1 Introduction
1.1 Purpose of this Operating Guide
This operating guide provides information for safe installation and commissioning of the AC drive. It is intended for use by qualified
personnel. Read and follow the instructions to use the drive safely and professionally. Pay particular attention to the safety instructions
and general warnings. Always keep this operating guide available with the drive.
1.2 Trademarks
VLT® is a registered trademark for Danfoss A/S.
1.3 Additional Resources
1.3.1 Other Resources
Other resources are available to understand advanced drive functions and programming.
• The VLT® HVAC Basic Drive FC 101 Programming Guide provides information on how to program and includes complete parameter
descriptions.
• The VLT® HVAC Basic Drive FC 101 Design Guide provides all technical information about the drive. It also lists options and
accessories.
The technical documentation is available in electronic form online at www.danfoss.com.
1.3.2 MCT 10 Setup Software Support
Download the software from the service and support section on www.danfoss.com.
During the installation process of the software, enter access code 81463800 to activate the VLT® HVAC Basic Drive FC 101 functionality.
A license key is not required for using the VLT® HVAC Basic Drive FC 101 functionality.
The latest software does not always contain the latest updates for drives. Contact the local sales office for the latest drive updates (in
the form of *.upd files), or download the drive updates from the service and support section on www.danfoss.com.
1.4 Document and Software Version
The operating guide is regularly reviewed and updated. All suggestions for improvement are welcome.
The original language of this manual is English.
Table 1: Document and Software Version
Edition Remarks Software version
AQ275641848264en-000101 Update to new software version. 4.4x
Introduction
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
6 | Danfoss A/S © 2019.11

From software version 4.0x and later (production week 33 2017 and after), the variable speed heat sink cooling fan function is
implemented in the drive for power sizes 22 kW (30 hp) 400 V IP20 and below, 18.5 kW (25 hp) 400 V IP54 and below, and 11 kW (15 hp)
200 V IP20 and below. This function requires software and hardware updates and introduces restrictions with regards to backwards
compatibility for H1–H5 and I2–I4 enclosure sizes. Refer to the following table for the limitations.
Table 2: Software and Hardware Compatibility
Software compatibility Old control card (production week 33
2017 or before)
New control card (production week
34 2017 or after)
Old software (OSS-file version 3.xx and be-
low)
Yes No
New software (OSS-file version 4.xx or
higher)
No Yes
Hardware compatibility Old control card (production week 33
2017 or before)
New control card (production week
34 2017 or after)
Old power card (production week 33 2017
or before)
Yes (only software version 3.xx or below) Yes (MUST update software to ver-
sion 4.xx or higher)
New power card (production week 34 2017
or after)
Yes (MUST update software to version 3.xx
or below, the fan continuously runs at full
speed)
Yes (only software version 4.xx or
higher)
1.5 Certificates and Approvals
Table 3: Certificates and Approvals
Certification IP20 IP54
EC Declaration of Conformity ✓ ✓
UL Listed ✓–
RCM ✓ ✓
EAC ✓ ✓
UkrSEPRO
089
✓ ✓
The drive complies with UL 508C thermal memory retention requirements. For more information, refer to the section Motor Thermal
Protection in the product-specific design guide.
Introduction
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 7
Danfoss A/S © 2019.11

1.6 Disposal
Do not dispose of equipment containing electrical components together with domestic waste.
Collect it separately in accordance with local and currently valid legislation.
Introduction
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
8 | Danfoss A/S © 2019.11

2 Safety
2.1 Safety Symbols
The following symbols are used in this manual:
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates information considered important, but not hazard-related (for example, messages relating to property damage).
2.2 Qualified Personnel
To allow trouble-free and safe operation of the unit, only qualified personnel with proven skills are allowed to transport, store,
assemble, install, program, commission, maintain, and decommission this equipment.
Persons with proven skills:
• Are qualified electrical engineers, or persons who have received training from qualified electrical engineers and are suitably
experienced to operate devices, systems, plant, and machinery in accordance with pertinent laws and regulations.
• Are familiar with the basic regulations concerning health and safety/accident prevention.
• Have read and understood the safety guidelines given in all manuals provided with the unit, especially the instructions given in the
Operating Guide.
• Have good knowledge of the generic and specialist standards applicable to the specific application.
2.3 Safety Precautions
WARNING
HIGH VOLTAGE
AC drives contain high voltage when connected to AC mains input, DC supply, or load sharing. Failure to perform installation,
start-up, and maintenance by qualified personnel can result in death or serious injury.
-Only qualified personnel must perform installation, start-up, and maintenance.
Safety
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 9
Danfoss A/S © 2019.11

