Dalsa Piranha4 Series User manual

Piranha4
Camera User’s Manual
Monochrome 2K and 4K
sensors | cameras | frame grabbers | processors | software | vision solutions
03-032-20176-06
www.teledynedalsa.com

2 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
N otice
© 2018 Teledyne DALSA
All informationprovided inthismanual isbelieved tobeaccurateand reliable.Noresponsibility is
assumed by Teledyne DALSA for its use. Teledyne DA LSA reserves the right to make changes to this
informationwithout notice.Reproductionof thismanual in wholeor in part,by any means,isprohibited
without prior permissionhavingbeenobtained from Teledyne DALSA.
Microsoft and Windows are registered trademarksof Microsoft Corporation in theUnited States and
other countries. Windows, Windows7, Windows8 aretrademarksof Microsoft Corporation.
All other trademarksor intellectual property mentioned herein belong to their respective owners.
Document Date: 15August 2018
Document Number: 03-032-20176-06
About TeledyneDALSA
TeledyneDALSA isan international high performancesemiconductor and ElectronicsCompany that
designs, develops, manufactures, and markets digital imaging products and solutions, in addition to
providingwafer foundry services.
TeledyneDALSA Digital Imaging offersthewidest rangeof machinevision componentsin theworld.
From industry-leading image sensors through powerful and sophisticated cameras, frame grabbers,
vision processors and software to easy-to-use vision appliances and custom vision modules.
Contact TeledyneDALSA
Teledyne DALSA is headquartered in Waterloo, Ontario, Canada. We have sales offices in the USA,
Europe and Asia, plus a worldwide network of representatives and agents to serve you efficiently.
Contact information for salesand support inquiries,pluslinksto mapsand directionsto our offices,can
be found here:
Sales Offices: http:/ / www.teledynedalsa.com/ corp/ contact/ offices/
Technical Support:http:/ / www.teledynedalsa.com/ imaging/ support/

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 3
Teledyne DALSA 03-032-20176-06
Contents
1. System Precautions and Cleaning_________________________________________________________________________6
Precautions .................................................................................................6
Electrostatic Discharge and the CMOS Sensor..........................................6
2. The Piranha4 Camera __________________________________________________________________________________7
Camera Highlights ...................................................................................................7
Camera Performance Specifications .......................................................................8
Flash Memory Size ..................................................................................................9
Environmental Considerations.................................................................................9
Certifications and Compliance.................................................................................10
Supported Industry Standards .................................................................................10
Responsivity.............................................................................................................10
Mechanicals.............................................................................................................12
Camera Mounting and Heat Sink Considerations.......................................14
3. Quick, Simple Steps to Acquire an Image___________________________________________________________________15
4. Software and Hardware Setup____________________________________________________________________________16
Recommended System Requirements.......................................................16
Setup Steps: Overview ............................................................................................ 16
1. Install and Configure Frame Grabber and Software...............................16
2. Connect Camera Link and Power Cables...............................................16
3. Establish Communicating with the Camera............................................16
4. Operate the Camera ...............................................................................16
Step 1. Install and Configure the Frame Grabber and Software .............................17
Install Frame Grabber.................................................................................17
Install Sapera LT and CamExpert GUI .......................................................17
Step 2. Connect Data, Trigger, and Power Cables..................................................18
Data Connector: Camera Link ....................................................................19
Camera Link Bit Definitions.........................................................................21
Camera Link Drive Capability .....................................................................22
Input Signals, Camera Link.........................................................................22
Output Signals, Camera Link Clocking Signals..........................................23
Power Connector ........................................................................................23
LEDs ...........................................................................................................24
Step 3. Establish Communication with the Camera.................................................24
Power on the camera..................................................................................24
Connect to the frame grabber..................................................................... 24
Connect to the camera................................................................................ 25
Check LED Status.......................................................................................25
Software Interface.......................................................................................25
Using Sapera CamExpert with Piranha4 Cameras..................................................26
CamExpert Panes.......................................................................................27
4. Camera Operation_____________________________________________________________________________________29
Factory Settings.......................................................................................................29
Area Mode................................................................................................................29

