DAQ system PCI-AIO02 User manual

PCI-AIO02 Users Manual (Rev 0.8)
-1- http://www.daqsystem.com
PCI-AIO02
User’s Manual
Windows, Windows2000, Windows NT and Windows XP are trademarks of Microsoft. We acknowledge that the
trademarks or service names of all other organizations mentioned in this document as their own property.
Information furnished by DAQ system is believed to be accurate and reliable. However, no responsibility is assumed by DAQ
system for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is
granted by implication or otherwise under any patent or copyrights of DAQ system.
The information in this document is subject to change without notice and no part of this document may be copied or
reproduced without the prior written consent.
Copyrights 2009 DAQ system, All rights reserved.

PCI-AIO02 Users Manual (Rev 0.8)
-2- http://www.daqsystem.com
Contents
1. PCI-AIO02 Block Diagram
2. Connector Pin Map
3. Board Address Setup
4. Analog Output Connection Diagram
5. Analog Input Connection Diagram
6. Installation
6.1 Package content
6.2 Installation Sequence
7. Sample Program
7.1 System Function
7.2 ADC Test Function
7.3 DAC Test Function
7.4 Select Channel graph
References

PCI-AIO02 Users Manual (Rev 0.8)
-3- http://www.daqsystem.com
UPDATE HISTORY
2010-10-12
API Function Add
ADC_StartBufferedRead()
ADC_StoptBufferedRead()
ADC_GetBufferedData()
ADC_GetBufferedDataEx()
ADC_SetAvgCounter()
API Function Explanation
ADC_GetData()
2010-11-05
API Function Add
GetBoardVersion() - It will apply to Board Version2.
2011-06-13
Change Document
12-Bit ADC -> 12/14/16-Bit ADC
2011-07-04
6. Installation Add
7. Sample Program Add

PCI-AIO02 Users Manual (Rev 0.8)
-4- http://www.daqsystem.com
1. PCI-AIO02 Block Diagram
PCI Target
PCI BUS
Local Bus
Address
Data(Mem,I/O)
ADC 8SE/4DI
12/14/16-bit
Resolution
External
Interface
IO Decoder
To each IO
Module
PCI-AIO02 INTERNAL BLOCK
MEM Decoder
BUS Mux
DAC 8ch
16bit Resolution
[Figure 1-1. PCI-AIO02 Internal Block Diagram]
The PCI-AIO02 is a board having the functions of analog I/O PCI board with the 16-bit DAC 8
channels, 12/14/16-bit ADC 8 channels.
-PCI 32-bit, 33MHz 5/3.3V Compatible Target Board
-8-Ch Input 12/14/16-비트 ADC(8-Ch SE or 4-Ch DI)
-Support various ADC Input Range (+5V, +10V, ±5V, ±10V)
-Support 10usec Settling time 8-Ch DAC
-Support various DAC Output Range (+5V, +10V, +10.8V, ±5, ±10, ±10.8V)

PCI-AIO02 Users Manual (Rev 0.8)
-5- http://www.daqsystem.com
2. Connector Pin Map
The D-SUB 15pin and 25pin connector which was fixed to standard PCI Bracket is used for Analog
signal Input/Output.
3
1
2
5
4
8
6
7
10
9
13
11
12
15
14
13
25
1
14
[Figure 2-1. PCI-AIO02 PCI Bracket]

PCI-AIO02 Users Manual (Rev 0.8)
-6- http://www.daqsystem.com
3
10
9
8
7
6
1
2
5
4
13
12
11
19
18
17
16
15
14
N.C
EREF25
EXT_FACE_IN1
EXT_PACE_OUT0
EXT_TRG0
DGND
N.C
N.C
AGND
EXT_FACE_IN0
EXT_TRG1
EXT_PACE_OUT1 25
24
23
22
21
20
N.C
N.C
ADC IN6
N.C
ADC IN4
ADC IN2
ADC IN0
ADC IN1
ADC IN3
ADC IN5
ADC IN7
N.C
N.C
[Figure 2-2. PCI-AIO02 D-sub25 Connecter Pin]

