HIK VISION DS-K5671B Series User manual

DS-K5671B Series Face Recognion Terminal
User Manual

Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K5671B Series Face Recognion Terminal User Manual
i

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-K5671B Series Face Recognion Terminal User Manual
ii

Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
DS-K5671B Series Face Recognion Terminal User Manual
iii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K5671B Series Face Recognion Terminal User Manual
iv

under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
DS-K5671B Series Face Recognion Terminal User Manual
v

Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
●Please use the power adapter, which is provided by normal company. This equipment is
intended to be supplied from the Class 2 surge protected power source rated DC 12V, 3A.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●When the product is installed on wall or ceiling, the device shall be rmly xed.
●If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think baeries might have
been swallowed or placed inside any part of the body, seek immediate medical aenon.
●If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
DS-K5671B Series Face Recognion Terminal User Manual
vi

Cauons:
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
●Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●Biometric recognion products are not 100% applicable to an-spoong environments. If you
require a higher security level, use mulple authencaon modes.
●Working temperature: -30 °C to +60 °C
●Indoor and outdoor use. If installing the device indoors, the device should be at least 2 meters
away from the light, and at least 3 meters away from the window or the door. If installing the
device outdoors, you should apply Sililcone sealant among the cable wiring area to keep the
raindrop from entering.
●Protecon level: IP65
●Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power
Source with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to
technical specicaons for detailed informaon.
●Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used baeries away from children.
If the baery compartment does not close securely, stop using the product and keep it away
from children.
DS-K5671B Series Face Recognion Terminal User Manual
vii

If you think baeries might have been swallowed or placed inside any part of the body, seek
immediate medical aenon.
DS-K5671B Series Face Recognion Terminal User Manual
viii

Available Models
Product Name Model
Face Recognion Terminal DS-K5671B-ZV
DS-K5671B-ZH
DS-K5671B-ZU
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
C2000IC12.0-24P-DE MOSO Power Supply
Technology Co., Ltd.
CEE
C2000IC12.0-24P-GB MOSO Power Supply
Technology Co., Ltd.
BS
KPL-040F-VI Channel Well Technology Co
Ltd.
CEE
DS-K5671B Series Face Recognion Terminal User Manual
ix

Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Overview ................................................................................................................................ 1
1.2 Features ................................................................................................................................. 1
Chapter 2 Appearance ................................................................................................................ 2
Chapter 3 Installaon ................................................................................................................. 4
3.1 Installaon Environment ........................................................................................................ 4
3.2 Mount With Bracket ............................................................................................................... 4
3.2.1 Preparaon before Mounng with Bracket .................................................................. 4
3.2.2 Mount Bracket I ............................................................................................................ 6
3.2.3 Mount Bracket II ......................................................................................................... 10
3.2.4 Mount Bracket III ........................................................................................................ 13
Chapter 4 Wiring ...................................................................................................................... 19
4.1 Terminal Descripon ............................................................................................................ 19
4.2 Wire Normal Device ............................................................................................................. 22
4.3 Wire Secure Door Control Unit ............................................................................................ 23
Chapter 5 Acvaon ................................................................................................................. 24
5.1 Acvate via Device ............................................................................................................... 24
5.2 Acvate via Web Browser .................................................................................................... 26
5.3 Acvate via SADP ................................................................................................................. 26
5.4 Acvate Device via Client Soware ...................................................................................... 28
Chapter 6 Quick Operaon ....................................................................................................... 29
6.1 Select Language ................................................................................................................... 29
6.2 Set Password Change Type ................................................................................................... 31
6.3 Set Applicaon Mode .......................................................................................................... 33
6.4 Set Network Parameters ...................................................................................................... 35
6.5 Access to Plaorm ............................................................................................................... 37
DS-K5671B Series Face Recognion Terminal User Manual
x

