Decon wheel MED3136 User manual

2020-04-24
Assembly instructions for PDG Eclipse
MED3136
1. Remove wheel, sleeve and anti-tip devices on both sides.
2. Check the correct placement for the stop pin, and check that the battery box is
removed.
Note! Remember that it must be Heavy Duty on the eDrive units, and it
have a maximum user weight of 150 kg, do not over load this weight,
even if the wheelchair have a user weight of 270 kg.

2020-04-24
3. Assembly the plate (right side) according to pictures.
Parts pair mounting set for one side:
Item No. Part Number Qty Description
1 MED2000B 1 Bracket
2 405241 2 Nordlock Washer M18
3 HW084 1 Sleeve
4 XSM18M 1 Nut M18 x1
5 100 400 073 1 Spacer
6 100 400 072 1 Stop Spacer
7 XSM8X16 1 Screw Round M8 x 16
Do not forget the
spacer tube inside
the frame.

2020-04-24
Assembly of the joystick
4. Assembly the joystick according to the picture above.
The parts you need for assemble the joystick
Item No. Part Number Qty Description
1 MED1368 1 Joystick Bracket
2 Original screw 1 Original screw
Assembly of the attendant control
Item No. Part Number Qty Description
1 XSM6TG 1 Washer External Teeth 6,4
2 XSM6X35 1 Screw M6 x 35
3 XSM6BR 1 Plain Washer 6,4
4 XA2-2612K-00 Drilled 6,2 1 Clamp with drilled hole 6,2 mm hål
5 XA2-2612E-00 1 Clamp with hole
Note! You need the extended
70 cm cable on the battery bag
with part number: X0C-88147-A0
if you use the attendant control.
This cable is not included in the
Mounting set.

2020-04-24
Brake adjustment
5. Brake adjustment needed, see picture above.
Parts for one side
Item No. Part Number Qty Description
1 XSM6X45 1 Screw M6 x 45
2 XSM6X30 1 Screw M6 x 30
3 XSM6ML 2 Lock Nut M6
4 100 400 044 2 Spacer
2
4
3
3
4
1

2020-04-24
Battery Placement
6. Assemble the back placed battery bag. See the picture above.
Note! You need the extended 70 cm cable on the battery bag with
part number: X0C-88147-A0 if you use the attendant control.
This cable is not included in the Mounting set.

2020-04-24
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsor.
Sleeves.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M16x1
30 Nm
M18x1
40 Nm
