DAQ system USB3-DIO01 User manual

USB3-DIO01
User Manual
Version 1.4
ⓒ2005 DAQ SYSTEM Co., Ltd. All rights reserved.
Microsoft®is a registered trademark; Windows®, Windows NT®, Windows XP®, Windows 7®, Windows 8®, Windows 10®
All other trademarks or intellectual property mentioned herein belongs to their respective owners.
Information furnished by DAQ SYSTEM is believed to be accurate and reliable, However, no responsibility is assumed by DAQ SYSTEM for its use, nor
for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under
any patent or copyrights of DAQ SYSTEM.
The information in this document is subject to change without notice and no part of this document may e copied or reproduced without the prior
written consent.

USB3-DIO01 User’s Manual
1
Contents
1. Introduction -------------------------------------------------------------------------- 3
1-1 Product Features ------------------------------------------------------------------------- 4
1-2 Product Application ------------------------------------------------------------------------- 4
2. USB3-DIO01 Board Function
2-1 Block Diagram ------------------------------------------------------------------------ 5
2-2 USB3-DIO01 & ADP-CA01 connection ------------------------------------------------- 6
3. USB3-DIO01 Board Description
3-1 USB3-DIO01 Board Layout ----------------------------------------------------------------- 7
3-2 Device Features --------------------------------------------------------------------- 8
3-3 Connector Pin out
3-3-1 CN1 Connector -------------------------------------------------------------------- 9
3-3-2 J2 Connector ----------------------------------------------------------------- 10
3-3-3 J5 Connector --------------------------------------------------------------------- 10
3-3-4 J7 Connector --------------------------------------------------------------------- 12
3-3-5 J9 Connector -------------------------------------------------------------------- 12
3-3-6 SW1 Switch -------------------------------------------------------------------- 13
3-3-7 J10 Switch -------------------------------------------------------------------- 13
3-3-8 SW3 Switch --------------------------------------------------------------------- 13
4. Installation
4-1 Product Contents ------------------------------------------------------------------------ 14
4-2 Installation Process ------------------------------------------------------------------------ 14

USB3-DIO01 User’s Manual
2
5. Sample Program ------------------------------------------------------------------------ 21
5-1 Image Frame Function ---------------------------------------------------------------- 22
5-2 Camera Function ------------------------------------------------------------------- 23
5-3 DIO Function --------------------------------------------------------------------- 31
5-4 I2C Function -------------------------------------------------------------------- 31
Appendix
A-1 Board Size --------------------------------------------------------------------- 32
A-2 Repair Regulations --------------------------------------------------------------------- 33
References ------------------------------------------------------------------------ 34

USB3-DIO01 User’s Manual
3
1. Introduction
USB3-DIO01 board is a board used by connecting a daughter board in the form of a base board.
[Figure 1-1] shows an example of using the daughter board ADP-CA01. USB3-DIO01 transfers the
video image received from the PC through the USB3.0 interface through the ADP-CA01 board at the
bottom. Converts it into a Camera Link signal and transmits it to the outside. The externally
transmitted camera link signal can be used by connecting to the company's camera link frame grabber
or other companies' products.
[Figure 1-1. USB3-DIO01 Board Usage]

USB3-DIO01 User’s Manual
4
1-1 Product Features
Items
Description
Remark
Hardware
PC Interface
USB 3.0
B-Type
Operation Power
+12VDC/650mA
External 12V DC Power
(A6-Type : 5.5x2.1mm)
Video Interface
Camera Link Output
ADP-CA01
Feature
Interface
On-board Memory
128MB (DDR2) x2
Communication
Simultaneous use of
boards
Max. 4
Software
OS
Windows 2000/XP/7/8/10 (32/64bit)
API
Windows Client DLL API
Development
Support
Sample Program
VC++ (C# please inquire)
Environmental conditions
Operating temperature
range
0 ~ 60℃
Storage temperature
range
-20 ~ 80℃
Humidity range
5 ~ 95%
Non-condensing
Board size
80mm X 110mm
PCB Board size
1-2 Product Applications
Replace Camera Link Camera
Camera Link Camera Test Board