4 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
Check Camera and Sensor Information ..................................................................31
Verify Temperature and Voltage..............................................................................31
Saving and Restoring Camera Settings...................................................................32
Camera Link Configuration......................................................................................34
TDI and Single Line Modes......................................................................................34
Sensitivity Modes and Pixel Readout .........................................................35
Trigger Modes.......................................................................................................... 36
Exposure Controls ...................................................................................................36
Exposure Modes in Detail........................................................................................37
Set Line Rate ...........................................................................................................39
Set Exposure Time ..................................................................................................42
Control Gain and Black Level ..................................................................................42
Set Image Size.........................................................................................................43
Set Baud Rate..........................................................................................................43
Pixel Format.............................................................................................................44
Camera Direction Control ........................................................................................44
Camera Direction........................................................................................45
Pixel Readout Direction (Mirroring Mode)................................................................45
Resetting the Camera..............................................................................................46
Calibrating the Camera............................................................................................46
Appendix A: GenICam Commands __________________________________________________________________________50
Camera Information Category..................................................................................50
Camera Information Feature Descriptions..................................................51
Camera Configuration Selection Dialog......................................................54
Camera Power-up Configuration ................................................................54
User Set Configuration Management .........................................................54
Camera Control Category........................................................................................55
Camera Control Feature Descriptions ........................................................56
Multi-Exposure Mode..................................................................................58
Digital I/O Control Feature Descriptions .....................................................62
Flat Field Category...................................................................................................63
Flat Field Control Feature Description........................................................64
Region of Interest (ROI)..............................................................................65
Image Format Control Category ..............................................................................66
Image Format Control Feature Description ................................................67
Binning ..................................................................................................................... 68
Area of Interest (AOI) Setup ....................................................................................69
Instructions on Using the Camera Scan Direction to Control Camera
Parameters..................................................................................................72
Transport Layer Control Category ...........................................................................75
Transport Layer Feature Descriptions ........................................................76
Acquisition and Transfer Control Category..............................................................76
Acquisition and Transfer Control Feature Descriptions..............................77
Serial Port Control Category.................................................................................... 78
Serial Port Control Feature Descriptions ....................................................78
File Access Control Category ..................................................................................79
File Access Control Feature Descriptions...................................................80
File Access via the CamExpert Tool...........................................................81

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 5
Teledyne DALSA 03-032-20176-06
Download a List of Camera Parameters.....................................................82
Appendix B: ASCII Commands _____________________________________________________________________________84
Port Configuration.......................................................................................85
Disabling the Esc Key for Direct Access to ASCII Commands...................86
Commands..................................................................................................86
Appendix C: Error and Warning Messages ____________________________________________________________________98
Appendix D: Quick Setup and Image Acquisition _______________________________________________________________100
Appendix E: The Sensor Window ___________________________________________________________________________103
Cleaning and Protecting Against Dust, Oil, and Scratches ........................103
Cleaning the Sensor Window......................................................................104
Appendix F: Camera, Frame Grabber Communication___________________________________________________________105
Setting Up Communication between the Camera and the Frame Grabber 105
EMC Declaration of Conformity_____________________________________________________________________________108
Revision History_________________________________________________________________________________________109
Index _________________________________________________________________________________________________110

6 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
1.SystemPrecautionsand
Cleaning
Precautions
Read these precautions and this manual carefully before using the camera.
Confirm that the camera’s packaging is undamaged before opening it. If the packaging is damaged please
contact the related logistics personnel.
Do not open thehousing of the camera. Thewarranty isvoided if the housing is opened.
Keep the camera’s front plate temperature in a range of 0°C to 65°C during operation.
Do not operate the camera in the vicinity of strong electromagnetic fields. In addition, avoid electrostatic
charging,violent vibration, and excess moisture.
To clean the device, avoid electrostatic charging by using a dry, clean absorbent cotton cloth dampened
with a small quantity of pure alcohol. Do not use methylated alcohol. To clean the surface of the camera
housing, use a soft, dry cloth. To remove severe stains use a soft cloth dampened with a small quantity of
neutral detergent and then wipe dry. Do not use volatile solvents such as benzene and thinners, as they
can damage the surface finish. Further cleaninginstructionsarebelow.
Though thiscamerasupportshot plugging, it isrecommended that you power down and disconnect
power to the camera before you add or replace system components.
ElectrostaticDischargeandtheCMOSSensor
Image sensors and thecamerabodieshousing are susceptible to damage from electrostatic discharge
(ESD). Electrostaticchargeintroduced to thesensor window surfacecan inducechargebuildup on the
underside of the window. The charge normally dissipates within 24 hours and the sensor returns to
normal operation.