PCI-AIO02 Users Manual (Rev 0.8)
-7- http://www.daqsystem.com
[Table 1. PCI-AIO02 D-sub 25 Pin Connecter Description]
Pin#
Pin Name
Description
Remark
1
ADC IN0
Analog Input Channel 0
+/- 10V Input
2
ADC IN2
Analog Input Channel 2
+/- 10V Input
3
ADC IN4
Analog Input Channel 4
+/- 10V Input
4
ADC IN6
Analog Input Channel 6
+/- 10V Input
5
NC
No Connection
6
NC
No Connection
7
NC
No Connection
8
NC
No Connection
9
EREF25
2.5V Analog Reference Output
2.5V Output
10
EXT_TRG0
Trigger External Input
It will be upgraded in the future.
11
EXT_PACE_OUT0
Digital External Output
It will be upgraded in the future.
12
EXT_FACE_IN1
Digital External Input
It will be upgraded in the future.
13
DGND
Digital GROUND
0V GROUND
14
ADC IN1
Analog Input Channel 1
+/- 10V Input
15
ADC IN3
Analog Input Channel 3
+/- 10V Input
16
ADC IN5
Analog Input Channel 5
+/- 10V Input
17
ADC IN7
Analog Input Channel 7
+/- 10V Input
18
NC
No Connection
19
NC
No Connection
20
NC
No Connection
21
NC
No Connection
22
AGND
Analog Input GROUND
0V GROUND
23
EXT_FACE_IN0
Digital External Input
It will be upgraded in the future.
24
EXT_TRG1
Trigger External Input
It will be upgraded in the future.
25
EXT_PACE_OUT1
Digital External Output
It will be upgraded in the future.

PCI-AIO02 Users Manual (Rev 0.8)
-8- http://www.daqsystem.com
DAC_STEP0_OUT
DAC_OUT6
DAC_OUT4
DAC_OUT2
DAC_OUT0
AGND
AGND
AGND
AGND
3
1
2
5
4
8
6
7
10
9
13
11
12
15
14 DAC_STEP1_OUT
DAC_OUT7
DAC_OUT5
DAC_OUT3
DAC_OUT1
DGND
[Figure 2-3. PCI-AIO02 D-sub15 Connecter Pin]
[Table 2. PCI-AIO02 D-sub 15 Pin Connecter Description]
Pin#
Pin Name
Description
Remark
1
DAC_OUT0
Analog Output Channel 0
Max. +/- 10.8V Output
2
DAC_OUT2
Analog Output Channel 2
Max. +/- 10.8V Output
3
DAC_OUT4
Analog Output Channel 4
Max. +/- 10.8V Output
4
DAC_OUT6
Analog Output Channel 6
Max. +/- 10.8V Output
5
DAC_STEP0_OUT
Digital Output 0
It will be upgraded in the future.
6
DAC_OUT1
Analog Output Channel 1
Max. +/- 10.8V Output
7
DAC_OUT3
Analog Output Channel 3
Max. +/- 10.8V Output
8
DAC_OUT5
Analog Output Channel 5
Max. +/- 10.8V Output
9
DAC_OUT7
Analog Output Channel 7
Max. +/- 10.8V Output
10
DAC_STEP1_OUT
Digital Output 1
It will be upgraded in the future.
11
AGND
Analog GROUND
0V GROUND
12
AGND
Analog GROUND
0V GROUND
13
AGND
Analog GROUND
0V GROUND
14
AGND
Analog GROUND
0V GROUND
15
DGND
Digital GROUND
0V GROUND

PCI-AIO02 Users Manual (Rev 0.8)
-9- http://www.daqsystem.com
3. Board Address Setup
If mounting works in one system that a lot of I/O ports are required, several AIO series boards are
classified according to each board address.
Distribution of each board sets it up through 4 pin DIP switch (SW1). A system is designed of
maximum four boards at the same time so as usable.
SW1 Setup
2 1 ON
OFF
1 2 Board No.
OFF OFF 0
ON OFF 1
OFF ON 2
ON ON 3

