Daktronics ST-2002 User manual

Models
ST-2002
ST-2003
ST-2004
ST-2005
Backlit & Non-Backlit
Scorer’s Tables
Display Manual
DD1709675 Rev 2 –1 April 2011
201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128
Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: [phone]
Web: www.daktronics.com Email: [email protected]m

DD1709675
P1313
Rev 2 –1 April 2011
DAKTRONICS, INC.
Copyright 2009-2011
All rights reserved. While every precaution has been taken in the preparation of this manual, the publisher
assumes no responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be
reproduced or copied in any form or by any means –graphic, electronic, or mechanical, including photocopying,
taping, or information storage and retrieval systems –without written permission of the publisher.
All trademarks used in this manual are the property of their respective owners.
Please fill in the information below to use for reference when calling Daktronics for assistance.
Display Serial No. _______________________________________________________
Display Model No._______________________________________________________
Date Installed___________________________________________________________

Table of Contents i
Table of Contents
1.1 Resources..................................................................................................................................1
1.2 Daktronics Nomenclature ......................................................................................................2
2.1 Specifications ...........................................................................................................................3
2.2 Setup .........................................................................................................................................3
3.1 Display Information................................................................................................................5
3.2 Display Access.........................................................................................................................5
3.3 Lamp Replacement .................................................................................................................5
3.4 Ballast Replacement................................................................................................................6
3.5 Troubleshooting ......................................................................................................................6
3.6 Replacement Parts...................................................................................................................6
3.7 Daktronics Exchange and Repair & Return Programs.......................................................7
Exchange Program...........................................................................................................7
Before Contacting Daktronics .................................................................................7
Repair & Return Program ...............................................................................................8
Shipping Address .....................................................................................................8
Daktronics Warranty and Limitation of Liability ........................................................8

Introduction 1
Section 1: Introduction
This manual explains the technology, operation, and maintenance of Daktronics backlit and non-
backlit scorer's tables. For additional information regarding safety, installation, operation, or service,
refer to the telephone numbers listed in Section 3.7. This manual is not specific to a particular
installation.
Important Safeguards:
Please read and understand all instructions before beginning the installation process.
Do not disassemble electronic controls of the display; failure to follow this safeguard will
make the warranty null and void.
Disconnect display power when not in use or when servicing.
Disconnect display power before servicing power supplies to avoid electrical shock. Power
supplies run on high voltage and may cause physical injury if touched while powered.
Do not modify the structure or attach any panels or coverings to the display without the
express written consent of Daktronics, Inc.
Project-specific information takes precedence over any other general information found in
this manual.
1.1 Resources
Figure 1 illustrates a Daktronics drawing
label. The drawing number is located in the
lower-right corner of a drawing. This
manual refers to drawings by listing the last
set of digits and the letter preceding them.
In the example, the drawing would be
referred to as Drawing C-325405.
Reference Drawing:
System Riser Diagram ...........................................................................Drawing C-325405
Daktronics identifies manuals by the DD or ED number located on the cover page of each
manual. For example, this manual would be referred to as DD1709675.
Figure 1: Daktronics Drawing Label

2 Introduction
1.2 Daktronics Nomenclature
Serial and model numbers can be found on the ID label on the display as shown in Figure 2.
Please list the model number, display serial number, and the date this display became
operational in the blanks provided on the second page of this manual. When calling
Daktronics customer service, please have this information available to ensure the request is
serviced as quickly as possible.
Most components within this display carry a white label that lists the part number of the unit.
If a component is not found in the Replacement Parts List in Section 3.6, use the label to order
a replacement. Figure 3 illustrates a typical label. The part number is in bold.
Main Component Labels
Part Type
Part Number
Individual circuit board
0P-XXXX-XXXX
Assembly; a collection of circuit boards
0A-XXXX-XXXX
Wire or cable
W-XXXX
Fuse
F-XXXX
Transformer
T-XXXX
Metal part
M-XXX
Fabricated metal assembly
0S-XXXXXX
Specially ordered part
PR-XXXXX-X
Accessory Labels
Component
Label
Termination block for power
or signal cable
TBXX
Grounding point
EXX
Power or signal jack
JXX
Power or signal plug for the
opposite jack
PXX
Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair &
Return Program. Refer to these instructions if replacing or repairing any display component.
Figure 2: Display ID Label
Figure 3: Typical Label