6.6 Privacy Sengs .................................................................................................................... 39
6.7 Set Administrator ................................................................................................................. 40
Chapter 7 Basic Operaon ........................................................................................................ 43
7.1 Login .................................................................................................................................... 43
7.1.1 Login by Administrator ................................................................................................ 43
7.1.2 Login by Acvaon Password ...................................................................................... 46
7.1.3 Forgot Password .......................................................................................................... 47
7.2 Communicaon Sengs ...................................................................................................... 49
7.2.1 Set Wired Network Parameters .................................................................................. 49
7.2.2 Set Wi-Fi Parameters ................................................................................................... 51
7.2.3 Set RS-485 Parameters ................................................................................................ 53
7.2.4 Set Wiegand Parameters ............................................................................................. 55
7.2.5 Set ISUP Parameters .................................................................................................... 56
7.2.6 Plaorm Access ........................................................................................................... 58
7.3 User Management ............................................................................................................... 58
7.3.1 Add Administrator ....................................................................................................... 59
7.3.2 Add Face Picture ......................................................................................................... 60
7.3.3 Add Card ..................................................................................................................... 62
7.3.4 View PIN code ............................................................................................................. 63
7.3.5 Set Authencaon Mode ............................................................................................ 64
7.3.6 Search and Edit User ................................................................................................... 64
7.4 Data Management ............................................................................................................... 65
7.4.1 Delete Data ................................................................................................................. 65
7.4.2 Import Data ................................................................................................................. 65
7.4.3 Export Data ................................................................................................................. 66
7.5 Identy Authencaon ........................................................................................................ 66
7.5.1 Authencate via Single Credenal .............................................................................. 66
7.5.2 Authencate via Mulple Credenal .......................................................................... 67
DS-K5671B Series Face Recognion Terminal User Manual
xi

7.6 Basic Sengs ....................................................................................................................... 67
7.7 Set Biometric Parameters .................................................................................................... 69
7.8 Set Access Control Parameters ............................................................................................ 72
7.9 Time and Aendance Status Sengs .................................................................................. 73
7.9.1 Disable Aendance Mode via Device ......................................................................... 73
7.9.2 Set Manual Aendance via Device ............................................................................. 73
7.9.3 Set Auto Aendance via Device .................................................................................. 75
7.9.4 Set Manual and Auto Aendance via Device .............................................................. 76
7.10 System Maintenance .......................................................................................................... 78
7.11 Preference Sengs ............................................................................................................ 79
7.12 Video Intercom .................................................................................................................. 81
7.12.1 Call Client Soware from Device ............................................................................... 82
7.12.2 Call Center from Device ............................................................................................ 82
7.12.3 Call Device from Client Soware ............................................................................... 83
7.12.4 Call Room from Device .............................................................................................. 83
7.12.5 Call Mobile Client from Device .................................................................................. 84
Chapter 8 Operaon via Web Browser ...................................................................................... 85
8.1 Login .................................................................................................................................... 85
8.2 Forget Password ................................................................................................................... 85
8.3 Live View .............................................................................................................................. 85
8.4 Person Management ............................................................................................................ 87
8.5 Search Event ........................................................................................................................ 88
8.6 Conguraon ....................................................................................................................... 89
8.6.1 Set Local Parameters ................................................................................................... 89
8.6.2 View Device Informaon ............................................................................................. 90
8.6.3 Set Time ...................................................................................................................... 90
8.6.4 Set DST ........................................................................................................................ 91
8.6.5 View Open Source Soware License ........................................................................... 91
DS-K5671B Series Face Recognion Terminal User Manual
xii