WARNING
UNINTENDED START
When the drive is connected to AC mains, DC supply, or load sharing, the motor may start at any time. Unintended start during
programming, service, or repair work can result in death, serious injury, or property damage. Start the motor with an external
switch, a fieldbus command, an input reference signal from the local control panel (LCP), via remote operation using MCT 10
software, or after a cleared fault condition.
-Disconnect the drive from the mains.
-Press [Off/Reset] on the LCP before programming parameters.
-Ensure that the drive is fully wired and assembled when it is connected to AC mains, DC supply, or load sharing.
WARNING
DISCHARGE TIME
The drive contains DC-link capacitors, which can remain charged even when the drive is not powered. High voltage can be
present even when the warning indicator lights are off.
Failure to wait the specified time after power has been removed before performing service or repair work could result in death
or serious injury.
-Stop the motor.
-Disconnect AC mains, permanent magnet type motors, and remote DC-link supplies, including battery back-ups, UPS, and
DC-link connections to other drives.
-Wait for the capacitors to discharge fully. The minimum waiting time is specified in the table Discharge time and is also
visible on the nameplate on top of the drive.
-Before performing any service or repair work, use an appropriate voltage measuring device to make sure that the capacitors
are fully discharged.
Table 4: Discharge Time
Voltage [V] Power range [kW (hp)] Minimum waiting time (minutes)
3x200 0.25–3.7 (0.33–5) 4
3x200 5.5–11 (7–15) 15
3x400 0.37–7.5 (0.5–10) 4
3x400 11–90 (15–125) 15
3x600 2.2–7.5 (3–10) 4
3x600 11–90 (15–125) 15
WARNING
LEAKAGE CURRENT HAZARD
Leakage currents exceed 3.5 mA. Failure to ground the drive properly can result in death or serious injury.
-Ensure the correct grounding of the equipment by a certified electrical installer.
Safety
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
10 | Danfoss A/S © 2019.11

WARNING
EQUIPMENT HAZARD
Contact with rotating shafts and electrical equipment can result in death or serious injury.
-Ensure that only trained and qualified personnel perform installation, start-up, and maintenance.
-Ensure that electrical work conforms to national and local electrical codes.
-Follow the procedures in this manual.
CAUTION
INTERNAL FAILURE HAZARD
An internal failure in the drive can result in serious injury when the drive is not properly closed.
-Ensure that all safety covers are in place and securely fastened before applying power.
2.4 Motor Thermal Protection
Procedure
1. Set parameter 1-90 Motor Thermal Protection to [4] ETR trip 1 to enable the motor thermal protection function.
Safety
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 11
Danfoss A/S © 2019.11

3 Installation
3.1 Mechanical Installation
3.1.1 Side-by-side Installation
The drive can be mounted side-by-side but requires the clearance above and below for cooling.
Table 5: Clearance Required for Cooling
Power [kW (hp)] Clearance above/below [mm (in)]
Size IP class 3x200–240 V 3x380–480 V 3x525–600 V
H1 IP20 0.25–1.5 (0.33–2) 0.37–1.5 (0.5–2) – 100 (4)
H2 IP20 2.2 (3) 2.2–4 (3–5) – 100 (4)
H3 IP20 3.7 (5) 5.5–7.5 (7.5–10) – 100 (4)
H4 IP20 5.5–7.5 (7.5–10) 11–15 (15–20) – 100 (4)
H5 IP20 11 (15) 18.5–22 (25–30) – 100 (4)
H6 IP20 15–18.5 (20–25) 30–45 (40–60) 18.5–30 (25–40) 200 (7.9)
H7 IP20 22–30 (30–40) 55–75 (70–100) 37–55 (50–70) 200 (7.9)
H8 IP20 37–45 (50–60) 90 (125) 75–90 (100–125) 225 (8.9)
H9 IP20 – – 2.2–7.5 (3–10) 100 (4)
H10 IP20 – – 11–15 (15–20) 200 (7.9)
I2 IP54 – 0.75–4.0 (1–5) – 100 (4)
I3 IP54 – 5.5–7.5 (7.5–10) – 100 (4)
I4 IP54 – 11–18.5 (15–25) – 100 (4)
I6 IP54 – 22–37 (30–50) – 200 (7.9)
I7 IP54 – 45–55 (60–70) – 200 (7.9)
I8 IP54 – 75–90 (100–125) – 225 (8.9)
NOTICE
With IP21/NEMA Type1 option kit mounted, a distance of 50 mm (2 in) between the units is required.
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
12 | Danfoss A/S © 2019.11

