dB Technologies VIO S118R Manual

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOS118RRev1.2cod.420120271Q
Quick start user manual
Section 1
The warnings in this manual must be observed together with the "USER MANUAL - Section 2".
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO – Sezione 2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG - Abschnitt 2" beobachtet
werden”.
Les avertissements specifiés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECHNIQUES -
Section 2"
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO” -
Sección 2”.

A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [e-mail]

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOS118RRev1.2cod.420120271Q
Thank you for choosing a dBTechnologies Product!
VIO S118R is an active bass reflex subwoofer, designed for professional use, equipped with one 18” woofer (voice
coil: 4”). The powerful DIGIPRO®G4 amplifier section, capable of handling up to 1600 W (RMS power), is controlled
by a DSP, which can perform a detailed customization of the output sound of the subwoofer. In particular, thanks to
the complete control interface, it is possible to accurately tune various types of configurations, like cardioid or end-
fire. The RDnet connections allow in-depth remote control, thanks also to free available software (AURORA NET,
dBTechnologies Composer). Professional accessories (like DRK-210 fly-bar and SWK-18 wheels kit) ensure easy
set-up to create different configurations, completing live installations with VIO line-array series.
Check the site www.dbtechnologies.com for the complete user manual!
1) Unpacking
The box contains:
No. VIO S118R
No. 1 Mains cable with Neutrik® powerCON TRUE1
connector
No. 1 Fuse for 100-120V~ usage
This quick start and warranty documentation
2) Easy installation
The easy use in different configurations is guaranteed
by:
handles [A], two for each side
pole-mount adapter [B], on the top, M20
threaded hole
pick points for DRK- 210 fly-bar [C] (in
stacked installation)
amplifier control panel [D]
threaded holes for SWK-18 wheels kit [E]
The main accessories are shown below. Please refer to
the related instructions and complete manuals for
further information.
The product and accessories must be handled by
trained personnel only! The user is required to
follow regulations and mandatory laws on safety
of the country in which the product is used. Don’t use
handles and/or roping points to suspend VIO S118R!

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOS118RRev1.2cod.420120271Q
3) First switch-on
The DIGIPRO G4 amplifier of VIO S118R is controlled by
a powerful DSP. All the connections and controls are in
the rear amplifier control panel:
The subwoofer is supplied with a mounted fuse for
operation within the 220-240V~ range. If you need to
operate in the 100-120V~ voltage range:
Disconnect all connections, including the power
supply
Wait 5 minutes
Replace the fuse with the one provided in the
package for the 100-120V~ range
1 – Input (balanced) connector
2 – Link/Xover Out (balanced) connector
3 – Subwoofer attenuation rotary control
4 – Delay rotary controls
5 – Polarity switch
6 – Cardioid preset switch
7 – Link/Xover Out switch
8 – Xover LPF
9 – Status LEDs (Limiter, Signal, Mute/Protection,
Ready)
10 – RDNet Data In
11 – RDNet Data Out
12 – RDNet status LEDs
13 – System test switch
14 – USB Data Service (USB-standard Type B)
15 – Full Range Mains input connector
16 – Mains Link connector
17 – Mains Fuse
a) Once you have properly set up the desired
configuration (see also the VIO S118R complete user
manual and accessories instructions for further
information), connect the audio input (1). Set the
Subwoofer attenuation (3) to 0 dB.
b) Connect the possible output direct link (2), and set
the Link/Xover Out switch (7). If your choice is Xover,
you can choose the LPF frequency with (8) Xover
rotary. This filter does not affect the “Link” output.
c) Choose the Subwoofer Setup (Delay 4, Polarity 5)
In cardioid configuration, please note that the
cardioid preset switch (6), when active, bypass these
controls.
d) In case of remote control, connect the Data Input
(10) to the hardware remote controller (RDNet
Control 2 or RDNet Control 8) with cables equipped
with etherCON connectors. Then connect the Data
Output (11) to the Data Input (10) of a possible
second device, and so on. When the RDNet network
is on and it has recognized the connected device, the
LED “Link” (12) is on. The other LEDs (12) “Active”
start blinking at the presence of data transmission,
the “Remote Preset Active” advise that all the local
controls set on the amplifier panel (level, DSP
presets, etc.) are by-passed and controlled remotely
by RDNet. In remote control it is essential the use of
free dBTechnologies software (check the last revision
on www.dbtechnologies.com ):
AURORA NET,
necessary for an in-depth control of different devices
in remote connection;
dBTechnologies Composer,
necessary for safety check and for the complete
sound system design, particularly developed for VIO
series.
e) Connect the power supply (15). Link the power to
other subwoofer or modules (see Technical Data for
further information) using mains link connector (16).
Check the complete user manual on www.dbtechnologies.com for further
information about the system and available accessories.
Scarica il manuale completo da www.dbtechnologies.com per ogni
ulteriore informazione sul sistema e sugli accessori disponibili.
Für weitere Informationen und verfügbares Zubehör lesen sie bitte die
vollständige Bedienungsanleitung unter
www.dbtechnologies.de.
Vérifiez le manuel de l'utilisateur complet sur www.dbtechnologies.com
pour des informations complémentaires du système et des accessoires
disponibles.
Compruebe el manual de usuario completo sobre
www.dbtechnologies.com para la información adicional sobre el sistema y
accesorios disponibles.

