DC-Connex VIP Tour User manual

Get the most reliable group audio
experience in any space —
indoor or outdoor.
VIP Tour
QUICK START GUIDE
DCX-P403: individual system
DCX-K4C03: 10 unit kit
2.4GHz Models

2
INSIDE THE BOX
VIP Tour Models
Unit & Battery
DCX-P403 DCX-K4C03
Single ear headset with boom
microphone
USB-C (A to C) Charging Cable
Belt Clip
Carry Case
Quick Start Guide
10-unit storage and charging
case
Talk
Button
Mode
Button
LCD
Antenna
LED indicator
Down
Button
Up
Button
USB Jack
Power
Button
Headset Jack
Charging
Contact

3
UNIT CONTROLS
Power Button
MODE Button
Up and Down Buttons
Talk Button
LCD
LED Indicator
USB Connection
Charging Contact
Long press the Power button to turn the unit On/Off.
Long press to enter SETTING mode. Single press to cycle through set-
ting options that include Group number and ID number while in
SETTING mode.
Press to Increase + or to Decrease - Volume level or Setting option.
TALK is the default function for units with assigned ID numbers 00 to
09. Long press Talk Button to Mute. Mute is indicated when Talk icon
disappears in LCD window. Long press again to activate Talk function.
Refer to complete user manual for functions specific for units with
assigned ID numbers “A” and “L”.
Displays current status and settings.
Red light turns on when charging. Flashing blue light indicates power is
on. Solid blue light indicates SETTING mode. No light indicates power is
off.
Type-C USB-port for battery charging. Units will be usable when
charging via USB-port.
Contact points for battery charging port in the charging case (sold with
DCX-K4C03). Units will not be usable when charging in case.

4
GET STARTED
Activate your 1-year product warranty when you
register your unit. Register the MODEL #
labeled on the back of your unit at
Remove the plastic tag from the battery pack on
the back of the unit. Pull firmly in the direction of
the arrow until the plastic is removed.
Fully charge your unit with the USB-C charging
cable or charging case (sold with DCX-K4C03)
before use. Unit takes up to 6 hours to fully
charge. The LED will turn red when charging.
Units will be usable when charging via USB-
port. Unit will be powered OFF when charging in
stand or case.
battery and any remaining plastic piece.
Reinsert the battery and close the cover.
remove the back cover, the
dc-connexsolutions.com/register.
REGISTER
Remove Plastic Tab
Charge Battery
If the
plastic breaks off,

5
GET STARTED
Insert the included headset connector into the
headset jack on the bottom of the unit.
Prior to use, remove the protective plastic film
layer on the LCD screen.
Long press the "Power" button to turn the unit
on. LED light will turn blue and LCD window will
briefly light up.
Long press MODE button to access SETTING
mode. Single press MODE button to access ID
Setting. Assign a
transceiver from 00 to 08. Press and hold
MODE button to exit Setting options.
ID number to each
NOTE:
NOTE: One unit must be assigned ID
number 00.
Connect Audio Unit
Remove Plastic Film
Turn On
Assign ID Numbers
Ensure connector is fully inserted.
unique
Audio unit is now ready to use in default Group 00.
See Operations for more detailed settings.
Press
I D

Enter Setting options
ACCESS SETTING
CHANGE SETTINGS
ADJUST VOLUME
6
OPERATIONS
by long pressing the MODE button. To exit
Settings and return to main display, long press the MODE button.
Change SETTING preferences for Group number, ID number, Side
Tone Level, Microphone gain, Operation mode, Security Code, and
VOX selection when in Settings by following the below method:
Single press the Up + button to increase hearing volume. Single press
the Down - button to decrease volume. The volume should be set to
the lowest level that allows the user to hear comfortably.
1.
2.
3.
4.
5.
Enter Settings. The first setting option is Group number. GRP
will be flashing in the display. Current group number will be
displayed on screen. The default Group number is 00.
Press the Up + and Down - buttons to change the Group number.
Press the MODE button to move to the next setting option.
Use the Up + and Down - buttons to select preferred number in
each setting option.
Exit Settings by long press the MODE button.

PROGRAM SEQUENCE
Setting values are shown in access order when you single press
MODE button.
All units in the group must share the same
Group number. 00 is default Group number.
Master unit must be assigned ID 00. Other
units in the group must have unique ID
numbers assigned between 01 through 09,
A or L.
Recommend leaving default settings
to be:
- S0 (Side Tone),
- C1 (Mic Gain),
- 10 20 30 40 (Security Code),
- Pt (Standard Mode), and
- AF (VOX off).
7
OPERATIONS
GRP
00 ~ 39
Side Tone
S0 ~ S5
VOX
AF, A0~A4
Side Tone
S0 ~ S5
Mode Setting
SEC Code
10 ~ 1F
20 ~ 2F
30 ~ 3F
40 ~ 4F
,
ID
00 ~ 09,
A, L
See user’s manual for more detail.

