Dear valued customer,
To discover a DDeeDDiieettrriicchhproduct is to experience the range of unique emotions
which only high-value items can produce.
The attraction is immediate, from the moment you set eyes on the product. The
sheer quality of the design shines through thanks to the timeless style and
outstanding finishes which make each appliance an elegant and refined little
masterpiece in its own right, each in perfect harmony with the others.
Next, comes the irresistible urge to touch it. DDeeDDiieettrriicchh''ssdesign makes
extensive use of robust and prestigious materials. The accent is placed firmly
upon authenticity.
By combining state-of-the-art technology with top quality materials, DDeeDDiieettrriicchh
produces beautifully crafted products to help you get the most from the culinary
arts, a passion shared by all lovers of cooking and fine food.
We hope that you enjoy using this new appliance and we would love to receive
your suggestions and to answer any questions you may have. Please feel free to
contact our customer service department via our website.
To benefit from the many advantages offered by the brand, we recommend that
you register your product at: wwwwww..ddee--ddiieettrriicchh..ccoomm..
Thank you for choosing a DDeeDDiieettrriicchhpprroodduucctt..
DDeeDDiieettrriicchh
You can find a full range of information about the brand at www.de-dietrich.com
Visit the De Dietrich Gallery, 6 rue de la Pépinière (Paris eighth district)
Open from Tuesday to Saturday from 10 am to 7 pm
Customer service department: 0892 02 88 04
As part of our commitment to constantly improving our products, we reserve the right to make
changes to them based on advances to their technical, functional and/or aesthetic properties.
Important:
Before installing and using your appliance, please read this Installation and Usage
Guide carefully, as it will allow you to quickly familiarise yourself with its operation.

3
TABLE OF CONTENTS EN
1 / NOTICES TO THE USER
••Safety instructions _________________________________________ 19
••Caring for the Environment __________________________________ 20
2 / INSTALLING YOUR APPLIANCE
••Choice of location__________________________________________ 21
••Build-in ___________________________________________________ 21
••Electrical connection _______________________________________ 22
••Changing the power supply cable_____________________________ 23
3 / DESCRIPTION OF YOUR APPLIANCE
••Accessories_______________________________________________ 24
4 / CARING FOR AND CLEANING YOUR APPLIANCE
••Cleaning the outer surfaces__________________________________ 26
••Self-degreasing catalytic ____________________________________ 27
••Changing the catalytic panels
••Dismantling the wire supports________________________________ 27
••What is pyrolysis? __________________________________________ 28
••In what situations should pyrolysis be used?____________________ 28
5 / ADJUSTING YOUR APPLIANCE
••Replacing the oven lamp ____________________________________ 29
6 / TROUBLESHOOTING __________________________________________ 30
7 / AFTER-SALES SERVICE________________________________________ 31

