dallmeier WSD-2 HD Operating and maintenance instructions

Installation and Configuration
Rev. 1.0.0 / 090616
English
Decoder - Streamer
WSD-2 HD

WSD-2 HD
2Dallmeier electronic
Information about copyright, trademarks, design patents
© 2009 Dallmeier electronic
All rights reserved. This document may not be copied, photocopied, reproduced, translated,
transferred to an electronic medium or converted to a machine-readable form either whole or in
part without rst receiving written permission from Dallmeier electronic GmbH & Co.KG.
We reserve the right to make technical modications.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due
to minor defects of the product or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
D 93051 Regensburg, Germany
www.dallmeier.com
[e-mail]
All trademarks identied by ®are registered trademarks of Dallmeier electronic.
All trademarks identied by *) are trademarks or registered trademarks of the following owners:
AMD Athlon of Advanced Micro Devices headquartered in Sunnyvale, California, USA
Adobe and Flash of Adobe Systems Incorporated headquartered in San Jose, California, USA
IBM of International Business Machines Corporation headquartered in Armonk, New York, USA
Intel and Pentium of Intel Corporation headquartered in Santa Clara, California, USA
Microsoft, DirectX, Internet Explorer and Windows of Microsoft Corporation headquartered in Redmond, Washington, USA
Mozilla and Firefox of Mozilla Foundation headquartered in Mountain View, California, USA
Third-party trademarks are named for information purposes only.
Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identication of
third-party trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this
circumstance is no reason to assume that the respective trademark is unprotected.

WSD-2 HD
3Dallmeier electronic
Table of contents
1 This document ..............................................................................................5
1.1 Validity ............................................................................................................5
1.2 Documents......................................................................................................5
1.3 Conventions....................................................................................................5
2 Safety instructions .......................................................................................7
3 General notes................................................................................................9
3.1 Scope of delivery ............................................................................................9
3.2 Transportation and packaging ........................................................................9
3.3 Appropriate use ..............................................................................................9
3.4 Performance features .....................................................................................9
3.5 Warranty .......................................................................................................10
3.6 Certications .................................................................................................10
4 Connection assignment .............................................................................11
4.1 Front .............................................................................................................11
4.2 Back.............................................................................................................. 11
5 Installation and commissioning ................................................................12
5.1 Requirements at the installation side............................................................12
5.2 Stand-alone Installation ................................................................................12
5.2.1 Requirements ...............................................................................................12
5.2.2 Installation.....................................................................................................12
5.3 Rack mounting..............................................................................................13
5.3.1 Requirements ...............................................................................................13
5.3.2 Mounting .......................................................................................................14
5.4 Commissioning .............................................................................................15
6 Preparation..................................................................................................16
6.1 System requirements....................................................................................16
6.2 Establishing a connection .............................................................................16
7 Basic settings .............................................................................................18
7.1 Language......................................................................................................18
7.2 Text display ...................................................................................................18
7.3 System time ..................................................................................................19
7.3.1 Manual setting ..............................................................................................19
7.3.2 Timeserver ....................................................................................................20
7.4 Video standard..............................................................................................20
7.5 COM interface...............................................................................................20
7.6 Password ......................................................................................................21
7.7 Fieldcontact display ......................................................................................21
7.7.1 Fieldcontact display lters.............................................................................21
7.7.2 Fieldcontact display position.........................................................................22
7.8 HDMI interface..............................................................................................23