PCI-AIO02 Users Manual (Rev 0.8)
-10- http://www.daqsystem.com
4. Analog Output Connection Diagram
DC
DAC CH0-7
EXT
Actuator
AGND
[Figure 4-1. Analog Output Connection]
An analog output goes out through D-sub 15 pin connector like Figure 4-1. The eight analog channel
outputs are making it with bases of channel0 ~ channel 7 by AGND. Always AGND and DAC channel
shall be connected outside with pairs.

PCI-AIO02 Users Manual (Rev 0.8)
-11- http://www.daqsystem.com
5. Analog Input Connection Diagram
An analog input supports SE (Single Ended) Input and DI (Differential Input) method.
ADC CH0-15
EXT
Sensor
AGND
[Figure 5-1. Analog SE (Single Ended) Input Connection]
A common analog GROUND(AGND) works input basis for the SE connection. At this time, the input
channel has total 8 channels.
ADC CH0/2/4/6
EXT
Sensor
ADC CH1/3/5/7
[Figure 5-2. Analog DI (Differential Input) Connection]
An analog DI connection is a difference between two input channel pairs. At this time, the input pairs
connect according (CH0 <-> CH1), (CH2 <-> CH3), (CH4 <-> CH5), (CH6 <-> CH7). So, in case of DI
connection have total 4 input channels.

PCI-AIO02 Users Manual (Rev 0.8)
-12- http://www.daqsystem.com
6. Installation
After unpacking, inspect the board carton to make sure there are no damages on the board.
6.1 Package Content
Product Contents
1. PCI-AIO02 Board
2. CD (Driver/Manual/API/Sample Source etc.)
6.2 Installation Sequence
To install your PCI-AIO01 board in your PC, follow the steps described in the document “How to
install PCI DAQ Board” provided by DAQ System. If the document is missing, you can get it from
www.daqsystem.com. The PCI-AIO02 board is completely Plug & Play. There are no switches or
jumpers to set. Therefore you can install it easily.
- Your OS requirement : Windows 2000 SP4 or Windows XP SP1 above
The PCI-AIO02 connects to PCI Card Port. After that you can show the below picture of “Found
New Hardware Wizard” window.

PCI-AIO02 Users Manual (Rev 0.8)
-13- http://www.daqsystem.com
If new hardware is found, Wizard will ask you to install the corresponding driver. For installation
of the driver, select the item “Install from a list or specific location (Advanced)” and click “Next”
as in the figure.
The driver folder includes a file of “pci_aio02.inf”and “pci_aio02.sys”that it is necessary for
driver installation.
A warning message appears during installation here, press “Continue Anyway”button.
You can show below message window. Process progress as follows.

PCI-AIO02 Users Manual (Rev 0.8)
-14- http://www.daqsystem.com
If the installation is completely finished, you can show below message window.

PCI-AIO02 Users Manual (Rev 0.8)
-15- http://www.daqsystem.com
If the installation is completely finished, you confirm it in the following ways. Do the following
steps to show up the “Device Manager” window. [My Computer -> properties -> Hardware ->
Device Manager -> Multifunction Adaptors -> PCI-AIO02]
If you can see the “PCI-AIO02” at Multifunction Adaptors, the driver installation is to have
been over. (Check the red circle)
Notice : After installation, you should re-boot the system for the proper operation.