4
1 / NOTICES TO THE USER
EN
SAFETY INSTRUCTIONS
— This oven was designed for use by private
individuals in their homes. It is intended solely
for cooking foodstuffs. This oven does not
contain any asbestos-based components.
— Please make sure children do not play with
the appliance.
— When you receive the appliance, unpack it
or have it unpacked immediately. Give it an
overall inspection. Make note of any concerns
or reservations on the delivery slip and make
sure to keep a copy of this form.
— Your appliance is intended for standard
household use. Do not use it for commercial
or industrial purposes or for any other
purpose than that for which it was designed.
— Do not modify or attempt to modify any of
the characteristics of this appliance. This
would be dangerous to your safety.
— WARNING: accessible parts may be hot
when in use. It is advisable to keep small
children away from the apppliance.
— Never pull your appliance by the door
handle.
— Before using your oven for the first time,
heat it while empty for approximately 15
minutes. Make sure that the room is
sufficiently ventilated. You may notice a
particular odour, or a small release of smoke.
All of this is normal.
— WARNING: accessible parts may become
hot when the grill is used. It is advisable to
keep children away from the apppliance.
— When in use, the appliance becomes hot.
Be careful not to touch the heating elements
located inside the oven.
— When placing dishes inside or removing
them from the oven, do not place your hands
close to the upper heating elements and use
heat-protective kitchen gloves.
— During pyrolysis, the exposed surfaces
become hotter than during normal use. It is
advisable to keep small children away from
the oven.
— Before beginning a pyrolysis cleaning cycle
in your oven, remove all parts of your grids,
trays and accessories and remove major spill
residue. During pyrolysis, exposed surfaces
become hotter than during normal use. It is
advisable to keep small children away from
the oven.
— At the end of cooking, do not pick up oven
or grill items (grid, rotisserie,...) with your bare
hands.
— Never place aluminium foil directly in
contact with the floor of the oven (see the
chapter on oven description), as accumulated
heat may cause deterioration of the enamel.
— Do not place heavy weights on the oven
door when open, and make sure that children
cannot climb or sit on it.
— The oven must be turned off when cleaning
inside the oven.
— This appliance is not intended to be used by
persons (including children) with reduced
physical, sensory or mental abilities, or
persons lacking experience or awareness,
unless using it with the help of a person
reponsible for their safety, or under supervision
and with prior instruction in its use.
— In addition to the accessories supplied with
your oven, only use dishes capable of
withstanding high temperatures (follow the
manufacturer’s instructions).
— After using your oven, make sure that all the
controls are in their stop position.
— Do not use your oven as a larder or to store
any items after use.
••
Important
Keep this user guide with your
appliance. If the appliance is ever sold or
transferred to another person, ensure that
the new owner receives the user guide.
Please become familiar with these
recommendations before installing and
using your oven. They were written for your
safety and the safety of others.

5
1 / NOTICES TO THE USER EN
CARING FOR THE ENVIRONMENT
••
— This appliance’s packing materials are
recyclable. Recycle them and play a role in
protecting the environment by depositing
them in local authority containers provided
for this purpose.
— Your appliance also contains many
recyclable materials. It is therefore marked
with this logo to indicate that used appliances
must not be mixed with other
waste. Recycling of the appliances
organised by your manufacturer will
thus be undertaken in optimum
conditions, in accordance with
European directive 2002/96/CE
relating to electrical and electronic
equipment waste. Contact your local council
or your retailer to find out the drop-off points
for used appliances that are nearest to your
home.
— We thank you for your help in protecting the
environment.
Warning
Installation should only be performed by qualified installers and technicians.
This appliance complies with the following European directives:
- Low Voltage Directive 2006/95/CE for affixing the CE mark.
- Electromagnetic Compatibility Directive 89/336/CEE modified by directive 93/68/CEE for
attaching the CE mark.
- CE regulation 1935/2004 concerning materials and objects intended for contact with food
substances.
— Never use steam or high-pressure devices to
clean the oven (electrical safety requirement).
— For your safety, your oven is equipped with
an AUTOMATIC STOP, if you forget to turn off
your oven by mistake. After 23 hours and
30 minutes of continuous use, the AS
(Automatic Stop) feature will be activated and
your oven will turn itself off. AS or Auto Stop
will be displayed instead of the time and a
series of successive beeps will be emitted for
a short time.

6
2 / INSTALLING YOUR APPLIANCE
EN
BUILD-IN
To do this:
1) Remove the rubber screw covers to access
the mounting holes.
2) Drill a hole in the cabinet panel to avoid
splitting the wood.
3) Attach the oven with the 2 screws.
4) Replace the rubber screw covers (they also
absorb the shock caused by closing the oven
door).
(*) if the cabinet is open, its opening must be
70 mm (maximum).
••
CHOICE OF LOCATION
The above diagrams show the dimensions of a
cabinet that will be able to hold your oven.
The oven can be installed in a cabinet column
(open* or closed) that has the appropriate
dimensions for built-in installation (see dia-
gram opposite).
Your oven has optimised air circulation that
allows it to achieve remarkable cooking and
cleaning results if the following guidelines are
followed:
• Centre the oven in the cabinet so as to
guarantee a minimum distance of 5 mm
between the appliance and the cabinet beside it.
• The material or coating of the cabinet must
be heat-resistant.
• For greater stability, attach the oven in the
cabinet with two screws through the holes
provided for this purpose on either side of the
front inner panel (fig.1).
••
875 mini
55
888
875
875
870
595
545
20 50
50
20
fig.1
Tip
To be certain that you have properly
installed your appliance, do not hesitate to
call on a household appliance specialist.