WSD-2 HD
4Dallmeier electronic
8 Network settings.........................................................................................24
8.1 General settings............................................................................................24
8.2 Alarm host.....................................................................................................24
8.2.1 Setting up......................................................................................................25
8.2.2 Editing and copying ......................................................................................30
9 Recording settings .....................................................................................31
9.1 Decoder ........................................................................................................31
9.2 Audio and video source ................................................................................31
9.3 Tracks ...........................................................................................................31
9.3.1 Creating tracks..............................................................................................32
9.3.2 Deleting a track.............................................................................................32
9.3.3 Deleting recordings.......................................................................................33
9.4 Recording .....................................................................................................33
10 Savingtheconguration............................................................................35
10.1 Saving the conguration le..........................................................................35
10.2 Sending the conguration le .......................................................................35
10.2.1 Individual module..........................................................................................36
10.2.2 Several modules ...........................................................................................36
11 Information and log ....................................................................................38
11.1 Information dialogue .....................................................................................38
11.2 MAC adress ..................................................................................................38
11.3 Event log.......................................................................................................39
12 Breaking the connection............................................................................40
13 Cleaning and service..................................................................................41
13.1 Cleaning........................................................................................................41
13.2 Service..........................................................................................................41
14 Technical data .............................................................................................42
15 Pin assignment interfaces .........................................................................43
16 Dimensions .................................................................................................44

WSD-2 HD
5Dallmeier electronic
1 This document
1.1 Validity
This document applies to the high-denition 2 channel audio and video decoder WSD-2
HD.
The descriptions in this document are based on the DCM-1 module software version
2.4.0.
1.2 Documents
Commissioning
The document entitled Commissioning contains the most important steps for the connection
and commissioning of the device.
InstallationandConguration(thisdocument)
The document entitled InstallationandConguration contains detailed descriptions of the
installation, connection, commissioning and conguration of the device. Safety instructions,
general notes and technical data are additionally provided.
The target audience is exclusively specially trained and authorized professionals (installers).
1.3 Conventions
This document contains warning words and symbols that indicate potential sources of danger.
Various symbols and formats are used to maintain the clarity of the document.
DANGER
The warning word DANGER denotes an immediate danger that
may cause death or serious injury if it is not averted.
WARNING
The warning word WARNING denotes a possible danger that
may cause death or serious injury if it is not averted.
CAUTION
The warning word CAUTION denotes a possible danger that
may cause minor injury if it is not averted.
IMPORTANT
The word IMPORTANT denotes information for preventing
damage, incorrect congurations or incorrect actions.
NOTE
A NOTE offers information on principles, special features and
efcient procedure as well as general recommendations.

WSD-2 HD
6Dallmeier electronic
Expression Expressions in bold and italics generally indicate a control ele-
ment on the device (switches or lables) or on its users interface
(buttons, menu, entries).

WSD-2 HD
7Dallmeier electronic
2 Safety instructions
Only use this unit if it is technically in proper working order, to the intended purpose and
while keeping safety and potential dangers in mind. Have malfunctions or damages elimi-
nated immediately!
Appoint a professional
Installation, mounting, connection, start-up and conguration of the unit may only be carried
out by trained and authorized professionals (installers).
Unless otherwise expressly specied, this also applies to the maintenance, testing and repair.
In doing so the regulations of the DIN VDE 0701 series of standards (repair, modication
and inspection of electrical appliances) must be followed in addition.
Read and pay attention to the documents
Carefully and completely read the documents included in delivery. Always pay attention to
the provided instructions, notes and warnings.
Regulations surveillance systems
The use of video and audio surveillance systems is strictly regulated in most countries.
Therefore, inform yourself on laws and regulations that govern individual applications be-
fore using the unit. Ensure compliance with these laws and regulations and also observe
regulations regarding data, working and environmental protection.
Donotmakemodications
Do not make any modications to the unit (neither to the software nor the hardware) without
consulting Dallmeier electronic. Improper modications can cause malfunctions or damages.
Dallmeier electronic accepts no liability for damages resulting from unauthorized or improper
modications to the unit.
Protection against condensation water
If the unit is brought from a cold to a warm environment, condensation water can form inside
the unit. Short-circuits may then lead to damage to the system. Wait up to 8 hours for the
unit to reach room temperature before starting it up.
Observe the rated voltage
The unit can be damaged or destroyed by the application of an incorrect voltage.
The mains voltage must always match the rated voltage of the unit. The rated voltage is
specied on the rating plate of the unit.
Observe ratings
Unsuitable ambient conditions and improper installation (mainly too high ambient tempera-
ture and insufcient ventilation) may reduce the unit’s life cycle. Ensure compliance with the
stated operating conditions (see technical data), requirements at the installation site and, if
applicable, maintenance regulations.
Expansion components/peripheral devices
Use only expansion components conforming with the technical data of the unit. Inappropriate
peripheral devices may result in the violation of local laws and regulations and damages to
the unit. In case of doubt, contact the sales partner responsible for your area.