3.1.2 Drive Dimensions
e
f
a
e
e
f
a
d
e
A
a
b
B
C
D
e30bf984.10
Illustration 1: Dimensions
Table 6: Dimensions, Enclosure Sizes H1–H5
Enclosure Size H1 H2 H3 H4 H5
IP class IP20 IP20 IP20 IP20 IP20
Power [kW (hp)] 3x200–240 V 0.25–1.5
(0.33–2.0)
2.2 (3.0) 3.7 (5.0) 5.5–7.5
(7.5–10)
11 (15)
3x380–480 V 0.37–1.5
(0.5–2.0)
2.2–4.0
(3.0–5.0)
5.5–7.5
(7.5–10)
11–15
(15–20)
18.5–22
(25–30)
3x525–600 V – – – – –
Height [mm (in)] A 195 (7.7) 227 (8.9) 255 (10.0) 296 (11.7) 334 (13.1)
A (1) 273 (10.7) 303 (11.9) 329 (13.0) 359 (14.1) 402 (15.8)
a183 (7.2) 212 (8.3) 240 (9.4) 275 (10.8) 314 (12.4)
Width [mm (in)] B 75 (3.0) 90 (3.5) 100 (3.9) 135 (5.3) 150 (5.9)
b56 (2.2) 65 (2.6) 74 (2.9) 105 (4.1) 120 (4.7)
Depth [mm (in)] C 168 (6.6) 190 (7.5) 206 (8.1) 241 (9.5) 255 (10)
Mounting hole [mm (in)] d 9 (0.35) 11 (0.43) 11 (0.43) 12.6 (0.50) 12.6 (0.50)
e4.5 (0.18) 5.5 (0.22) 5.5 (0.22) 7 (0.28) 7 (0.28)
f5.3 (0.21) 7.4 (0.29) 8.1 (0.32) 8.4 (0.33) 8.5 (0.33)
Maximum weight kg (lb) 2.1 (4.6) 3.4 (7.5) 4.5 (9.9) 7.9 (17.4) 9.5 (20.9)
1Including decoupling plate.
Table 7: Dimensions, Enclosure Sizes H6–H10
Enclosure Size H6 H7 H8 H9 H10
IP class IP20 IP20 IP20 IP20 IP20
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 13
Danfoss A/S © 2019.11

Enclosure Size H6 H7 H8 H9 H10
Power [kW (hp)] 3x200–240 V 15–18.5
(20–25)
22–30
(30–40)
37–45
(50–60)
– –
3x380–480 V 30–45
(40–60)
55–75
(70–100)
90 (125) – –
3x525–600 V 18.5–30
(25–40)
37–55
(50–70)
75–90
(100–125)
2.2–7.5
(3.0–10)
11–15
(15–20)
Height [mm (in)] A 518 (20.4) 550 (21.7) 660 (26) 269 (10.6) 399 (15.7)
A (1) 595 (23.4)/635 (25),
45 kW
630 (24.8)/690 (27.2),
75 kW
800 (31.5) 374 (14.7) 419 (16.5)
a495 (19.5) 521 (20.5) 631 (24.8) 257 (10.1) 380 (15)
Width [mm (in)] B 239 (9.4) 313 (12.3) 375 (14.8) 130 (5.1) 165 (6.5)
b200 (7.9) 270 (10.6) 330 (13) 110 (4.3) 140 (5.5)
Depth [mm (in)] C 242 (9.5) 335 (13.2) 335 (13.2) 205 (8.0) 248 (9.8)
Mounting hole [mm (in)] d – – – 11 (0.43) 12 (0.47)
e8.5 (0.33) 8.5 (0.33) 8.5 (0.33) 5.5 (0.22) 6.8 (0.27)
f15 (0.6) 17 (0.67) 17 (0.67) 9 (0.35) 7.5 (0.30)
Maximum weight kg (lb) 24.5 (54) 36 (79) 51 (112) 6.6 (14.6) 12 (26.5)
1Including decoupling plate.
Table 8: Dimensions, Enclosure Sizes I2–I8
Enclosure Size I2 I3 I4 I6 I7 I8
IP class IP54 IP54 IP54 IP54 IP54 IP54
Power [kW (hp)] 3x380–480 V 0.75–4.0
(1.0–5.0)
5.5–7.5
(7.5–10)
11–18.5
(15–25)
22–37
(30–50)
45–55
(60–70)
75–90
(100–125)
Height [mm (in)] A 332 (13.1) 368 (14.5) 476 (18.7) 650 (25.6) 680 (26.8) 770 (30)
a318.5 (12.53) 354 (13.9) 460 (18.1) 624 (24.6) 648 (25.5) 739 (29.1)
Width [mm (in)] B 115 (4.5) 135 (5.3) 180 (7.0) 242 (9.5) 308 (12.1) 370 (14.6)
b74 (2.9) 89 (3.5) 133 (5.2) 210 (8.3) 272 (10.7) 334 (13.2)
Depth [mm (in)] C 225 (8.9) 237 (9.3) 290 (11.4) 260 (10.2) 310 (12.2) 335 (13.2)
Mounting hole [mm (in)] d 11 (0.43) 12 (0.47) 12 (0.47) 19 (0.75) 19 (0.75) 19 (0.75)
e5.5 (0.22) 6.5 (0.26) 6.5 (0.26) 9 (0.35) 9 (0.35) 9 (0.35)
f9 (0.35) 9.5 (0.37) 9.5 (0.37) 9 (0.35) 9.8 (0.39) 9.8 (0.39)
Maximum weight kg (lb) 5.3 (11.7) 7.2 (15.9) 13.8 (30.42) 27 (59.5) 45 (99.2) 65 (143.3)
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
14 | Danfoss A/S © 2019.11

