Danfoss DHP-M Guide

MAKING MODERN LIVING POSSIBLE
Commissioning
DHP-M
www.heating.danfoss.com

Danfoss A/S is not liable or bound by warranty if these
instructions are not adhered to during installation or service.
The English language is used for the original instructions.
Other languages are a translation of the original instructions.
(Directive 2006/42/EC)
© Copyright Danfoss A/S

Table of Contents
1 About documents and decals ........................................................ 4
1.1 Introduction ................................................................ 4
1.2 Symbols in documents .......................................................... 4
1.3 Symbols on decals ............................................................ 5
2Important information/Safety instructions ............................................... 6
2.1 General safety precautions ....................................................... 6
2.2 Refrigerant ................................................................. 7
2.3 Electrical connection ........................................................... 9
2.4 Water quality ................................................................ 9
2.5 Commissioning .............................................................. 10
3 Checking piping and electrical installation ............................................... 11
3.1 Checking piping installation ...................................................... 11
3.2 Checking electrical installation ..................................................... 11
4 Filling and bleeding .............................................................. 13
4.1 Filling and bleeding the water heater and heating system ................................... 13
4.2 Filling and bleeding the brine circuit ................................................. 13
5 Configuration of control system ...................................................... 15
5.1 Display description ............................................................ 15
5.2 Select display language ......................................................... 16
5.3 Setting date and time .......................................................... 16
5.4 Adjusting the indoor temperature .................................................. 16
5.5 Adjusting the Heat Curve ........................................................ 17
5.6 Heating Settings .............................................................. 19
5.7 Network connection, Online and setting up primary and secondary functionality .................... 19
6 Manual test .................................................................... 22
6.1 Activate manual test ........................................................... 22
7 Starting and tuning the system ...................................................... 26
7.1 Enable functions .............................................................. 26
7.2 Activate / deactivate functions ..................................................... 26
7.3 Selecting operating mode ....................................................... 26
7.4 System information ............................................................ 28
7.5 Checking sensors ............................................................. 29
7.6 Checking abnormal noise ........................................................ 30
7.7 Activating accessories .......................................................... 31
7.8 Distribution circuits ............................................................ 33
7.9 Completed commissioning ....................................................... 34
8 Installation protocol and customer information ........................................... 35
8.1 Installation protocol ........................................................... 35
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 3

1 About documents and decals
1.1 Introduction
The following documents are available for this product:
▪The Installation Quick Guide is an illustrated step-by-step guide on how to install the heat pump.
Supplied with the heat pump on delivery.
▪Installation Guide. Complements the Installation Quick Guide and gives thorough information on how to install the heat pump.
Available for download, see below.
▪The Commissioning Guide contains the required information in order to commission the heat pump and tune the heating system.
Available for download, see below.
▪The Wiring Diagrams for the heat pump intended for fault tracing and service.
Available for download, see below.
▪The User Guide is intended for the end user and must be handed over and gone through with the end user when installation and
commissioning is completed.
Supplied with the heat pump on delivery.
▪The Technical Description contains information about the heat pump’s function, fault tracing and technical data.
Available for download, see below.
▪Country specific instructions and forms are available where relevant.
Supplied with the heat pump on delivery.
▪Self-adhesive decals with translation text. Must be placed on the manufacturing plate in conjunction with installation.
Supplied with the heat pump on delivery.
Documents not delivered with the heat pump are available for download here:
www.documentation.heatpump.danfoss.com
1.2 Symbols in documents
The instructions contain different warning symbols, which, together with text, indicate to the user that there are risks involved with ac-
tions to be taken.
The symbols are displayed to the left of the text and three different symbols are used to indicate the degree of danger:
Danger Indicates an immediate danger that leads to fatal or serious injury if
necessary measures are not taken.
Warning Risk of personal injury!
Indicates a possible danger that can lead to fatal or serious injury if
necessary measures are not taken.
Caution Risk of installation damage.
Indicates a possible hazard that can lead to item damage if necessary
measures are not taken.
A fourth symbol is used to give practical information or tips on how to perform a procedure.
N
Information regarding making the handling of the installation easier
or a possible operational technical disadvantage.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
4