WSD-2 HD
8Dallmeier electronic
Do not move while in operation
Strong vibrations can cause damage to the unit, in particular to the hard disk(s). Therefore,
do not bump the unit or move it in a jerky motion while in operation. Instruct the cleaning
personnel accordingly if necessary!
Do not open the unit
Do not open the housing of the unit. There are no components inside the unit that require
maintenance by the user. The inspection, maintenance and repair with an open housing
must only be carried out by trained and authorized professionals (installer).
Penetration of foreign bodies and liquids
No objects or liquids may be allowed to get into the device. In this case, immediately dis-
connect the unit from the power supply (pull out the power plug). Please contact the sales
partner responsible for your area.
Measures to be taken in the event of damage and burnt smell
If you notice burnt smell or formation of smoke from a unit, immediately disconnect it from
the power supply (pull out the power plug). Please contact the sales partner responsible
for your area.
Disposal
Disconnect the unit from the power supply. Remove all connected units and system com-
ponents. Return the unit to your respective sales partner.

WSD-2 HD
9Dallmeier electronic
3 General notes
3.1 Scope of delivery
Included in the standard scope of delivery is:
1x WSD-2 HD
1x Power supply unit
1x 19“ bracket
1x Documentation InstallationandConguration (CD)
The scope of delivery may differ depending on the ordered equipment or device variant.
The device’s range of functions depends on the ordered equipment or device variant and
may therefore not correspond with this document’s content. Certain functions and features
may require an activation that is subject to costs.
3.2 Transportation and packaging
Store the original packaging for transportation at a later date. Dallmeier electronic is not
responsible for damage resulting from unprofessional/improper transportation. The goods
should only be shipped in their original packaging.
If the original packaging is no longer available, ensure that the packaging used sufciently
protects the unit against damage, moisture, heat and cold.
3.3 Appropriate use
The WSD-2 HD is a high-denition 2 channel audio and video decoder with recording ca-
pability. It is able to receive audio and video streams via an Ethernet network (unicast or
multicast), decode them and output them via its HDMI interfaces (up to 1080p).
The WSD-2 HD is a stand-alone device in compact design (1HU). Additionally, it is designed
for the installation in a 19“ rack an operation in control and server room.
3.4 Performance features
The WSD-2 HD is especially characterised by the following functions and properties:
l2x IP based video decoder channel
lSimultaneous decoding, recording and live display/playback
l Supported video formats: MPEG-2/-4, MJPEG, H.264
l Supported audio formats: MPEG-1 Layer 2, G.722
l Bit rate (constant or dynamic) up to 16 Mbps
l HDMI ready with an output format up to 1080p
l Video outputs: 2x CVBS/BNC (only active at SD resolution)
l Fast display times, low delay (less than 100ms)
l Upscaling from SD to 720p, 1080i or 1080p
l Conguration with web browser via LAN
lEvaluation with SeMSy®or PView via Ethernet
l Linux operating system on Flash memory

WSD-2 HD
10Dallmeier electronic
l 2x HDDs for recording optionally available
l Compact design, 1HU
l Provided with power supply unit and 19“ bracket for installation into a 19“ rack
NOTE
For detailed information please see chapter Technical data.
3.5 Warranty
The terms and conditions valid at the signing of the contract shall apply.
3.6 Certications
The following certications were in effect at the time this document was produced:
l CE

WSD-2 HD
11Dallmeier electronic
4 Connection assignment
4.1 Front
Fig. 4-1
DCM-1
1 HDD plug-in module
2 Status LEDs (Power, Record, Alarm, Error)
3 Video OUT (CVBS)
4 Video OUT (HDMI)
5 Audio OUT (3.5 mm phone jack)
6 Serial interface (RS232/RS485 RJ12)
7 LAN interface (RJ45)
NOTE
The modules on the left and on the right are identically deve-
loped.
4.2 Back
8 Fan 1
9Fan 2
10 12V power in
DCM-1 Module
Fig. 4-2 1 2 3 4 5 6 7
8 9 10
Fig. 4-3
DCM-1 Module

