Decathlon HB500 User manual

HB500
HANDBIKE
INSTRUCTION FOR USE - MODE D’EMPLOI - MODO DE EMPLEO - GEBRAUCHSANWEISUNG - GUIDA
PER L’UTENTE - MODO DE UTILIZAÇÃO - INSTRUKCJA OBSŁUGI - UPUTE ZA UPORABU - NAVODILA ZA
UPORABO

ENGLISH 2
FANÇAIS 16
ESPAÑOL 30
DEUTSCH 44
ITALIANO 58
PORTUGUÊS 72
POLSKIE 86
HRVATSKI 100
SLOVENŠČINA 113
1

Please read this manual carefully before adjusng or using this product.
If necessary, contact Decathlon or the manufacturing company at the address provided below.
Should you suffer from visual impairment, please download the manual in PDF format from our
website:
www.decathlon.com
Handbike designed and manufactured by:
OFF CARR s.r.l.
Via dell’Argianato II, 29
35010 Villa del Conte (Padova) Italy
Tel. [phone] Fax [phone]
E-mail: offcarr@offcarr.com hp://www.offcarr.com
If necessary, and for any further details regarding the safety of the handbike, repairs and ordinary or
extraordinary maintenance, please contact:
DECATHLON
4 BOULEVARD DE MONS - BP 299
59650 VILLENEUVE D’ASCQ CEDEX - FRANCE
hps://www.decathlon.com
All rights reserved
2

1. Presentaon 4
HB500 Descripon 4
HB500 Features 4
2. Warning 5
3. Supplied base configuraon 5
First use 6
Base configuraon 6
4. Adjustments 6
Rear seat height adjustment 6
Front seat height adjustment 7
Adjusng the seat inclinaon 7
Adjusng the backrest incline 8
Adjusng the tautness of the backrest canvas 8
Footplate depth adjustment 8
Leg strap assembly 9
Assembling the pelvic strap 9
5. Tips and recommendaons for use 9
6. Maintenance, inspecons and checks 10
Replacing the tyre and air chamber 10
Replacing the bearings 11
Brake inspecon 11
Derailleur inspecon 11
Axle inspecon 12
Lights, bell and reflectors inspecon 1 2
7. Cleaning and disinfecon instrucons 1 3
8. Packaging, transport and delivery 1 4
9. Material idenficaon 1 4
3

1. Presentaon
The HB500 is a handbike designed to meet the needs of adults and young people who are new to the sport of
handcycling on tracks and roads. Made with a lightweight aluminium alloy, it offers a wide range of
adjustments, meaning it can be configured in line with the users’ needs and the requirements of their various
pathologies. Addionally, it means it can accompany them as they develop and progress in their sport, from
leisure to compeons. The wheelchair complies with the following standards:
ISO 7176-8 (test model 120 kg)
ISO 7176-16
You must NOT use wheelchairs and their elements incorrectly or for uses other than those indicated
in this manual.
1.1 HB500 Descripon
The HB500 is a three-wheeled manual handbike with an aluminium frame.
1.2 HB500 Features
● Aluminium alloy frame
● Wheels: 26” (25-571), road tyre casings
● Predefined camber: 12°
● Derailleur:Shimano Nexus on front wheel (8 speeds on the front wheel hub)
● Seat width: 400 mm
● Seat depth: 420 mm
● Backrest height: 350 mm
● Backrest angle relave to the ground: 105°- 75°
● Seat angle:min 2° max 10°
● Leg angle relave to the seat: min 55° max 90°
● Distance between seat and footplate: 430 mm ( adjustable )
● Seat front height in relaon to ground: 500 mm ( adjustable from 500 to 600 mm)
● Height of seat back from the ground: 420 mm ( adjustable from 420 to 560 mm)
● Backrest incline: 91° (adjustable)
● Foot strap: standard
● Polyurethane cushion 75 sh., H 30 mm (prof. Std. 420 mm) not an-sores.
● Dimensions:
○ Total width: 775 mm [700 mm ]**
○ Total length: 1800 mm [1200 mm]**
○ Total height: min 1000 mm, max 1050 mm [1200 mm]**
○ Turning diameter: 4850 mm
** Note: Some dimension measurements may be greater than the measurements set out in
4

