Defiant G7X2D01AA Instructions / Assembly
G32-KPDA612 Rev. 16/03-00
(/fullviews/1749761/1749761_files/1749761-1.jpg)
3 Pre-installation (continued) – Door Preparation
NOTE: If your door is pre-drilled, check the hole sizes to make sure they are the proper
size. If they are the proper size, skip to the INSTALLATION section.
FOR
(/fullviews/1749761/1749761_files/1749761-2.png)
TOLL FREE HELP LINE 1-877-ONE-LOCK HOMEDEPOT.COM
(/fullviews/1749761/1749761_files/1749761-3.png)
^ Cut out TEMPLATE (reverse page) and use to mark the door, drill holes, and chisel out
the mortise.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
2/19
NOTE: Drill from both sides of the door to prevent wood splitting.
Centerline
(/fullviews/1749761/1749761_files/1749761-4.jpg)
2-1/8"(54 mm) or
1-1/2"(38 mm)
Backset
(25 mm)
(/fullviews/1749761/1749761_files/1749761-5.jpg)
2-1/8"(54 mm) or
Faceplate
(/fullviews/1749761/1749761_files/1749761-6.jpg)
Outline
Chisel 5/32” deep
For 2-3/8” backset: 3-7/16”
For 2-3/4” backset: 3-13/16”
Note: For drive-in latch.
Simply insert latch.
WARRANTY
LIMITED LIFETIME MECHANICAL AND 1 YEAR ELECTRONIC WARRANTY
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
3/19
The retailer of this product, hereby warrants, subject to the conditions set forth below, that it will
either repair or replace, at its option, this product if it proves to be defective by reason of
improper workmanship or materials within the original purchaser's limited time. In order to obtain
repairs or replacement under this limited warranty you must bring this product to the retailer's
store in which you bought it.
Original purchaser: This limited warranty is limited to the original purchaser at retail of this
product from retailer.
Except to the extent prohibited by applicable law, no other warranties, whether express or
implied, including the warranties of merchantability and fitness for a particular purpose, shall
apply to this product. Under no circumstances shall retailer be liable for consequential or
incidental damages in connection with this product. To the extent retailer is prohibited by
applicable law from excluding implied warranties, the duration of such implied warranties which
are not excludable shall be the original purchaser's lifetime. Some states do not allow the
limitation on how long an implied warranty lasts, so the above limitation on the duration of implied
warranties which are not excludable, if any, may not apply to you. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion of incidental or consequential damages may not apply to you.
Retailer neither assumes not authorizes any representative or other person to assume for it any
obligation or liability other than such as is expressly set forth herein. This limited warranty gives
you specific legal rights, and you may also have other rights which vary from state to state.
1 Safety Information
Read the precautions and instructions in this manual before installing and using this lock. Save
this manual for future reference.
(/fullviews/1749761/1749761_files/1749761-7.png)
CAUTION:
Please use four alkaline batteries for the best performance.
A. Do not attempt to disassemble any internal components of the lockset. Doing so will void the
limited warranty.
B. Do not drop or hit the lockset. Too much shock may result in permanent damage.
C. Do not use pins or sharp objects to press the keypad.
D. Always create a backup of information you wish to keep (programming code, user codes,etc.)
Please use the last page of this booklet as a reference.
E. Promptly change the programming code before operating this lockset
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
4/19
(/fullviews/1749761/1749761_files/1749761-8.jpg)
CARE and MAINTENANCE:
The following instructions should be followed to properly protect and maintain your lockset:
A. Remove locks, or do not install locks, prior to painting your door.
B. Periodically clean with mild soap and a soft cloth only.
C. Do not use any abrasives or chemical products containing alcohol, benzene, acids, and avoid
using sharp or abrasive objects to clean this lockset.