USB3-DIO01 User’s Manual
5
2. USB3-DIO01 Board Function
2-1 Block Diagram
As shown in the figure below, in the case of USB3-DIO01, FPGA Core Logic is in charge of
overall control. The main function is to transmit Image Frame Data to the connector through the
External I/O connector. These functions are performed using API in PC through USB 3.0 interface.
The External I/O connector can be connected to the USB3-CA01 2x25 2.54Pitch Female Plug
connector by using a 2x25 2.54Pitch Male Header connector. For detailed signal specifications,
refer to Section 3-3-3.
USB3-DIO01
USB 2.0
Signals
USB3.0
Interface
External I/O
Additional
Signals
FPGA Core Logic
1 : Camera-Link
Interface
JTAG
D+
D-
VBUS
GND
SSTX+/-
SSRX+/-
USB 3.0
DDR2
[Figure 2-1. USB3-DIO01 Block Diagram]
The FPGA core logic is programmed using JTAG, and the logic program is saved in FPGA
Program Logic and loaded when power is applied.

USB3-DIO01 User’s Manual
6
2-2 USB3-DIO01 & ADP-CA01 connection
Second, it is used by connecting with the ADP-CA01 board through the 50-pin External I/O
connector inside the board. USB3-DIO01, which receives PC's Image Frame Data at high speed,
transmits image information to ADP-CA01, and ADP-CA01 board converts the image signal
according to Camera Link specification and transmits it to the outside through Camera Link
connector. The USB3-DIO01 connection to the ADP-CA01 board provides a low-cost alternative
to expensive Camera Link cameras when building or testing Camera Link frame grabbers..
[Figure 2-2. ADP-CA01 Board Layout]
[Figure 2-3. USB3-DIO01 & ADP-CA01 Connection View]

USB3-DIO01 User’s Manual
7
3. USB3-DIO01 Board Description
3-1 USB3-DIO01 Board Layout
CN1
USB3-DIO01 Board
U5
J7
D4
D8
J5 J2
J4
J11
J9
J1
SW1
J2
ON
1 2 3
U2
U8
U11
U3
D5 D6 D7
J3
USB3-DIO01
Rev. E
U9
U10
J8
U1
REF1 REF2
123 789 123 789
A
C
E
G
J
L
N
R
A
C
E
G
J
L
N
R
DAQ Sysytem
U4
U7
J6
D10
SW3
J12
[Figure 3-1. USB3-DIO01 Layout]
There are six important LEDs on the board, each of which is described below.
D8 : Lights up when the FPGA is operating normally.
D10 : Lights up when power is supplied.
D4 ~ D7 : For test. Not used.

USB3-DIO01 User’s Manual
8
3-2 Device Features
Each board function will be briefly described. For detailed function information, please refer to
the parts specification.
(1) FPGA : U6
All of the functions are controlled by the logic program of the FPGA.
(2) USB3.0 SIE : U5
This block supports USB3.0 Super Speed interface.
(3) EEPROM : U8, U10
The 64K Serial I2C EEPROM contains firmware for USB3.0 SIE
(4) Regulator : U1, U2, U7, U11, U12
The Regulator is supplying the power (1.8V, 3.3V) to the board.

USB3-DIO01 User’s Manual
9
3-3 Connector Pin-out
This section describes the connectors and jumpers used in USB3-DIO01. The main connectors
are CN1, a USB-B type connector for USB connection, and J5, which receives external I/O and
image frames.
3-3-1 CN1 Connector
[Figure 3-2] shows the PIN of the USB3.0 standard powered-B type connector on the
board when viewed from the front where the cable is connected.
USB B type
Connector
12
3 4
10 11
56789
[Figure 3-2. CN1 Connector (USB3.0 standard powered-B type Front View)]
[Table 1. USB3.0 Standard Powered-B Connector]
Pin
Signal Name
Description
Remark
1
VBus
+5V Power
+5V Power
2
USB D-
USB2.0 data (Negative)
USB2.0 Signal
3
USB D+
USB2.0 data (Positive)
USB2.0 Signal
4
GND
Ground for Power Return
USB Power GND
5
StdA_SSTX-
Super Speed Transmitter
(Negative)
USB3.0 Signal
6
StdA_SSTX+
Super Speed Transmitter
(Positive)
USB3.0 Signal
7
GND_DRAIN
Ground for Signal Return
USB Power GND
8
StdA_SSRX+
Super Speed Receiver
(Positive)
USB3.0 Signal
9
StdA_SSRX-
Super Speed Receiver
(Negative)
USB3.0 Signal
10
DPWR
Power Provided by Device
USB Power GND
11
DGND
Ground return for DPWR
USB Power GND