7
2 / INSTALLING YOUR APPLIANCE EN
The electrical connections are made before the oven
is installed in its housing.
• The fuse for your installation must conform to the
table shown opposite.
• Where the oven is connected using a separate plug
and socket this must be accessible after the oven has
been installed.
• An omnipolar cutout device (with a contacts gap of
at least 3 mm) must be fitted on the supply side of
the connection to meet requirements.
• The oven must be connected using a standard
power cable for which the number of conductors is
dependent upon the type of connection required and
in conformity with the table shown below.
Electrical connections
min.
network voltage connection diameter fuse
of cable
➀230V- 50Hz 1 L + N 4 mm² 32 A
➁400V 2N-50Hz 2 L + N 1,5 mm² 16 A
④230V 2N-50Hz 2 L + N 1,5 mm² 16 A
Warning
We cannot be held responsible for any accident resulting from inexistent, defective or
incorrect earthing.
If the electrical installation in your residence requires any changes in order to hook up your
appliance, contact a professional electrician.
If the oven malfunctions in any way, unplug the appliance or remove the fuse corresponding
to the sector where the oven is hooked up.
7
1
2
5
4
3
1
2
5
4
3
1
2
5
4
3
➀
➁
③
T
NPh
T
T
N
Ph 1
Ph 2
TN2 Ph 1
Ph 2
N1
N
Ph 2

8
2 / INSTALLING YOUR APPLIANCE
EN
••
——The power cable (H05 RR-F, H05 RN-F or H05 VV-F) must be of sufficient length to be
connected to the build-in oven while it sits on the floor in front of the cabinet.
To do this the appliance must be disconnected from the electrical network:
——Open the inspection flap located at the lower right of the back cover by unscrewing the two
screws, then pivot the inspection flap.
——Strip 12 mm along each wire of the new power cable.
——Carefully twist the strands together.
——Loosen the screws from the terminal board and remove the power cord to be replaced.
——Insert the power cable through the side of the cover into the cable clip located to the right of
the terminal board.
——All the strands of the electrical wires must be secured tightly under the screws.
— The phase wire on the L terminal.
— The green-yellow coloured earth wire should be connected to the terminal .
——The neutral wire (blue) on the N terminal.
----Connect the wires according to the table on page 7.
——Screw down tightly the screws on the terminal board and check the connection by pulling on each
wire.
——Attach the cable with the cable clip located to the right of the terminal board.
——Close the inspection flap using the two screws.
Warning
We cannot be held responsible for any accident resulting from inexistent, defective or
incorrect earthing.
If the electrical installation in your residence requires any changes in order to hook up your
appliance, contact a professional electrician.
If the oven malfunctions in any way, unplug the appliance or remove the fuse corresponding
to the sector where the oven is hooked up.
The oven is sold without a cable.
1
st CONNECTION OR CHANGE OF THE POWER CABLE