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 7
Teledyne DALSA 03-032-20176-06
2.ThePiranha4Camera
CameraHighlights
Teledyne DALSA expands its Piranha4™ dual lineCMOScamerafamily with 2K and 4K resolution
models. The new Piranha4 models offer higher speeds and more responsive pixels in a choice of sizes
and resolutions.Programmablefeaturesincludemultipleregion-of-interest, high dynamicrange
operation, and rapid bi-directional switching,and aredesigned tomeet today’sdemandingimaging
applications.
Key Features
•High speed:up to100 kHz inTDI modeand up to 200 kHz in Area mode
•Combinationof variouspixel sizesand resolutions
•Bi-directional
•Compact camera body
Programmability
•Multiple Regions of Interest for calibration and data reduction
•8, 10, and 12bit output
•Flat field and lensshadingcorrection
•8 programmable coefficient sets
•GenICam or ASCII compliant interfacing
Applications
•Automated optical inspection
•Transportation safety and security systems
•High performance sorting systems
•Materialsgradingand inspection systems
•Web inspection
•General purposemachinevision

8 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
Models
The camera is available in the following configurations:
Table 1: Camera Models Comparison
Piranha4 Dual Line Model Comparison
Part Number Resolution Maximum Line Rates
TDI Mode (Area Mode)
Pixel Size
P4-CM-02K05D-00-R
2048 x 2 pixels
50 kHz (100 kHz)
10.56 µm x 10.56 µm
P4-CM-02K10D-00-R 2048 x 2 pixels 100 kHz (200 kHz) 10.56 µm x 10.56 µm
P4-CM-04K05D-00-R
4096 x 2 pixels
50 kHz (100 kHz)
10.56 µm x 10.56 µm
P4-CM-04K10D-00-R 4096 x 2 pixels 100 kHz(200 kHz) 10.56 µm x 10.56 µm
Table 2: Software
Software Product Number / Version Number
Camera firmware
Embedded within camera
GenICam™ support (XML camera description file)
Embedded within camera
SaperaLT,includingCamExpert GUI application and
GenICam for Camera Link imaging driver
Version 7.20 or later
CameraPerformanceSpecifications
Table 3: Camera Performance Specifications
Specifications Performance
Imager Format High speed CMOSdual line scan
Resolution
2048 x 2 pixelsand 4096 x 2
Pixel Size 10.56 µm x 10.56 µm
Pixel Fill Factor 100 %
LineRate
Up to 100 kHzin TDI mode (200 kHz area mode)
ExposureTime 4µs to 3 ms
Bit Depth
8, 10, and 12 bit, selectable
Connectors and Mechanicals
Control & Data Interface
Base, Medium, Full, and Deca Camera Link configurations(2 x SD R-26)
Power Connector Hirose 6-pin male circular
Power Supply
+ 12 V to + 24 V DC ± 5%
Power Dissipation < 11 W (4K), < 8.3 W (2K)
Si ze 62 mm (W)x 62 mm (H) x 48 mm (D)
Mass
< 340 g
Operating Temp 0 °C to 65 °C,front platetemperature
Optical Interface
LensMount M42 x 1 (2k) and M58 x 0.75 (4k), F-mount adapter available
Sensor to Camera Front Distance
12 mm
Sensor Alignment (aligned to sides of camera)

