CAB3
Mobile enclosed three-stack dish dispensers
Short form specications
Cabinet top shall be 16-gauge stainless steel with all corners welded and polished and
reinforced with heavy-gauge channels. Cabinet exterior panels and corner support angles
shall be 20-gauge stainless steel. Unit shall have four 4.00" (10.2cm) diameter polyolen
swivel casters (all locking), and non-marking gray bumpers at each corner.
Dispenser tube shall have 3 vertical side channels and a bottom brace of 22-gauge
stainless steel. Top supporting ange shall be 18-gauge stainless steel . Flange, channels
and bottom brace shall be integrally welded together. Flange shall have 3 guide posts molded
from high impact plastic.
Self-leveling mechanisms shall be eld adjustable by adding or removing stainless steel
extension springs on perimeter of vertical side channels. The dish carrier head shall be
stainless steel welded rods with a removable 18-gauge stainless steel top plate.
Capacity of tubes shall be approximately 72 dishes, with a maximum stacking height of
24.00" (61.0cm).
NOTE: Models without “-ET” or “-QT” sufx are unheated.
THE FOLLOWING APPLIES TO CAB3-ET EVEN TEMP HEATED DISPENSERS ONLY:
Unit shall be supplied with 9' (2.7m) cord and NEMA 5-20P plug. Electrical connections
shall be 120 volt, 60 hertz, single phase.
Each tube shall have its own convection heating module consisting of a single 400 watt
heating element and fan motor, located in the center of the interior bottom cavity. Air intake
shall have a lter. Each tube shall have an adjustable thermostat inside the motor housing
and an ON/OFF switch on one of the dish guide posts. Unit shall maintain temperature
between 120°F–140°F (49°C–60°C).
THE FOLLOWING APPLIES TO CAB3-QT QUICK TEMP HEATED DISPENSERS ONLY:
Unit shall be supplied with 9' (2.7m) cord and NEMA 6-20P plug. Electrical connections
shall be 208-230 volt, 60 hertz, single phase.
Each tube shall have its own convection heating module consisting of a single 700 watt
heating element and fan motor, located in the center of the interior bottom cavity. Air intake
shall have a lter. Each tube shall have an adjustable thermostat inside the motor housing
and an ON/OFF switch on one of the dish guide posts. Unit shall maintain temperature
between 150°F–170°F (66°C–77°C).
Each tube shall have a stainless steel cover.
Optional accessories & modications
• Heavy-duty casters (consult factory)
• Flange-mount feet in lieu of casters
• Special dispenser tube heights
• 12" (30.5cm) dia. stainless steel dish dispenser tray (CAB3-1200, CAB3-1200-ET and
CAB3-1200-QT only)
• Non-marring adjustment rods for oval dishes and various dish diameters (–813
through –1450 sizes only)
• Stainless steel cover with access to dishes (–813 through –1450 sizes only; stan-
dard on QT models)
• Stainless steel tube cover
• Hold-down rod for dispenser tubes
• Wrap-around bumpers (adds 1.75" [4.4cm] to overall length and depth)
• Fiberglas
®
panels
• Laminate panels