9
3 / DESCRIPTION OF YOUR APPLIANCE EN
••Safety grid with handle (fig.1)
Equipped with a handle at the front to make it
easy to grasp. The grid can be used to hold all
dishes and moulds containing foodstuffs to
be cooked or browned.
It can be used for barbecues (to be placed
directly on the grid).
ACCESSORIES (depending on the model)
••
fig.1
••Rotisserie (fig.3)
Slide one of the forks onto the spit; skewer
the piece of meat to be roasted; slide on the
second fork; centre and tighten by screwing
the two forks.
Place the spit in its cradle: place the cradle on
the sloped enamelled dish, slide the cradle in
at shelf support 3, push it lightly to engage
the end of the spit into the guide slot at the
back of the oven.
Remove the handle by unscrewing it, so you
can close the door. After cooking, screw the
spit handle on again to remove the roasted
meat without burning yourself.
NNOOTTEE::if you want to put something large
onto the spit, in order to prevent it from
touching the back of the dish and stopping
the spit from turning, you can place the dish
on the floor of the oven and engage the cradle
at support 3.
fig.3
••Oven equipment for low-
termperature cooking (fig.2)
Place meat (except for poultry) directly on the
grid with the enamelled dish underneath.
Place yogurt containers directly in the dish.
fig.2
Rear
Front

10
3 / DESCRIPTION OF YOUR APPLIANCE
EN
ACCESSORIES (depending on the model)
••
fig.4
••Multi-purpose 5 mm dish (fig.4)
This serves as a cake dish and has a sloped
edge. It is used for cooking pastries such as
cream puffs, meringues, cup cakes, puff
pastry, etc.
••Multi-purpose 45 mm dish (fig.5)
When inserted in the supports under the grid,
it collects juice and fat from grilling, and can
be used half-filled with water as a double-
boiler.
Avoid placing roasts or meat directly in the
dish because this is certain to cause
significant spattering on the oven walls.
fig.5
fig.6
••Sloped 45 mm dish equipped with
a special grid for grilling (fig.6)
It serves to collect juices and fat from
cooking meat or fish placed directly on the
grid during a grill or pulsed grill sequence.
Never place this dish on the floor of the oven
(it may damage the enamel) unless it is in the
grill position (the bottom heating element
does not turn on when the oven is set for
grilling).
fig.7
••Dish extracting support (fig.7)
Thanks to this system, you can slide out your
enamelled dish all the way and easily access
your preparations during cooking.
RReemmoovveeffrroommtthheeoovveennbbeeffoorreessttaarrttiinngg
ppyyrroollyyttiicccclleeaanniinngg..

11
4 / CARING FOR AND CLEANING YOUR APPLIANCE EN
CLEANING THE OUTER SURFACES
••
To clean both the electronic programmer window and the oven door, use a window washing
product applied to a soft cloth.
Do not use abrasive creams or scouring sponges.
Warning
Do not use abrasive cleaning
products or hard metallic scrapers for
cleaning the oven’s glass door, as they
could scuff the surface and cause the glass
to shatter.

12
4 / CARING FOR AND CLEANING YOUR APPLIANCE
EN
SELF-DEGREASING CATALYTIC (enamelled oven)
••
- This oven is composed of an enclosure fitted with detachable walls covered with a special
microporous enamel (catalytic enamel), which provides its self-degreasing properties. As soon
as dirt appears, it spreads out and is dispersed into the microporous holes. It is oxidised on
both sides and gradually disappears. The self-degreasing enamel is mainly suited for fatty, rather
than sugary substances. This is why the oven floor, which is more subject to sugary overflow, is
not covered with this enamel.
WWeessttrroonnggllyyrreeccoommmmeenndd::
- That you do not scrub these catalytic walls with metallic brushes, pointed or sharp instruments.
- That you do not try to clean them with commercial scouring products.
- When grilling food, the temperature of the walls is not always sufficient to eliminate major
spattering of fat.
In this case, following cooking, prolong the heating of the oven for 20 to 30 minutes, at the
maximum temperature of the chosen sequence.
If traces of spatter remain, they will be reduced during subsequent cooking operations.
BBeeffoorreessttaarrttiinnggttooddiissaasssseemmbbllee,,aalllloowwtthhee
aapppplliiaanncceettooccoooollddoowwnnaannddcchheecckktthhaatttthhee
ccooookkiinnggsseelleeccttoor
riissiinntthheeSSTTOOPPppoossiittiioonn..
CHANGING THE CATALYTIC PANELS -
DISMANTLING THE WIRE SUPPORTS
••
--SSiiddeeppaanneellsswwiitthhwwiirreessuuppppoorrttss::
Unhook the wire shelf support ((BBffiigg..22))at the
front by lifiting it (
diagram
AAffiigg..11). Pull the shelf
support structure towards you, lifting it so as to
unhook the rear attachment (
diagram
BBffiigg..11)).
Remove it from the 2 holes ((CCffiigg..22))in the
catalytic panel and from the oven cavity. Then
remove the catalytic panel ((AAffiigg..22))..Replace the
new elements (shelf supports) by performing
these operations in reverse.
--RReeppllaacceetthheebbaacckkppaanneell
Completely unscrew the screw ((EEffiigg..22))
located at the top of the back panel ((DDffiigg..22)).
Tilt the panel forwards in order to remove it
from the oven cavity. Fit the new panel by
repeating these steps in reverse. fig.2
A
B
C
D
E
A
B
C
B
A
fig.1
Warning
For any cleaning operation inside the
oven cavity, the oven must be switched off.
Before you remove the back panel, the
appliance must be disconnected from the
power. After cleaning, the back panel must
be put back in place, as detailed in the
instructions.

