Dancover AC153020 User manual

28-07-2021
for
Electrical Screen/Sidewall for
Gazebo San Pablo
Manual

Qty
1xL
1xR
1xL
1xR
(A)
(B)
(C)

installation guide rail--right
main frame
installation guide rail--left
1. Assemble the guide rails and install the main frame
motor cable

3. Fix the screen onto pergola
pergola pole pergola pole
pergola pole pergola pole
top view
B (left) B (right)

7. Matching code, deleting code, stroke setting and clean stroke
Settings for matching code
Power off OK,
OK,
motor rotates
one time motor rotates
one time motor rotates
one time
Press
Motor beep once
and rotates once
5.1 " " Button one time
Press
5.2 " " Button one time
Motor beep once
and rotates once
Settings for deleting code
2.Press P2 one time 3.Press the middle
"stop" one time
Motor beep once
and rotates once
4.Press P2 one more time
Motor beep once
and rotates once code has been
deleted
Settings for stroke
Note 1:
1. It can not be the same position for the upper stroke and the lower stroke
2. It can be quit only when the lower stroke setting completed.
3. When the stroke is set, it has the memory function when power-off.
Note 2:
1. In the process of adjusting the upper and lower limit stroke
when the motor is running up and down,
press the setting key once, the motor will enter the step mode,
and then press he setting key once again to exit the step mode.
2. Step mode: the motor will run up and down in step mode
to adjust the limit position more accurately.
1. Switch on
1. Switch on 2.Press " " Button 3. Press the middle "stop" once
when the screen reaches the upper limit,
then press the "stop" no release until
motor rotates.
Press
4. " " Button 5. Press the middle "stop" once
when the screen reaches the lower limit,
then press the "stop" no release until
motor rotates.
Stroke setting
completed
Setting for stroke clean
1. Switch on 2. Press P2 once
Press
3. " " Button once
4. Press P2 once again
Motor rotates
once Motor rotates once Motor beep once
and rotates once Stroke cleaned

I
For more information
please visit:
www.dancovershop.com