• Special voltages (consult factory)
Model CAB3-575
with optional wrap-around bumpers

36.00"
91.4cm
3.62"
9.2cm
5.00"
12.7cm
JUNCTION
BOX
36.00"
91.4cm
3.62"
9.2cm
5.00"
12.7cm
D
L
D
L
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
MSCAB3 02/02
MODEL NUMBER LENGTH DEPTH
DISH DIAMETER
RANGE AMPS
SHIP
WEIGHT
CAB3-500 41.25"/104.8cm 17.00"/43.2cm 3.00"–5.00"/7.6cm–12.7cm 173 lbs/79 kg
CAB3-575 41.25"/104.8cm 17.00"/43.2cm 5.00"–5.75"/12.7cm–14.6cm 176 lbs/80 kg
CAB3-650 41.25"/104.8cm 17.00"/43.2cm 5.75"–6.50"/14.6cm–16.5cm 177 lbs/80 kg
CAB3-725 41.25"/104.8cm 17.00"/43.2cm 6.50"–7.25"/16.5cm–18.4cm 179 lbs/81 kg
CAB3-813 47.25"/120.0cm 17.00"/43.2cm 7.25"–8.12"/18.4cm–20.6cm 190 lbs/86 kg
CAB3-913 47.25"/120.0cm 17.00"/43.2cm 8.12"–9.12"/20.6cm–23.2cm 193 lbs/88 kg
CAB3-1013 47.25"/120.0cm 17.00"/43.2cm 9.12"–10.12"/23.2cm–25.7cm 196 lbs/89 kg
CAB3-1200 53.25"/135.3cm 19.00"/48.3cm 10.12"–12.00"/25.7cm–30.5cm 212 lbs/96 kg
CAB3-1450 62.00"/157.5cm 21.50"/54.6cm 12.00"–14.50"/30.5cm–36.8cm 229 lbs/104 kg
CAB3-500ET 41.25"/104.8cm 17.00"/43.2cm 3.00"–5.00"/7.6cm–12.7cm 13.0 207 lbs/94 kg
CAB3-575ET 41.25"/104.8cm 17.00"/43.2cm 5.00"–5.75"/12.7cm–14.6cm 13.0 210 lbs/95 kg
CAB3-650ET 41.25"/104.8cm 17.00"/43.2cm 5.75"–6.50"/14.6cm–16.5cm 13.0 213 lbs/97 kg
CAB3-725ET 41.25"/104.8cm 17.00"/43.2cm 6.50"–7.25"/16.5cm–18.4cm 13.0 219 lbs/99 kg
CAB3-813ET 47.25"/120.0cm 17.00"/43.2cm 7.25"–8.12"/18.4cm–20.6cm 13.0 233 lbs/106 kg
CAB3-913ET 47.25"/120.0cm 17.00"/43.2cm 8.12"–9.12"/20.6cm–23.2cm 13.0 239 lbs/108 kg
CAB3-1013ET 47.25"/120.0cm 17.00"/43.2cm 9.12"–10.12"/23.2cm–25.7cm 13.0 245 lbs/111 kg
CAB3-1200ET 53.25"/135.3cm 19.00"/48.3cm 10.12"–12.00"/25.7cm–30.5cm 13.0 262 lbs/119 kg
CAB3-1450ET 62.00"/157.5cm 21.50"/54.6cm 12.00"–14.50"/30.5cm–36.8cm 13.0 277 lbs/126 kg
CAB3-813QT 47.25"/120.0cm 17.00"/43.2cm 7.25"–8.12"/18.4cm–20.6cm 13.0 243 lbs/110 kg
CAB3-913QT 47.25"/120.0cm 17.00"/43.2cm 8.12"–9.12"/20.6cm–23.2cm 13.0 249 lbs/113 kg
CAB3-1013QT 47.25"/120.0cm 17.00"/43.2cm 9.12"–10.12"/23.2cm–25.7cm 13.0 255 lbs/116 kg
CAB3-1200QT 53.25"/135.3cm 19.00"/48.3cm 10.12"–12.00"/25.7cm–30.5cm 13.0 272 lbs/123 kg
CAB3-1450QT 62.00"/157.5cm 21.50"/54.6cm 12.00"–14.50"/30.5cm–36.8cm 13.0 287 lbs/130 kg
NA
NA
NA
NA
NA
NA
NA
NA
NA
CAB3
Mobile enclosed three-stack dish dispensers
NOTES
• CAB3-ET models are 120 volt, 60 hertz, single phase, and include a 9' (2.7m) cord with NEMA 5-20P plug. CAB3-QT models are 208-230
volt, 60 hertz, single phase, and include a 9' (2.7m) cord with NEMA 6-20P plug.
• Optional adjusting rods (available on 813–1450 models only) reduce the maximum round dish diameter by 1.25" (3.2cm); overall adjustment
by rods is 1.50" (3.8cm). Non-marking adjustment rods must be ordered for each individual dispenser tube; installed at factory only.
PLAN VIEW
CAB3
MODELS
ELEVATION VIEW
CAB3 MODELS RIGHT END VIEW
CAB3-ET & CAB3-QT
MODELS
RIGHT END VIEW
CAB3 MODELS
PLAN VIEW
CAB3-ET &
CAB3-QT
MODELS
ELEVATION VIEW
CAB3-ET &
CAB3-QT
MODELS