1.3 Symbols on decals
The following symbols can occur on decals on the different parts of the heat pump. Which symbols are used depends on the heat pump
model.
1.3.1 General
!
Warning, danger!
!
Read the documentation provided.
Read the documentation provided.
Warning, hazardous electrical voltage!
Warning, hot surfaces!
Warning, moving parts!
Warning, risk of crushing injury!
1.3.2 Electrical components
Explanation
Component, ordinary delivery according to proposed system solutions
Components, accessories according to proposed system solutions
1.3.3 Pipe connections
Tap water
Heating system
Brine system
Defrosting tank
Expansion tank with safety valve, brine
Air bleeding
Temperature and pressure relief valve
Outdoor unit
Water heater
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 5

2 Important information/Safety instructions
2.1 General safety precautions
Warning This appliance can be used by children aged 8 years and above, and
by persons with reduced physical, sensory or mental capabilities or
lack of experience or knowledge, provided that they are supervised or
have been instructed in the safe use of the appliance and understand
the hazards involved. Children must not clean or carry out user main-
tenance on the appliance except under adult supervision.
Warning Ensure that children do not play with the product.
Warning The installation must only be carried out by a qualified installation en-
gineer, following applicable rules and regulations in addition to these
installation instructions.
Caution The heat pump must be located in a frost-free environment!
Caution Installation and connection should be carried out in accordance with
the instructions, in order to avoid subjecting local residents to noise
disturbance.
Caution The heating appliance should be placed on a stable surface that can
support the gross weight of the heating appliance.
Caution Before the heat pump is powered, you must ensure that the heating
system and coolant system, including the heating pump, are full and
bled; otherwise, their circulation pumps may be damaged.
Caution If the electrician wishes to test the electrical connections before the
above is carried out, this should only be done after ensuring that the
heat transfer fluid pump and coolant pump are disconnected.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
6

Caution When filling the coolant system the coolant pump must be operating;
you must ensure that the compressor and the heat transfer pump can-
not start.
Caution This appliance is intended for use by expert or trained users in shops,
in light industry and on farms, or for commercial use by lay people.
Caution In accordance with EN60335-2-40, this product is classified as "not
available to the general public." This means that the product is de-
signed to be handled by trained staff and installed in an engine room
or similar.
Caution Isolate the power supply to the heat pump while servicing the appli-
ance or replacing parts.
Caution Only spare parts approved by Danfoss Värmepumpar may be used for
this appliance.
N
In normal operation the heat pump generates noise and vibrations.
The appliance should be set up and connected in accordance with the
instructions in order to avoid noise being spread to noise-sensitive
areas.
2.2 Refrigerant
2.2.1 Refrigerant
Caution Work on the refrigerant circuit must only be carried out by a certified
refrigeration engineer.
Although the heat pump's cooling system (refrigerant circuit) is filled with a chlorine-free and environmentally-approved refrigerant that
will not affect the ozone layer, work on this system may only be carried out by authorised persons.
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 7

2.2.2 Fire risk
The refrigerant is not combustible or explosive in normal conditions.
2.2.3 Toxicity
In normal use and normal conditions the refrigerant has low toxicity. Even though the toxicity of the refrigerant is low, it can cause injury
(or even death) in abnormal circumstances or if deliberately abused.
Warning Risk of personal injury! Spaces in which heavy vapor can collect below
the level of the air must be well ventilated.
Refrigerant vapour is heavier than air, and in enclosed spaces or in areas below the level of the door, for example, seepage can give rise
to high concentrations with a resultant risk of suffocation due to lack of oxygen.
Warning Risk of personal injury! Refrigerant exposed to a naked flame creates a
poisonous irritating gas. This gas can be detected by its odor even at
concentrations below its permitted levels. Evacuate the area until it
has been sufficiently ventilated.
2.2.4 Working on the refrigerant circuit
Caution When the refrigerant circuit is repaired, the refrigerant must not be re-
leased from the heat pump - it must handled appropriately.
Draining and refilling must only be carried out using new refrigerant (for the amount and type of refrigerant see manufacturer's plate)
through the service valves.
Caution All warranties will become void if a refrigerant, other than what Dan-
foss specifies, is used for refilling.
2.2.5 Scrapping
Caution When the heat pump is to be scrapped the refrigerant must be extrac-
ted for disposal. Local rules and regulations related to the disposal of
refrigerant must be followed.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
8

