decoflame ARC 103A User manual

110 rue Robinson Sud, Granby (Quebec) J2G 7L4
Tel.: [phone] Fax: [phone]
www.decoflame.ca
Instruction Manual for Wall Mounted Fireplace, Models: ARC 103A & VAGUE 101A
CONTENTS:
Safety instructions..............................................p. 2
Wall mounted fireplace installation ................p. 3
Burner installation.................................................p. 3
Burner.......................................................................p. 3
Combustible Fuel...................................................p. 4
Instructions ............................................................p. 4
- General rules
- Filling
- Lighting
- Extinguishing
- While using
Cleaning the burner ..............................................p. 5
Cleaning the fireplace...........................................p. 5
Warranty...................................................................p.6

VAGUE 101A
Please note your model & serial numbers here:
_______________________________
Model number
_______________________________
Serial number
_______________________________
Purchase date
Read carefully before using your fireplace. - Keep these instructions for future reference.
SAFETY INSTRUCTIONS
Read and follow the below instructions before using this device.
Not respecting the rules may cause serious injury (especially burns) for the user and others
nearby, as well as becoming a fire hazard.
The « decoame » fireplace is for decorative purposes only, and not to be used as your main
heat source.
Keep children and pets away while operating the fireplace, especially while lighting it up.
Caution! If your wall is covered with wallpaper, wood varnish or other flammable material, you
must use a fire-proof backing on the wall.
Any furniture, curtains or other flammable materials must be located at a safe and secure dis-
tance from the unit.
Ensure that there is sufficient air circulation in the room.
Never use an unvented decorative device in areas where flammable vapours or gases may be
present.
Fasten the device onto the wall according to the instructions.
Do not cover the fireplace; do not place any material or clothing on the fireplace.

Never light the combustible fuel in a burner that is not properly positioned.
Only use « decofuel » combustible fuel in your fireplace.
Never use any fuel other than the fuel specifically identified for use in an unvented decorative
device. Never use gasoline, solvents, methylated or burning alcohol, thinner, ethanol gel, etc.
The use of an ethanol gel is strictly prohibited since this will render your tank unusable.
Do not combine any other fuel to the « decofuel » fuel.
Do not smoke while handling the combustible fuel.
Light the burner with the lighting rod. Holding the lighting rod away from you slightly soak the
end of the rod in the « decofuel »fuel in order to use it as a lighting device. Light the rod with
a lighter (view illustration in appendix).
Do not use paper or newspaper to start the fire.
Never add fuel if the fireplace is partially or fully in operation.
Never refill the unvented decorative fireplace fuel reservoir when the unvented decorative fire-
place is functioning or still hot.
Do not fill the fuel reservoir completely and use the adjustable pourer to do so. If the « deco-
fuel »fuel spills out of the reservoir, wipe it with an absorbent paper before lighting.
Continually monitor the device as soon as the fire is started.
The steel elements of the fireplace can become very hot while the combustible fuel is burning.
Never touch these elements while the fireplace is in operation, even several minutes after it is
turned off.
Do not move the fireplace while it is lit.
Avoid drafts.
This device was subjected to tests for its use with glass doors. To reduce fire hazard or injury,
never remove the doors.
Do not use additional parts or other products that are not designated for use with this fireplace.
The combustible fuel is a highly flammable product.
Never store or transport the fuel in anything other than a metal or plastic container that is ac-
ceptable for use with the specified fuel in accordance with the Consumer Chemicals and Con-
tainers Regulations 2001 and is the original container for the specified fuel.
Never store fuel in the same location as the appliance.

Due to the high temperature of the fireplace surfaces, keep children and pets at a safe distance.
Do not use the unvented decorative fireplace to heat or boil water or use as a cooking appliance.
Do not use in a room with oxygen tanks.
Risk of Indoor Air Pollution – Use the unvented decorative fireplace only in a well-ventilated
area and with doors of adjacent rooms open. Do not obstruct air flow to the fuel holder box by
piling logs over
the fuel reservoir or in any other way with any other material. People with breathing problems
should consult a physician before using the unvented decorative fireplace.
The following or equivalent information for provision of combustion and ventilating air for un-
vented decorative devices: ‘’In a house of typical construction, that is, one that is not of un-
usually tight construction due to heavy insulation and tight seals against air infiltration, an
adequate supply of air for combustion and ventilation is provided through infiltration.” The
unvented decorative appliance should not be used in a small room where less than 5.7 m3(200
ft3)of air space is provided for each 1000 Btu per hour of the unvented decorative device rating
(considering the maximum burner adjustment). Do not use the unvented decorative fireplace in
a bathroom, a room where sleeping accommodation is provided or any other small room.
Make sure that the shut off device works properly before lighting.
INSTALLATION OF THE WALL MOUNTED FIREPLACE AND BURNER
Models ARC 103A & VAGUE 101A are wall-mounted.
A horizontal support and two vertical supports are provided with the fireplace.
Determine the location of your fireplace. It must be located at a minimum of 12’’ above the
floor, at a minimum of 24’’ from the ceiling, and allow a clear distance of 12’’from the right and
left edge of the unit.
To attach the hanging support, refer to the drawing for installation.
Locate 2 wall studs (obligatory), that are at 16’’ center to center.
Attach the horizontal support (no 1) using a bubble level tool with 2 no.12 x 1 ½’’ wood screws
(no.4).
Hang the 2 vertical straps (no.2) on the hooks of the horizontal support (no.1) and ensure that
they are square. Add brackets (no. 3) to the bottom of the vertical supports, attach them with