13
4 / CARING FOR AND CLEANING YOUR APPLIANCE EN
If your oven emits smoke during preheating or releases large amounts of smoke during cooking.
If your oven releases an unpleasant odour when cooled after various types of cooking (lamb,
fish, grills, etc...).
- Pyrolysis is a cycle during which the oven cavity is heated to a very high temperature in order
to eliminate spatters and spills. Smoke and odours released during pyrolysis are destroyed by
moving through a catalyzer.
- Pyrolysis is not necessary after each cooking cycle, simply when the degree of soiling warrants it.
- As a safety measure, the cleaning operation only begins after the door has automatically
locked. As soon as the internal temperature of the oven exceeds cooking temperatures, it is
impossible to unlock the door even if the “function selector” is set to 0.Once the temperature
inside the oven exceeds cooking temperatures, it is impossible to unlock the door, even by
selecting stop on the oven.
RReellaattiivveellyycclleeaann
ccooookkiinnggooppeerraattiioonnss
MMeessssyy
ccooookkiinnggooppeerraattiioonnss
VVeerryymmeessssyy
ccooookkiinnggooppeerraattiioonnss
Biscuits, vegetables, pastry,
quiches, soufflés...
Meat, fish (in a dish), stuffed
vegetables.
Large cuts of meat on the spit.
Splatter-free cooking: pyrolysis is
not warranted.
Pyrolysis may be warranted after
every 3 cooking cycles.
Pyrolysis can be performed after
one cooking application of this
kind, as there is a lot of
splattering.
WHAT IS PYROLYSIS?
Tip
You should not wait until the oven is overly coated in grease to initiate a cleaning cycle.
IN WHAT SITUATIONS SHOULD PYROLYSIS BE USED?
••
••
Tip
Your oven is equipped with enamelled wire shelf supports: these need to be removed
before running the pyrolysis cycle.
Warning
Remove any cookware, grids and trays from the oven and clean any major spill residue
before carrying out the pyrolysis.