8.6.6 Upgrade and Maintenance ......................................................................................... 91
8.6.7 Log Query .................................................................................................................... 93
8.6.8 Security Mode Sengs ............................................................................................... 93
8.6.9 Cercate Management ............................................................................................. 94
8.6.10 Change Administrator's Password ............................................................................. 95
8.6.11 Account Security Sengs .......................................................................................... 95
8.6.12 View Device Arming/Disarming Informaon ............................................................ 96
8.6.13 Network Sengs ....................................................................................................... 96
8.6.14 Set Video and Audio Parameters ............................................................................ 101
8.6.15 Customize Audio Content ....................................................................................... 103
8.6.16 Set Image Parameters ............................................................................................. 104
8.6.17 Time and Aendance Sengs ................................................................................ 105
8.6.18 General Sengs ...................................................................................................... 107
8.6.19 Video Intercom Sengs .......................................................................................... 112
8.6.20 Access Control Sengs ........................................................................................... 114
8.6.21 Set Biometric Parameters ....................................................................................... 118
8.6.22 Set Theme ............................................................................................................... 122
Chapter 9 Client Soware Conguraon ................................................................................. 124
9.1 Conguraon Flow of Client Soware ............................................................................... 124
9.2 Device Management .......................................................................................................... 124
9.2.1 Add Device ................................................................................................................ 125
9.2.2 Reset Device Password ............................................................................................. 133
9.3 Group Management ........................................................................................................... 134
9.3.1 Add Group ................................................................................................................. 134
9.3.2 Import Resources to Group ....................................................................................... 135
9.3.3 Edit Resource Parameters ......................................................................................... 135
9.3.4 Remove Resources from Group ................................................................................ 135
9.4 Person Management .......................................................................................................... 136
DS-K5671B Series Face Recognion Terminal User Manual
xiii

9.4.1 Add Organizaon ...................................................................................................... 136
9.4.2 Congure Basic Informaon ..................................................................................... 137
9.4.3 Issue a Card by Local Mode ....................................................................................... 138
9.4.4 Upload a Face Photo from Local PC .......................................................................... 140
9.4.5 Take a Photo via Client .............................................................................................. 141
9.4.6 Collect Face via Access Control Device ..................................................................... 142
9.4.7 Congure Access Control Informaon ...................................................................... 143
9.4.8 Customize Person Informaon .................................................................................. 145
9.4.9 Congure Resident Informaon ................................................................................ 146
9.4.10 Congure Addional Informaon ........................................................................... 146
9.4.11 Import and Export Person Idenfy Informaon ...................................................... 147
9.4.12 Import Person Informaon ..................................................................................... 147
9.4.13 Import Person Pictures ........................................................................................... 147
9.4.14 Export Person Informaon ...................................................................................... 148
9.4.15 Export Person Pictures ............................................................................................ 148
9.4.16 Delete Registered Pictures ...................................................................................... 149
9.4.17 Get Person Informaon from Access Control Device .............................................. 149
9.4.18 Move Persons to Another Organizaon .................................................................. 150
9.4.19 Issue Cards to Persons in Batch ............................................................................... 150
9.4.20 Report Card Loss ..................................................................................................... 151
9.4.21 Set Card Issuing Parameters .................................................................................... 151
9.5 Congure Schedule and Template ..................................................................................... 152
9.5.1 Add Holiday ............................................................................................................... 152
9.5.2 Add Template ............................................................................................................ 153
9.6 Set Access Group to Assign Access Authorizaon to Persons ............................................ 155
9.7 Congure Advanced Funcons .......................................................................................... 157
9.7.1 Congure Device Parameters .................................................................................... 157
9.7.2 Congure Remaining Open/Closed ........................................................................... 162
DS-K5671B Series Face Recognion Terminal User Manual
xiv

9.7.3 Congure Mul-Factor Authencaon ..................................................................... 164
9.7.4 Congure Card Reader Authencaon Mode and Schedule .................................... 166
9.7.5 Congure First Person In ........................................................................................... 168
9.7.6 Congure An-Passback ........................................................................................... 169
9.7.7 Congure Device Parameters .................................................................................... 170
9.8 Congure Linkage Acons for Access Control .................................................................... 176
9.8.1 Congure Client Acons for Access Event ................................................................. 176
9.8.2 Congure Device Acons for Access Event ............................................................... 177
9.8.3 Congure Device Acons for Card Swiping ............................................................... 178
9.8.4 Congure Device Acons for Person ID .................................................................... 179
9.9 Door Control ...................................................................................................................... 180
9.9.1 Control Door Status ................................................................................................... 180
9.9.2 Check Real-Time Access Records .............................................................................. 181
9.10 Event Center .................................................................................................................... 182
9.10.1 Enable Receiving Event from Devices ..................................................................... 182
9.10.2 View Real-Time Events ............................................................................................ 183
9.10.3 Search Historical Events .......................................................................................... 184
9.11 Time and Aendance ....................................................................................................... 188
9.11.1 Congure Aendance Parameters .......................................................................... 188
9.11.2 Add General Timetable ........................................................................................... 195
9.11.3 Add Shi .................................................................................................................. 198
9.11.4 Manage Shi Schedule ........................................................................................... 201
9.11.5 Manually Correct Check-in/out Record ................................................................... 204
9.11.6 Add Leave and Business Trip ................................................................................... 205
9.11.7 Calculate Aendance Data ...................................................................................... 206
9.11.8 Aendance Stascs .............................................................................................. 208
9.12 System Conguraon ....................................................................................................... 211
9.12.1 Set General Parameters .......................................................................................... 211
DS-K5671B Series Face Recognion Terminal User Manual
xv

