mobiles a savoir
s'il ya blocage, un bris, ou toute autre condition qui
nuirait a son utilisation . Une piece ou un protecteur
endommage doit etre repare OU remplace.
20.
SENS D'ALIMENTATION. Alimentez la piece vers la
lame ou le couteau dans le sens contraire de sa
rotation seulement.
21.
NE LAISSEZ JAMAIS UN OUTIL FONCTIONNER DANS
SURVEILLANCE - ETEIGNEZ L'OUTIL. Ne laissez pas
l'outil sans surveillance jusqu'a ce qu'il s'arrete
completement .

14CX 8 REV#072023
GROUNDING INSTRUCTIONS
1. All grounded, cord-connected tools:
In the event of a malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This tool is equipped with an electric cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into a
matching outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
Do not modify the plug provided – if it will not fit the outlet, have the proper outlet installed by a
qualified electrician.
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
The conductor with insulation having an outer surface that is green with or without yellow stripes is
the equipment-grounding conductor. If repair or replacement of the electric cord or plug is
necessary, do not connect the equipment-grounding conductor to a live terminal.
Check with qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded.
Use only 3-wire extension cords that have 3-prong grounding plugs and 3 pole receptacles that
accept the tool's plug.
Repair or replace damaged or worn cord immediately.
2. Grounded, cord-connected tools intended for use on a supply circuit having a nominal rating less
than 150 volts:
This tool is intended for use on a circuit that has an outlet that looks like the one illustrated in
Sketch A in Fig. 1. The tool has a grounding plug that looks like the plug illustrated in Sketch A in
Fig. 1. A temporary adapter, which looks like the adapter illustrated in Sketch B and C, may be
used to connect this plug to a 2-pole receptacle as shown in Sketch B if a properly grounded
outlet is not available. The temporary adapter should be used only until a properly grounded outlet
can be installed by a qualified electrician. This adapter is not permitted in Canada. The green-
colored rigid ear, lug, and the like, extending from the adapter, must be connected to a permanent
ground such
as a properly grounded outlet box.
3. Grounded, cord-connected tools intended for use on a supply circuit having a nominal rating of
150–250 volts, inclusive:
This tool is intended for use on a circuit that has an outlet that looks like the one illustrated in
Sketch D. The tool has a grounding plug that looks like the plug illustrated in Sketch D on next
page. Make sure the tool is connected to an outlet having the same configuration as the plug. No
adapter is available or should be used with this tool. If the tool must be reconnected for use on a
different type of electric circuit, the reconnection should be made by qualified service personnel;
and after reconnection, the tool should comply with all local codes and ordinances.

14CX 9 REV#072023
Table A
Ampere Rating
Volts
Total length of cord in feet
120
25
50
100
150
240
50
100
200
300
More Than
Not More Than
Minimum gage for cord
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Recommended
LOCKING OUT BANDSAW
It is strongly recommended that the bandsaw is never unattended and unlocked.
To lock the machine; fabricate a cover (not supplied) to cover the control panel. Below are two concepts for
locking the panel. The cover can be made from wood or plastic.
Push down the emergency stop. Lock the cover together by attaching padlocks (not included) on the two
handles of the control panel. To safeguard your machine from unauthorized operation and accidental starting
by young children, the use of padlocks is strongly recommended

14CX 10 REV#072023
UNPACKING
Before unpacking your machine ensure that there is no visible damage to the packaging. All damages
must be noted on delivery documents signed by user and driver. Must report damages within 24
hours of delivery.
Unpacking requires; tin snips, knife, and wrench.
Note: The machine is heavy, and if you have any doubt about the described procedure, seek
professional assistance. Do not attempt any procedure that you feel is unsafe or that you do not have
the physical capability of achieving.
Using the tin snips, cut the banding that is securing the machine to the pallet (if fitted).
WARNING: EXTREME CAUTION MUST BE USED BECAUSE THE BANDING WILL SPRING
AND COULD CAUSE INJURY.
Your bandsaw will be shipped in custom packaging consisting of a heavy-duty cardboard box
and Styrofoam internal packaging.
1. Open the cardboard box, remove the loose parts, and top Styrofoam.
2. Lift the bandsaw out of the packaging. You will need two or more people, as the bandsaw is
heavy.
3. Lift the bottom Styrofoam out and remove the parts that are packaged under the bandsaw
and packaging.
Parts Included:
Fence Guide Bar
Fence Parts