D. Do not allow any water or liquids into the lockset during installation.
2 Pre-installation – Tools Required / Hardware Included
(/fullviews/1749761/1749761_files/1749761-9.png)
(/fullviews/1749761/1749761_files/1749761-10.jpg)
(/fullviews/1749761/1749761_files/1749761-11.png)
^Prepare the door of the door jamb.
door jamb – use the strike plate as a template to drill the latch and screw holes and chisel
out the mortise. The strike plate must fit flush with the surface
Door jamb hole dimension a. 1-3/16"(30 mm) b. 1-9/64"(29 mm) c. 7/8"(22 mm)
Strike dimentions
d.
e. f. Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
5/19
5/32"(4 mm)
2-1/4"(57 mm)
1"(25 mm)
4 Installation
^ INSTALLING THE LATCH
A. Attach the correct faceplate
Edge of door
(/fullviews/1749761/1749761_files/1749761-12.png)
(/fullviews/1749761/1749761_files/1749761-13.png)
(/fullviews/1749761/1749761_files/1749761-14.jpg)
Edge of door
Faceplate
R
Drive-in collar
For 2-3/4" backset.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
6/19
(/fullviews/1749761/1749761_files/1749761-15.jpg)
sure the latch cam is upright before making any backset adjustment.
Turn to extend the latch bolt.
Turn back to retract the latch bolt.
2-3/4 should be visible.
C. Install the latch
B. Set the latch backset length
Flat head screwdriver
a.With the bolt extended, twist latch end 1/8 turn.
b.Pull as shown in the diagram.
(/fullviews/1749761/1749761_files/1749761-16.jpg)
Backset
Drive-in latch
(/fullviews/1749761/1749761_files/1749761-17.png)
Tap latch flush
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
7/19
Wood block (not included)
Optional
Optional
Optional
Optional
Optional
A. Door bore options
B. Install the lock assemblies
Remove the Battery Cover
Quantity
Thread the cable through the hole and under the latch.
For installation into 1-1/2”(38mm) bore hole, simply pry the adapter collar off with a screwdriver.
WARNING:
If the door needs to be drilled, please be familiar with how to use a drill safely and understand all
of the door preparation steps before proceeding.
^ INSTALLING THE LOCK ASSEMBLIES
Package Contents
The cable must be arranged as shown in the diagram.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
8/19
(/fullviews/1749761/1749761_files/1749761-18.jpg)
BB
CC
CAUTION :
1.Please use four alkaline batteries for better performance.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
9/19
2.Please set up the lock and perform bolt direction determination to complete the installation.
Enter default programming code (123456) and the lock will set up bolt direction to complete
installation.
Part Description
AA
2-5/16" (58 mm) Mounting Bolt
1-13/16" (46 mm) Mounting Bolt
2
BB 13/16" (20 mm) Screw 2
CC 3/4" (19 mm) Wood Screw 4
(/fullviews/1749761/1749761_files/1749761-19.png)
The latch bolt should be in retracted position.
(/fullviews/1749761/1749761_files/1749761-20.png)
Part Description Quantity
A Exterior Assembly 1
B Power Cable 1
C Torque blade 1
D Mounting Plate 1
E Interior Assembly 1
F Battery Cover 1
G Latch 1
OR
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
10/19
H Strike Plate 1
I Dust Box 1
J Key 2
K Drive-in Collar (Optional) 1
L Exterior Gasket 1
(/fullviews/1749761/1749761_files/1749761-21.png)
The bulged part of the mounting plate must face towards the door.
Slide the cable through the notch in mounting plate
Connect the cable firmly into connector port .
Note : The metal connector side should face outward.
(/fullviews/1749761/1749761_files/1749761-22.jpg)
Install batteries
(/fullviews/1749761/1749761_files/1749761-23.png)
(/fullviews/1749761/1749761_files/1749761-24.jpg)
Install battery cover
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
11/19
Insert screws and tighten.
(/fullviews/1749761/1749761_files/1749761-25.jpg)
TEMPLATE
NOTE: Double check your product for the correct hole sizes.
(/fullviews/1749761/1749761_files/1749761-26.jpg)
(/fullviews/1749761/1749761_files/1749761-27.jpg)
PROGRAMMING
1 OVERVIEW OF FUNCTIONS
HOW TO LOCK / UNLOCK THE LOCKSET
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
12/19
(/fullviews/1749761/1749761_files/1749761-28.png)
OR
(/fullviews/1749761/1749761_files/1749761-29.png)
(/fullviews/1749761/1749761_files/1749761-30.png)
^
^ ^ ^ ^
^
ENTER / LOCK BUTTON
1. Red light: Represents an incorrect entry or the unit is in programming mode.
2. Yellow light: Flashes when the batteries are low in power.
3. Green light: Represents a correct entry.
4. Press to activate or lock the lockset.
KEYPAD
1. Unlock the lockset by entering a valid User Code.
2. Program the lockset by entering a valid Programming Code in Programming Mode.
MECHANICAL KEYWAY OVERRIDE
1. Lock or unlock the lockset by a valid key.
BATTERY COVER
1. Protect the batteries from unexpected damage.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
13/19
[SET] BUTTON
1. Press set button for 1 second to enter programming mode.
2. Please refer to 2 - ^ for more information about programming mode.
INTERIOR THUMBTURN
1. Lock or unlock the lockset manually.
To lock
To unlock
(/fullviews/1749761/1749761_files/1749761-31.png)
Press “ ” to lock.