Display Specifications & Setup 3
Figure 4: Adjusting Latch Tension
Loosen Nut
Turn Hook
Section 2: Display Specifications & Setup
2.1 Specifications
The table below shows all of the mechanical specifications, circuit specifications, and
maximum power requirements for each model in this manual.
* These are non-backlit displays. Power requirements are for convenience outlets only.
Notes:
1. Power shown includes max load placed on table including convenience outlets. Refer
to Drawing A-210619 for details.
2. Table counter top capacity is rated at 150 lbs max.
2.2 Setup
To set up a scorer‟s table:
1. Move the scorer‟s table to the desired location.
If more than one scorer‟s table is to be used as part of a
single display face, line the tables up side by side and
use the three metal latches (one above the counter top,
one next to the rear castors, and one on the lower-front
of the frame) to link the tables together.
The tension of the latches used to connect multiple
scorer‟s tables is not set at the factory. When engaged,
the latches should create a snug fit. If there is a
noticeable gap between tables, or it is difficult to clasp
the latches shut, the tension can be adjusted as follows:
a. Use a 5/16" wrench to loosen the nut that is
holding the metal hook in place.
Model
Dimensions:
Height, Width
(including padding),
& Depth
Weight
Watts
Volts
Amps
ST-2002
H 3'0" x W 8'5" x D 3'4"
(914mm, 2565mm, 1016mm)
185 lb
(84 kg)
1440 W
120 V AC*
12 A
ST-2003
H 3'0" x W 8'5" x D 3'4"
(914mm, 2565mm, 1016mm)
235 lb
(107 kg)
1440 W
120 V AC
12 A
ST-2004
H 3'0" x W 4'5" x D 3'4"
(914mm, 1346mm, 1016mm)
90 lb
(41 kg)
1440 W
120 V AC*
12 A
ST-2005
H 3'0" x W 4'5" x D 3'4"
(914mm, 1346mm, 1016mm)
115 lb
(52 kg)
1440 W
120 V AC
12 A

4 Display Specifications & Setup
b. Turn the metal hook clockwise to give the latch a tighter fit, or turn the metal hook
counterclockwise to give the latch a looser fit.
c. Make sure the metal hook is pointing downward and then tighten the nut.
2. Lift the table surface approximately 90 degrees and swing the side legs out and into place
underneath. Use the locking slots to secure.
Note: It may be helpful to have two people perform this procedure: one to lift and hold
the table surface and another to position and lock the legs in place.
3. Press down on the leg stops to make sure the table is level on both sides. For further
stability, also lock the rear table wheels.
4. For backlit models (and non-backlit models using convenience outlets), connect the twist
lock power cord to the power-in plug in the lower-right corner of the scorer‟s table, and
then connect the three pin plug to a grounding-type power outlet.

Maintenance & Troubleshooting 5
Section 3: Maintenance & Troubleshooting
IMPORTANT NOTES:
1. Always disconnect power before doing any repair/maintenance work on the display.
2. Permit only qualified service personnel to access internal display electronics.
3. Disconnect power when not using the display.
3.1 Display Information
Daktronics backlit scorer‟s tables occasionally require replacement of failed lamps or ballasts.
Refer to Drawings B-381209 and B-381575 in Appendix A for detailed wiring schematics and
refer to Section 3.6 for replacement part numbers.
Do not use higher power lamps or damage to the circuit may result.
Obtain replacement lamps and ballasts from Daktronics or a local store.
3.2 Display Access
1. Lift an end pad off one side of
the scorer‟s table and set aside.
2. Carefully slide the face panel out
of the retainer frame to expose
the internal components.
Refer to Figure 5.
Note: When multiple tables are
linked together, the metal latches
must be disconnected and the tables
separated before the face panel can
be removed.
3.3 Lamp Replacement
Lamps are held by “tombstone “-style fluorescent lamp sockets on each end. One socket for
each lamp will be spring-loaded.
1. Access the display components as described in Section 3.2.
2. To replace a lamp, grasp and push the lamp towards the spring-loaded end of the lamp
holder, then pull it out.
3. Replace lamps per the replacement parts list (refer to Section 3.6). Lamp sizes are given
in inches, stamped on one end of the bulb. The size is indicated by the set of numbers
following the letter “F.”
4. Close the display and reconnect power.
Figure 5: Front Display Access