14CX 11 REV#072023
MACHINE ASSEMBLY
For instructional video follow link: https://www.youtube.com/watch?v=6zrMJ1aCrgI
Or scan the QR code!
1. After making sure there is no damage to the outside of the packaging, proceed to open packaging
and inspect internal contents for damage.
2. Remove all components from box, starting with this manual. Box contents include: user manual,
fence, fence knuckle, hardware, cast iron table and the main saw assembly. NOTE: lift assist with
cast iron table = 50lbs.
3. Remove packaging from main saw assembly, make sure to get all of the loose Styrofoam.
4. In the hardware kit locate rubber feet along with hardware (shown above). Install with hex T-bar.
NOTE: Optional mobility kit available: “MBA14/12 Wheel System”.
Follow link for installation video:
https://www.youtube.com/watch?v=ldImqjeTBgw&ab_channel=LagunaTools
a. Support the bandsaw on wooden blocks.
b. Fit the swivel assembly to the back of the bandsaw with the provided bolts.
c. Fit the front wheels to the front of the bandsaw with the bolts provided and remove the two
rubber feet that are close to the front wheels.
5. Carefully stand the saw upright on a flat, level surface.
6. Unwrap the bottom side of the table (ungreased side) and inspect the 2 bolts on the underside of
the table, make sure they can pivot freely in their slots.
7. With assistance lift and flip over the table so that these 2 bolts line up with the 2 holes on the table
mount.
8. Check to make sure the bolts are all the way through before releasing table top. In the hardware
kit locate 2 washers and 2 adjusting handles. Add the washer followed by the adjusting handle.
Tighten on adjusting handle by pushing the button and turning the hub that extends out when
button is pushed. After tightened let go of button and use handle to lock in table tilt.

14CX 12 REV#072023
NOTE: The table has a reference stop bolt that is used to quickly align the table after tilting. The stop
bolt hits the tilt-blanking disc when it is positioned over the table tilt hole. When the tilt blanking disc
is moved away from the hole, it allows the tilt stop bolt to pass through the table tilt hole, and the
table can be moved to the maximum amount of tilt (-7 degrees).
9. Locate black plastic handle in hardware bag and use 14mm wrench to attach this
handle to the handwheel on the top right of the machine.
10.Remove plastic from table & remove protective oil on table top. Recommended:
WD-40.
11.Install the front fence scale, using 2 Hex Cap Screw (M5x0.8x10) to the upper
holes on the front of the table. Later when blade is installed adjust scale so 0 is equal to the
blades path.
12.From your hardware package, using x2 Socket Head Cap Screw
(5/16"-18x2") and x2 spacers. Attach fence rail to table using the
cap screw and stand-off bolts.
NOTE: Hole 5-1/2” from end should be on the left side.
13.Take fence knuckle and back-off the lock knob enough to fit it onto
the fence rail.
14.Aluminum fence may now be added to the fence knuckle. Fence can be
mounted high or low. To mount, loosen the smaller lock knobs on side of
fence knuckle and slide T-slot over the bracket on the fence knuckle. Lock
knobs when in place. Make sure fence is square
NOTE: If fence needs to be adjusted, nylon slider nut on the inside
of the casting to adjust fence up or down. There are also 2 set
screws on the side of the casting that adjust the angle of the fence.
Before First Time Start
1. If you are still not thoroughly familiar with the operation of the bandsaw, get advice from a
qualified person.
2. Make sure the machine is properly grounded and that the wiring codes are followed.
3. Do not operate the bandsaw while under the influence of drugs, alcohol, or medicine or if tired.
4. Always wear eye protection, safety glasses or a safety shield, and hearing protection.
5. Wear a dust mask; long-term exposure to the fine dust created by the bandsaw is not healthy.
6. Remove your tie, rings, watch and all jewelry. Roll up your sleeves to prevent catching clothes
in the saw.
7. Make sure that the guards are in place and always use them. The guards protect you from
contacting the blade.