2.3 Electrical connection
Warning Hazardous electrical voltage! The terminal blocks are live and can
cause death through electric shock. All power supplies must be isola-
ted before electrical installation is started. The heat pump is connec-
ted internally at the factory, for this reason electrical installation con-
sists primarily of the connection of the power supply.
Caution Electrical installation may only be carried out by an authorized electri-
cian and must follow applicable local and national regulations.
Caution The electrical installation must be carried out using permanently rout-
ed cables and must follow applicable local and national regulations. It
must be possible to isolate the power supply using an all-pole circuit
breaker with a minimum contact gap of 3 mm.
2.4 Water quality
Caution A normal heating system always contains a certain amount of corro-
sion particulates (rust) and sludge products from calcium oxide. This
comes from acid that is naturally occurring in the fresh water that the
system is filled with. It is not good practice to have to fill the heating
system regularly which is why any leakage in the heating system
should be repaired immediately. Normal filling should occur only once
or twice a year. The water in the heating system should be as clean as
possible, always position the dirt filter on the return line from the heat-
ing system to the heat pump, as close to the heat pump as possible.
Caution Hard water; Normally it is not a problem installing a heat pump in
areas with hard water because the normal operating temperature for
the hot water does not exceed 60°C. In areas where there are excep-
tional prevailing conditions with the water one can install a softening
filter, which softens the water, cleans any impurities and prevents the
build up of calcification.
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 9

2.5 Commissioning
Caution The installation may only be commissioned if the heating system and
brine system have been filled and bled. Otherwise the circulation
pumps can be damaged.
Caution If the installation is only to be driven by the immersion heater during
the installation, ensure that the heating system is filled and the brine
pump and compressor cannot be started.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
10

3 Checking piping and electrical installation
3.1 Checking piping installation
During transportation and installation there is a risk that the heat pump may be damaged and components may move or become bent,
and this can cause abnormal noise. It is therefore important to check that the heat pump is free from defects after installation and before
commissioning.
Before filling the heating system, check the pipe installation according to the checklist below.
For further information, also see the Installation Quick Guide.
Piping checklist OK Not OK
Are the pipe connections in accordance with the connection diagram?
Is the dirt strainer fitted on the return pipe? See image below.
Is an expansion tank fitted?
Is a valve pipe with safety valve and manometer fitted?
Is a filler cock with non-return valve for the heating system fitted?
A
DCB
Fig. 1: Dirt strainer
A Stopcock
B Cover
C Dirt strainer
D O-ring
3.2 Checking electrical installation
Before turning on electrical power, check the electrical installation according to the checklist below.
Electrical installation checklist OK Not OK
Are circuit-breakers installed?
Are correct fuses installed? See fuse table below.
Positioning of the outdoor sensor. See "Positioning of the outdoor sensor".
Fuse table
Heat pump Unit M L XL
400 V 3-N 50 Hz heat pump A C40 C50 C63
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 11

Positioning of the outdoor sensor
H
2/3 x H
Recommended location
Unsuitable location
▪Position the outdoor sensor on the north or north west side of the
house.
▪Make sure that the outdoor sensor is not placed in direct sun light.
▪For taller buildings, the sensor should be positioned between the
second and third floors.
▪The sensor location must not be completely protected from the
wind but not placed in a direct draft.
▪The outdoor sensor must not be placed on reflective panel walls.
▪The sensor must be positioned at least 1 m from openings in the
walls which may emit hot air.
▪If the sensor cable is connected through a pipe, the pipe must be
sealed so that the sensor is not affected by outgoing air.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
12