HANDS FREE COMMUNICATIONS
9 group members can participate in hands-free, open dialogue with
each other. This feature is activated when the group units have the
following settings:
All 9 units are connected to each other to allow participants to
conference as a group in real time. A participant can MUTE themselves
by long pressing the TALK button until the Talk icon disappears from
the LCD screen. Activate the Talk function by long pressing the TALK
button until the Talk icon reappears on LCD screen.
- Identical Group numbers for all designated units (choose any Group
number between 00 and 39),
- Assigned ID number “00” to only one unit in the group, and
- Assigned unique ID number 01 to 08 for each group unit.
8
OPERATIONS
ID 00
ID 08
ID 07
ID 06
ID 05
ID 04
ID 03
ID 02
ID 01

9
OPERATIONS
ADD UNLIMITED LISTENERS
Unlimited listen-only participants are able to join any active group. Set
the Group number to be the same as the group to be joined. Group
numbers may be any number between 00 to 39. Additionally, set one
of the following ID numbers:
A = listen-only + push to talk
NOTE:
L = listen-only
- ID number
- ID number
ID numbers 00 to 08 are the only available IDs if “A” or “L” are
used. ID “09” is not available when “A” or “L” are used.
(one at a time)
ID 00
ID 08
ID 07
ID 06
ID 05
ID 04
ID 03
ID 02
ID 01
+
ID A
~
ID L
dc-connexsolutions.com/support
Visit
explore more setting options to create your
preferred VIP Tour audio connection.
to

10
COMPLIANCE
Federal Communications Commission (FCC) Compliance Notices
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
FCC Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interferences received, including interferences that may cause undesired operation.
Canadian ICES Statements
European Union and European Fair Trade Association (EFTA) Regulatory Compliance
WARRANTY
This digital apparatus does not exceed the Class B limits for radio-noise emissions from a digital apparatus as set out in the Radio Interference
Regulations of the Canadian Department of Communications. This Class B digital apparatus complies with Canadian ICES-003.
DC-ConneX
TM
, a brand owned by David Clark Company, hereby declares that this product is in compliance with the essential requirements and other
relevant provisions of EMC Directive 2014/30/EU and all other applicable EU directive requirements. The complete declaration of conformity can be
found at
David Clark Company stands firmly behind our products and our customers with the most outstanding service and support in the industry. We
expect you to experience years of reliable service from our products beyond normal wear and tear.
15054, Worcester, MA 01615-0054 warrants this product to be free from defects in material and workmanship under normal and proper use, for
the period of one year from the date of original purchase and agrees, at its option, to repair or replace such parts showing factory defects subject
to the following provisions,
If a defective product or part cannot reasonably be repaired or replaced, David Clark Company Incorporated will refund its purchase price. This
warranty applies only to a new product which has been sold through authorized channels of distribution. The purchaser voids the warranty if he
or others not authorized by David Clark Company Incorporated attempt to repair or service the unit, or if any parts not supplied by David Clark
Company Incorporated are inserted in the unit. Defective products or parts must be returned to the above address prepaid. THE FOREGOING
IS YOUR SOLE REMEDY FOR FAILURE IN SERVICE OR DEFECT, DAVID CLARK COMPANY INCORPORATED SHALL NOT BE LIABLE
UNDER THIS OR ANY IMPLIED WARRANTY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. This warranty is in lieu of all other
warranties, express or implied, INCLUDING THE WARRANTY OR MERCHANTABILITY OR FITNESS FOR USE, WHICH WARRANTIES ARE
HEREBY EXCLUDED. To the extent that this exclusion is not legally enforceable, the duration of implied warrants shall be limited to one year
from the date of purchase. No suit for breach of express or implied warranty may be brought after one year from the date of purchase. Some
states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or
consequential damages and the exclusion of implied warranties may not be legally enforceable, so the above limitations or exclusions may not
apply to you. This warranty gives you specific legal rights and you may have other rights which vary from state to state.
David Clark Company Incorporated, 360 Franklin St., Box
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
dc-connexsolutions.com/compliance.
LIMITED ONE-YEAR (Power Units) or Ninety Day (Accessories) WARRANTY

11