14CX 13 REV#072023
8. Make sure that the saw blade teeth point downward toward the table.
9. Adjust the upper blade guard so that it is just clearing the material being cut.
10.Make sure that the blade has been properly tensioned and tracked.
11.Stop the machine before removing the scrap piece from the table.
12.Always keep your hands and fingers away from the blade.
13.Make sure that you use the proper size and type of blade.
14.Hold the work piece firmly against the table. Do not attempt to saw stock that does not have a
flat surface facing down unless a suitable support is used.
15.Use a push stick at the end of a cut. This is the most dangerous time because the cut is
complete, and the blade is exposed. Push sticks are commercially available.
16.Hold the wood firmly and feed it into the blade at a moderate speed.
17.Turn off the machine if you must back the material out of an uncompleted or jammed cut.
Testing the Saw
1. Close the doors.
2. Check that the red Emergency Stop Button is in the fully out position.
3. Check that the machine is clear of all tools and other loose objects.
4. Check that all the adjusting and locking handles are tight.
5. Check that there is no blade installed; it is far safer to test the machine without a
blade fitted.
6. Connect the bandsaw to the electricity supply.
7. Start the bandsaw by pressing the “I” start button.
8. The lower flywheel is now turning.
9. Now is the time to check that the Stop Switch is functioning correctly.
10.With the machine running (no blade installed), operate the “O” Stop Switch by
pressing in, toward the machine. The motor should have the power turned off and
slowing down.
11.If the switches fail to operate correctly, do not use the machine until the fault has
been corrected.
12.With the motor running, press the red emergency stop button. The motor should
have the power turned off and slowing down.
13.With the motor running, press the foot brake pedal. The motor should have the power
disconnected and come to a stop.
Should the bandsaw fail the test, it must not be used until the fault has been corrected.

14CX 14 REV#072023
Blade Installation
Disconnect the machine from the power source before making any adjustments.
1. Open the top door to the machine. Located on the back side saw head locate tensioner lever.
2. Lower the tension lever handle down to the minimum position. This will allow the wheel to drop.
NOTE: (Sometimes, the upper wheel might stick in place over time after the tension handle is
compressed. Spray WD-40 or PB-Blaster where the tensioning slot is located occasionally to
prevent this from happening. If the wheel is still stuck, pull downward on the wheel to be
released).
3. Loosen the blade guides upper and lower blades guides.
4. On the top section door, open the red magnetic blade guard to expose
the blade cavity. Finally open the bottom cabinet door to expose the drive
pulley of the saw.
5. With the bottom door open, locate the plastic blade guide slider that slide
between the bandsaw blade and remove.
6. Remove the throating plate that is surrounding the blade on the
worktable.
7. Carefully unravel the blade and slide the blade into the slot leading to the
worktable throat plate area with the blade teeth facing you (teeth should
be pointing downward). Finally slide the blade into the left-hand side
grove located on the main frame of the bandsaw.
8. Work the blade around the upper and lower pulley wheels. Make sure the
blades are as evenly centered around the wheels as best as you can.
9. Raise the blade tensioner lever handle to the maximum position to tighten the blade.
Tensioning the Blade
Always use good judgement when tensioning a blade. The scale is only a guide to
get close to correct tension quickly.
1. The scale inside the top half door of the bandsaw is a good reference to use
determining what tensions are good based off the width of the blades for many
applications.
2. To make your final adjustments, the adjusting wheel that is facing upward above
the worktable adjusts your final blade tension. The wheel has a reverse thread, therefore turning
the wheel to the left will tighten the blade tension and turning the wheel to
the right will loosen the blade tension.
3. When proper tensioning is achieved, lock blade in place using lock knob
below the blade/wheel adjusting knob.
4. Looking at the top wheel, place your finger at the 9 o'clock position. Move
your finger down 6", and, using moderate pressure with your thumb,
press on the flat of the blade. You should get 3/16" to 1/4" of deflection.
5. Make sure blade is tracking correctly on wheels before operating the saw. Continue to next steps
to for properly blade tracking adjustments.