6 Maintenance & Troubleshooting
3.4 Ballast Replacement
1. Access the display as described in Section 3.2.
2. Remove every lamp from the display as described in Section 3.3 and carefully set aside.
3. Loosen the screw securing the 2nd access door from the left and lift it off the keyhole to
reveal the ballast.
4. Secure the wires on the ballast side of the wire-nut connections so the same color code
can be followed for the replacement ballast.
5. Remove the four (4) machine screw nuts securing the ballast to the display.
Note: The four screws holding the ballast are stud-mounted and will remain in place
after the ballast is removed.
6. Lift the ballast off the mounting screws and out of the display.
Note: Between each ballast and the display shell is an aluminum heat-sink bar. This bar
must be used with the replacement ballast.
7. Secure the replacement ballast and heat-sink bar to the inside of display using the four (4)
machine screw nuts previously removed.
8. Following the wire chart on the ballast, and using the color code of the existing wires
from the previous ballast (from Step 4), use the wire-nuts to connect the wires from the
lamps to the ballast wires. Call Daktronics customer service before continuing if there is
an inconsistency.
9. Slide the access door into place and reinstall the lamps.
10. Perform “Hy-Pot” and continuity tests to the display before activating power to ensure
all the wiring is correct and there are no shorts in the circuit.
3.5 Troubleshooting
This list does not include every possible problem, but does represent some of the more
common situations that may occur.
Symptom/Condition
Possible Cause
Display will not light
Poor connection
No power to the display
Circuit breaker tripped at service panel
Section of the display will not light
Lamp(s) burned out
Ballast burned out
Poor contact at main power connection
Circuit breaker tripped at service panel
3.6 Replacement Parts
Description
Daktronics Part Number
Scorer’s Table Model
Ballast; 120V, 2.8A
A-1370
ST-2005
Ballast; 120V, 5.3A
A-1371
ST-2003
Fluorescent Lamp , 48", 110W
DS-1026
ST-2005
Fluorescent Lamp , 96", 110W
DS-1048
ST-2003
Replacement Leg Stop Pad
HS-1763
All

Maintenance & Troubleshooting 7
3.7 Daktronics Exchange and Repair & Return Programs
Exchange Program
The Daktronics Exchange Program is a quick, economical service for replacing key
components in need of repair. If a component fails, Daktronics sends a replacement part to
the customer who, in turn, returns the failed component to Daktronics. This not only saves
money but also decreases equipment downtime. Customers who follow the program
guidelines explained below will receive this service.
Before Contacting Daktronics
Identify these important numbers:
Display Serial Number: _________________________________________________________
Display Model Number:_________________________________________________________
Contract Number: ______________________________________________________________
Date Installed: _________________________________________________________________
Daktronics Customer ID Number: ________________________________________________
To participate in the Exchange Program, follow these steps.
1. Call Daktronics Customer Service.
Schools (primary through community/junior colleges),
religious organizations, municipal clubs and community
centers
877-605-1115
Universities and professional sporting events, live events
for auditoriums and arenas
866-343-6018
2. When the new exchange part is received, mail the old part to Daktronics.
If the replacement part fixes the problem, send in the problem part being replaced.
a. Package the old part in the same shipping materials in which the replacement
part arrived.
b. Fill out and attach the enclosed UPS shipping document.
c. Ship the part to Daktronics.
3. A charge will be made for the replacement part immediately, unless a qualifying
service agreement is in place. In most circumstances, the replacement part will be
invoiced at the time it is shipped.
If the failed part or replacement part is not returned to Daktronics within 3 weeks of
the ship date, Daktronics will assume that the customer is purchasing the
replacement part and will send an invoice for the value of the new sale part. If the
part or parts are returned within 2 weeks of the second invoice date, Daktronics will
credit the customer for the second invoice.