14
5 / ADJUSTING YOUR APPLIANCE
EN
The lamp is accessible:
IInnssiiddeetthheeoovveenn((ffiigg..11))..
The bulb is located on the ceiling of your
oven’s cavity.
- Unscrew the view port counter-clockwise
(fig.2),
- Pull out the bulb.
Bulb specifications:
- 25 W
- 220-240 V~
- 300°C
- G9.
- Replace the bulb then replace the view port
and reconnect your oven.
Tip
To unscrew the view port and the
light, use a rubber glove, which will make
disassembly easier.
Warning
Make sure the appliance is
disconnected from the power before
replacing the lamp in order to avoid the risk
of electric shock. Change the lamp only
when the appliance has cooled down.
fig.1
REPLACING THE OVEN LAMP
••
Bulb
Unscrew View port
fig.2
Light
Bulb
Unscrew Port
The bulb is located on the ceiling of your
oven’s cavity.
a) Unplug the oven.
b) Unscrew the view port (fig.1).
c) Unscrew the bulb in the same direction.
Bulb specifications:
- 15 W
- 220-240 V ~
- 300°C
- E 14 cap
d) Replace the bulb then reposition the port
and reconnect your oven.
CHANGING THE BULB ON YOUR TOP OVEN
••
fig.1

15
6 / TROUBLESHOOTING EN
Tip
In all circumstances, if your efforts are not sufficient, contact the After-Sales Service
Department without delay.
IIffyyoouuhhaavveeaaddoouubbttaabboouutttthheeccoorrrreeccttffuunnccttiioonniinnggooffyyoouurroovveenn,,this does not
necessarily mean that there is a malfunction.
IInnaannyyeevveenntt,,cchheecckktthheeffoolllloowwiinnggppooiinnttss::
Warning
- Repairs to your appliance should only be performed by professionals. Non-standard
repairs may be a source of danger for the user.
**OOnnllyyffoorrmmooddeellsswwiitthhtthheeppyyrroollyyssiissffuunnccttiioonn..
YYOOUUOOBBSSEERRVVEE
TTHHAATT……
PPOOSSSSIIBBLLEE
CCAAUUSSEESSWWHHAATTSSHHOOUULLDDYYOOUUDDOO??
TThheeoovveenniissnnootthheeaattiinngg..
- The oven is not connected to
the power supply.
- Your fuse is not working.
- The selected temperature is
too low.
➡Plug in your oven.
➡Replace the fuse in your electrical
set-up and check its capacity (16A).
➡Increase the selected temperature.
**TThheeppaaddlloocckkiissffllaasshhiinngg..- Problem with the door’s
locking mechanism.
➡Call the After-Sales Service
Department.
TThheeoovveennlliigghhttiissnnoott
wwoorrkkiinngg..
- The light is not working.
- The oven is not connected or
the fuse is not working.
➡Change the bulb.
➡Plug in your oven or change the
fuse.
**TThheeppyyrroollyyssiisscclleeaanniinngg
ccyycclleeddooeessnnoottbbeeggiinn..
- The door is not properly
closed.
- The locking system is
defective.
➡Verify that the door is locked.
➡Call the After-Sales Service
Department.
YYoouurroovveenniissbbeeeeppiinngg..
- During cooking.
- At the end of a cooking cycle.
➡The temperature recommended
for your choice has been reached.
➡Your programmed cooking cycle
is finished.
TThheeccoooolliinnggffaannccoonnttiinnuueess
ttooooppeerraatteeaafftteerrtthheeoovveenn
ssttooppss..
- The fan should work for up to
an hour after cooking, or
when the oven temperature is
greater than 125°C.
- If it does not stop after 1 hour.
➡Open the oven door to cool down
the oven faster.
➡Call the After-Sales Service
Department.

CZ5701058-00 07/11
7 / AFTER-SALES SERVICE
EN
Any repairs that are made to your appliance
must be handled by a qualified professional
authorised to work on the brand. When you
call, mention your appliance’s complete
reference (model, type, serial number). This
information appears on the manufacturer’s
nameplate
(fig.1).
GENUINE REPLACEMENT PARTS
During maintenance work, request that
only
certified genuine replacement parts are
used.
• SERVICE CALLS
BRANDT APPLIANCES SAS
7 rue Henri Becquerel
92500 RUEIL MALMAISON
230V ~ 50 Hz
MADE IN FRANCE
fig.1
FFaaggoorrBBrraannddttSSAASS, Management company – SAS: social capital of 20,000,000 euros RCS Nanterre 440 303 196.