4 Filling and bleeding
4.1 Filling and bleeding the water heater and heating system
Caution The pressure in the heating system must never exceed 6 bar.
Bleed the system thoroughly!
N
Leave all radiator valves fully open.
1. Fill the system with cold water by opening the filler valve on the valve pipe to a pressure of 1 bar.
2. Open all radiator valves fully.
3. Bleed all radiators.
4. Refill the heating system to a pressure of min. 1 bar.
5. Repeat the procedure until all air has been removed.
6. Check the system for leakage.
4.2 Filling and bleeding the brine circuit
4.2.1 Introduction
Caution Before the brine circuit is filled, the electrical installation must be com-
pleted and checked so that the brine pump can be manoeuvred.
Caution Always check local rules and regulations before filling with antifreeze.
Caution The pressure in the brine circuit must never exceed 6 bar, and the dif-
ferential pressure must be at least 1.2 bar.
Bleed the system thoroughly!
N
Antifreeze with anti-corrosive properties must be used so that frost
protection down to -17 ±2°C is achieved.
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 13

4.2.2 Filling
1. Set the heat pump to OFF on the control panel.
2. Mix water and antifreeze to the correct freezing point in an external container .
N
Ensure that the external container contains the requisite
amount of brine.
3. Use a refractometer to check the freezing point, -17±2°C.
4. Use an external pump to fill the brine system. Connect the pressure side of the pump to the filler cock.
5. Close the shut-off valve on the filler cock.
6. Open the suction valve on the filler cock and the return valve on the brine system.
7. Connect a transparent hose to the filler cock. The hose should discharge into the external container.
8. Open the return valve on the filler cock.
9. Start the external pump and fill the brine circuit .
N
Allow the external pump to run until the manual test of the
brine pump is complete. See "Manual test".
Check the brine level in the external container at regular inter-
vals.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
14

5 Configuration of control system
5.1 Display description
Start screen
The screen which appears when the system is up and running.
Here you can also carry out comfort adjustment:
1. Drag clockwise or anticlockwise to raise or lower the offset.
Each point represents an increase/decrease of 1°C.
2. Alternatively, press or
Menu screen
This screen appears when you have pressed on the start screen.
Drop down view
There is a quick link to system information. Press
11:20
at the top of any screen .
This screen appears where system information is presented.
Press
11:20
+2
5˚C
09/07/2015 13:15
at the bottom of the drop down view to hide the screen.
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 15

5.2 Select display language
1. Press in the upper left corner of the Start screen
2. Press
3. Press on the text Language.
4. Select language.
5. Press to return to System settings.
Or press in the upper left corner to return to the Menu screen.
5.3 Setting date and time
1. Press in the upper left corner of the Start screen.
2. Press
3. Press on the text System settings.
4. Press on the text Date/time.
5. Press +or –for each field to change the setting.
6. Press to confirm settings.
7. Press to return to System settings.
Or press in the upper left corner to return to the Menu screen.
5.4 Adjusting the indoor temperature
The heat curve is a graph that compares the outdoor temperature with the supply temperature. The colder the outdoor temperature is,
the more heat is supplied to the heating system. The heat curve is adjusted during installation. It must however be re-adjusted later to
obtain a pleasant indoor temperature in all weather conditions.
For an explanation of the factory pre-set heat curve, see Adjusting the Heat Curve.
At an outdoor temperature of 0°C the supply temperature should be 40°C. Note that this is only a benchmark. There are radiator sys-
tems, floor heating systems and other types of heating system which require either lower or higher temperatures.
At outdoor temperatures below 0°C, supply line water hotter than 40°C is supplied to the radiators. Supply line water colder than 40°C is
supplied if the outdoor temperature is above 0°C.
A correctly set heat curve reduces the need for maintenance, as well as making operation more energy-efficient.
The indoor temperature is adjusted by changing the heat curve of the heat pump. This curve is the control system's tool for calculating
the correct supply temperature of water for the heating system.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
16

Comfort adjustment, to change temperature
Comfort adjustment means moving the whole curve upwards or downwards.
Drag clockwise or anticlockwise to raise or lower the offset. Each point represents an increase/
decrease of approximately 1°C of the supply line temperature, depending on comfort factor set-
tings.
Alternatively, press or
NOTE: This option should be primarily used for temporary temperature adjustments. When permanently changing the indoor tempera-
ture for a more precise indoor climate, change the heat curve settings.
5.5 Adjusting the Heat Curve
The Curve indicator has two modes that can be toggled by pressing the Curve indicator symbol.
40
When lit, the curve is adjusted as one unit.
40
When not lit, individual curve points can be moved separately.
1. Press on the Start screen to open the Menu screen.
2. Press
3. Press if the Heat curve is not shown.
4. There are two ways of adjusting the heat curve:
▪If the Curve indicator
40
is lit, press or to adjust the entire curve.
Or:
▪If the Curve indicator
40
is not lit individual points can be moved separately by pressing
and to the desired temperature.
5. Confirm the new selection by pressing
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 17

