Dear Cu󰘵omers,
Thank you for purchasing a B’TWIN electrically-assi󰘵ed bike. It will introduce you to the joys
of travelling on 2 wheels for your leisure, it will be the mo󰘵 practical and economical way for
you to get around in town and will allow you to burn calories to keep 󰘰t.
We invite you to read this in󰘵ruction manual to get the mo󰘵 out of your B’TWIN electrical-
ly-assi󰘵ed bike.
Never forget that an electrically-assi󰘵ed bike is not a moped. It needs your help to go further,
fa󰘵er and longer.
We sugge󰘵 that you learn how to use your electrically-assi󰘵ed bike in an open area in order
to get used to the feel of the motor kicking in and thus ensure optimum control of your bicycle.
Only use sport mode for your 󰘰r󰘵 kilometres if you are sure that you are able to control your
bike.
Here are the 10 commandments to get the be󰘵 use of your B’TWIN electrically-assi󰘵ed
bicycle.
Electrically assi󰘵ed bicycles are heavier than classic pushbikes. Without assi󰘵ance, pedal-
ling can be harder.
You mu󰘵 always make sure you are capable of riding the entire journey without assi󰘵ance,
in case your battery runs 󰘱at.
Important, this in󰄋ruction manual only applies to the electrical characteri󰄋ics of
your bicycle.
You should refer to the B’TWIN user manuals common to all our bicycles that ac-
company this document and are also available on our website www.btwin.com or on
reque󰄋 in our DECATHLON 󰄋ores.

4
10 be󰘵 practices for getting the mo󰘵 out of your electrically-assi󰘵ed bicycle.
1. You need to pedal to go further
3,5 - 4,5 bar
2. In order to improve battery life and e󰘲ciency, pump
the tyres to between 3.5 and 4,5 bar
< 3 bar
pfff
3. Under-in󰘱ated tyres are more prone to punctures
20° 5°
4. cold weather reduces battery life
5. Overloading the bicycle will reduce the battery life 6. Battery life will drop when cycling uphill
< 3 months
7. The battery mu󰘵 be fully charged at lea󰘵 once every
3 months
> mode 1 < mode 1
8. It is advisable to reduce the power assi󰘵ance mode
when the battery charge is low
9. the battery level indicator is more accurate when the
bike is at a complete 󰘵op
10. Remove the battery before conducting any mainte-
nance work

5
PRODUCT DESCRIPTION ............................................................................... 6
Electrically-assi󰄋ed bike technical features ..................................................................... 6
General operation of the electrical assi󰄋ance .................................................................. 6
SCREEN AND CONTROL ELEMENTS ........................................................... 7
Screen data and function .................................................................................................... 7
BATTERY AND CHARGER ............................................................................. 8
Precautions for use .............................................................................................................. 9
In󰄋alling and removing the battery.................................................................................. 11
Recharging the Battery ...................................................................................................... 12
Maintenance and lifetime (warranty conditions) ............................................................. 12
Additional precautions for use ......................................................................................... 13
Maintenance ....................................................................................................................... 14
Contents of the commercial warranty for your electrically-assi󰄋ed bike16
TABLE OF CONTENTS

6
PRODUCT DESCRIPTION
Electrically-assi󰄋ed bike technical features
A
Rear LED light
BBattery and controller
CBeam + connectors: brakes / control screen
DControl screen
EBraking detector
FFront LED light
GMotor wiring harness
HMotor
IPedalling detector
General operation of the electrical assi󰄋ance
The electrically-assi󰘵ed bike can be used with or without assi󰘵ance by pressing the ON/OFF button. Always
lock the battery with the key when in use. The electrical assi󰘵ance will only operate if you pedal. The assis-
tance will switch o󰘯 the moment either of the two brake levers is depressed or the speed reaches more than
25 km/h. It will then re󰘵art automatically when below 23 km/h. In order to preserve battery life, the bike is
equipped with a «power» limiter that limits assi󰘵ance when the motor is under heavy 󰘵rain. During intensive
use and in exceptional weather conditions, the assi󰘵ance may switch o󰘯 to safeguard the entire sy󰘵em.
A
B
C
DE
F
G
H
I

7
SCREEN AND CONTROL ELEMENTS
Screen data and function
light
1Assi󰄋ance mode :
Each mode corresponds to the maximum assi󰘵ance speeds given below:
Mode o󰓐 eco normal sport
Maximum assi󰄋ance speeds** 0 km/h 15 km/h 20 km/h 25 km/h
Average autonomous range** / 20 - 35 km
2ON/OFF button:
Switch the electrically-assi󰘵ed bike on and o󰘯 with a short press on the ON/OFF
button.
3
light
Lighting button:
Switch the bike lights on and o󰘯.
4MODE button:
Select the assi󰘵ance mode with a short press.
5
Battery level*:
Four battery levels.
When the battery level is too low: the indicator will 󰘵art to 󰘱ash.
*Check the battery charge indicator when 󰘵ationary. In the event that heavy assi󰘵ance is required, disparities
may be noticed.
** Under the conditions of te󰘵 protocols for a 75kg user, tyre pressures at 4 bar and respecting the 10 good
habits

8
BATTERY AND CHARGER
All our electric bike batteries use lithium-ion technology and are not subject to the memory e󰘯ect.
Recharging the battery after each use is recommended.
Charge the battery to 100% prior to its 󰄈r󰄋 use.
Battery Charger
Battery 24 V / 7.8 Ah Input: 100-240 V
Output: 29.4 V
Your battery is guaranteed for 2 years or 500 charging and discharging cycles (1 cycle = 1 charge from 0% to
100% + 1 discharge from 100% to 0%) subject to compliance with the proper conditions of use and 󰘵orage.

9
Precautions for use
+50° Do not expose to temperatures exceeding 50°C.
< +10°C +10°C / +50°C > +50°C
+10°C
+25°C
Storage conditions:
It is essential to 󰘵ore the battery charged and in a dry, cool place (between
+10°C and +25°C), out of sunlight.
< +10°C +10°C / +25°C > +25°C
+10°C
+40°C
Charge your battery in a dry environment at a temperature of between +10°C
and 40°C.
< +10°C +10°C / +40°C > +40°C
Important:
Under certain exceptional conditions, the controller may reach high tempera-
tures.
Never dismantle it.
Do not dispose of the battery in non-suitable containers. Return the used
battery to your Decathlon 󰘵ore for recycling.
Risk of 󰘰re.
Risk of electrocution.
To be handled with care.
Product is sensitive to impacts.
Never short-circuit the battery by connecting the positive and negative termi-
nals.

10
Never permit children to play with or handle the battery.
Do not immerse in water.
Do not clean using a high-pressure washer.
Rain resi󰘵ant.
x : 1..... 500 Your battery can be completely charged and drained 500 times.
Hereafter, the capacity and autonomy of the battery is reduced.
Always make sure that the battery and charger are compatible.
+100 V / +240 V Always ensure the charger is compatible with the local electrical grid:
Voltage: 100 V, 240 V maximum.
+50 Hz / +60 Hz
Frequency: 50 Hz minimum, 60 Hz maximum.
Only charge the battery indoors.
Transport by aeroplane is prohibited.
Any failure to comply with the precautions for use will void the manufactu-
rer warranty.
