Danfoss VM2 User manual

1
Installation Guide
VM2, VB2
Danfoss Heating VI.HB.C2.00 DH-SMT/SI
DN L3(mm)
15 69
20 74
25 79
32 104
40 114
50 134
DN L1(mm)
15 131
20 141
25 159
32 196
40 196
50 228
DN L(mm)
15 65
20 70
25 75
32 100
40 110
50 130
DN L2(mm)
15 139
20 154
25 159
32 184
40 294
50 330
LL1L2
L3
VM 2 VB 2
Max. 25 Nm
2
1
Max. 25 Nm
32 mm
2
1

AMV 10, 13 AMV 20, 23, 30, 33
Type DN k VS AMV(E) 10/13 AMV(E) 20/23;
AMV(E) 30/33
(m3/h)
VM 2
15 0,25-4,0 • •
20 4,0 • •
20 6,3 -•
25 6,3 • •
25 8,0 -•
32 10 -•
40 16 -•
50 25 -•
Type DN k VS AMV(E) 10/13 AMV(E) 20/23;
AMV(E) 30/33
(m3/h)
VB 2 15-20 0,25-6,3 • •
25-50 10-40 -•
AMV(E) 10, AMV(E) 13
VM2 DN 15 - 25
AMV(E) 20, 30; AMV(E) 23, 33
VM2 DN 15 - 50
AMV(E) 10, AMV(E) 13
VB2 DN 15 - 25
AMV(E) 20, 30; AMV(E) 23, 33
VB2 DN 15 - 50
Tmax 150°C
VM2 / VB2 + AMV(E) 20, 23, 30, 33
Tmax 130°C
VM2/VB2 + AMV(E) 10, 13
p max
PN 25
∆p max
16×10 5Pa (16 bar)
Installation Guide VM2, VB2
Produced by Danfoss A/S © 03/2013
73690530/VI.HB.C2.00