PCI-AIO02 Users Manual (Rev 0.8)
-16- http://www.daqsystem.com
7. Sample Program
DAQ system provides a sample program to make the user be familiar with the board operation and
to make the program development easier. You can find the sample program in the CDROM
accompanying with the board. One of the execution file is “PCI_AIO.exe”.
Sample program is provided in source form in order to show the usage of API (Application
Programming Interface) of the board and may be modified for customer’s own usage.
[Figure 7-1. When Sample program “PCI_AIO.exe” is executed]]
To run the sample application program, you need to use API, it is a form of client DLL. To compile
the sample source to make its executable file, you have to use Import Library files and header files.
You can find them in the CDROM. To run the .exe file, the API DLL file (PCI_AIO.DLL) must be in the
same directory with the .exe file or Windows system folder. Another method is to add the directory of
API DLL file to PATH environmental variable.

PCI-AIO02 Users Manual (Rev 0.8)
-17- http://www.daqsystem.com
7.1 System Function
(1) Select Device
Open the device PCI-AIO0 ~ AIO05 Board
(2) Board Number
Select the board number. (0 ~ 3)
(3) „Device Open‟ Button
When the button clicks, open the selected board.
(4) „Device Close‟ Button
When the button clicks, close the operated borad.
(5) Board Version
It display a board hardware version.
7.2 ADC (Analogue Digital Converter) Test Function
(1) „ADC Reset‟ Button
Reset the ADC function.
(2) „ADC Init‟ Button
Initialize the ADC function.
(3) ADC Differential Input
When the box toggles, get the Differential input.
(4) Select Channel
Write the ADC channels. The PCI-AIO01 channel numbers are from 0 to 7.
(5) „ADC Read‟ Button
The ADC input of Select Channel read a data once.
(6) „ADC Read All‟ Button
Read the all current ADC input.
(7) ADC Auto Read
Auto read all current ADC value.

PCI-AIO02 Users Manual (Rev 0.8)
-18- http://www.daqsystem.com
(8) Select Range
Set up the ADC input range per channel. (0 to 5, ±5, 0 to 10V, ±10V)
(9) Voltage Level Conversion
Change the data to voltage level.
(10) Select Resolution
Set up AD Data width (bit).
The AD converter of board can support three resolution (12, 14, 16bit).
(11) CH0 ~ CH15
In case of PCI-AIO01, it use only CH0 ~ CH7.
7.3 DAC Test
(1) „DAC Reset‟ Button
Reset the DAC function.
(2) „DAC Init‟ Button
Initialize the DAC setup.
(3) Select Channel
Write the DAC channel. The PCI-AIO01 channel number is from 0 to 1.
(4) „DAC Out‟ Button
The range is from 0 to 4095 (Refer to API function DAC_GetData() at chapter 8)
Ex) In case of 0 ~ 10V range setup
If output voltage is 5V, the setup value is (5V/ 10V) * 4096 = 2048.
In case of -10 ~ + 10V range setup
If output voltage is 5V, the setup value is (10+5V/20V) * 4096 = 3072.
If output voltage is -5V, the setup value is (10-5V/20V) * 4096 = 1024.
(5) „Select Range‟ Button
Set up the DAC output range per channel. (+5V, +10V, +10.8V, ±5, ±10V, ±10.8V)
(6) DAC Auto Out
All current DAC value automatically output.

PCI-AIO02 Users Manual (Rev 0.8)
-19- http://www.daqsystem.com
7.4 Select Channel Graph
(1) Average Numbers
It designate the data number that a moving average is applied to 0 ~ 255.
It is not applied to AD data collection by ADC_GetData() function.
(2) Offset
It is an offset to display graph.
As an offset value is added to data collection, it is used if data aren’t marked to a graph.
(3) Divide
It is a division value to display graph.
It marks let the data reduction in case of the data aren’t marked if the collected data is too large.
(4) „Set‟ Button
Set the Average Number, Offset, Divide value.

PCI-AIO02 Users Manual (Rev 0.8)
-20- http://www.daqsystem.com
References
1. PCI System Architecture
-- MindShare Inc.
2. PCI Local Bus Specification
-- PCI-SIG
3. General information on PCI board API
-- DAQ system
4. AN201 How to build application using APIs
-- DAQ system
5. AN242 PCI-AIO02 API Programming
-- DAQ system