14CX 15 REV#072023
Blade Tracking / Top Idler Wheel Camber Adjustment
This adjustment aligns the tilt of the idler pulley with the drive pulley. If the wheel seems to be off
centered, making noise, follow these steps to properly align the blade.
1. With your hand, rotate the upper wheel while looking through the window at how the blade tracks.
Blade should track in the middle of wheels. If the blade is not in centered continue to next steps to
adjust.
2. On the back side of the bandsaw, loosen the locking nut located above the
tensioning lever.
3. If the adjusting screw-wheel is turned clockwise the blade will move further
back on the wheel, and turning the screw-wheel counter-clockwise moved
the blade towards the front of the wheel.
4. Make adjustments while you turn the upper wheel by hand, continue to adjust until proper blade
tracking is achieved. Lock blade down using the lower locking knob.
Blade Guide Adjustment
1. Loosen the guide assembly by turning the small knob.
2. With the blade guides loose pull both of them back to expose the rear thrust bearing.
3. Unlock the guide post lock handle and move guide assembly forward until back of blade is barely
touching the ceramic thrust bearing surface. Lock in place using the guide post locking handle.
4. Slide right and left blade guide forward until ceramic guides are about 1/8” from the gullets of the
blade. Lock in position using the small knob on the right.
5. Move right and left blade guide in so that both sides are barely touching the
blade. Lock into position using the 2 adjustment knobs in the front of the
guide assembly. NOTE: Do not deflect or pinch the blade!
6. Using your hand track the blade through the guides to make sure the blade
is not binding and that the weld can pass through the guides. Make sure to do at least 2 full
revolutions. NOTE: If the weld is binding between the guide adjust the guides wider by about the
width of a piece of paper. Re-test blade by hand to re-check.
7. Repeat steps for lower blade guide assembly. Lower guide is easier to access when table is
adjusted to 45°. Note: Rotate the back guide by approximately 15 degrees after every 8 hours of
use. This will extend the life of the back blade guide, as it will even out the wear.
FIRST TIME OPERATION
First Run Checks:
1. Make sure the blade is properly adjusted for tension and tracking. And make sure table is square
with blade.
2. Connect machine to power and make sure the toggle is switched on, on the converter at the
bottom rear of the machine.
3. On the control panel on the left of the machine make sure the E-stop is not depressed. Push the
on button to start the saw.
4. Adjust speed with speed adjustment knob.
5. Press the off button to stop blade movement. E-Stop and Foot brake with also stop blade
operation and cut power to the saw.