USB3-DIO01 User’s Manual
10
3-3-2 J2 Connector
It is a connector that can interface with USB 3.0 SIE (U5) from the outside through I2C.
In the idle state of I2C, the bus is always high.
12 3
J2
[Figure 3-3. J2 Connector (Top View)]
[Table 2. J2 PIN-OUT]
No.
Name
Description
1
SCL
Serial Clock
2
SDA
Serial DATA
3
GND
Ground
3-3-3 J5 Connector
The figure below shows the pin map of the external input/output J5 connector of the
board. It is used as a signal line for Red, Green, Blue signals, camera control signals CC
(Camera Control) and image control signals (LVAL, FVAL, Clock). The voltage used is 3.3V
(3.135V ~ 3.465V).
1
2
3
4
95
6 8
7
10
11
12
13
14 20 24
2321
22
19
18
17
16
15
J5
26
25 27
28
29
30 36 40
3937
38
35
34
33
32
31
46 50
4947
48
45
44
43
42
41
[Figure 3-4. J5 Connector (Top View)]
[Table 3. J5 Connector]
No.
Name
Description
Remark
1
+3.3V
+3.3V Power
Output
2
+5V
+5V Power
3
DIO_0
Digital Input/Output 0
4
DIO_1
Digital Input/Output 1
5
DIO_2
Digital Input/Output 2
6
DIO_3
Digital Input/Output 3
7
DIO_4
Digital Input/Output 4
8
DIO_5
Digital Input/Output 5

USB3-DIO01 User’s Manual
11
9
DIO_6
Digital Input/Output 6
10
DIO_7
Digital Input/Output 7
11
DIO_8
Digital Input/Output 8
12
DIO_9
Digital Input/Output 9
13
DIO_10
Digital Input/Output 10
14
DIO_11
Digital Input/Output 11
15
DIO_12
Digital Input/Output 12
16
DIO_13
Digital Input/Output 13
17
DIO_14
Digital Input/Output 14
18
DIO_15
Digital Input/Output 15
19
GND
Ground
20
GND
Ground
21
DIO_16
Digital Input/Output 16
22
DIO_17
Digital Input/Output 17
23
DIO_18
Digital Input/Output 18
24
DIO_19
Digital Input/Output 19
25
DIO_20
Digital Input/Output 20
26
DIO_21
Digital Input/Output 21
27
DIO_22
Digital Input/Output 22
28
DIO_23
Digital Input/Output 23
29
DIO_24
Digital Input/Output 24
30
DIO_25
Digital Input/Output 25
31
DIO_26
Digital Input/Output 26
32
DIO_27
Digital Input/Output 27
33
DIO_28
Digital Input/Output 28
34
DIO_29
Digital Input/Output 29
35
DIO_30
Digital Input/Output 30
36
DIO_31
Digital Input/Output 31
37
DIO_32
Digital Input/Output 32
PCLK(Pixel Clock)
38
DIO_33
Digital Input/Output 33
Vsync
39
DIO_34
Digital Input/Output 34
Hsync
40
DIO_35
Digital Input/Output 35
DE(Data Enable)
41
DIO_36
Digital Input/Output 36
42
DIO_37
Digital Input/Output 37
43
DIO_38
Digital Input/Output 38
44
DIO_39
Digital Input/Output 39
45
12V
+12V Power
46
U_SDA
Serial Data
SDA
47
REV0
Reserved 0
MCLK(Master Clock)
48
U_SCL
Serail Clock
SCL

