dallmeier PANOMERA S4 User manual

© 2023 Dallmeier electronic V1.4.0 2023-06-13 1/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
Replacing the sealing rubber on a
Panomera® S4/8
▶ Loosen the four front screws of
the camera cover counterclockwise
using an Allen key (5).
NOTE
Wear gloves for disassembly to protect
camera glass and lenses.
▶ Remove the camera cover from the
housing and place it on a soft surface.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 2/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Loosen and remove the four screws of
the pane holder with an Allen key (2.5).
▶ Remove the two metal brackets...
...and carefully lift the camera glass out
of the frame.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 3/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Lift the sealing rubber on one side...
...and carefully pull it o the frame.
▶ Then insert the new sealing rubber
into the frame.
▶ Make sure that the nipple is inserted
into the hole of the frame on one
side rst.
NEW

© 2023 Dallmeier electronic V1.4.0 2023-06-13 4/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Insert the sealing rubber completely
into the frame...
...and press it rmly with light pressure.
▶ Then press the bars of the sealing
rubber into the frame until they are
level with the frame.
▶ Make sure that the sealing rubber is
evenly and rmly seated in the frame.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 5/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Now reinsert the camera glass.
▶ Reassemble the two metal holders
clockwise using an Allen key (2.5).
▶ Make sure that all four screws are
tightened.
NOTE
To avoid device stresses, tighten the
screws crosswise.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 6/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Put the front cover back on the
camera housing.
▶ Retighten the screws clockwise
with a torque wrench (5) to 4Nm.
NOTE
To avoid device stresses, tighten
the screws crosswise.
▶ The camera is now ready for
mounting the Air Blast Kit.
4 Nm

© 2023 Dallmeier electronic V1.4.0 2023-06-13 7/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
Preparing Panomera® S4/8
▶ Press down the safety pin of the
locking ring.
▶ Remove the locking ring.
▶ Loosen the screws of the
Mountera® Plug counterclockwise
using an Allen key (5).

© 2023 Dallmeier electronic V1.4.0 2023-06-13 8/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Remove the Mountera® Plug.
▶ Loosen the screw of the cover
system at the back of the housing.
▶ Pull the cover system back and
press the guide bars together.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 9/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Remove the cover system from
the housing.
▶ Loosen and remove the screws
of the housing cover.
▶ Lift o the housing cover.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 10/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Remove the three sealing rubbers.
▶ Insert the two connectors at the
connection points and tighten
them clockwise.
▶ Insert the coupling and tighten it.
ATTENTION
Be sure to insert and tighten vertically
to avoid damage to the thread.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 11/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Insert both air hoses rmly into
their respective connectors.
ATTENTION
Test the connection with a light pull.
If the connections are plugged in too easily,
air can escape into the housing.
▶ Place the sealing ring on the screw
of the compressed air coupling.
ATTENTION
The rubber nose of the sealing ring
should rest level on the coupling.
▶ Put the camera cover back on
the camera and tighten the
screws clockwise.

© 2023 Dallmeier electronic V1.4.0 2023-06-13 12/12
panomera®S4/8
INSTALLATION OF A PANOMERA®AIR BLAST KIT ON A PANOMERA® S4/8
▶ Reinstall the Mountera® Plug and
tighten the screws clockwise to
14.4 Nm using a torque wrench.
▶ Insert and tighten the connector for
the air hose to the compressor.
NOTE
Select an angle or vertical connection
that you would like to use on site for
this purpose.
Alternative
▶ Reinsert the locking ring and let it
snap into place.
▶ Mount the cover system on the
housing and tighten the screw.
14.4 Nm
