EN - User manual
ROCKRIDER E-ST900
3
Dear Cuomers,
Thank you for purchasing a ROCKRIDER electrically-assied bike.
We invite you to read the inruction manual to get the mo out of your e-ST900 bike.
Never forget that an electrically-assied bike is not a moped. It needs your help to go further,
faer and longer.
We sugge that you learn how to use your electrically-assied bike in an open area in order
to get used to the feel of the motor kicking in and thus ensure optimum control of your bicycle.
An electrically assied bicycle is heavier than a conventional bicycle (unloaded weight of the
ROCKRIDER e-ST900 is 21.9 kg for the small version, 22.1 kg for the medium, 22.2 kg for
the large version and 22.3 kg for the extra large version). Without power assiance, pedalling
can be more dicult.
You mu always make sure you are capable of riding the entire journey without assiance,
in case your battery runs at.
Here is what you need to do to get the mo out of your ROCKRIDER power-assied bike.
Important, this inruction manual only applies to the electrical characteriics of
your bicycle.
You should refer to the user guides for all our bicycles that come with this document
and that are also present on our www.supportdecathlon.com website or on reque
in our DECATHLON ores.
4
How to get the mo from your PAB
1,0 - 1,8 bar
1. The bike will operate better and more eciently with
tyres inated between 1.0 and 1.8 bar
< 3 bar
pfff
2. Under-inated tyres are more prone to punctures
< 6 months
3. The battery mu be fully charged at lea once every
6 months 4. cold weather reduces battery life
5. Overloading the bicycle will reduce the battery life 6. Battery life will drop when cycling uphill
7. Remove the battery before conducting any mainte-
nance work
> mode 1 < mode 1
8. It is advisable to reduce the power assiance mode
when the battery charge is low
5
PRODUCT DESCRIPTION ............................................................................... 6
Electrically-assied bike technical features ..................................................................... 6
General operation of the electrical assiance .................................................................. 6
SCREEN AND CONTROL ELEMENTS ........................................................... 7
Screen data and function .................................................................................................... 7
Browsing between screens ................................................................................................. 8
Settings screen navigation ................................................................................................. 9
MOTOR ........................................................................................................... 10
BATTERY AND CHARGER ........................................................................... 10
Battery properties and warranty ....................................................................................... 10
Theoretical battery life according to the conditions of use and assiance mode ...... 10
Precautions for use ............................................................................................................ 11
Inalling and removing the battery.................................................................................. 13
Recharging the Battery ...................................................................................................... 14
Maintenance and lifetime (warranty conditions) ............................................................. 14
Battery self-diagnoic....................................................................................................... 15
Safety information ......................................................................................... 16
Maintenance .................................................................................................. 17
Accessories ................................................................................................... 18
Error code ...................................................................................................... 18
Contents of the commercial warranty for your electrically-assied bike20
Appendix 1: Component tightening torque ................................................ 21
TABLE OF CONTENTS
6
PRODUCT DESCRIPTION
Electrically-assied bike technical features
A
Battery
B
Battery lock handle and barrel
C
Motorised unit
D
Control screen
E
Cable from the controller screen to the motorised unit
General operation of the electrical assiance
The power-assied bike can be used with or without assiance by pressing the ON/OFF button or altering the modes 0-1-2-3-4. The selectable
0-1-2-3-4 assiance modes on the «D» display screen allow you to choose a power assi level in addition to the eort provided. Power assiance
will only work if you are pedalling, with a selected mode other than 0. Assiance cuts o when the speed is above 25km/h. In case of intensive use
and in exceptional climatic conditions, assiance may be cut o to safeguard the whole syem.
The power supplied is calculated by the motorised unit controller «C» based on your pedalling rate and the force applied to the pedals. The control-
ler «C» will provide more or less power depending on the mode selected and the force applied.
Power assiance does not kick in or shuts down in the following situations:
- The speed is above 25km/h
- You’re not pedalling
- The remaining battery charge is not sucient
- »0» is the power assiance mode selected
- When the control screen is o
In case of intensive use and in exceptional climatic conditions, power assiance may be cut o to safeguard the whole syem
A
B
C
D
E
7
SCREEN AND CONTROL ELEMENTS
Screen data and function
1
2
34
05
0
Long press: turns the electric bike on and o
1
Short press: switches to a higher assiance mode
Long and suained press: activates the pederian assiance mode when not
in mode 0
2
Short press: switches to a lower assiance mode
3
Short press: switches on the lights
Long press: switches o the lights
4
Navigation joyick (horizontal direction, vertical to select, click the
centre to conrm)
5
Information screens (details below)
Mode 0 1 2 3 4
Maximum assiance speeds*** + 0% + 40% 80% + 160% + 320%
For example, for a 100 W eort,
the nal power will be: 100W 140W 180W 260W 420W
Welcome screen
11
6
7
8
9
10
6
Active assiance mode: 4 modes available + mode 0 without assiance
7
Inantaneous speed
8
Battery charge level
9
Pederian assiance mode: When you have to push your bike up a hill, this mode is ideal as you
won’t notice the weight of the bike! N.B.: Do not use this mode when you are on the bike. This
mode arts and continues to be applied while the button is held down (when not in mode 0).The
mode ops when the pressure on the button is released.