(/fullviews/1749761/1749761_files/1749761-32.png)
Enter valid User Code or Programming Code.
OR
OR
(/fullviews/1749761/1749761_files/1749761-33.png)
Use a mechanical key to lock.
(/fullviews/1749761/1749761_files/1749761-34.png)
Use a mechanical key to lock.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
14/19
Keypad is temporarily disabled for 1 minute after 4 consecutive incorrect entries.
2 PROGRAMMING
RESTORE TO FACTORY SETTINGS
(/fullviews/1749761/1749761_files/1749761-35.png)
Remove one battery
(/fullviews/1749761/1749761_files/1749761-36.png)
Press and hold SET button while inserting the battery back. Hold the set button until long beep
over.
1. This will erase all stored information, including bolt direction
2. Please re-enter the default Programming Code to set up the lock after restoring to factory
settings.
^ HOW TO PROGRAM THE LOCKSET
BASIC SETTINGS
Change
Programming
Code
・Programming Code can be
used to program or unlock the
lockset. ・The default
Programming Code is “123456”.
Press
[SET]
for 1
second.
Programming
Code (6
digits)
1 0
New
Programming
Code(6
digits)
Add a User
Code(S)
・User Code can be used to
unlock the lockset.
・User Code cappcity: 10 sets (4-
6 digits).
Press
[SET]
for 1
second.
Programming
Code (6
digits)
2 0
New User
Code (4-6
digits)
Add another
code
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
15/19
Delete
individual
User / Single-
entry Code(s)
・Delete individual User Code(s).
Press
[SET]
for 1
second.
Programming
Code (6
digits)
3 0
User Code /
Single-entry
Code (4-6
digits)
Delete
another code
Delete all User
/ Single-entry
Codes
・Delete all User & Single-entry
Codes.
Press
[SET]
for 1
second.
Programming
Code (6
digits)
4 0
ADVANCED SETTINGS
Add
Single-
entry
Code(s)
・Single-use User Code can
only be used once to unlock
the lockset.
・Single-use User Code
capacity: 5 sets (4 digits).
Press
[SET] for 1
second. Programming
Code (6
digits)
2 1
Single-
entry
Code (4
digits)
Add
another
code
Vacation
Mode
・Vaction mode temporarily
disable ALL User Codes.
Press
[SET] for 1
second.
Programming
Code (6
digits)
5 0
Turn
On
Turn
Off
1
0
Volume
Control
・Turn on / off door lock
operation volume.
・Volume is always on in the
programming mode.
Press
[SET] for 1
second.
Programming
Code (6
digits)
6 0
Turn
On
Turn
Off
1
0
Auto-lock ・Auto-lock is disabled by
default.
Press
[SET] for 1
second.
Programming
Code (6
digits)
8 0
Turn
On
Turn
Off
1
0
Auto-lock
Delay
Timer
・Default Auto-lock Delay
Timer : 10 seconds.
・Auto-lock Delay Timer
range: 10 -99 seconds.
Press
[SET] for 1
second.
Programming
Code (6
digits)
7 0
Enter
New
Amount
(10 - 99)
・The lockset will exit the programming mode and resume to the stand-by status if no input is
made in 10 seconds. ・3 Beeps means something was entered incorrectly. Please redo the step
again.
TROUBLESHOOTING
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
16/19
^ INSTALLATION
QUESTIONS ANSWERS
A.The latch does not
operate correctly after
installation.
1. Make sure the backset on the latch is set to the proper length.
2. Make sure prior to installation latch bolt is retracted and key is not
in lockset when installing the deadbolt.
3. Please restore to factory setting and enter the default
Programming Code to set up the lock.
B. Feel a bump while
turning the thumbturn or
the key?
1. Please execute lock & unlock function to allow the motor to
reposition itself again.
2. The battery is low if the battery indicator light keeps flashing.
Please replace with four new batteries. Hold the set button until long
beep over.
