Deep Sea Electronics Plc 5320 Setup guide

A
CCESSING THE FRONT PANEL CONFIGURATION EDITOR
CONFIGURATION
ENTER PIN
****
•Press the Stop/Reset and Info buttons
simultaneously
•If a module security PIN has been set, the PIN number
request is then shown (The first * is flashing) :
•Press +or – buttons to adjust it to the correct value. Press 9when the first digit is correctly entered.
Repeat this process for the other digits of the PIN number.
•When 9is pressed after editing the final PIN digit, the PIN is checked for validity. If the number is not
correct, the editor is automatically exited. To retry you must re-enter the editor as described above.
CONFIGURATION
Oil pressure pre-alarm
•
If the PIN has been successfully entered (or the module PIN
has not been enabled) the first configurable parameter is
displayed :
EDITING A PARAMETER
2bar 30PSI 200kPa
•Enter the editor as described above. CONFIGURATION
Oil pressure pre-alarm
2bar 30PSI 200kPa
•Press the +and –buttons to cycle to the parameter you wish
to change.
•Press the 9button to enter edit mode. When in edit mode
(indicated by the flashing parameter) pressing the +and –
buttons will adjust the parameter to the desired value.
•For date and time editing only: press to select between day, month, year, hours and minutes.
•Press the 9button to ‘save’ the value. The value will stop flashing to confirm that it has been saved.
•To select another value to edit, press the + button. Continuing to press the +and –buttons will cycle
through the adjustable parameters as shown overleaf.
•To exit the front panel configuration editor at any time, press the Stop/Reset button. Ensure you
have saved any changes you have made by pressing the 9button first.
NOTE:- When the editor is visible, it is automatically exited after 5 minutes of inactivity to
ensure security.
NOTE:- The PIN number is automatically reset when the editor is exited (manually or
automatically) to ensure security.
NOTE:- More comprehensive module configuration is possible using the 5xxx series PC
configuration software in conjunction with the P810 PC interface. Please contact us for further
details.
DEEP SEA ELECTRONICS
5320 INSTALLATION INSTRUCTIONS
053-014
ISSUE4
Deep Sea Electronics Plc.
Highfield House, Hunmanby Industrial Estate,
North Yorkshire. YO14 0PH.
ENGLAND
Tel:[phone].
Fax: [phone].
LO CALL (from UK BT landlines) :
Telephone [phone]. Fax [phone]
Email: [email protected]
Web: www.deepseaplc.com
Deep Sea Electronics inc.
3230 Williams Avenue
Rockford, Illinois 61101-2668,
U.S.A.
Phone: [phone].
Fax: [phone]
TOLL FREE (USA only) : Tel: [phone]
Email: [email protected]
Web: www.deepseausa.com
DIMENSIONS : 240mm x 172mm x 57mm
(9.5” x 6.8” x 2.25”)
PANEL CUTOUT : 220mm x 160mm
(
8.7” x 6.3”
)
TYPICAL WIRING DIAGRAM

ADJUSTABLE PARAMETERS (Factory default settings are shown in bold italicised text)
Section Parameter Display shows Values
Input settings Low Oil Pressure warning Oil pressure pre-alarm 0-4bar (1.17bar)
Low Oil Pressure shutdown Oil pressure shutdown 0-4bar (1.03bar)
High Temperature warning Coolant temp pre-alarm 80-140°C (115°C)
High Temperature shutdown Coolant temp shutdown 80-140°C (120°C)
Low Temperature warning
Low Coolant temp 0-138°C (64°C)
Timers Mains transient delay Mains transient delay 0-30s (2s)
Generator transient delay Gen transient delay 0 -30s (0s)
Start delay Start delay 0 -10h (5s)
Return delay Return delay 0 -5h (30s)
Preheat Preheat 0 -5m (0s)
Crank attempt Cranking time 0 -60s (10s)
Crank rest Crank rest 0-60s (10s)
Safety delay Safety on 0-60s (10s)
Overspeed overshoot Overspeed overshoot 0-10s (2s)
Warming up Warm up 0-60m (0s)
Transfer delay Transfer delay 0-10m (0.7s)
Cooling run Cooling 0-60m (60s)
Fail to stop delay Fail to stop 0-2m (30s)
Low battery volts delay Battery low delay 0-24h (60s)
High battery volts delay Battery high delay 0-24h (60s)
Mains (utility) Mains Low Voltage Mains undervolt trip 50-360V ph-N (184V)
Mains High Voltage Mains overvolt trip 50-360V ph-N (276V)
Mains Low Frequency Mains underfreq trip 0-75Hz (45Hz)
Mains High Frequency Mains overfreq trip 0-75Hz (55Hz)
Generator Generator Under voltage shutdown Gen low voltage shutdown 50-360V ph-N (184V)
Generator Under voltage prealarm Gen low voltage prealarm 50-360V ph-N (196V)
Generator Over voltage prealarm Gen high voltage prealarm 50-360V ph-N (265V)
Generator Over voltage shutdown Gen high voltage shutdown 50-360V ph-N (276V)
Generator Under frequency shutdown Gen low frequency shutdown 0 -75Hz (40Hz)
Generator Under frequency prealarm Gen low frequency prealarm 0 -75Hz (42Hz)
Generator Over frequency prealarm Gen high frequency prealarm
0 -75Hz (55Hz)
Generator Over frequency shutdown Gen high frequency shutdown
0 -75Hz (57Hz)
Generator delayed overcurrent Delayed high current 100-200% (100%)
Engine Underspeed (RPM) shutdown Underspeed shutdown 0-6000RPM (1270)
Underspeed (RPM) warning Underspeed prealarm 0-6000RPM (1350)
Overspeed (RPM) warning Overspeed prealarm 0-6000RPM (1650)
Overspeed (RPM) shutdown Overspeed shutdown 0-6000RPM (1710)
Overspeed overshoot % Overspeed overshoot 0-10 (0%)
Low DC Voltage Battery low warning 0-40V (8V)
High DC Voltage Battery high warning 0-40V (33V)
Charge Alternator Failure Charge fail warning 0-39V (6V)
Display Language Language
ENGLISH , OTHER
ALTERNATIVE AC WIRING
3 phase, 3 wire
For other AC systems please consult the
module operators manual
ADJUSTABLE PARAMETERS (continued)
Section Parameter Display shows Values
Application Engine speed selection Alternative Frequency Disable, Enable
Volts selection Alternative Voltage Disable, Enable
AC System AC System 3 phase 4 wire
Single phase, 2 wire
3 phase, 3 wire
2 phase 3 wire (L1 & L2)
2 phase 3 wire (L1 & L3)
Generator Full Load Generator full load 0-6000A(500A)
Droop control Droop Disable, Enable
Droop 0% (0%-5%)
Compatible en
g
ine ECUs onl
y
Frequency Adjust Frequency Adjust Cummins CM850 only
LCD Contrast Contrast | 
Date/Time Date and Time dd mmm yyyy hh:mm