14CX 16 REV#072023
General Instructions:
1. Adjust blade guide assembly so that the blade guides are just above the workpiece (about 3/16”)
allowing minimum exposure to the blade.
2. If using the fence, move it into position and lock it to the guide rail. If you are using the miter
gauge for a crosscut, the fence should be moved safely out of the way.
3. Turn the machine on and wait a few seconds for the machine to fully get up to speed.
4. Place the straightest edge of the workpiece against the fence and push the workpiece slowly into
the blade. Do not force the workpiece into the blade. Let the blade do the work.
NOTE: (DO NOT over feed that bandsaw blade. This will reduce blade life and have a greater
chance of breaking the blade).
5. When cutting long stock, the operator should use roller stands, support tables, or an assistant to
help stabilize the workpiece.
6. When cutting at an angle with a tilted table, provide a guide against which the material being cut
can rest. Freehand cutting at an angle can result in injury, and maintaining an accurate cut is
difficult.
High to Low Setting & FPM setting:
First we’ll explain the procedure to change the 14CX from high gear to low gear or vice versa. The
same procedure applies both ways.
Disconnect the machine from the power source before making any adjustments.
1. Turn the machine off and unplug from the power source.
NOTE: (The motor MUST BE OFF before going to the next step)
2. Once the motor is completely off, open the bottom door. In the back of the machine use the
adjusting handle to unlock motor position. Push the motor adjustment lever down to lift the motor
and give the belt slack.
3. The belt can now be moved on the lower and upper pulleys. Belt on back pulleys for high speed
and front pulleys for low speed.
4. Make sure belt is fully on the pulley before loosening the adjustment handle and lowering the
motor back down by lifting the motor adjustment lever.
Blade Speed Ranges (FPM)
Rear Pulleys
High Gear Range
160 – 4400 FPM
Front Pulleys
Low Gear Range
60 – 1600 FPM
Below is the procedure to change the speed (FPM) of the bandsaw (SAW ON, AND RUNNING).
1. To change to the desired speed on the bandsaw, the bandsaw MUST be on and the blade
rotating.
2. The speed adjuster knob is located on the control panel on the left-hand side of saw. Above this
knob displays current blade speed.
3. Slowly rotate the handwheel CW to increase the blade speed, or CCW to decrease the blade
speed. USE CAUTION: Never start the 14CX bandsaw with any slack in the drive belt.
Doing so can cause machine damage as the belt is forced to pull through the slack.

14CX 17 REV#072023
Blade Speed Chart
Material
Speed Range
(FPM)
Material
Speed Range
(FPM)
Structural Steel Shapes
165
Bronze
90
Low Carbon Steel
160-165
Al-Bronze
40
Medium Carbon Steel
115
Monel
40-45
High Carbon Steel
90-100
Titanium Alloy
25-40
Cr-moly Steel
105-135
Aluminum (soft)
3000
Ni-Cr-moly Steel
90-115
Aluminum (T-6+)
3000
Chromium Steel
80-140
Carbon
3000
Cr-vanadium Steel
105-115
Slate
80-160
Tool Steel
40-80
PTFE Sheet, Rod, Rounds
3000
Stainless Steel
40-70
Hard Rubber
3000
Free Machining Steel
80-100
Plywood
3000
Cast Iron
55-90
Other Woods
3000
Copper Alloy (Cu-Zm)
55
ADJUSTMENTS
Adjusting Fence for Drift
1. Make a straight pencil line on the edge of a board.
2. Feed the wood into the blade cutting next to the pencil mark. If the blade is drifting, you will have
to compensate by angling the wood to keep the cut straight.
3. Stop the cut in the middle of the wood and mark (with pencil) the angle on the table. This is the
angle of drift, and you will have to set the fence to the pencil line.
4. To adjust the fence, loosen the clamp bolts that attach it to the cast bracket. Move the fence so
that it lines up with the pencil mark on the table and retighten the clamp screws.
Blade Guidepost Adjustment:
1. Locate the guidepost locking screw located on the rear top half go the bandsaw. To make any
adjustments, loosen the locking screw to allow the blade guidepost to freely move vertically.
2. The hand wheel located above the blade guidepost on the side of the machine adjusts the
vertical movement of the guidepost.
NOTE: (Maintain a clearance of 3/16 inch between the blade guidepost and the workpiece to
allow minimum exposed blade to prevent injury).
3. After correctly adjusting the height of the blade guidepost, ALWAYS tighten the guidepost screw
for the guide will stay in the desired position.