WSD-2 HD
12Dallmeier electronic
5 Installation and commissioning
5.1 Requirements at the installation side
Unfavorable local conditions may shorten the life of the product or lead to malfunctions.
Do not operate the WSD-2 HD at places:
lwith large scale dust and dirt
lwith steam or oil vapors (e.g. kitchen)
lwith direct sunlight
lwith unsuitable ambient temperatures (see technical data)
lnear sources of strong radiation, i.e. X-rays, radio transmitters or magnetic elds
lwith corrosive surroundings (e.g. gases or salt water)
lwith insufcient ventilation (e. g. closed cabinet)
5.2 Stand-alone Installation
The WSD-2 HD may be freely positioned in a place respecting the requirements mentioned
above.
Attention should be paid to the fact that all connections are freely accessible.
5.2.1 Requirements
Computer room
This device is not for use in a computer room as dened in the “Standard for Protection of
Electronic Computer/Data Processing Equipment, ANSI/NFPA 75”.
Secured room
Manipulation and sabotage danger. A stand-alone installation should be made in secured
rooms with restricted access only.
Socket-outlet
The used socket-outlet has to be installed near the device. It has to be easily accessible.
5.2.2 Installation
ØDo not place the device upside down.
ØEnsure a stable and horizontal surface.
ØEnsure sufcient ventilation with 4 inch free space on the front and back side.

WSD-2 HD
13Dallmeier electronic
Fig. 5-1
ØEstablish the required connections as described in the following.
ØStart-up and login for conguration as described in the following.
5.3 Rack mounting
The WSD-2 HD can be installed in a 19“ standard rack using two 19’’ mountings (option).
5.3.1 Requirements
Elevated operating ambient
The operating ambient temperature in a multi-unit rack may be greater than the room ambient.
Ensure that the maximum ambient temperature in the rack complies with the requirements
specied in the technical data.
Reducedairow
The air ow in a (closed) rack may be reduced. Ensure that the amount of air ow required
for save operation is not compromised. Ensure sufcient ventilation with 4 inch free space
on the WSD-2 HD front and back side.
Mechanical loading
Mechanical loading may damage the device. Do not mount the WSD-2 HD upside down.
Ensure a stable and horizontal mounting.
Circuit overloading
The device can be damaged or destroyed by the application of an incorrect voltage. The
mains voltage must always match the rated voltage. The rated voltage is specied on the
nameplate.

WSD-2 HD
14Dallmeier electronic
Reliable earthing
Ensure a reliable earthing of the WSD-2 HD. Use power strips when other supply connec-
tions than direct connections to the branch circuit are being used.
5.3.2 Mounting
ØRemove the four housing screws.
Fid. 5-2
ØPlace the two 19“ mountings against the housing.
Fig. 5-3
ØSecure the 19“ mountings to the housing using the removed screws.
ØInstall the device in the 19“ rack.
IMPORTANT
Follow the instructions supplied by the rack manufacturer.
ØDo not mount the device upside down.
ØEnsure a stable and horizontal mounting.
ØEnsure sufcient ventilation with 4 inch free space on the fan sides.
ØEstablish the required connections as described in the following.
ØStart-up and login for conguration as described in the following.

WSD-2 HD
15Dallmeier electronic
5.4 Commissioning
WARNING
Danger of death from electric shock in the event of a lightning
strike!
Data transfer and video cables must not be connected or dis-
connected during a storm.
ØConnect both modules of the WSD-2 HD to the network.
ØConnect the WSD-2 HD to the power supply.
Both modules start at the same time.
They are ready for conguration via network after approx. 45 seconds.
ØMake the conguration as described in the following.