9.12.2 Set Picture Storage .................................................................................................. 212
9.12.3 Set Alarm Sound ..................................................................................................... 213
9.12.4 Set Access Control and Video Intercom Parameters ............................................... 213
9.12.5 Set File Saving Path ................................................................................................. 214
9.12.6 Set Email Parameters .............................................................................................. 214
9.13 Operaon and Maintenance ............................................................................................ 215
Appendix A. Tips When Collecng/Comparing Face Picture .................................................... 216
Appendix B. Tips for Installaon Environment ........................................................................ 218
Appendix C. Dimension .......................................................................................................... 219
Appendix D. Communicaon Matrix and Device Command .................................................... 220
DS-K5671B Series Face Recognion Terminal User Manual
xvi

Chapter 1 Overview
1.1 Overview
Face recognion terminal is a kind of access control device for face recognion, which is mainly
applied in security access control systems, such as logisc centers, airports, university campuses,
alarm centrals, dwellings, etc.
1.2 Features
●Compable with Hikvision turnsle
●Communicates with the third-party turnsle via IO output or Wiegand
●7-inch LCD touch screen
●2 MP wide-angle dual-lens
●Adjusts supplement light brightness manually
●Face recognion distance: 0.3 m to 3 m
●High performance processor with deep learning algorithm
●50,000 face capacity and 100,000 event capacity
●Mulple authencaon modes
●Face recognion duraon ≤ 0.2 s/User; face recognion accuracy rate ≥ 99%
●Transmits card and user data from or to the client soware via TCP/IP protocol and saves the
data on the client soware
●Imports pictures from the USB ash drive to the device or export pictures, events, from the
device to the USB ash drive
●Stand-alone operaon
●Device management, log search, and parameter sengs via the device
●Connects to one external card reader or access controller via RS-485 protocol
●Connects to Wiegand card reader via Wiegand protocol
●Remote live view via RTSP protocol; encoding mode: H.264
●NTP, manually me synchronizaon, and auto synchronizaon
●Voice prompt
●Watchdog design for protecng the device and ensuring device running properly
●Support English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese,
Portuguese (Brazil)
DS-K5671B Series Face Recognion Terminal User Manual
1

Chapter 2 Appearance
Refer to the following contents for detailed informaon of the face recognion terminal:
Figure 2-1 Face Recognion Terminal Diagram
Table 2-1 Descripon of Face Recognion Terminal
No. Name Descripon
1 White Light Supplement light for camera.
2 IR Light Supplement light for camera.
3 Camera White light camera for recording or capturing
white light videos or pictures.
4 Display Screen 7-inch LCD touch screen.
5 Infrared Intrusion Detector Detects whether objects is reaching the device
or not.
6 USB Interface Connect to USB ash drive.
7 Indicator Indicates the device status.
8 Wiring Terminals Connect to other external devices, including RS-
485 card reader, Wiegand card reader, door
lock, alarm input, alarm output, etc.
9 Power Interface Connect to power supply.
DS-K5671B Series Face Recognion Terminal User Manual
2

No. Name Descripon
10 Debugging Port The debug terminal is used for debugging only.
11 Network Interface Connect to Ethernet.
12 TF Card Slot Reserved
DS-K5671B Series Face Recognion Terminal User Manual
3