USB3-DIO01 User’s Manual
12
49
GND
Ground
50
GND
Ground
Note) 12V is not applied to pin 45 to boards below Rev C.
3-3-4 J7 Connector
DC-005(2.0) standard external 12V DC Jack power connector. If the USB power is
insufficient, the program may crash or the video may not appear. Use this connector
when power is insufficient. It is also used when using the 5V output of J5 pin 2 of the
connector.
12V 1.0A
[Figure 3-5. Rated output]
3-3-5 J9 Connecter
The J9 connector is used for the FPGA program upgrade. Never use it at the normal
operation. [Figure 3-6] shows the J9 connector.
J9
910 5 6 7
12
34
8
[Figure 3-6. J9 Connecter (Top View)]
[Table 4. J9 Connecter]
No.
Name
Description
1
BTCK
Clock
3
BTMS
Mode Select
5
BTDI
Data In
7
BTDO
Data Out
2,4,8
GND
GND
6
3.3V
+3.3V Power
9
N.C
No Connection
10
PROG_B

USB3-DIO01 User’s Manual
13
3-3-6 SW1 Switch
It is a Reset Switch that is Low Active.
Ground
SW_RST SW1
[Figure 3-7. Switch SW1]
3-3-7 J10 Switch
The USB3-DIO01 board is designed so that up to 8 USB3-DIO01 boards can be used
simultaneously in one system (PC). Each board classification can be set through the 4-
pin DIP switch (J10) in the board.
1
ON
J10
2 3
OFF
[Figure 3-8. Switch J10]
[Table 5. J10 Switch]
1
2
3
Description
OFF
OFF
OFF
Board No. 0
ON
OFF
OFF
Board No. 1
OFF
ON
OFF
Board No. 2
ON
ON
OFF
Board No. 3
OFF
OFF
On
Board No. 4
ON
OFF
On
Board No. 5
OFF
ON
On
Board No. 6
ON
ON
On
Board No. 7
3-3-8 SW3 Switch
Board power (5V from USB or 12V external DC Power) On/Off switch.

USB3-DIO01 User’s Manual
14
4. 설치
4. Installation
After unpacking, inspect the board to make sure there are no damages on the package.
4-1 Package Contents
Product Contents
1. USB3-DIO01 Board
2. USB3(A-B) Cable
3. CD (Driver/Manual/API/Samples etc.)
4-2 Installation Sequence
To install USB3-DIO01 board in your environment, do the following steps. The USB3-DIO01
board is completely Hot-Plug and Plug & Play. Therefore, you can install it easily.
The required PC operating system for the USB3-DIO01 is Windows 2000 SP4 or Windows XP
SP1 higher. The USB3-DIO01 uses USB Super Speed interface thus “xxx USB 3.0 Root Hub”
should be installed in your PC. You can check this condition by doing the following steps.

USB3-DIO01 User’s Manual
15
[Figure 4-1. “Device Manager” window]
The item “USB 3.0 Root Hub” should be shown in the “Device Manager” window as shown in
[Figure 4-1]. After checking the PC environmental conditions for USB3-DIO01, do the following
steps to install the board
(1) Install the USB3-DIO01 board into your system.
(2) Power on the frame grabber.
(3) Confirm the LED (D8) and LED (D10) on the USB3-DIO01 board turns on.
(4) After check the power, Connect USB3 A-B cable between the case and your PC.
The Add New Hardware Wizard will appear in order to install the driver for new hardware.
(5) The Add new Hardware Wizard will install the driver in the following process. The following
install process is explained based on Windows XP operating system.

USB3-DIO01 User’s Manual
16
[Figure 4-2. “Hardware Wizard” window]
If new hardware is found, Wizard will ask you to install the corresponding driver, For installation
of the driver, select item “Install from a list or specific location(Advanced)” and click “Next” as in
the [Figure 4-3].

USB3-DIO01 User’s Manual
17
[Figure 4-3. Specify the driver folder]
Select “Search for the best driver in these locations”. Check “Search removable media (floppy, CD-
ROM)”. Check “include this location in the search”. Click “Browse” button. Select the folder where the
drivers are located. Click “OK”. Click “Next”.
The necessary files are “cyusb3.inf” and “cyusb3.sys” in the driver polder.

USB3-DIO01 User’s Manual
18
[Figure 4-4. Warning window]
When a window’s warning message will be appeared regarding the compatibility problem as
shown the [Figure 4-4] during the installation process, just click “Continue” button and go
on the installation.

USB3-DIO01 User’s Manual
19
If the installation is completely finished, a completion window message shall be shown as
in [Figure 4-5]. Click “Finish”.
[Figure 4-5. “Completion” message window]