10
Lighting: Visible but irrelevant here since the Rockrider e-ST900 is not equipped with a lighting sys-
tem. A short press switches on the indicator light. A long press switches it o. You can purchase
suitable lights (not oered by Décathlon) and connect them to the motor (see support page at
www.supportdecathlon.com).
8
Browsing between screens
Human power
0
W
Residual range
38
km
Tour distance
39.6
km
Speed
19.7
km/h
Max. Speed
44.5
km/h
RESET
Total distance
478
km
RESET
Auto Light
Language
Mount position
12 13 14
15
16
17
18
19 2011
12
Human power: Inant pedalling power.
13
Residual range: Residual range, kilometres that can be covered in active mode and the level of charge remaining.
14
Tour diance: Diance travelled.
15
Ø Speed: Average speed.
16
Max.Speed: Maximum speed.
17
RESET: Resets the values for Ø Speed, Max. speed, Tour diance.
18
Push the joyick to conrm the reset.
19
Total diance: Diance travelled.
20
Settings
9
Settings screen navigation
German
English
French
Auto Light
Language
Mount position
Auto Light
Language
Mount position
Auto Light
Language
Mount position
German
English
French
Allemand
Anglais
Français
Right
Left
Right
Left
Right
Left
Right
Left
Auto Light
Language
Mount position
Auto Light
Language
Mount position
20
21
22
23
21
Auto-light: Option that automatically controls the lights. Visible but not relevant here since the Rockrider e-ST900 is not equipped with a
lighting syem.
22
Language: Choice of display language (German, English, French, Italian, Dutch, Spanish)
23
Mount position: Reverses the direction of the screen so that it can be xed on the left or the right, as required.
10
MOTOR
Motor «C» of your power-assied bike is a brushless-type motor with mechanical reduction, allowing you to have high torque and less resiance
(quieter motor). So motor noise in use does not exceed 70 db. The power of the motor is limited to 250 W maximum.
BATTERY AND CHARGER
Battery properties and warranty
Voltage: 100 V, 240 V maximum.All batteries in our electric bikes use Lithium-Ion cell technology and have no memory eect. (the battery can be
recharged at any time; there’s no need to wait until it’s completely discharged).
Recharging the battery after each use is recommended.
Charge the battery to 100% prior to its r use.
Battery Charger
36 V/14 Ah
504Wh
Input: 100-240 V
Output: 42V 4A
Your battery is guaranteed for 2 years or 500 charging and discharging cycles (1 cycle = 1 charge from 0% to 100% + 1 discharge from 100% to
0%) subject to compliance with the proper conditions of use and orage. The battery should be recharged after each use. Charge the battery fully
before using for the r time.
Do not use a dierent charger from the one supplied by DECATHLON for this bike model. Using another charger may damage the battery or cause
serious incidents (sparks, re).
Theoretical battery life according to the conditions of use and assiance mode
Easy conditions Mode 1
Mode 1
Mode 1
Mode 2
Mode 2
Mode 2
Mode 3
Mode 3
Mode 3
Normal conditions
Dicult conditions
Mode 4
Mode 4
Mode 4
Subject to proper use, for a cycli weighing 75kg in a gentle wind with an outside temperature of 25°C.
11
Precautions for use
+50°
Do not expose to temperatures above 50°C. Outside this range, battery life will be aected.
< +10°C +10°C / +50°C > +50°C
+10°C
+25°C
Storage conditions: It is essential to ore the battery charged and in a dry, cool place (between +10°C
and +25°C), out of sunlight.
< +10°C +10°C / +25°C > +25°C
+10°C
+40°C
Charge your battery in a dry environment at a temperature of between +10°C and 40°C.
< +10°C +10°C / +40°C > +40°C
Important: Under certain conditions, the controller, charger and mechanical brake discs may reach high
temperatures.
Never dismantle it.
Do not dispose of the battery in non-suitable containers. Return the used battery to your Decathlon ore
for recycling.
Risk of re.
Risk of electrocution.
To be handled with care.
Product is sensitive to impacts.
Never short-circuit the battery by connecting the positive and negative terminals.
12
Never permit children to play with or handle the battery.
Do not immerse in water.
Do not clean using a high-pressure washer.
The battery and other electrical components are designed to withand rain.
Your battery can be fully charged and discharged 500 times without any signicant drop in perfor-
mance.