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 9
Teledyne DALSA 03-032-20176-06
Θy (parallelism)
x
y
z
Θz
0.08° or 100 µm
± 100 µm
± 100 µm
± 250µm
± 0.2°
Compliance
Regulatory Compliance CE, FCC, and RoHS; GenICam
Operating Ranges Performance Notes
Single Line Dual Line
Dynamic Range 61.5 dB 60dB
Random Noise 3.42 DN* rms 4.16 DN rms FFC enabled
Broadband Responsivity
430 DN/(nJ/cm
2
)
677DN/(nJ/cm
2
)
Gain 1x to 10x Nominal range 1x to 10x Nominal range
DCOffset
7DN
14 DN
FFC enabled
PRNU < 1% @50% Sat < 1% @50% Sat
FPN < 8DN < 8DN
SEE
9.52 nJ / cm
2
6.05 nJ / cm
2
NEE 7.95 p J / cm 26.14 p J / cm 2
Antiblooming
> 100 x Saturation
> 100 x Saturation
Integral non-linearity 1.5 % DN 2.5 % DN
*DN = digital number
Test Conditions:
•Values measured using 12-bit, 1x gain.
•10 kHzlinerate
•Light source: broadband, quartz halogen, 3250 K with 700 nm IR cut-off filter.
•Front platetemperature:45º C
FlashMemorySize
Camera Flash Memory Size
P4-CM-02K05D-00-R
16 MByte
P4-CM-02K10D-00-R
16 MByte
P4-CM-04K05D-00-R
16 MByte
P4-CM-04K10D-00-R 16 MByte
EnvironmentalConsiderations
Environmental Specifications Performance
Storagetemperaturerange
-20 °C to +80 °C
Humidity (storageand operation)
15% to 85% relative, non-condensing
MTBF (mean time between failures)
> 100,000 hours, typical field operation

10 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
CertificationsandCompliance
Compliance
EN 55011, FCC Part 15, CISPR 11, and ICES-003 Class A Radiated Emissions Requirements
EN 55024 and EN 61326-1Immunity toDisturbance
RoHSper EU Directive 2011/ 65/ EC and WEEE per EU Directive 2002/ 96/ EC and China Electronic Industry
Standard SJ/ T11364-2006
GenICam XML Description File, Superset of the GenICam™ Standard Features Naming Convention specification
V1.5, CameraLink Serial Communication:GenICam™GenericControl Protocol (GenCPV1.0)
SupportedIndustryStandards
GenICam™
Piranha4 cameras are GenICam compliant. They implement a superset of the GenICam™ Standard
Features Naming Convention specification V1.5.
This description takes the form of an XML device description file respecting the syntax defined by the
GenApi module of the GenICam™ specification.The camera uses theGenICam™ GenericControl
Protocol (GenCP V1.0) to communicate over the Camera Link serial port.
For more information see www.genicam.org.
Responsivity
The responsivity graph describes the sensor response to different wavelengths of light (excluding lens
and light sourcecharacteristics).
Figure 1: Spectral Responsivity vs. Wavelength (Dual Line)

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 11
Teledyne DALSA 03-032-20176-06
Figure 2: QE % vs. Wavelength
Figure 3: Relationship between FPN and Temperature

12 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
Mechanicals
[INSERT PDF HERE]
Figure 4: 2K (Top) and 4K (Bottom) Camera Mechanicals
NOTES:
1. UNITS: MILLIMETERS.
2. IMAGE AREA IS ALIGNED TO DATUMS A B & C .
(11.4)
(20.34)
(19.1)
(9)(9)
(42)
(7)
(47.87)
M4x0.7 - 6H Z6
(2X) THIS SIDE
(2X) FAR SIDE
(54)
62B0.05
62
B
0.05
M4x0.7 - 6H Z6
(4X)
(54)
FIRST PIXEL
REFERENCE HOLES M42x1 - 6H
(42)
(7) M4x0.7 - 6H Z6
(2X) THIS SIDE
(2X) FAR SIDE
A
B
C
31B0.10
31
B
0.10
CENTER OF
IMAGE AREA
±0.2°
12B0.25 OPTICAL DISTANCE
H0.1 A
E0.05
AREA
7(/('<1(
NOTES:
1. UNITS: MILLIMETERS.
2. IMAGE AREA IS ALIGNED TO DATUMS A B & C .
(54)
62B0.05
62
B
0.05
M4x0.7 - 6H Z6
(4X)
FIRST PIXEL
REFERENCE HOLE
(54)
C
B
(42)
(47.87)
(7)
M4x0.7 - 6H Z6
(2X) THIS SIDE
(2X) FAR SIDE
(42)
(7) M4x0.7 - 6H Z6
(2X) THIS SIDE
(2X) FAR SIDE
A
M58x0.75 - 6H
12B0.25 OPTICAL DISTANCE
AREA
H0.1 A
E0.05
31
B
0.10
31B0.10 CENTER OF
IMAGE AREA
±0.2°
(9)
(9)
(19.1)
(20.34)
(11.4)