the EN ISO 12183 regulaon [xxx mm]. In some cases, it may be difficult or impossible to use
emergency exits provided.
● Total weight: 21,1 kg
● Maximum user weight: 120 kg
● Accessories: lights, bell, reflectors
2. Warning
The user is reminded that they should carry out a self-assessment of the crical points associated with their
specific pathology, and with their parcular postural requirements, before proceeding with any adjustments or
use of the handbike. OFFCARR does not accept any responsibility for any damages caused by incorrect
seang in the handbike, or by features of sing in the wheelchair which are incompable with the user's
pathology.
The cushion provided IS NOT ANTI-SORE , it is made with expanded polyurethane with a density of 75
shore with a Nylon fabric cover.
Avoid contact of the handbike with water.Undesirable rust may occur on some metal parts and/or loss of
the safety features of the materials concerned.
The handbike must only be used for the sport it has been designed for, or for compable disciplines, and
not for transporng objects in general, and it must not be used in other contexts. This could be dangerous
insofar as some of the usual safety elements for the device in moon are absent (e.g. Parking brakes, etc.).
Allergies caused by contact with parts of the handbike should be reported.
Keep the handbike away from heat sources in order to avoid any of the components seng alight. The
coverings meet the criteria for the standard ISO 7176 16:2012.
Do not put your fingers into the spikes when the handbike is in moon.
Inflate the tyres to a pressure within the range indicated inside the tyre. If transporng by plane, it is
suggested that you deflate the tyres to avoid excess pressure.
The handbike must be regularly maintained, so that it is kept in good working condion but especially so
that the safety condions are upheld.
Inefficient maintenance and the improper use of the device may cause damages and injury to users.
Alteraons may invalidate the minimum safety condions.
The registraon of the device and the address of the manufacturer can be found on a small scker
located underneath the handbike’s lower frame. This scker must never be removed, at risk of invalidang the
product's guarantee.
The indicated life span of the wheelchair is 4 years under normal usage condions, subject to it always
being used by the same person and undergoing regular maintenance.
3. Supplied base configuraon
The HB500 handbike comes with a standard configuraon and is ready to use.
5

3.1 First use
Set-up must be performed before using the device and must be done by the user or the person assisng
him/her.The handbike is shipped with the rear wheels removed. Posion the rear wheels and secure them
using a 6 mm Allen key (supplied).It is recommended you check the pressure of the wheels before use,
ensuring they're at 9 BAR. The inflaon pressure is indicated on the sides of the tyre covers. However, it is
recommended that you always ensure that the wheels are properly secured before using the handbike.
3.2 Base configuraon
The TW500 wheelchair comes with the following adjustment:
Seat width
L
400 mm
Drive wheels
W
26”
Seat depth
D
420 mm
Backrest height
HS
350 mm
Backrest incline
IS
91°
Front height of the seat in relaon to the ground
FH
500 mm
Rear height of the seat in relaon to the ground
RH
420 mm
Camber
C
12°
Derailleur
8 gears on the hub
Cushion H 30mm
400 x 420 mm
4. Adjustments
4.1 Rear seat height adjustment
To funcon properly, the carriage mount should be as parallel as possible to the ground. To adjust the rear
height:
● Loosen but do not remove screws "F4" and "F3" (see 4.2)
● Unscrew and remove the “4” screws.
● Posion the rear seat at the desired height, aligning the holes in the plate.
● Replace the "D" screws and ghten them properly.
● Tighten the F4 "F3" screws
Ensure that the screw posions on the plates are the same on both sides.
6

