DaVinci Parker 2 Door Changer Installation and operating instructions

!!PLEASE READ!!
Assembly of this furniture is easier with two
people. Assemble furniture on debris free
carpets or on the enclosed foam sheets to
prevent scratching of finish. Using any
power tools to assemble this furniture may
potentially strip the wood. DO NOT
OVERTIGHTEN SCREWS.DO NOT USE
THE CHANGING TABLE IF IT IS
DAMAGED OR BROKEN.
WARNING!
!
page 1
Congratulations on purchasing an MDB Family product. This changer will provide many years of service if
you adhere to the following guidelines for assembly, maintenance and operation. This changer is for residential
use only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for assembling
the changer in addition to the Allen wrench included in the hardware box. Do not use power screwdrivers. All
of our changers are made from natural woods. Please understand that natural woods have color variations
which are the result of nature and are not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND
HARDWARE. YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO
STYLISTIC VARIATIONS.
Changer (5152) - Assembly and Operation Manual
READ ALL INSTRUCTIONS BEFORE USE OF THE CHANGING TABLE, ADD-ON
CHANGING UNIT, OR CONTOURED CHANGING PAD.
revised 21JUL2015
The recommended maximum weight of
the occupant is 30 lbs.
READ ALL INSTRUCTIONS
BEFORE USING THE
PRODUCT. KEEP THE
INSTRUCTIONS FOR
FUTURE USE.
KEEP THIS MANUAL IN A
SAFE PLACE FOR FUTURE
REFERENCE.

A. Left and Right
Side Panel (2)
PARTS
page 2
C. Left and
Right Door
(2)
G. Foot (4)
H. Shelf (2)
J2. Top Panel
K. Changing
Pad
B. Center Panel
GG. Rear Top Support Panel
HH. Rear Bottom Support
Panel
J1. Bottom
Panel
D. Top Front Support Panel
E. Top Rear Support Panel
F1. Bottom Front Panel
Side
View

ZZ. Knob (2)
S. 1” Phillips
Head Bolt (2)
BB. 1/2”
Washer (10)
HARDWARE
N. 1 5/8” flat head
screw (8)
M. 2 3/4” Allen head bolt (8)
X. Metal Dowel (8) Y. Door Peg (4)
R. Barrel nut (8)
DD. Door
Catch (2)
EE. Screw
Plate (2)
FF. Allen
Wrench
AA. Strap
T. 5/8” Pan Head
Screw (4)
U. 5/8” Flat Head
Screw (8)
Tools Needed
(not included)
Phillips
screwdriver
JJ. Wood
Dowel (4)
KK. 1 1/4” Allen
head bolt (2)
1
All barrel nuts are threaded and come pre-attached to the bolts. Please
ensure you have the correct number of barrel nuts needed as indicated
in the instruction manual before assembly.
BARREL NUT - ADDITIONAL INSTRUCTION
2
All barrel nuts are threaded and come pre-attached to the bolts. Please
ensure you have the correct number of barrel nuts needed as indicated
in the instruction manual before assembly.
page 3

page 4
R
X
X6
R
X2
1
D
E
RR
RR
X
X
X
F1
X
X
X
HH
RR
RR
ASSEMBLY INSTRUCTIONS
* The bolt may not be able to screw through the barrel
nuts smoothly. It is suggested to use a flat screwdriver
to stabilize and adjust the direction of the barrel nut.
Flat Screwdriver
Please follow the rest of the instruction steps in the instruction manual to complete the assembly
.
Please use an Allen wrench to screw the bolt with the
lock washer straight into the threaded nut until it is tight.
.
Allen wrench
3

page 5
2
3
A
N
NN
N
G
G
G
F1
BB
A
M
M
HH
BB
JJ
JJ
GG
X2
JJ

page 6
4
J1
HH
5
X
* Attach the door catches
(DD) on both sides of
center panel (B).
X
U
U
U
UDD
DD
X
B

page 7
6
7* Make sure to align the pre-
attached metal dowel on
the center panel (B) with the
pre-drilled hole in the top
panel (D).
BB
M
BB
D
E
A
B
F1
M
* NOTE: Do not
tighten the top front
panel (D) until after
the door attachment
in step 10.
T
TB
F1
* Metal dowels (X)
must be inserted into
the pre-drilled holes in
the bottom front panel
and rear panels (F1,
GG & HH).
HH GG
BB
KK
X2

page 8
8
9
A
B
F1
J2
D
F1
Y
D
X4

page 9
* Tighten the top support rail (D) when
finished.
10
U
S
S
U
C. Left Door
C. Right Door
ZZ
EE
ZZ
EE
D
11
M
M
BB
BB
BB BB
M
M
A
X
X
D
F1
E
JJ JJ
* NOTE: Make sure that the barrel nuts
(R) are placed in the proper position
in the pre-drilled holes in the support
panels (D, E & F1).
R R

* Stand the unit upright on its feet.
K
H
A
AA
E
D
T
12
13 14
X2
page 10