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 13
Teledyne DALSA 03-032-20176-06
Figure 5: Nikon M58 to F-Mount Adapter
Figure 6: Piranha4 Heat Sink Accessories Kit
Optional Lens Mount and Heat Sink Accessories
Part No. Description
AC-LN-00002
M58 to F-mount adapter, heavy duty, 12mm BFD, for 4K model
AC-LC-00001
M42x1 to C-mount adapter, 12mm BFD, for 2K model
AC-LA-00115
M42x1 to F-mount adapter, heavy duty, 12mm BFD, for 2K model
AC-MS-00108
Heat sink for 2k and 4k models

14 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
CameraMountingandHeatSinkConsiderations
Up to two optional heat sinkscan beinstalled on thePiranha4 camera. As illustrated, they are ideally
positioned toallow closespacingof thecameras. These heat sinks are designed to provide adequate
convection cooling when not obstructed by enclosures or mounting assemblies.
Teledyne DALSA recognisesthat each customer’s application can be unique. In consideration,the P4
camera heat sinks have been designed in such a way that they can berepositioned on the different faces
of the camera or removed entirely,depending on themounting configuration and itsheat sinking
potential.
Repositioning or removal of the heat sinks must be performed with care in order to avoid temperature
issues. The camera has the ability to measure its internal temperature. Use this feature to record the
internal temperature of the camera when it ismounted in your system and operating under the worst
case conditions. Thecamerawill stop outputtingdataif its internal temperature reaches 80 °C. Refer to
the Verify Temperature and Voltage section for moreinformation.
Figure 7: Heat Sink Installation (4K model)
7(/('<1(
NOTES:
1. UNITS: MILLIMETERS.
2. IMAGE AREA IS ALIGNED TO DATUMS A B & C .
OPTIONAL EXTERNAL
HEAT SINK ACCESSORY (2X)
AC-MS-00108-00-R
(98)
HEAT SINK
GAP PAD
SCREW M4-0.7X8
TORQUE 25 IN*LB

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 15
Teledyne DALSA 03-032-20176-06
3.Quick,SimpleStepsto
AcquireanImage
For users who are familiar with Camera Link cameras, have a basic understanding of their imaging
requirements, and who are primarily interested in evaluating the Piranha4 camera, an overview of the
steps required to get this camera operational and acquiring images quickly can befound in Appendix D:
Quick Setup and ImageAcquisition.

16 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
4.SoftwareandHardwareSetup
RecommendedSystemRequirements
To achieve best system performance, the following minimum requirements are recommended:
•High bandwidth frame grabber, e.g. Xcelera-CL PX8 Full Camera Link frame grabber (Part # OR-
X8CO-XPF00): www.teledynedalsa.com/ imaging/ products/ fg/ OR-X8C0-XPF00/ .
•Operating systems: Windows XP / Vista / 7, 32 / 64-bit.
SetupSteps:Overview
Take the following steps in order to setup and run your camera system. They are described briefly below
and in moredetail in thesections that follow.
1.InstallandConfigureFrameGrabberandSoftware
Werecommend the Xcelera-CL PX8 Full framegrabber or equivalent, described in detail on the
teledynedalsa.com site here. Follow themanufacturer’sinstallation instructions.
A GenICam™ compliant XM L device description file is embedded within the camera firmwareallowing
GenICam™ compliant application to know the camera’s capabilities immediately after connection.
Installing SaperaLT gives you access to the CamExpert GUI, a GenICam™ compliant application.
2.ConnectCameraLinkandPowerCables
•Connect the Camera Link cables from the camera to the computer.
•Connect a power cable from the camera to a power supply that can provideaconstant voltage
between +12 VDC and +24 VDC ± 5%.
3.EstablishCommunicatingwiththeCamera
Start theGUI and establish communication with thecamera.
ASCII Commands
As an alternative to the CamExpert (or equivalent) GUI, you can communicate with this camera using
A SCII-based commands. Open up an ASCII interfaceand presstheESC key,then thecommunication
mode will be switched into the ASCII command modeother than theGenICam mode. A complete list of
thecommands and adescription of how to accessthem can befound in Appendix B:ASCII Commands.
4.OperatetheCamera
At thispoint you will beready tostart operatingthecamera in order toacquireimages, set camera
functions, and savesettings.