4.2 Front seat height adjustment
The handbike is shipped with a front height of 50 cm from the ground. Please note that this seng is the only
way to change the distance relave to the footplate.We therefore recommend verifying that this distance is
correct immediately aer selecng the desired seat inclinaon and adjusng the rear height in the same way:
To funcon properly, the carriage mount should be as parallel as possible to the ground. The distance between
the seat and ground can vary from 500 to 600 mm, and between 400 and 500 mm for the footplate. To set the
front height:
● Loosen but do not remove screws "F3" and "F4" (see 4.1)
● Unscrew and remove the “B” screw.
● Posion the front seat support at the same height as the rear (parallel to the ground), aligning the
holes in the plate
● Put the "B" screws back in place and ghten them properly.
● Tighten the F3 "F4" screws
4.3 Adjusng the seat inclinaon
The seat angle can be adjusted via two plates on either side of the seat.
● Loosen the F1 screws
● Unscrew and remove the "A" screws
● Select the new angle from the 4 possible posions
● Re-insert and ghten the A screws
● Tighten the F1 screws
These operaons must be carried out at the same me on both sides.
7

4.4 Adjusng the backrest incline
The backrest is shipped with a standard angle of 91°, which can be modified in the following manner:
● Loosen the F6 screws
● Loosen and remove screws "E" and "F"
● Select the desired angle by aligning the holes correctly.
● Insert and ghten screws "E" and "F" properly and ghten the "F6" screws.
Ensure that the screw posions on the plates are the same on both sides.
4.5 Adjusng the tautness of the backrest canvas
● Li the rear secon of the canvas.
● Loosen the straps.
● With the athlete in playing posion, pull taut the straps as much as necessary, starng with the top
strap.
● Fold the backrest canvas back again.
● Try some game movements and repeat the operaon if the posion isn't quite right.
4.6 Footplate depth adjustment
The depth of the footplate is adjustable in depth. To do this:
● Slightly loosen screw "K"
● Slide the footplate along the guide to the desired posion
● Tighten screw "K" securely
8

4.7 Leg strap assembly
The HB500 is equipped with a leg strap to keep the knees aached to the frame. On each end of the strap
there is respecvely a male and a female velcro patch.For assembly, we recommend pressing the male velcro
end of the strap onto the legs (velcro upwards) and running the strap around the legs so that the other end
with the female velcro aaches to the first, as shown in the photo:
4.8 Assembling the pelvic strap
The HB500 is designed to accommodate a 45° pelvic strap.This can be mounted on the backrest adjustment
bar, as shown in the diagram.
5. Tips and recommendaons for use
If needed, the padding can be washed at low temperatures. Nevertheless, avoid immersing the other,
mechanical parts of the wheelchair in water. Always clean the handbike thoroughly for maximum efficiency.
9

6. Maintenance, inspecons and checks
ATTENTION!
● Always ensure that the wheels are correctly locked (see par. 6.5).
● Always ensure that the lights, bell and reflectors are correctly posioned (see par. 6.2)
● The handbike should be regularly checked to ensure it remains efficient and safe.
● Insufficient maintenance and improper use of the device may cause damages and injury to people
or property.
● There is no real danger of personal injury when using the handbike as it has been designed to
reduce the risk of accidents during use or preparaon for use. However, as this is a specialist
product that could become dangerous if used in different contexts, we recommend using only
original or manufacturer-approved spare parts when replacing certain components.
● Should you encounter any difficules in finding spare parts on the market, please contact
DECATHLON.
Each week :
● Check the tyre pressures. On the side of each wheel cover, you’ll find the recommended tyre
pressure. A deflated tyre compromises the smooth operaon of the Handbike.
● Check the efficiency of the brakes (see par 6.3).
● Check that the gear and brake cables are not entangled.
Each quarter:
● Ensure that the rear wheel bearing bolts are securely fastened.
● Verify the efficiency of the bearings on the front and rear wheels and lubricate if necessary. We
recommend using silicon oil as a grease, as it's effecve and non-staining.
● Check the posion of the gear shi (see par.6.4).
6.1 R eplacing the tyre and air chamber
Disassembling the tyre and air chamber
● Deflate the tyre
● Install a special lever between the circle and the shoulder of the tyre, so that when the lever is lted,
the side of the wheel comes out (fig. 1 and 2)
● Install another lever 100 mm from the previous point and repeat the operaon (fig. 3)
● Slide the two levers around the whole circle to release the enre tyre.
● Remove the air chamber, starng with the side opposite the inflaon valve (fig. 4)
● Once the air chamber has been removed, you can easily remove the tyre to replace either or both of
them.
Assembling the air chamber and tyre
● Remove the air chamber (deflated) in the tyre (fig. 5).
● Insert the air chamber inflaon valve into the whole intended for this purpose, located on the circle.
● Around the whole circle, install the tyre, taking note of the direcon of the tyre, which indicates
whether it's the right or le drive wheel.
● Install the opposite shoulder over the tyre, starng from the point where the valve is, moving round in
both direcons.
● Insert the final part of the shoulder with the help of the levers intended for this, reversing the
instrucons shown in Fig. 3, Fig. 2, and Fig. 1.
● Inflate the tyre to the pressure indicated on its side.
10