The dimensions are only for the physical units. When installing in an application, allow space above and below the units for cooling.
The amount of space for free air passage is listed in 3.1.1 Side-by-side Installation.
3.2 Electrical Installation
3.2.1 Electrical Installation in General
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper conductors are
required. 75 °C (167 °F) is recommended.
Table 9: Tightening Torques for Enclosure Sizes H1–H8, 3x200–240 V & 3x380–480 V
Power [kW (hp)] Torque [Nm (in-lb)]
Enclo‐
sure
size
IP class 3x200–240 V 3x380–480 V Mains Motor DC con‐
nection
Control
terminals
Ground Relay
H1 IP20 0.25–1.5
(0.33–2)
0.37–1.5
(0.5–2)
0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
H2 IP20 2.2 (3) 2.2–4.0 (3–5) 0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
H3 IP20 3.7 (5) 5.5–7.5 (7.5–10) 0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
H4 IP20 5.5–7.5
(7.5–10)
11–15
(15–20)
1.2 (11) 1.2 (11) 1.2 (11) 0.5 (4) 0.8 (7) 0.5 (4)
H5 IP20 11 (15) 18.5–22 (25–30) 1.2 (11) 1.2 (11) 1.2 (11) 0.5 (4) 0.8 (7) 0.5 (4)
H6 IP20 15–18.5
(20–25)
30–45
(40–60)
4.5 (40) 4.5 (40) – 0.5 (4) 3 (27) 0.5 (4)
H7 IP20 22–30 (30–40) 55 (70) 10 (89) 10 (89) – 0.5 (4) 3 (27) 0.5 (4)
H7 IP20 – 75 (100) 14 (124) 14 (124) – 0.5 (4) 3 (27) 0.5 (4)
H8 IP20 37–45 (50–60) 90 (125) 24 (212) (1) 24 (212) (1) – 0.5 (4) 3 (27) 0.5 (4)
1Cable dimensions >95 mm2.
Table 10: Tightening Torques for Enclosure Sizes I2–I8
Power [kW (hp)] Torque [Nm (in-lb)]
Enclosure
size
IP class 3x380–480 V Mains Motor DC connec‐
tion
Control ter‐
minals
Ground Relay
I2 IP54 0.75–4.0 (1–5) 0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
I3 IP54 5.5–7.5 (7.5–10) 0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
I4 IP54 11–18.5 (15–25) 1.2 (11) 1.2 (11) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4)
I6 IP54 22–37 (30–50) 4.5 (40) 4.5 (40) – 0.5 (4) 3 (27) 0.6 (5)
I7 IP54 45–55 (60–70) 10 (89) 10 (89) – 0.5 (4) 3 (27) 0.6 (5)
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 15
Danfoss A/S © 2019.11