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 17
Teledyne DALSA 03-032-20176-06
Step1.InstallandConfiguretheFrameGrabber
andSoftware
InstallFrameGrabber
Install a Full configuration Camera Link framegrabber accordingtothemanufacturer’sdescription.
We recommend the Xcelera-CL PX8 frame grabber or equivalent, described in detail on the
teledynedalsa.com site here.
InstallSaperaLTandCamExpertGUI
Communicatewith thecamerausing aCameraLink-compliant interface. We recommend you use
CamExpert. CamExpert is the camera interfacing tool supported by the Sapera library and comes
bundled with SaperaLT.Using CamExpert is the simplest and quickest way to send commands to and
receive information from the camera.
CameraLink Control Communications
The P4 family of cameras are GenICam™ compliant. Sapera usestheGenICam™ GenericControl
Protocol (GenCP V1.0) to communicate with the camera over the Camera Link serial port. When
communicationsarefirst established Saperawill when connectingfor thefirst timedownload the
GenICam™XML Description file.Thisfiledetailshow toaccessand control thecamera.

18 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
Step2.ConnectData,Trigger,andPowerCables
Note: the use of cables types and lengths other than those specified may result in increased emission or
decreased immunity and performance of the camera.
Figure 8: Input and Output, Trigger, and Power Connectors
WARNING!GroundingInstructions
Staticelectricity can damageelectroniccomponents.It’scritical that you discharge any static
electrical charge by touching a grounded surface, such as the metal computer chassis, before
handling the camera hardware.
!
B
B
C
A
Power
+12V to +24V DC Hirose 6-pin
Control & Data
Camera Link 26-pin SDR26 connectors
Status
Diagnostic LED
A
B
B
C

Piranha4 2K and 4K Dual Line Monochrome CMOS Camera 19
Teledyne DALSA 03-032-20176-06
DataConnector:CameraLink
The camera uses two Camera Link SDR26 cablestransmitting theCamera Link Base, M edium, or Full
configuration.Thefigurebelow showstheSDR26 CameraLink Connector and the tables that follow list
the Camera Link Base, Medium, and Full configurations.
For detailed information on Camera Link please refer to the Camera Link Road M ap available from the
Knowledge Center on the Teledyne DALSA Web site:
(http:/ / www.teledynedalsa.com/ mv/ knowledge/ appnotes.aspx).
Figure 9. Camera Link Connector
Data 2 Control / Data 1
Camera
Connector
Right Angle
Frame Grabber
Connector
Channel Link
Signal
Camera
Connector
Right Angle
Frame Grabber
Connector
Channel Link
Signal
1 1 inner shield 1 1 inner shield
14 14 inner shield 14 14 inner shield
2 25 Y0- 2 25 X0-
15
12
Y0+
15
12
X0+
3
24
Y1-
3
24
X1-
16
11
Y1+
16
11
X1+
4
23
Y2-
4
23
X2-
17
10
Y2+
17
10
X2+
5
22
Yclk-
5
22
Xclk-
18
9
Yclk+
18
9
Xclk+
6 21 Y3- 6 21 X3-
19 8 Y3+ 19 8 X3+
7 20 100 ohm 7 20 SerTC+
20 7 terminated 20 7 SerTC-
8 19 Z0- 8 19 SerTFG-
21 6 Z0+ 21 6 SerTFG+
9 18 Z1- 9 18 CC1-
22
5
Z1+
22
5
CC1+
10
17
Z2-
10
17
CC2+
23
4
Z2+
23
4
CC2-
11
16
Zclk-
11
16
CC3-
24
3
Zclk+
24
3
CC3+
12
15
Z3-
12
15
CC4+
25
2
Z3+
25
2
CC4-
13 13 inner shield 13 13 inner shield
26 26 inner shield 26 26 inner shield
*Exterior Overshield is connected to the shells of the connectors on both ends. Unused pairs should be terminated in 100 ohms at
both ends of the cable. Inner shield is connected to signal ground inside camera