FIG. 1 FIG. 2 FIG. 3 FIG. 4 FIG. 5
6.2 Replacing the bearings
Disassembly
● The drive wheel bearings (6001 2RS) are mounted by applying pressure. To remove them, you simply
need to push them from the inside, using a pin dri and a hammer.
Assembly
● Posion a new bearing on the inner side of the hub, taking care to insert it evenly (it must be co-axial
with the hub, otherwise it won't go in).
● Before posioning the bearing, on the opposite side, you need to insert the quick removal axle into
the bearing which has already been inserted, so that the axle itself acts as a guide for the two
bearings. This way, you make sure that the hub and two bearings are co-axial.
6.3 Brake inspecon
To check the proper funconing of the brakes, first examine the integrity of each brake component (lever,
lining, clamp), then press the brake levers one at a me to check whether each independently acvates the
brake clamp.
OPEN AND CLOSED BRAKE CLAMP BRAKE LEVER
6.4 Derailleur inspecon
Raise the front wheel with a tripod so that it can turn freely. Move the levers in the direcon of travel, acvate
the derailleur by means of the two levers on the right-hand crank and check whether each gear change
11

corresponds to the relevant adjustment of the derailleur (you can feel whether the pedalling movement
becomes more difficult or easier depending on the direcon given).
DERAILLEUR LEVERS
6.5 Axle inspecon
Once the wheel has been mounted as shown below and the axle has been screwed in clockwise, pull the wheel
outwards and push it towards the inside of the chair to verify that there is no movement.
6.6 Lights, bell and reflectors inspecon
The front and rear (independent) lights are posioned on the HB500 in the locaons shown in the figure
below.One reflector is placed on each wheel as shown below.
12

FRONT LIGHTING REAR LIGHTING
REFLECTORS
7. C leaning and disinfecon instrucons
ATTENTION! Use the appropriate eye/face protecon and gloves during cleaning and disinfecon
operaons.
If the wheelchair comes into contact with blood or other bodily fluids, it must first be cleaned and disinfected,
following the instrucons below.
Note: In most cases, it is more interesng and more efficient to remove the seat and backrest canvas before
cleaning and disinfecng.
Frame
● Wash the HB500 with a damp cloth, using warm water and neutral soap to remove dirt or stains.
● Wash the HB500 again with a damp cloth to remove the detergent product.
● Dry the HB500
● Visually check that the wheelchair is clean
● Disinfect the wheelchair with 70-90% alcohol.
● Make sure that the wheelchair is completely dry before proceeding.
Canvases
If the user is the same before and aer cleaning:
● Wash, rinse and disinfect the canvases, using the same procedure as used for the frame.
● Make sure that the canvases are completely dry before re-aaching them to the frame.
If the user changes aer cleaning:
● We recommend replacing the canvas from the seat and backrest with new, fresh canvases.
NOTE: During cleaning operaons, the wheelchair must be carefully inspected for ant damages, rust or
malfuncons.. If damage or malfuncon is reported, the elements must be repaired or replaced.
13

