Dancover Pagoda Marquee UNICO 6x6m User manual

6x6m
Pagoda EventZone

Safety Advice
Attention
In some countries approval is needed to set up a tent larger than 75 m2.
The owner of the tent has the sole responsibility to make sure that these local
rules are followed and that the mounting is correct.
In case of bad weather conditions, it is your responsibility to ensure that people
inside are safe and that the tent does not cause damage to others.
It is always recommended that you secure your tent properly with safety straps
and augers when you put up the structure.
We recommend you to insure the tent, or check if it is covered by home con-
tents insurance, in case of unplanned events, accidents or bad weather.
Tents are meant as temporary shelter and must be evacuated under extreme
weather conditions.
always recommend to remove snow from the top.
Attention: Marquees are made for use at parties and other festive arrangements
and are as such only meant for short term temporary assembly and the follow-
ing disassembly. Please note that the warranty will not apply if used in any other
way.

Pagoda Parts
1) Spider / Roof Tensioner / Spine
2) Ground rails / ground Bars
3) Upright, inc. Folding eave
Connection and base plate
4) Roof tubes
5) Eave Beams
6) Locking ‘P’ Device
7) Base plate fi tted to upright
1
2
3
4
5
6
7

Step 1) Lay out all the
eave beams and legs,
making sure you fold the
eave connectors up by
removing the locking bolt
and lifting the locking plate

Step 2) insert eave beam
(1) into legs (1&2) then
insert eave beams
(2&3)
into legs (1&2) , next in-
sert eave beam 4 into legs
(3&4) . Once all eave beams
are fi tted bolt together using
M10 bolts.
Eave beam 1
Eave beam 2 Eave beam 3
Eave beam
4
Leg 1 Leg 2
Leg 3 Leg 4

Step 3) to insert the fi nal eave and legs, you need to
slide both legs in together, once fi tted bolt in place
using M10 bolts.
Eave beam 4
Leg 3 Leg 4

Completed main frame, ready for roof
tubes.

Step 4) insert the four roof tubes onto the steel
tube on each of the eave knuckles. Once you
have fi tted all four tubes you can fi t the spider /
tensionor. The easiest way to fi t this
is to insert opposite tubes together.

Step 5) once all the roof tubes are fi tted drape the
cover over the frame being careful not to drag the
cover as this can
damage the fi nish.
Once the cover is
draped over you
need to lift one
side to allow
access under
cover to fi t the
centre pole
assembly. This
must be done
before you fully
fi t the cover.

Step 6) fi t-
ting the centre
pole assembly
(shown here
with cover not
drawn)
If you have a
cap top
cover, once
the cover is
over frame
insert the
centre pole
and the cap
top
Cap
Centre pole
Cone
Cone
tube
if you have a pointed
top roof cover you
would once the roof
cover is on, insert the
centre pole, then the
cone tube followed by
the cone.

Step 7) fi tting the roof cover,
Once you have got the cen-
tre pole assembly fi tting
installed you can start to
secure the roof cover to the
frame, this is done by the
use of the P channel locking
device you will need to slide
the p channel onto the keder
of the roof sheet (fi g 1) then
clip this over the edge of the
eave beam (fi g 2) once you
have done one side install
the p channel to the oppo-
site side. You may fi nd once
you get to side 3 and 4 the
p channels may become
harder to fi t due to the ten-
sion in the roof cover. On
these sides start fi tting the
p channel from the centre
on the eave and work back
to the corners, you may fi nd
this much easier. Once all
side have the P channel fi t-
ted and before you tension
the roof make sure all the
corners are aligned as once
it is tensioned this will not be
possible.
Fig 1
Fig 2

Step 8)
Now you are ready to start to
stand the pagoda up. Start by
lifting one side, the legs should
slowly fold down as you lift, but
you may need to help them.
Once the legs are fully extend-
ed lock the in place with the
locking plate and refi t the M10
bolt.
Now with the tent up on two
legs you can tension the roof
cover by turning the ring on the
bottom of the Spider/ tensionor
in a clockwise direction.

Step 9) once you have tensioned the roof cover
you can lift the other side and fi t the legs making
sure you lock them in place.

Step 10) Fitting the walls, if you
want to fi t the walls to your pago-
da this is done by fi rst fi tting the
keder of the wall into the keder
slot in the leg. But make sure
you have the slight shinny side
of the pvc on the outside and the
plastic fi ttings (T fi tting and slid-
ing ball fi tting) at the top. Once
you have fi tted this you can then
slide the T fi ttings into the open
slot in the bottom of the eave
beam. Repeat this with the other
half of the wall making sure it is
the opposite piece ie. You have
1 lace wall and 1 eyelet wall. To
close the wall up pull both wall
to the centre and lace together
by inserting the lace though the
eyelet at the top then placing the
second lace though the next eye-
let and fi rst lace. Continue all the
way down the wall. When you
get to the bottom fi nish off with a
bow knot.
Next you can fi t the
ground rail, insert the
ground rail into the
pocket at the bottom
of the wall and slide in
making sure when the
rail gets to the centre
that you insert it into the
second half of the wall.
To secure in place you
fi t the ground rail to the
base plate by placing
over the raised stud and
securing with an R clip.

WEATHER AND SAFETY
Relocatable aluminum beamed fabric structures have been used for decades. Even
with millions of square feet of this and similar structures now in the world, the indus-
try as whole has maintained an excellent safety record. The industry and the avail-
able inventory continue’s to grow. However, these structures are engineered for
temporary use under the codes and may be frequently relocated, presenting safety
issues that are uniquely diff erent from more rigid permanent structures.
It is the customer’s responsibility to ensure that the structure has been purchased
and specifi ed in accordance with the local codes having jurisdiction over the site on
which the structure will be used. We suggest that code issues be dealt with early in
the planning stages so that conformity can be considered through all phases of site
preparations and structure installation, including proper anchoring for all weather
and soil conditions of the site.
HTS Structures is responsible only for the product kit of parts delivered to the cus-
tomer. It is the customer’s responsibility to ensure that a ground anchoring system is
used that meets the required code with the soil conditions present at the location.
The IFAI Procedural Handbook for the Safe Installation and Maintenance of Tentage
gives good additional advice on installations of tents and structures similar to the
HTS Structure.
The IFAI also provides a reference on the “Pullout Capacity of Tent Stakes that
should be consulted regarding temporary anchoring with tent stakes.
Though HTS Structures stands behind the quality of its product, structures that are
disassembled and reassembled should be inspected frequently for damaged or
missing parts that could jeopardize the safety of the re-installation. Fabric should be
stored in a cool, dry location to prevent mildew that could compromise its integrity.
Each installation should be supervised by a competent leader who is experienced
and familiar with the proper assembly of components and the installation process.
Proper installation procedures as outlined in this assembly manual should be fol-
lowed diligently for each installation of the structure. At all times, installers should
follow approved safety standards as it pertains to safety clothing such as hard hats,
steel toed shoes and the proper use of tools and power equipment.
The structure has been engineered to meet appropriate code requirements. How-
ever, weather conditions vary drastically within small geographic locations. Heavy
winds and microbursts can occur with almost pinpoint but unpredictable precision.
Therefore, the customer should always err on the side of safety and evacuate the
structure if there is any possibility that inclement weather could become a safety
concern.
When used properly and safely, your structure should provide many years of satis-
faction for your temporary shelter needs.
