CAB2

Mobile enclosed two-stack dish dispensers

Short form specications

Cabinet top shall be 16-gauge stainless steel with all corners welded and polished and reinforced

with heavy-gauge channels. Cabinet exterior panels and corner support angles shall be 20-gauge

stainless steel. Unit shall have four 4.00" (10.2cm) diameter polyolen swivel casters (all lock-

ing), and non-marking gray bumpers at each corner.

Dispenser tube shall have 3 vertical side channels and a bottom brace of 22-gauge stainless

steel. Top supporting ange shall be 18-gauge stainless steel. Flange, channels and bottom

brace shall be integrally welded together. Flange shall have 3 guide posts molded from high

impact plastic.

Self-leveling mechanisms shall be eld adjustable by adding or removing stainless steel exten-

sion springs on perimeter of vertical side channels. The dish carrier head shall be stainless steel

welded rods with a removable 18-gauge stainless steel top plate.

Capacity of tubes shall be approximately 72 dishes, with a maximum stacking height of 24.00"

(61.0cm).

NOTE: Models without “-ET” or “-QT” sufx are unheated.

THE FOLLOWING APPLIES TO CAB2-ET EVEN TEMP HEATED DISPENSERS ONLY:

Unit shall be supplied with 9' (2.7m) cord and NEMA 5-15P plug. Electrical connections shall

be 120 volt, 60 hertz, single phase.

Each tube shall have its own convection heating module consisting of a single 400 watt heating

element and fan motor, located in the center of the interior bottom cavity. Air intake shall have

a lter. Each tube shall have an adjustable thermostat inside the motor housing and an ON/OFF

switch on one of the dish guide posts. Unit shall maintain temperature between 120°F–140°F

(49°C–60°C).

THE FOLLOWING APPLIES TO CAB2-QT QUICK TEMP HEATED DISPENSERS ONLY:

Unit shall be supplied with 9' (2.7m) cord and NEMA 5-20P plug. Electrical connections shall

be 120 volt, 60 hertz, single phase.

Each tube shall have its own convection heating module consisting of a single 700 watt heating

element and fan motor, located in the center of the interior bottom cavity. Air intake shall have

a lter. Each tube shall have an adjustable thermostat inside the motor housing and an ON/OFF

switch on one of the dish guide posts. Unit shall maintain temperature between 150°F–170°F

(66°C–77°C).

Each tube shall have a stainless steel cover.

Optional accessories & modications

• Heavy-duty casters (consult factory)

• Flange-mount feet in lieu of casters

• Special dispenser tube heights

• 12" (30.5cm) dia. stainless steel dish dispenser tray (CAB2-1200, CAB2-1200-ET and CAB2-

1200-QT only)

• Non-marring adjustment rods for oval dishes and various dish diameters (–813 through

–1450 sizes only)

• Stainless steel cover with access to dishes (–813 through –1450 sizes only; standard on

QT models)

• Stainless steel tube cover

• Hold-down rod for dispenser tubes

• Wrap-around bumpers (adds 1.75" [4.4cm] to overall length and depth)

• Fiberglas® panels

• Laminate panels

• Special voltages (consult factory)