ATTENTION! All waste generated by this process must be discarded in line with the applicable local
legislaon.
8. P ackaging, transport and delivery
All HB500 are shipped packaged in sealed cardboard boxes, intended to protect them from impacts and dust.
The packaging includes the HB500 in its basic configuraon, fied with wheels and accessories, a service kit
for basic maintenance, and this user manual to which the guarantee card is aached. The HB500 should be
transported using sealed transport methods which protect it from atmospheric agents, as reminded in the
instrucons provided to this effect on the packaging. Upon delivery, check the integrity of the packaging:
Open the packaging and check to make sure that the wheelchair hasn't been damaged in transit. Once these
inial checks, which are compulsory for the validity of the guarantee, have been carried out and if the HB500
isn't used soon aer, repackage it and store it in a dry place, in a storage area at a temperature between -15
°C and 50° C and RH lower than 80%. Do not lean or place objects on the packaging, as indicated via the
symbols featured on the packaging.
9. M aterial idenficaon
The HB500 is made using the following materials: aluminium, steel, tanium, polyurethane thermoseng
resins, and other composite materials. The sorng and disposal of these materials must be carried out in
accordance with the current regulaons.
14

HB500 products comply with Regulaon (EU) MDR 2017 745.
OFF CARR s.r.l. Reserves the right to make improvements and/or changes to its products without prior noce, in
compliance with the appropriateness of the assistance wheelchair, the contractual condions of guarantee and
the availability of spare parts in compliance with the applicable legal provisions.
UMHB500R6 Date of update: May 2021
15

Lire aenvement les indicaons du présent manuel avant d’effectuer une quelconque opéraon de
réglage et/ou de mise en service sur ce produit.
En cas de nécessité contacter Decathlon ou la société fabricante à l’adresse indiquée ci-après.
En cas de déficience visuelle veuillez télécharger le manuel au format PDF sur le site:
www.decathlon.com
Appareil conçu et produit par:
OFF CARR s.r.l.
Via dell’Argianato II, 29
35010 Villa del Conte (Padova) Italy
Tel. [phone] Fax [phone]
E-mail: offcarr@offcarr.com hp://www.offcarr.com
Si nécessaire et pour toute précision concernant la sécurité du disposif, les réparaons et l’entreen
ordinaire et extraordinaire veuillez contacter :
DECATHLON
4 BOULEVARD DE MONS - BP 299
59650 VILLENEUVE D’ASCQ CEDEX - FRANCE
hps://www.decathlon.com
Tous droits réservés
16

1. Présentaon 18
Descripon HB500 18
Caractérisque HB500 18
2. Averssements 19
3. Configuraon de base de fourniture 20
Mise en service 20
Configuraon de base 20
4. Réglages 20
Réglage de la hauteur arrière du siège 20
Réglage de la hauteur avant du siège 21
Réglage de l’inclinaison du siège 21
Réglage de l’inclinaison du dossier 22
Réglage de la tension de la toile du dossier 22
Réglage de la profondeur du repose-pieds 23
Montage de la sangle des jambes 23
Montage de la sangle pelvienne 23
5. Conseils et recommandaons d'ulisaon 24
6. Entreen, inspecons et contrôles 24
Remplacement pneu et chambre à air 24
Remplacement des coussinets 25
Contrôle des freins 25
Contrôle dérailleur 26
Contrôle axe 26
Contrôle éclairage, sonnee, catadioptres 26
7. Instrucon de neoyage et désinfecon 27
8. E mballage, transport et livraison 28
9. Différenciaon des matériaux 28
17