Symbol description
Fig. 1: The figure shows the standard curve 40
Symbol description
45
(+2)
Shows when the curve is comfort-adjusted. The digit shows how much.
Shows that the comfort adjustment window is inactive. Press on the symbol to open comfort
adjustment.
Shows that the comfort adjustment window is active.
Shows that the heat curve window is inactive. Press on the symbol to open heat curve settings.
Shows that the heat curve window is active. This window is the default window.
Shows that the heating settings window is inactive. Press on the symbol to open heating set-
tings.
Shows that the heating settings window is active.
40
When the curve indicator is lit, press or to move whole curve upwards or downwards.
40
When the curve indicator is not lit, press or to move individual curve points upwards or
downwards.
Press to reset to factory settings.
Indicates that underfloor heating is active and radiator heating is deactivated.
See chapter Default Heating Settings for more information.
Indicates that radiator heating is active and underfloor heating is deactivated.
See chapter Default Heating Settings for more information.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
18

5.6 Heating Settings
In Heating settings, you can set seasonal stop, min/max supply line temperature and comfort factor.
The Comfort factor (0 - 3) influences the desired Supply line (HP) value. If the Comfort factor is set to for example 3, an increase of the of
the Comfort wheel setting with +1 will result in an increase of the supply line temperature with +3 ºC.
Default value is 1x.
1. Press on the Start screen to open the Menu screen.
2. Press
3. Press if the Heat settings window is not shown.
4. Make the desired changes.
5. Confirm settings by pressing
5.7 Network connection, Online and setting up primary and secondary functionality
Danfoss Online
The heat pump is factory prepared for monitoring (and as an additional service being operated) remotely via internet. (Danfoss Online)
In order to use the Danfoss Online service:
▪Make sure that there is an available internet connection (router or equivalent) in the building
▪An account and registration is required to use the Danfoss Online service.
For more information, see:
www.documentation.heatpump.danfoss.com
▪Make a note of the heat pump MAC-address. The MAC-address is available in the Network menu in the display
Bear in mind that firewalls, deficient connections etc. can cause problems that will prevent desired functionality. Some operators, munic-
ipal networks etc. does not allow traffic through their firewalls.
Contact the internet service provider or network administrator if there are any such problems.
Connecting to internet
Connect the commissioned heat pump to an existing internet connection (router or equivalent). Use the RJ45 connection placed below
the display (CM module) behind the front panel. Use a patch cable (not cross over cable).
Network settings
In the Network settings DHCP (factory default) or Static IP-address can be selected. For DHCP, the router in the local network will provide
IP-address etc. See Menu settings.
If Static is selected, then IP-address, Network mask, IP gateway, DNS1 and DNS2 must be set manually. See Menu settings.
Commissioning DHP-M
Danfoss Heating Solutions VIJSE302 19

Two heat pumps, setting up primary and secondary functionality
First ensure that the primary is correctly set up with a valid IP number in the "Network
settings" menu. (You should NOT use dhcp.)
In the "primary/secondary" menu ensure that the unit Id and the number of secondary
units is correctly configured. Once the primary has been correctly configured. Proceed
to setup the secondary unit.
On the secondary unit, go to the network settings menu and configure the machine to
be on the same subnet.
Finally, in the "primary/secondary" menu, configure the secondary unit.
No external network connection to the system. Ethernet cable: Standard Cat 5 network cable, RJ 45.
1 2
1. Primary (controlling) heat pump with IP address e.g. 192.168.0.100
2. Secondary heat pump with IP address e.g. 192.168.0.102
The secondary heat pump must always point to the primary heat pump IP address.
Commissioning DHP-M
VIJSE302 Danfoss Heating Solutions
20