4 no. 12 x 1 ½’’ wood screws (no.4). You will need two people to move the fireplace (no.5) into
position, place it onto the hooks of the horizontal support (no.1) by matching up the hooks with
the square holes at the back of the unit.
Make sure that the fireplace is level.
Attach the 2 vertical supports (no.3) at the base of the fireplace (no.5) with 2 self-tapping
screws (no.6).
Place the burner support (no.7) into the fireplace opening.
Insert the reservoir (no.8) into the burner support (no.7).
Place the damper (no.9) onto the top of the bioethanol reservoir (no.8).
Using the designated holes install the window panes (no. 10)onto the front of the fireplace.
Ensure that they open and close correctly.
BURNER
Filling capacity: our model has a capacity of 1 litre and a tank of 15% flood (.150 litre). Which
gives 2.75 hours burning capacity when the damper is completely open. You can increase the
length to 5 hours by reducing the flames’ height by simply moving the damper forward. The
burner elements are removable and must be installed in the fireplace according to the instruc-
tions before ignition. The fuel must be poured into the burner reservoir.
If any spatters occur, make sure to clean them before lighting the fire.
COMBUSTIBLE FUEL
Only use « decofuel » liquid fuel.
CAUTION: DO NOT USE PAPER, NEWSPAPERS, STRAW, KINDLING WOOD OR ANY OTHER
FLAMMABLE PRODUCT TO START THE FIRE.
The combustible fuel is a highly flammable product. It should be kept away from any heat
sources. Never place in direct sunlight. Do not store or carry fuel in a plastic or metal container
that is not designated for this purpose. Never store fuel in the same location as the fireplace.
Keep it in a safe place and keep it away from children.
In case of ingestion, inhalation and/or contact with eyes or skin, urgently contact the poison
control centre or consult a Doctor.

INSTRUCTIONS
Read and follow the instructions in their entirety before using the fireplace.
Never add fuel when the fireplace is functioning, wait until the reservoir and the fireplace have
cooled (wait at least 15 minutes) before refilling.
GENERAL RULES:
Only use the fireplace according to these instructions.
Do not use the fireplace in a bathroom or any other small room.
Minimum room limitations: 1000 ft 3.
The fireplace must be used in a ventilated area.
No flammable objects must be located near the fireplace.
FILLING:
Fill the reservoir with the adjustable pouring spout (or funnel). Be careful not to exceed the
level indicator (maximum of 1.5 Litres). Do not overflow or splash around the reservoir. If any
spatters occur, clean them with a rag or a paper towel in order to absorb the excess. Do not
throw this rag or paper towel in the garbage; let it dry and keep it away from the fire, children
and pets, then dispose of it.
Only use « decofuel » fuel.
LIGHTING:
The damper must be completely open.
The fuel must be kept at room temperature before usage.
Light the burner with the lighting rod. Slightly soak the end of the rod in the « decofuel » fuel
reservoir while keeping away from the burner. Light the rod with a lighter.
Close the glass doors completely.
The adjustment of the height of the flames is made by using the damper knob. Pull the knob to-
wards the outside to obtain lower flames and push towards the inside to obtain higher flames.

The flames will reach their maximum height within 15 to 30 minutes, depending on the com-
bustible fuel temperature. During this period, a slight odour may appear. If necessary, air out
the room for a few minutes.
Let the fire burn until all of the fuel has been depleted. You can extinguish the fire at all times
simply by completely closing the burner. If you have to relight the fireplace when the fuel is still
hot, be very careful as the gas residue is likely to cause a large flame. Do not try to extinguish
the flames with an object other than the designated damper.
Keep children and pets away while operating the fireplace and especially while lighting it up.
Never add fuel if the fireplace is in operation, wait until the burner and the fireplace have cooled
before refilling.
Do not touch the fireplace or the burner while it is in operation: serious burns may occur.
EXTINGUISHING:
Keep the glass doors closed.
Pull the damper completely closed.
WHILE USING:
Constantly monitor the device as soon as the fire has been started.
Have a class B fire extinction device nearby.
In case of a burn, call the nearest hospital.
Consult a Doctor if in doubt of any severe burn.
Igniting the fireplace implies that you have carefully read and will follow these directions.
CLEANING THE BURNER
When the contents of the burner have completely been consumed, wait until the burner has
cooled before moving it. After each use, it is recommended to clean the burner using a sponge
or rag and soapy water and then rinse with clear water. When the burner is dry, it can be refilled.
If the burner is not cleaned after each use, odours may occur.
After several uses, the burner will turn light brown due to the heat. This can be removed by
rubbing with the rough side of a sponge; always rub in the same direction as the grain.

CLEANING THE FIREPLACE
All the fireplace elements can be cleaned in soapy water with a sponge or a rag, then rinsed with
clear water.
Make sure that the shut off device works properly before lighting.
We guarantee the good performance of your fireplace with the use of « decofuel » combustible
fuel only.
LIMITED WARRANTY
decoame guarantees, to the original purchaser (retail sale), that this product is free of any
defects in material or workmanship and commits to reparing or replacing (at decoame’s dis-
cretion) any defective product , free of charge ,within 2 years from the date of purchase.
A proof of purchase such as a dated sales receipt, sales slip, etc indicating the model and serial
number will be required before any intervention from our dealers will be made on the guaranteed
product. You are obligated to meet the delivery or shipping charges of the product in the event
of guaranteed repairs, as well as the pick up or return of the product after repairs have been
made.
We wish you the best of moments with your « decoame »fireplace…

INSTALLATION OF THE WALL MOUNTED FIREPLACE AND BURNER: ARC 103A

INSTALLATION OF THE WALL MOUNTED FIREPLACE AND BURNER: VAGUE 101A