Power [kW (hp)] Torque [Nm (in-lb)]
I8 IP54 75–90 (100–125) 14 (124)/24
(212) (1)
14 (124)/24
(212) (1)
– 0.5 (4) 3 (27) 0.6 (5)
1Cable dimensions ≤95 mm2.
Table 11: Tightening Torques for Enclosure Sizes H6–H10, 3x525–600 V
Power [kW (hp)] Torque [Nm (in-lb)]
Enclo‐
sure size
IP class 3x525–600 V Mains Motor DC connec‐
tion
Control ter‐
minals
Ground Relay
H9 IP20 2.2–7.5 (3–10) 1.8 (16) 1.8 (16) Not recom-
mended
0.5 (4) 3 (27) 0.6 (5)
H10 IP20 11–15 (15–20) 1.8 (16) 1.8 (16) Not recom-
mended
0.5 (4) 3 (27) 0.6 (5)
H6 IP20 18.5–30 (25–40) 4.5 (40) 4.5 (40) – 0.5 (4) 3 (27) 0.5 (4)
H7 IP20 37–55 (50–70) 10 (89) 10 (89) – 0.5 (4) 3 (27) 0.5 (4)
H8 IP20 75–90 (100–125) 14 (124)/24
(212) (1)
14 (124)/24
(212) (1)
– 0.5 (4) 3 (27) 0.5 (4)
1Cable dimensions ≤95 mm2.
3.2.2 IT Mains
CAUTION
IT Mains
Installation on isolated mains source, that is, IT mains.
-Ensure that the supply voltage does not exceed 440 V (3x380–480 V units) when connected to mains.
On IP20, 200–240 V, 0.25–11 kW (0.33–15 hp) and 380–480 V, IP20, 0.37–22 kW (0.5–30 hp) units, open the RFI switch by removing the
screw on the side of the drive when at IT grid.
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
16 | Danfoss A/S © 2019.11

e30bb612.10
1
1EMC screw
Illustration 2: IP20, 200–240 V, 0.25–11 kW (0.33–15 hp), IP20, 0.37–22 kW (0.5–30 hp), 380–480 V
On 400 V, 30–90 kW (40–125 hp) and 600 V units, set parameter 14-50 RFI Filter to [0] Off when operating in IT mains.
For IP54, 400 V, 0.75–18.5 kW (1–25 hp) units, the EMC screw is inside the drive, as shown in the the following illustration.
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 17
Danfoss A/S © 2019.11

e30bc251.10
1EMC screw
Illustration 3: IP54, 400 V, 0.75–18.5 kW (1–25 hp)
NOTICE
If reinserted, use only M3x12 screw.
3.2.3 Mains and Motor Connection
3.2.3.1 Introduction
The drive is designed to operate all standard 3-phase asynchronous motors.
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
18 | Danfoss A/S © 2019.11

• Use a shielded/armored motor cable to comply with EMC emission specifications and connect this cable to both the decoupling
plate and the motor.
• Keep the motor cable as short as possible to reduce the noise level and leakage currents.
• For further details on mounting the decoupling plate, see VLT® HVAC Basic Drive Decoupling Plate Mounting Instruction.
• Also see EMC-Correct Installation in the 3.2.5 EMC-correct Electrical Installation.
3.2.3.2 Connecting to Mains and Motor
1. Mount the ground cables to the ground terminal.
2. Connect the motor to terminals U, V, and W, and then tighten the screws according to the torques.
3. Connect the mains supply to terminals L1, L2, and L3, and then tighten the screws according to the torques described in 3.2.1
Electrical Installation in General.
3.2.3.3 Relays and Terminals on Enclosure Sizes H1–H5
e30bb634.10
1
2
2
3
4
M
ot
or
U
V W -DC
+DC
M
AINS
1Mains
3Motor
2Ground
4Relays
Illustration 4: Enclosure Sizes H1–H5, IP20, 200–240 V, 0.25–11 kW (0.33–15 hp), IP20, 380–480 V, 0.37–22 kW (0.5–30 hp)
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078| 19
Danfoss A/S © 2019.11

3.2.3.4 Relays and Terminals on Enclosure Size H6
1
95
99
L1 91 / L2 92 / L3 93
U 96 /
V 97 /
W 98
03 02 01
06 05 04
2
3
4
e30bb762.11
1Mains
3Ground
2Motor
4Relays
Illustration 5: Enclosure Size H6 , IP20, 380–480 V, 30–45 kW (40–60 hp) , IP20, 200–240 V, 15–18.5 kW (20–25 hp) , IP20, 525–600 V, 22–30
kW (30–40 hp)
Installation
Operating Guide | VLT® HVAC Basic Drive FC 101
AQ275641848264en-000101 / 132R0078
20 | Danfoss A/S © 2019.11