Always make sure that the battery and charger are compatible.
+100 V / +240 V
Always ensure the charger is compatible with the local electrical grid:
Voltage: 100 V, 240 V maximum.
+50 Hz / +60 Hz
Frequency: 50 Hz minimum, 60 Hz maximum.
Only charge the battery indoors.
Transport by aeroplane is prohibited.
Any failure to comply with the precautions for use will void the manufacturer warranty.
13
Inalling and removing the battery
Inallation:
Before inserting your battery in its housing, make sure that the lock is in the open position and does not interfere with the insertion of the
battery.
Removal:
Remember to unlock your battery before removing it from its housing.
14
Recharging the Battery
Start of charging red LED.
Green LED when charging is complete. LED ashing red, problem during charging, contact
cuomer services.
Maintenance and lifetime (warranty conditions)
Do not ore the discharged battery (1 ashing blue LED) to avoid deep discharge, which may cause
it to malfunction.
In cases of extended orage, recharge the battery once every 6 months.
6h00
6 months
15
Battery self-diagnoic
11% - 20%
21% - 40%
41% - 60%
61% - 80%
81% - 100%
Battery recharge is needed urgently
<10%
Undervoltage protection
temperature protection
Return your battery to your af
-
ter-sales service
short circuit protection
other protection
LED o LED on LED ashing
16
SAFETY INFORMATION
Please note: this bike is designed for oroad use.
The following uses are inappropriate and should be avoided:
Descent - Dirt Jump - Freeride - Enduro
(Risk of accident and cancellation of the bike’s guarantee if you do not respect this condition)
Warning, in the event of wheel removal, you mu ensure the direction of rotation of your wheel
is correct.
Before each use you mu make sure that your brakes and electric syem are working properly
The weight, power, manufacturing year and maximum speed are indicated on your bicycle’s
frame.
As the weight of your bike with electric assiance exceeds 15kg, we recommend that 2 persons
transport it.
Always wear a helmet when riding your bike.
These electric bikes are designed for persons aged 14 and over.
Maximum permissible weight on the bike: 120 kg in total (including accessories)
Never modify the bike’s components or electrical syem! Any change is dangerous and prohi-
bited by law.
If a modied bike breaks down or is damaged, Decathlon will not under any circumances take
care of repairs (warranty cancelled). You will also be legally responsible for any accident that
may have occurred with the bike.
Caution: in rain, fro, or snow, you may have less tyre traction.
17
MAINTENANCE
Warning - the maintenance of electrical components requires special skills and is not carried in
ores but in Decathlon regional workshops and can take several days.
All cleaning work mu be done with the battery on the bike but the bike turned o! That way, the
battery connections will be hidden and protected from the water.
Electrical or mechanical maintenance operations mu be carried out with the bike switched o,
with the battery removed from the bike. Maintenance operations specic to the bike’s electric
syem other than checking the connections mu be carried out by qualied, trained personnel.
If the chain comes o, switch o the power before carrying out any repairs.
NB: the weight of the bicycle may exceed that of your assembly and or bicycle rack.
6 months
We advise you to bring your electrically-assied bike back to your DECATHLON ore for its
6-month service.
Always carry out maintenance operations in sucient light.
If the bike or battery suers a fall, check that your battery is intact.
If the battery is physically damaged, go to a DECATHLON workshop for a battery diagnoic te.
18
Prohibited: cleaning using a high-pressure jet.
Not recommended: cleaning under running water.
Recommended: cleaning using a damp sponge.
For more information on use, maintenance, after-sales services or in case of queions, visit
DECATHLON’s support website: www.supportdecathlon.com or visit a DECATHLON ore.
The central drive belt mu be changed every 15,000 km
ERROR CODE
Error code Denition Solutions
10 / 12
Battery power low Charge the battery.
11
Power surge protection Switch o and reart the bicycle.
20
Power measurement error Switch o and reart the bicycle.
21 / 23
Temperature sensor error Switch o and reart the bicycle.
24 / 25
Abnormal current or power Recharge the battery and reart the bicycle.
26
Program reboot error Recharge the battery and reart the bicycle.
30
Pederian mode error Allow the motor to cool. Recharge the battery and reart the
bicycle.
40 / 41
Motor power surge Allow the motor to cool by pedalling more gently or lowering the
assiance mode.
ACCESSORIES
It is possible to add front and back lights powered by the motorised unit. These lights mu be 6V and compatible with the BROSE motor. You can
nd a reference to a compatible syem and more information on the Decathlon SUPPORT website: www.supportdecathlon.com, and a reference
to a compatible syem (not available from Decathlon).
19
42 / 43
Motor error or short circuit Switch o and reart the bicycle.
44
Motor overheating Allow the motor to cool by pedalling more gently or lowering the
assiance mode.
45
Error corrected during use Switch o and reart the bicycle.