20 Piranha4 2K and 4K Dual Line Monochrome CMOS Camera
03-032-20176-06 Teledyne DALSA
Full Configuration
8 bits Camera Link Full Configuration
Connector 1: Channel link X Connector 2: Channel link Y Connector 3: Channel link Z
Camera/Frame
Grabber Pin Bit Name
Camera/Frame
Grabber Pin Bit Name
Camera/Frame
Grabber Pin Bit Name
Tx0/Rx0 D0(0) Tx0/Rx0 D3(0) Tx0/Rx0 D6(0)
Tx1/Rx1 D0(1) Tx1/Rx1 D3(1) Tx1/Rx1 D6(1)
Tx2/Rx2 D0(2) Tx2/Rx2 D3(2) Tx2/Rx2 D6(2)
Tx3/Rx3 D0(3) Tx3/Rx3 D3(3) Tx3/Rx3 D6(3)
Tx4/Rx4 D0(4) Tx4/Rx4 D3(4) Tx4/Rx4 D6(4)
Tx5/Rx5 D0(7) Tx5/Rx5 D3(7) Tx5/Rx5 D6(7)
Tx6/Rx6 D0(5) Tx6/Rx6 D3(5) Tx6/Rx6 D6(5)
Tx7/Rx7 D1(0) Tx7/Rx7 D4(0) Tx7/Rx7 D7(0)
Tx8/Rx8 D1(1) Tx8/Rx8 D4(1) Tx8/Rx8 D7(1)
Tx9/Rx9 D1(2) Tx9/Rx9 D4(2) Tx9/Rx9 D7(2)
Tx10/Rx10 D1(6) Tx10/Rx10 D4(6) Tx10/Rx10 D7(6)
Tx11/Rx11 D1(7) Tx11/Rx11 D4(7) Tx11/Rx11 D7(7)
Tx12/Rx12 D1(3) Tx12/Rx12 D4(3) Tx12/Rx12 D7(3)
Tx13/Rx13 D1(4) Tx13/Rx13 D4(4) Tx13/Rx13 D7(4)
Tx14/Rx14 D1(5) Tx14/Rx14 D4(5) Tx14/Rx14 D7(5)
Tx15/Rx15 D2(0) Tx15/Rx15 D5(0) Tx15/Rx15 Not Used
Tx16/Rx16 D2(6) Tx16/Rx16 D5(6) Tx16/Rx16 Not Used
Tx17/Rx17 D2(7) Tx17/Rx17 D5(7) Tx17/Rx17 Not Used
Tx18/Rx18 D2(1) Tx18/Rx18 D5(1) Tx18/Rx18 Not Used
Tx19/Rx19 D2(2) Tx19/Rx19 D5(2) Tx19/Rx19 Not Used
Tx20/Rx20 D2(3) Tx20/Rx20 D5(3) Tx20/Rx20 Not Used
Tx21/Rx21 D2(4) Tx21/Rx21 D5(4) Tx21/Rx21 Not Used
Tx22/Rx22 D2(5) Tx22/Rx22 D5(5) Tx22/Rx22 Not Used
Tx23/Rx23 Not Used Tx23/Rx23 Not Used Tx23/Rx23 Not Used
Tx24/Rx24 LVAL Tx24/Rx24 LVAL Tx24/Rx24 LVAL
Tx25/Rx25 FVAL Tx25/Rx25 FVAL Tx25/Rx25 FVAL
Tx26/Rx26 Not Used Tx26/Rx26 Not Used Tx26/Rx26 Not Used
Tx27/Rx27 D0(6) Tx27/Rx27 D3(6) Tx27/Rx27 D6(6)
Tap 1 bits are D0(x)...Tap 8 bits are D7(x)
