Datecs Zebra PD20 User manual

1 DATECS
Zebra PD20/PD20-1
User Manual

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 2
THE INFORMATION IN THIS DOCUMENT CANNOT BE REPRODUCED IN ANY MECHANICAL, ELECTRICAL
OR ELECTRONIC WAY AND UNDER ANY CIRCUMSTANCES WITHOUT THE WRITTEN CONSENT FROM DATECS LTD.
Address: 4 Datecs Street, Sofia 1592, Bulgaria
Phone: +359 2 816 55 50
Fax: +359 2 816 55 65
E-mail: [email protected]

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 3
REVISION HISTORY
Version
Data
Change description
1.0.0
08.01.2021
First Release
1.1.0
31.03.2021
Added PD20
1.2.0
16.04.2021
Updated “TECHNICAL SPECIFICATIONS”
1.3.0
28.04.2021
Updated section “Status LEDs”
1.4.0
03.06.2021
Updated section “Smart cards reading”
Added section “REGULATORY”

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 4
CONTENTS
REGULATORY........................................................................................................................................................................... 5
TECHNICAL SPECIFICATIONS ................................................................................................................................................... 6
GENERAL VIEW........................................................................................................................................................................ 7
GETTING STARTED................................................................................................................................................................... 9
PERIODIC INSPECTION AND MAINTENANCE ........................................................................................................................ 10
OPERATION MODES .............................................................................................................................................................. 11
APPLICATION DOWNLOAD MODE,SYSTEM MODE AND CLEARING BLUETOOTH PARING INFO.................................................................. 11
STATUS LEDS........................................................................................................................................................................ 11
BLUETOOTH PAIRING.............................................................................................................................................................. 13
MAGNETIC CARDS READING ..................................................................................................................................................... 15
CONTACTLESS CARDS READING.................................................................................................................................................. 16
SMART CARDS READING........................................................................................................................................................... 17
CARE, MAINTENANCE AND WARRANTY............................................................................................................................... 18
SERVICE AND SUPPORT......................................................................................................................................................... 18

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 5
REGULATORY
FCC ID: YRW-PD20
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could
void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 6
TECHNICAL SPECIFICATIONS
Processor
ARM Cortex® M3 Security Microcontroller
Memory
64KB Internal ROM
256KB Internal RAM
1MB Internal Flash
Application Memory
4MB Serial Flash
Keypad
•ON / OFF key and Bluetooth pairing conformation/cancel
Magnetic Card Reader
• 3-track bi-directional reading
• ISO 7810, 7811 and 7813
Smart Card Reader
ISO7816, EMV L1 certified
Contactless Card Reader
for payment applications
(option)
• AMEX ExpressPay
• Discover D-PAS
• MasterCard Contactless
• VISA PayWave
• China Union Pay
• JCB
Contactless Card Reader
(option)
•NFC-A/ISO 14443 Type-A
•NFC-B/ISO 14443 Type-B
•NFC-F/Felica
•NFC-V/ISO 15693
Battery
Rechargeable lithium-Polymer battery 3.7V, 400 mAh
Connectivity
• USB
- Device
• Bluetooth Low Energy 4.2
Audio indication
Electro-Magnetic Buzzer
OS compatibility
iOS, Android, Windows
Reliability
•500 000 chip card cycles
• 1 000 000 magnetic card swipes
Certifications
PCI 6, CE, FCC
Dimensions (W x D x H), mm
75.80 (78.80) х 55.10 (58.10) х 15 (top housing max. outer dimensions)
Weight, g
74
Environmental
Operating (while internal battery is discharging): -10oC to +40oC / 5 to 95% RH
Operating (while internal battery is charging): 0oC to +45oC / 5 to 95% RH
Storage: -20oC to +55oC / 5 to 90% RH
Power Supply
DC 5 V, 500mA through USB connector or POGO pins
* Specification can be change without any notice.
Use only original equipped cable USB-A to USB-C.
Use only approved USB adapters. The minimum requirements of USB adapter
are 5V/500mA.
Waste Electrical & Electronic Equipment
The symbol means that according to local laws and regulations your product
shall be disposed of separately from household waste at the end of its working
life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of wastes
and recycle it responsibly to promote the sustainable reuse of material
resources.

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 7
GENERAL VIEW
Figure 1

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 8
1. LEDs indication for Contactless transaction / LEDs indication for device status
2. Mounting insert 1
3. Rear Pads (USB and charging)
4. Contactless reader
5. On/Off button (Bluetooth pairing and cancel button)
6. USB port
7. Mounting insert 2
8. Opening for magnetic card
9. Opening for inserting smart card

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 9
GETTING STARTED
PD20/PD20-1 has rechargeable Li-Po battery. Can be charge from USB port or Rear pads.
Before first use, battery must be fully charged.
If the device is fully discharged, charging time to fully charged would be approx.
1 hour and 30min.
Charging form USB adapter:
Figure 2
Main battery replacement:
To replace the main battery of PD20/PD20-1 please contact with your local
Datecs representative or service provider.