46
Motor not operating Check that the motor connections are properly plugged in. Reart
the bike.
60
Controller communication/screen error
Check that the screen connection is pushed in properly and that
the battery is correctly inalled on the bicycle, then reart the
bicycle.
70 / 71 / 72
/ 73
Torque sensor error Switch o and reart the bicycle.
80 / 82 / 83
/ 84
Controller programme error Switch o and reart the bicycle.
81
Speed data not recognised Check that the magnet xed on a spoke on the back wheel is ill
there and is in the correct position for the speed sensor.
Check the screen connections if the screen
does not light up.
20
CONTENTS OF THE COMMERCIAL WARRANTY FOR YOUR ELECTRI-
CALLY-ASSISTED BIKE
Please ensure that you keep your invoice as proof of purchase.
The bicyle has a lifelong guarantee on the ructural components (frame, handlebar em, handlebar and saddle-pillar), 2 years on
parts subject to normal wear and tear.
The warranty does not cover damage resulting from misuse, from a failure to respect the precautions for use, from accidents, from
improper use or from commercial use of the bike.
This bike is for personal use only and not for professional use.
The warranty does not cover damage resulting from repairs carried out by persons not authorised by Decathlon.
Each electronic component is permanently sealed. Opening one of these components (battery, battery sheath, controller, screen,
motor) may cause physical injury to persons or damage to the syem. Opening or modifying a component in the syem will void the
warranty for the bike. The warranty does not cover cracked or broken screens showing visible signs of impacts.
FURTHER DETAILS REGARDING THE LIFETIME WARRANTY ON B’twin BIKES, purchased as of 1 June 2013.
B’twin brand bikes are products designed to provide complete satisfaction to their users. For this reason,
B’twin wishes to commit to the quality and durability of its bikes.
Within this context, B’twin oers its clients a lifetime warranty which exclusively covers the following noncarbon parts: frames, rigid
forks (non-suspension forks), handlebars and ems tted to B’twin brand bikes. This warranty begins on the date of purchase of (a)
B’twin brand bike(s).
It is specied that, for the lifetime warranty to be valid, the buyer mu:
either have a DECATHLON ore loyalty card and regier his/her purchase on it at the time of checkout,
or complete the warranty certicate available online on the www.supportdecathlon.com site within one month of the purchase date.
During this regiration, the buyer mu provide the following information: la name, r name, purchase date, e-mail address, and
bicycle tracking number.
By virtue of this warranty, B’twin oers either the replacement by an equivalent of the frame, rigid fork, handlebars or em, or their
repair, within a reasonable time period, after being brought to a DECATHLON retail ore repair shop. It is specied that travel and
transportation cos remain the responsibility of the cuomer.
However, this contractual obligation will not apply in the event of poor maintenance or misuse of B’twin bikes, as dened in the user
manual of the product in queion.
To benet from the warranty covering one of the parts lied above, you mu simply visit the repair shop of a DECATHLON retail
ore, bringing either your DECATHLON ore loyalty card or your warranty certicate with you.
B’twin reserves the right to verify that all conditions of the lifetime warranty have been met and to implement all due necessary mea-
sures to verify this.
It is also specied that the lifetime warranty does not exclude the application of the legal guarantee(s) provided for under the French
Consumer Code (Code de la consommation) and Civil Code (Code civil), namely:
Article L. 211-4 of the Consumer Code: «The seller mu deliver goods in conformity with the contract and take responsibility for any
lack of conformity present at the time of delivery. The seller is also held liable for any lack of conformity caused by the packaging, the
assembly inructions or the inallation if he/she was made responsible for the latter under the contract or if it was conducted under
his/her responsibility».
Article L. 211-5 of the Consumer Code: «To be compliant with the contract, goods mu:
Be suitable for the use normally expected for similar goods and, if necessary:
match the description provided by the seller and possess the qualities that he/she presented to the buyer in the form of a sample or a
model;
display the qualities that a buyer can legitimately expect in view of public atements made by the seller, the producer, or his/her
representative, notably in advertising or labelling;
Or display the features dened by a mutual agreement between the parties or be suitable for any special use sought by the buyer,
made known to, and agreed upon by, the seller».
Article L. 211-12 of the Consumer Code: «Legal action prompted by lack of conformity lapses two years after the date of delivery of the
goods.»
Article 1641 of the Civil Code: «The seller is bound to the warranty on account of hidden defects of the item sold which render it unt
for the use for which it was intended, or which so impair that use that the buyer would not have acquired it, or would only have paid a
lesser price for it, had he/she been aware of them.
Article 1648 paragraph 1 of the Civil Code: «Legal action prompted by unacceptable defects mu be brought by the buyer within a
period of two years from the date of discovery of the defect».
Table of contents
Other Decathlon Bicycle manuals