3. Please restore to factory setting and enter the default
Programming Code to set up the lock.
C. Fail to set up the lock.
1. Please make sure the lock is installed correctly.
2. Please install the fresh batteries and make sure the cable is
connected correctly.
^ OPERATION
QUESTIONS ANSWERS
A. Battery
indicator keeps
flashing.
1. The batteries are getting low, please replace with four new batteries for
the best performance (alkaline batteries only ).
B. Keypad not
responding.
1. Make sure the batteries are installed properly.
2. The batteries are getting low if the battery indicator keeps flashing. please
replace with four new batteries for the best performance (alkaline batteries
only ).
3. Make sure the cable is well-connected to the port, and was not damaged
during installation.
4. Please make sure the lock has been set up and complete the bolt
direction determination.
C. Programming
Code can not be
changed.
1. Please refer to 2 - ^ in the user guide to restore factory setting and
reprogram all codes.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
17/19
D. What should I
do if wrong code
was entered?
1. Press button once and continue to input code according to regular
procedures.
E. Can not delete
all User Codes.
1. Make sure the whole code entering process is completed within 10
seconds, otherwise the unit will time out.
2. Make sure the Programming Code has been entered correctly.
F. Can not add a
new User Code.
1. Make sure the whole code entering process is completed within 10
seconds, otherwise the unit will time out.
2. Make sure the Programming Code has been entered correctly.
3. The new User Code will not be accepted when the capacity is full. Try to
delete any or some existing User Codes and then add new one(s) again. A
User Code must be at least 4 to 6 digits.
QUESTIONS ANSWERS
G. "Auto lock" does not
function.
1. The batteries are low on power if the battery indicator keeps
flashing. Please replace with four new batteries for the best
performance. (Alkaline Batteries Only).
2. Please refer to 2 - ^ in the guide to enable the Auto-Lock
function.
H. Lockset is not able to
unlock / lock by keypad.
1. Make sure you have entered the correct User Code.
2. The battery is low if the battery indicator light keeps flashing.
Please replace with four new batteries.
3. Make sure the cable is firmly connected.
4. Check the cable for any damage that may have occurred during
installation.
5. Make sure the batteries are properly installed. (Alkaline
batteries only)
6. Check the strike plate to make sure it is properly aligned and
clear so the bolt can freely move in the hole.
I. Lockset is unable to reset. 1. Please refer to 2 - ^ in the user guide to restore factory settings
and reprogram all codes. Hold the set button until long beep over.
2. The battery is low if the battery indicator light keeps flashing.
Please replace with four new batteries. Hold the set button until
long beep over.
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
18/19
J. How to operate the lockset
in darkness?
1. Press any button to activate the lockset back light.
K. The red indicator is still on
after setting is completed.
1. Check if [SET] button is jammed.
2. Re-install the batteries.
L. The lockset locks when I
enter my code and unlocks
when I press the
.
1. Un-install the interior and exterior assemblies.
Before re-installation, please follow these guidelines:
1) Make sure the bolt is in the retracted position.
2) Do not have any key in the cylinder durring installation.
3) Make sure the torque blade is inserted horizontally.
4) Reset the unit to factory settings and reprogram the
programming code and user codes.
M. I cannot remove my key
unless it is in the locked
position.
1. Un-install the interior and exterior assemblies.
Before re-installation, please follow these guidelines:
1) Make sure the bolt is in the retracted position.
2) Do not have any key in lock cylinder.
3) Make sure the torque blade is inserted horizontally.
If the lock appears to be damaged or does not operate properly, please contact customer service
for further assistance.
4 ACCESS CODE LIST
FEDERAL COMMUNICATIONS COMMISSION STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment. NOTE: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Your experience on this site will be improved by allowing cookies. Allow cookies

10/24/22, 11:16 AM
Defiant G7X2D01AA Instructions / Assembly
https://mans.io/files/fullviewer/825373
19/19
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
IC REGULATIONS
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation of the device.
(/fullviews/1749761/1749761_files/1749761-37.jpg)
After changing your Programming Code, do not pass your Programming Code to anyone else.
Programming Code
Name User Code
en
To contact us, please e-mail: [email protected] (mailto:[email protected]) Privacy Policy (https://mans.io/privacy)
(https://play.google.com/store/apps/details?id=ru.mans.mans3)
Your experience on this site will be improved by allowing cookies. Allow cookies