14CX 18 REV#072023
Squaring Table to Blade
1. Check that the stop bolt is in contact with the tilt-blanking disc.
2. Place a square on the tabletop and bring it up to the side of the blade.
3. Check if the blade is square to the table.
4. If adjustment is required loosen the lock nut on the tilt-stop bolt and adjust in the
required direction.
NOTE:Only adjust the tilt-stop bolt in small increments.
5. Tighten the lock nut and re-check the blade squareness to the table.
6. If additional adjustment is required repeat the above steps.
Adjusting Table Tilt:
1. Loosen lock nut and stop bolt until it does not contact the table underneath the
worktable.
2. On both side of the worktable, there are 2 locking levers. Loosen them both then the table is free
to move to the desired angle of cut.
3. Pivot the worktable referencing to the protractor angle to set the angle of cut.
4. Tighten the level handles, stop bolt, and locking nut to secure the wanted angle. CW is 45
degrees, CCW is 7 degrees degree of freedom.
Fence Assembly Adjustment:
This will change the accuracy length cut of the workpiece. Check the clearance between the table
and the fence. The fence should not rub against the table surface but be slightly above it. This gap
should be the same at the front of the table as it is at the rear.
1. Loosen the fence locking wheel located on the fence assembly.
2. The fence is now free to move vertically along the worktable.
3. Once in the desired spot, lock the fence in place by tightening the locking screw.

14CX 19 REV#072023
OPTIONAL LIGHT KIT INSTALLATION
Laguna Part No: ALEDMACH
Dake Part No: 303815
The light is attached to the top of the bandsaw as shown. The light is supplied with a three-pin plug to
suit either 110V or 220V depending on machine voltage. The cable must be held in position with the
clips provided and positioned so that the cable is safe and will not in any way come close to the blade
or cabinet door. Below is the suggested cable route. Use the sticky cable clamps to secure the cable
along the top of the bandsaw. Ensure that the cable is not over the vertical shaft hole, as it could be
damaged when the shaft exits the hole.

14CX 20 REV#072023
BLADE SELECTION
This section of the manual is meant to be a refence guide only. If you are
unsure which blade to use please contact your local blade supplier.
Tell-tale Metal Chips
Chips are the best indicator of correct feed force. Monitor chip
information and adjust feed accordingly.
Thin or powdered chips – increase feed rate or reduce blade speed.
Burned heavy chips – reduce feed rate and/or blade speed.
Curly silvery and warm chips – optimum feed rate and blade speed.
Material Hardness & Pitch
When choosing the blade with the proper pitch, one factor you should consider is the hardness of the
material that is being cut: the harder the material, the finer the pitch that is required.
Having a variety of tooth configurations in the same width will give you an acceptable choice for a
particular job. There are certain things that indicate if a blade has a proper pitch, too fine a pitch or
too coarse a pitch. Some are listed below:
Proper Pitch:
•Blades cut quickly.
•A minimum amount of heat is created when the blade cuts. Minimum feeding pressure is required.
•Minimum horsepower is required.
•The blade makes quality cuts for a prolonged period.
Pitch Is Too Fine:
•The blade cuts slowly.
•There is excessive heat, which causes premature breakage or rapid dulling.
•Unnecessarily high feeding pressure is required.
•Unnecessarily high horsepower is required. The blade wears excessively.
Pitch Is Too Coarse:
•The blade has a short cutting life.
•The teeth wear excessively.
•The bandsaw vibrates.
Causes of Blade Breakage
1. Excessive blade thickness in relation to the flywheel diameter.
2. Defective weld.
3. Incorrect tension, particularly if the blade is over tensioned; the tension spring no longer fulfills its
function.
4. After use it is recommended that you slacken the tension, especially overnight. (Be sure to place a
clearly visible note on the machine that you have done this).
5. Misalignment of the flywheels.
6. Irregularity of flywheel surface, for instance, an accumulation of chips while cutting.
You can correct these problems by readjusting the machine, changing the way you operate it or by
changing the blade. Try only one change at a time.
