Decon wheel MEM6003-11 User manual

2016-05-10
Page: 1
Assembly instructions for Panthera S2/U2, S2 Swing, Bambino
MEM6003-11/12 and MEM6004-11/12
Type 11, Type12
1. Check that you have the correct model.
2. Remove wheels and brakes.
3. Check the correct placement for the eMove, see pictures above and check that it is
Ø12,7 x 46 mm axle with Part Number: XOE-2530E-00.

2016-05-10
Page: 2
4. Assembly the plate (right side) according to picture.
Parts for right side mounting:
Item No. Part Number Qty Description
1 290010 1 Clamp
2 100 400 004 1 Spacer
3 100 400 005 1 Spacer
4 XSM8ML 1 Lock Nut M8
5 100 400 003 1 Spacer
6 XSM8BR 1 Washer Plain M8
7 XSM8X50 1 Screw Socket M8 x 50
8 XOE-22294-B0 1 Right Bracket
9 405239 1 Nordlock Washer M16
10 HW069 1 Hubsleever M16x1/12,7
Note! If you only order the mounting set, the axle it’s not included, for replacement
see the service manual.

2016-05-10
Page: 3
5. Assemble the under placed battery bag or if have order a Lithium battery place the
battery holder as the picture bellow.
Assemble instructions for MEM5000 Rev6 on Panthera wheelchairs
Item No. Part Number Qty Description
1 MEM5002 1 Hoop
2 MEM5003 2 Clamp
3 MEM5004 2 Clamp
4 XSFM5X12 2 Screw Countersunk M5 x12
5 XSM5ML 2 Nut Self-Locking M5
6 XSSM8X16 4 Bolt Round-Square M8 x16
7 XSM8ML 4 Nut Self-Locking M8
8 MED5001 Rev3 1 Battery plate eDrive/ eMove
9 XSFM6X12 4 Screw Countersunk M6 x12
10 XSM6ML 4 Nut Self-Locking M6
11 MEM5011 1 Bracket
6. Special assemble for the battery box under the chair. (Bambino is not included.)
This mounting set are the same for all models but it is possible that the rear axle on the
picture is from a different model.