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 10
PERIODIC INSPECTION AND MAINTENANCE
The following inspections must be performed on a regular basis after initial receipt and installation of
PD20/PD20-1:
• There are no visual indications for trying unauthorized opening of the device
• There are no unusual wires connected to the ICC acceptor or any of the ports on the terminal.
• There is no shim device in the ICC acceptor slot.
• The terminal serial number (on the label) corresponds to the one in the inventory paperwork.

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 11
OPERATION MODES
For start operating with PD20/PD20-1 needs to be paired to another Bluetooth BLE device with
installed application. For downloading the latest SDKs for iOS, Android and Windows please contact
with your distributor.
Application download mode, System mode and Clearing Bluetooth paring info
Application download mode - to enter application download mode on the PD20/PD20-1, the power
button must be maintained pressed and USB cable plugged. A characteristic sound is played and first
white LED will start to light, then is releasing the power button. When device is in Boot
Loader/Application download mode will be played characteristic sound.
System mode - to enter in “SYSTEM MODE” on the PD20/PD20-1, the power button must be
maintained pressed and USB cable plugged. A characteristic sound is played and first white LED will
start to light. Power button must be hold until third white LED is light on, then is releasing the power
button.
Clear Bluetooth paring information - to enter in “Clear Bluetooth Pairing Info” on the PD20/PD20-1,
the power button must be maintained pressed. A characteristic sound is played, and first white LED
will start to light, then is releasing the power button. When pairing info will be played characteristic
sound.
Status LEDs
LED indication
Green LED continuously light on
Green LED flashing

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 12
LED indication
Description
Device operating
No indication
Device is turned off
No indication (Depends
of Application)
Device is turned on
System errors
After power on the
device, on front side
first LED light
continually and fourth
LED blinking
Device is TAMPERED
second LED light
continually and fourth
LED blinking
Device error (General Exception)

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 13
Bluetooth Pairing
Turn on PD20/PD20-1, connect it to PC via USB cable. When device is connected to PC, will create
virtual COM port. Check on device manager on which port is connected. After that run the special
application for PC (Fig. 3). Press “Search” button on the app, and in right side will be show all available
COM ports. Select on which is connected device, then press “Connect to device”. From Bluetooth
management on mobile device (equipped with BLE 4.2) select connect to PD20/PD20-1, then on mobile
device screen will be show PASSKEY (Fig. 6). White LEDs will start to light one by one continually, on
special app will be show Passkey (Fig. 4), if they are same press “On/Off” two times on PD20/PD20-1
to confirm (Fig. 5), then special app return message “THE DEVICES ARE CONNECTED” (Fig.7 when on
each device is confirming pairing). If Passkey is being different press “On/Off” button one time on
PD20/PD20-1 to cancel pairing.
Figure 3
Figure 4
Figure 5
Figure 6

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 14
Figure 7

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 15
Magnetic cards reading
The PD20/PD20-1 has a built-in magnetic card reader. The card reader incorporates a (3) track
magnetic read head, requiring a single swipe to read field data from all three tracks.
The magnetic reading head faces down, towards the top of the bottom cover of the cradle. When
swiping the card into the reader, the magnetic stripe must be facing as shown in the figure below.
Keep the edge of the card flat on the inner base of the reader to ensure that the magnetic stripe passes
over the reading head evenly.
Figure 8

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 16
Contactless cards reading
The contactless card transaction procedure can vary depending on the application loaded on the
PD20/PD20-1. Verify the proper procedure with your application provider before performing a
contactless card transaction.
In order to use the Contactless card reading function, special software must be used. Please contact
your distributor in order to get the latest demo application and SDK.
To Conduct a Contactless Credit/Debit Card Transaction
1. Place a contactless card to shown on the PD20/PD20-1 contactless logo.
2. Remove the card when the display indicates the transaction is completed.
Figure 9

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 17
Smart cards reading
The smart card transaction procedure can vary depending on the application loaded on the
PD20/PD20-1. Verify the proper procedure with your application provider before performing a smart
card transaction.
To Conduct a Smart Card Transaction
1 Position a smart card with the gold contacts facing downward.
2 Insert it into the ICC card reader slot in a smooth, continuous motion until it seats firmly.
3 Remove the card when indicates the transaction is completed.
Figure 10

1 DATECS ZEBRA PD20/PD20-1 USER MANUAL
UM 07.01.31/v1.4.0 18
CARE, MAINTENANCE AND WARRANTY
•Keep the PD20/PD20-1 side of the reach of small children.
•Keep the PD20/PD20-1 dry. Precipitation, humidity and liquid contain
minerals that will corrode electronic circuits.
•Do not use or store in dusty or dirty areas.
•Do not drop or knock PD20/PD20-1.
•Do not open the PD20/PD20-1. Only qualified personnel can open the
device and make repair. If the PD20/PD20-1 is not working, please
contact with your dealer.
•Forbidden is allowing unqualified personnel to service your PD20/PD20-
1!
SERVICE AND SUPPORT
Service and Support:
For PD20/PD20-1 problems, product service, and repair information, contact your local Datecs
representative or service provider.
• International – Contact your local Datecs distributor
Service Returns:
All customers, please contact your local Datecs Ltd representative or distributor for assistance with
your service, return, or replacement.

FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your
authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
Specific Absorption Rate (SAR) information:
This Communicator meets the government's requirements for exposure to radio
waves. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the safety of all
persons regardless of age or health. FCC RF Exposure Information and Statement
the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device
types: Communicator has also been tested against this SAR limit. This device
was tested for typical body-worn operations with the back of the phone kept 10mm
from the body. To maintain compliance with FCC RF exposure requirements, use
accessories that maintain an 10mm separation distance between the user's body and
the back of the phone. The use of belt clips, holsters and similar accessories should
not contain metallic components in its assembly. The use of accessories that do not
satisfy these requirements may not comply with FCC RF exposure requirements, and
should be avoided.

ISED Statement
English:This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
The digital apparatus complies with Canadian CAN ICES‐3 (B)/NMB‐3(B).
French: Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux RSS exemptés
de licence d'Innovation, Sciences et Développement économique Canada.
L'exploitation est soumise aux deux conditions suivantes :
(1) Cet appareil ne doit pas provoquer d'interférences.
(2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un
fonctionnement indésirable de l'appareil.
l'appareil numérique du ciem conforme canadien peut ‐ 3 (b) / nmb ‐ 3 (b).
This device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS
102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
cet appareil est conforme à l'exemption des limites d'évaluation courante dans la section 2.5 du cnr - 102 et
conformité avec rss 102 de l'exposition aux rf, les utilisateurs peuvent obtenir des données canadiennes sur
l'exposition aux champs rf et la conformité.
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment.
Cet équipement est conforme aux limites d'exposition aux rayonnements du Canada établies pour un
environnement non contrôlé.
RF Exposure Statement
The device has been evaluated to meet general RF exposure requirement. The device can be usedin portable
exposurecondition without restriction.
L'appareil a été évalué pour répondre aux exigences générales d'exposition aux radiofréquences. L'appareil
peut être utilisé en condition d'exposition portable sans restriction.
SAR English
Specific Absorption Rate (SAR) information:
This PD20 meets the government's requirements for exposure to radio waves. The guidelines are based on standards
that were developed by independent scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or
health. ISED RF Exposure Information and Statement the SAR limit of Canada(ISED) is 1.6 W/kg averaged over one
gram of tissue. Device types: PD20 has also been tested against this SAR limit. This device was tested for typical body-
worn operations with the back of the Tablet kept 10mm from the body. To maintain compliance with ISED RF
exposure requirements, use accessories that maintain an 10mm separation distance between the user's body and the
back of the Tablet . The use of belt clips, holsters and similar accessories should not contain metallic components in its
assembly. The use of accessories that do not satisfy these requirements may not comply with ISED RF exposure
requirements, and should be avoided.
France
Informations sur le débit d'absorption spécifique (DAS):
Cette PD20 répond aux exigences du gouvernement en matière d'exposition aux ondes radio. Les lignes directrices
sont basées sur des normes élaborées par des organisations scientifiques indépendantes à travers une
évaluation périodique et approfondie des études scientifiques. Les normes comprennent une marge de sécurité
substantielle conçue pour assurer la sécurité de toutes les personnes, quel que soit leur ge ou leur état de santé.
Information et déclaration d'ISDE sur l'exposition aux RF la limite DAS du Canada (ISDE) est de 1,6 W / kg en
moyenne sur un gramme de tissu. Types d'appareils: la PD20 a également été testée par rapport à cette limite
SAR. Cet appareil a été testé pour des opérations typiques portées sur le corps avec le dos de la tablette gardé
à 10 mm du corps. Pour maintenir la conformité avec les exigences d'exposition RF d'ISDE, utilisez des accessoires
qui maintiennent une distance de séparation de 10 mm entre le corps de l'utilisateur et l'arrière de la tablette.
L'utilisation de clips de ceinture, d'étuis et d'accessoires similaires ne doit pas contenir de composants métalliques
dans son assemblage. L'utilisation d'accessoires qui ne satisfont pas à ces exigences peut ne pas être conforme aux
exigences d'exposition aux RF d'ISDE et doit être évitée.
This manual suits for next models
1
Table of contents
Other Datecs Touch Terminal manuals
Popular Touch Terminal manuals by other brands

HIK VISION
HIK VISION K1T671 quick start guide

HIK VISION
HIK VISION DS-K5671B Series user manual

Redline
Redline RDL-3000 SC Installation guidelines

protech
protech PS3100 Series user manual

red lion
red lion Graphite Series installation guide

Global Payments
Global Payments Genius Smart P2PE instruction manual