WSD-2 HD
16Dallmeier electronic
6 Preparation
Both modules will be congured via a PC with web browser in the LAN.
6.1 System requirements
Detail Requirements
Desktop PC (IBM*) compatible)
CPU Intel*) Pentium*) 1.3 GHz (or higher)
or
AMD*) Athlon*) (or equivalent) 1.3 GHz (or higher)
RAM Min.128 MB, recommended 256 MB
OS Microsoft*) Windows 2000 / XP
OS service packs Recommended, latest version
Graphics card VGA compatible, min. 64 MB,
DirectX*) capable
Monitor Resolution min. 1024 x 768, colors min. 16 Bit
Ethernet 100 Mbit/s
Browser Microsoft Internet Explorer*) 6.0 or higher
Mozilla Firefox*) 1.0.1 (Linux) or 1.0.6 (Windows)
Miscellaneous Adobe Flash Player*) 5 (Windows) or 7 (Linux)
6.2 Establishing a connection
Before you establish a connection, rst ensure that the conguration PC and the modules
of the WSD-2 HD are in the same LAN.
The WSD-2 HD and PC or laptop can also be connected direct using a cross cable.
ØFirst start the browser.
ØEnter the IP address of the module in the browser’s address line.
NOTE
If the DCM-1 has not yet been congured, use the default
address set at the factory (10.2.6.98).
ØConrm the input.
The connection to the respective module will be established.
First of all the login pages will be displayed.

WSD-2 HD
17Dallmeier electronic
Fig. 6-1: DCM-1 module login page
ØEnter the password.
ØConrm the password by clicking on OK.
NOTE
If the modules have not yet been congured, use the default
password set at the factory (3).
To protect the modules from unauthorized access, you must
change the default password.
After you have logged in successfully, the main or navigation pages will be displayed.
Fig. 6-2: DCM-1 navigation page
The single conguration dialogue can be selected and opened with the navigation bar
(left).

WSD-2 HD
18Dallmeier electronic
7 Basic settings
The basic conguration dialogues are centralised under Common settings:
Fig. 7-1
7.1 Language
ØOpen the User interface dialogue via Common settings > User interface ....
Fig. 7-2
ØSelect the Language tab.
ØSelect the required Language.
ØConrm with OK.
7.2 Text display
The WSD-2 HD is able to integrate and display data in the output video signal.
ØOpen the User interface dialogue via Common settings > User interface ....
Fig. 7-3

WSD-2 HD
19Dallmeier electronic
ØSelect the Player tab.
ØSet which data should be integrated and displayed (activate checkbox).
ØSet the Transparency level for the displayed text (0 = not transparent).
ØControl the displayed image.
ØConrm with OK.
NOTE
The camera name can only be displayed if it is dened on the
evaluation station (SeMSy®).
7.3 System time
The system time can be set manually or be actualised via network.
ØOpen the Set time dialogue via Common settings > Time ....
7.3.1 Manual setting
NOTE
If a time server was set (see chapter Timeserver), neither the
date nor the time can be set manually.
ØSelect the Date/Time tab.
Fig. 7-4
ØEnter Date and Time.
ØSelect the Timezone tab.
Fig. 7-5
ØSet the Timezone.
ØConrm with OK.

WSD-2 HD
20Dallmeier electronic
7.3.2 Timeserver
ØSelect the Timeserver tab.
Fig. 7-6
ØActivate the use timeserver checkbox.
ØEnter the IP adress of the Timeserver.
ØFinally conrm with OK.
7.4 Video standard
ØOpen the Video standard dialogue via Common settings > Video standard ....
Fig. 7-7
ØSet the Standard.
ØConrm with OK.
7.5 COM interface
External devices, such as a dome or PTZ camera, can be connected to the module’s COM
interface.
These devices are controlled by the evaluation software (PView, SeMSy®, etc.). The control
signals are sent to the module using the DaVid protocol. This then forwards the signals to
the external device.
ØOpen the Interfaces dialogue via Common settings > Interfaces ....
Fig. 7-8
ØSet the Function to Crosslink.
ØMake the necessary settings.
ØFinally conrm with OK.