Model CAB2-913

The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com

MSCAB2 02/02

Mobile enclosed two-stack dish dispensers

CAB2

MODEL NUMBER LENGTH DEPTH

DISH DIAMETER

RANGE AMPS

SHIP

WEIGHT

CAB2-500 28.25"/71.8cm 17.00"/43.2cm 3.00"–5.00"/7.6cm–12.7cm 125 lbs/57 kg

CAB2-575 28.25"/71.8cm 17.00"/43.2cm 5.00"–5.75"/12.7cm–14.6cm 125 lbs/57 kg

CAB2-650 28.25"/71.8cm 17.00"/43.2cm 5.75"–6.50"/14.6cm–16.5cm 127 lbs/58 kg

CAB2-725 28.25"/71.8cm 17.00"/43.2cm 6.50"–7.25"/16.5cm–18.4cm 130 lbs/59 kg

CAB2-813 32.25"/81.9cm 17.00"/43.2cm 7.25"–8.12"/18.4cm–20.6cm 132 lbs/60 kg

CAB2-913 32.25"/81.9cm 17.00"/43.2cm 8.12"–9.12"/20.6cm–23.2cm 135 lbs/61 kg

CAB2-1013 32.25"/81.9cm 17.00"/43.2cm 9.12"–10.12"/23.2cm–25.7cm 142 lbs/64 kg

CAB2-1200 37.00"/94.0cm 19.00"/48.3cm 10.12"–12.00"/25.7cm–30.5cm 160 lbs/73 kg

CAB2-1450 42.00"/106.7cm 21.50"/54.6cm 12.00"–14.50"/30.5cm–36.8cm 176 lbs/80 kg

CAB2-500ET 28.25"/71.8cm 17.00"/43.2cm 3.00"–5.00"/7.6cm–12.7cm 9.0 144 lbs/65 kg

CAB2-575ET 28.25"/71.8cm 17.00"/43.2cm 5.00"–5.75"/12.7cm–14.6cm 9.0 146 lbs/66 kg

CAB2-650ET 28.25"/71.8cm 17.00"/43.2cm 5.75"–6.50"/14.6cm–16.5cm 9.0 148 lbs/67 kg

CAB2-725ET 28.25"/71.8cm 17.00"/43.2cm 6.50"–7.25"/16.5cm–18.4cm 9.0 152 lbs/69 kg

CAB2-813ET 32.25"/81.9cm 17.00"/43.2cm 7.25"–8.12"/18.4cm–20.6cm 9.0 160 lbs/73 kg

CAB2-913ET 32.25"/81.9cm 17.00"/43.2cm 8.12"–9.12"/20.6cm–23.2cm 9.0 168 lbs/76 kg

CAB2-1013ET 32.25"/81.9cm 17.00"/43.2cm 9.12"–10.12"/23.2cm–25.7cm 9.0 171 lbs/78 kg

CAB2-1200ET 37.00"/94.0cm 19.00"/48.3cm 10.12"–12.00"/25.7cm–30.5cm 9.0 192 lbs/87 kg

CAB2-1450ET 42.00"/106.7cm 21.50"/54.6cm 12.00"–14.50"/30.5cm–36.8cm 9.0 201 lbs/91 kg

CAB2-813QT 32.25"/81.9cm 17.00"/43.2cm 7.25"–8.12"/18.4cm–20.6cm 15.0 161 lbs/73 kg

CAB2-913QT 32.25"/81.9cm 17.00"/43.2cm 8.12"–9.12"/20.6cm–23.2cm 15.0 166 lbs/75 kg

CAB2-1013QT 32.25"/81.9cm 17.00"/43.2cm 9.12"–10.12"/23.2cm–25.7cm 15.0 169 lbs/77 kg

CAB2-1200QT 37.00"/94.0cm 19.00"/48.3cm 10.12"–12.00"/25.7cm–30.5cm 15.0 186 lbs/84 kg

CAB2-1450QT 42.00"/106.7cm 21.50"/54.6cm 12.00"–14.50"/30.5cm–36.8cm 15.0 201 lbs/91 kg

PLAN VIEW

CAB2 MODELS

NOTES

• CAB2-ET models are 120 volt, 60 hertz, single phase, and include a 9' (2.7m) cord with NEMA 5-15P plug. CAB2-QT models are 120 volt, 60 hertz, single phase, and include a 9' (2.7m) cord with NEMA 5-20P plug.

• Optional adjusting rods (available on 813–1450 models only) reduce the maximum round dish diameter by 1.25" (3.2cm); overall adjustment by rods is 1.50" (3.8cm). Non-marking adjustment rods must be ordered

for each indivual dispenser tube; installed at factory only.

PLAN VIEW

CAB2-ET & CAB2-QT MODELS

36.00"

91.4cm

3.62"

9.2cm

5.00"

12.7cm

36.00"

91.4cm

3.62"