1. Présentaon
HB500 est un handbike conçu pour répondre aux exigences d’adultes et jeunes qui découvrent la discipline
handbike praquée sur piste et sur route. Réalisé dans un alliage d’aluminium léger, il offre une large gamme
de réglages lui permeant d’être configuré en foncon des besoins d' ulisateurs ayant des pathologies
différentes, et de les accompagner dans le développement et leurs progrès sporfs, de loisir et de compéon.
Le disposif est conforme aux normes suivantes :
ISO 7176-8 (mannequin d’essai 120 kg)
ISO 7176-16
Il est interdit d'uliser les fauteuils roulants et les éléments de ceux-ci à des fins impropres ou
différentes de celles prévues dans ce manuel.
1.1 Descripon HB500
HB500 est un modèle de handbike manuel à trois roues avec châssis en aluminium.
1.2 Caractérisque HB500
● Châssis en alliage d’aluminium
● Roues: 26” (25-571), enveloppes de pneu route
● Carrossage prédéfini: 12°
● Dérailleur: Shimano Nexus intégré sur roue avant (8 vitesses intégrées sur le moyeu de la roue
antérieure)
● Largeur assise: 400 mm
● Profondeur assise: 420 mm
● Hauteur dossier: 350 mm
● Angle dossier par rapport au sol: 105°- 75°
● Angle assise: min 2° max 10°
● Angle jambes par rapport à l’assise: min 55° max 90°
● Distance du siège au repose pieds: 430 mm ( réglable )
● Hauteur siège antérieur par rapport au sol: 500 mm ( réglable de 500 à 600 mm)
● Hauteur siège postérieur du sol: 420 mm ( réglable de 420 à 560 mm)
● Inclinaison dossier: 91° (réglable)
● Sangle bloque-pied: de série
● Coussin en polyuréthane 75 sh., h 30 mm (prof. Std. 420 mm) non an-escarres
● Encombrements:
○ Largeur totale: 775 mm [700 mm ]**
○ Longueur totale: 1800 mm [1200 mm]**
○ Hauteur totale: min 1000 mm, max 1050 mm [1200 mm]**
○ Diamètre de braquage: 4850 mm
18

** note: Certaines mesures d’encombrement pourraient être supérieures aux mesures
prévues par la réglementaon EN ISO 12183 indiquées [xxx mm]. Dans certains cas, il
pourrait être difficile ou impossible d'uliser les issues de secours prévues.
● Poids total: 21,1 kg
● Portée maximum 120 kg
● Accessoires : éclairage, sonnee, catadioptres
2. A verssements
Il est rappelé à l’ulisateur qu’une autoévaluaon des points criques liés à sa pathologie propre et aux
exigences posturales spécifiques est indispensable avant de procéder à l’éventuel réglage et ulisaon du
handbike. OFFCARR décline toute responsabilité pour d’éventuels dommages causés par une assiee
incorrecte du handbike ou par des caractérisques de celui-ci incompables avec la pathologie de
l’ulisateur.
Le coussin fourni N’EST PAS ANTI-ESCARRES , il est réalisé en polyuréthane expansé d’une densité 75
shore avec housse en ssu de Nylon.
Éviter le contact du handbike avec l’eau. Il peut se produire une oxydaon indésirable de certaines
pares métalliques et la perte des caractérisques de sécurité des matériaux concernés.
Le handbike ne doit être ulisé que pour praquer le sport pour lequel il a été conçu ou des disciplines
compables, et non pour le transport d'objets en général, il ne doit pas être ulisé dans d’autres cadres. Il
pourrait s’avérer dangereux dans la mesure où certains éléments de sécurité habituels dans les appareils de
promenade sont absents.
Il convient de signaler les allergies causées par le contact avec des pares du handbike.
Tenir le handbike éloigné de sources de chaleur dans la mesure où tous les composants ne sont pas
ignifugés. Les revêtements répondent aux condions de la norme ISO 7176 16:2012.
Ne pas introduire les doigts dans les rayons lorsque le handbike est en mouvement.
Gonfler les pneus à une pression non supérieure à celle indiquée dans le pneu lui-même. En cas de
transport par avion, il est suggéré de dégonfler le pneu pour éviter les surpressions.
Le handbike doit être régulièrement entretenu aussi bien pour le conserver en bon état de marche mais
surtout pour conserver les condions de sécurité.
Des entreens inefficaces et l’ulisaon inappropriée de l’appareil pourraient causer des dommages et
des blessures aux ulisateurs.
D’éventuelles altéraons pourraient faire disparaître les condions minimales de sécurité.
Le matricule du disposif et l’adresse du constructeur se trouvent sur une pete plaque placée sous le
châssis inférieur du handbike. Cet autocollant ne doit jamais être enlevé sous peine de déchéance de la
garane.
La durée de vie indiquée du disposif est de 4 ans dans des condions normales d’ulisaon, à
condion d’être toujours ulisé par la même personne et d’être régulièrement entretenu.
19