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOS118RRev1.2cod.420120271Q
Technical Data
Speaker Type: Active bass-reflex subwoofer
Acoustical data
Frequency Response [-6 dB]:35 Hz – Cut frequency
(crossover - dependent)
Frequency Response [-10 dB (HPF)]:32 Hz
Max SPL (1 m): 139 dB
LF: 1 x 18”
LF Voice Coil: 4”
Crossover freq.: 60 to 110 Hz + full-range
Directivity: (omnidirectional) Cardioid with DSP
Amplifier
Amp Technology: Digipro® G4
Power supply: Full range with PFC
Amp Class: Class-D
RMS Power: 1600 W
Peak Power: 3200 W
Cooling: Passive (convection) and internal fan
Operating voltage:
100-240V~ 50-60 Hz (Full Range)
Processor
Controller: DSP, 32 bit
AD/DA converter: 96 kHz
Limiter: Peak, RMS, Thermal
Controls: Rotary Delay Control (0-9.9 ms, steps: 0.1 ms),
switches (Link/Xover, Cardioid Preset, System test,
Polarity), Sub Attenuation, Xover LPF
Input
Mains connections: PowerCON ® TRUE1 In/link
Maximum number of subwoofer for each daisy chain
power connection [mains input + mains link]: 1+3 VIO
S118R** (220-240V~), 1+1 VIO S118R** (100-120V~)
Signal Input: (Balanced) 1x IN (female)
Signal Out: (Balanced) Link/Xover OUT (male)
RDNET connectors: Data In / Data Out
USB connector: standard USB B-type (for SERVICE DATA)
Mechanics
Housing: Wooden box/black polyurea finish
Grille: Full metal (CNC machining)
Handles: 2 per side
Pole mount adapter: 1 on the top (M20 threaded hole)
Pick points (stack mode): yes (on top for DRK210)
Width: 720 mm (28.34 in)
Height: 530 mm (20.87 in)
Depth: 700 mm (27.56 in)
Weight: 47 kg (103.62 lbs.)
Download the complete user manual on:
www.dbtechnologies.com/EN/Downloads.aspx
EMI CLASSIFICATION
According to the standards EN 55103 this equipment is designed and suitable to operate in E5 Electromagnetic environments.
FCC CLASS A STATEMENT ACCORDING TO TITLE 47, PART 15, SUBPART B, §15.105
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
WARNING: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference.
WARNING: Make sure that the loudspeaker is securely installed in a stable position to avoid any injuries or damages to persons or properties.
For safety reasons do not place one loudspeaker on top of another without proper fastening systems. Before hanging the loudspeaker check
all the components for damages, deformations, missing or damaged parts that may compromise safety during installation. If you use the
loudspeakers outdoor avoid spots exposed to bad weather conditions.
Contact dB Technologies for accessories to be used with speakers. dBTechnologies will not accept any responsibility for damages caused by
inappropriate accessories or additional devices.
Features, specification and appearance of products are subject to change without notice.
dBTechnologies reserves the right to make changes or improvements in design or manufacturing without assuming any obligation to change
or improve products previously manufactured.