8 Maintenance & Troubleshooting
If after 2 weeks Daktronics has still not received the parts back, the customer must
pay the second invoice and will not be credited for the return of the failed part.
Daktronics reserves the right to refuse parts that have been damaged due to acts of
nature or causes other than normal wear and tear.
Repair & Return Program
For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a
part for repair, follow these steps:
1. Call or fax Daktronics Customer Service:
Refer to the appropriate market number in the chart listed on the
previous page.
2. Receive a Return Materials Authorization (RMA) number before shipping.
This expedites repair of the part.
3. Package and pad the item carefully to prevent damage during shipment.
Electronic components, such as printed circuit boards, should be placed in an
antistatic bag before boxing. Daktronics does not recommend using packing „peanuts‟
when shipping.
4. Enclose:
name
address
phone number
the RMA number
a clear description of symptoms
Shipping Address
Daktronics Customer Service
RMA #
201 Daktronics Drive, Dock E
Brookings, SD 57006
Fax: [phone]
Daktronics Warranty and Limitation of Liability
The Daktronics Warranty and Limitation of Liability is located in Appendix B. The Warranty
is independent of Extended Service agreements and is the authority in matters of service,
repair, and display operation.

Reference Drawings 9
Appendix A: Reference Drawings
System Riser Diagram; Scores Table Setup............................................................................ A-210619
Schematic; ST-1002/1003/2002/2003...................................................................................... B-381209
Schematic; ST-1004/1005/2004/2005...................................................................................... B-381575
Shop DWG; 2000 Series Scorer’s Tables ................................................................................ B-845254

7+(&21&(376(;35(66('$1''(7$,/66+2:1217+,6
'5$:,1*$5(&21),'(17,$/$1'35235,(7$5<'2127
5(352'8&(%<$1<0($16:,7+2877+((;35(66
:5,77(1&216(172)'$.7521,&6,1&
&23<5,*+7'$.7521,&6,1&
'$.7521,&6,1&
%+
'5$:1 '$7(
6+((7 -2%125(9
08/7,237,216&25(67$%/(
6&+(0$7,&67
.%,(5%$ 0$5
3 5  %
.%,(5%$


'$7(5(9 %<
 2&7 (-6
$''('(;75$:,5(672-)25($6,(5
%$//$67&211(&7,213(5(&2
'$7(
5(9 %<
 129 .=%
509237,21/,*+7675,36(783:2'5,9(5
6((':*509237,21$//,*+7675,3
6(783:,7+'5,9(56((':*
'$7(
5(9 %<
 $35 1-0
3(5(&&+$1*('(72(

7+(&21&(376(;35(66('$1''(7$,/66+2:1217+,6
'5$:,1*$5(&21),'(17,$/$1'35235,(7$5<'2127
5(352'8&(%<$1<0($16:,7+2877+((;35(66
:5,77(1&216(172)'$.7521,&6,1&
&23<5,*+7'$.7521,&6,1&
'$.7521,&6,1&
%+
'5$:1 '$7(
6+((7 -2%125(9
08/7,23$7,216&25(67$%/(6
6&+(0$7,&67
.%,(5%$ 0$5
3 5  %
.%,(5%$


'$7(5(9 %<
 '(& 0:0
83'$7('':*725(029(237,21$//,*+7
675,3'(7$,/6$/62$''(':,5(83'$7(6
3(5(&2
'$7(
5(9 %<
 $35 1-0
3(5(&&+$1*('(72(

HOME PERIOD GUEST GUEST
PERIOD
HOME
POSS
%+
'$7(5(9 %<
 0$5 '52
5(029(')/$7%/$&.3$,17&2/25127(
5(029('676&25(567$%/(
'5$:1 '$7(
6+((7 -2%125(9
+($'6&25(567$%/(237,216
6+23':*6(5,(66&25(567$%/(6
-/8('(5 0$<
3 3  %



'$7(5(9 %<
 $8* %&'
),;('&23<$5($9,(:
'$7(5(9 %<
 0$5 .''
83'$7('6,1*/(%21863266,1',&$7256
