Delfield 500 Series User manual

April 2010
500 Series
Service and Installation Manual
Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all
components immediately. See page 2.
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS!

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
2
©2010 The Delfield Company. All rights reserved. Reproduction without
written permission is prohibited. “Delfield” is a registered trademark of The
Delfield Company.
RECEIVING & INSPECTING EQUIPMENT..............................2
SPECIFICATIONS ..................................................................3
PRESSURE CONTROL SETTINGS.........................................5
INSTALLATION................................................................. 5, 6
OPERATION ..................................................................... 5, 6
CARE & CLEANING..............................................................6
WIRING DIAGRAMS
500-CR self-contained refrigerated units.......................7
500-OR open refrigerated units .....................................7
500-CD dry storage units ..............................................8
500-CH curved heated units ..........................................8
EXPLODED VIEWS & PARTS LISTS
537-CD ..........................................................................9
549-CD ..........................................................................9
561-CD ........................................................................10
573-CD ........................................................................10
537-CR, CRR ...............................................................11
549-CR, CRR ...............................................................11
561-CR, CRR ...............................................................12
573-CR, CRR ...............................................................12
549-CH ........................................................................13
561-CH ........................................................................13
573-CH ........................................................................14
549-OR ........................................................................14
FLUORESCENT LIGHT ASSEMBLY .....................................15
DOOR ASSEMBLY...............................................................16
REFRIGERATION ASSEMBLES............................................17
FOOD WELL ASSEMBLY.....................................................18
REPLACEMENT PARTS LIST ..............................................19
STANDARD LABOR GUIDELINES........................................20
STANDARD WARRANTIES............................................ 21-22
NOTES ................................................................................23
The Serial number on all 500 Series units is located on the
rear of the unit, near the ON/OFF switch.
Always have the serial number of your unit available when
calling for parts or service. A complete list of authorized
Delfield parts depots can be found at www.delfield.com.
CONTENTS SERIAL NUMBER LOCATION
RECEIVING AND INSPECTING THE EQUIPMENT
Even though most equipment is shipped crated, care should
be taken during unloading so the equipment is not damaged
while being moved into the building.
1. Visually inspect the exterior of the package and skid or
container. Any damage should be noted and reported
to the delivering carrier immediately.
2. If damaged, open and inspect the contents with the
carrier.
3. In the event that the exterior is not damaged, yet upon
opening, there is concealed damage to the equipment
notify the carrier. Notification should be made verbally
as well as in written form.
4. Request an inspection by the shipping company of the
damaged equipment. This should be done within 10
days from receipt of the equipment.
5. Check the lower portion of the unit to be sure adjustable
feet are not bent.
6. Also open the compressor compartment housing and
visually inspect the refrigeration package. Be sure lines
are secure and base is still intact.
7. Freight carriers can supply the necessary damage forms
upon request.
8. Retain all crating material until an inspection has been
made or waived.
Uncrating the Equipment
First cut and remove the banding from around the crate.
Remove the front of the crate material, use of some tools will
be required. If the unit is on legs remove the top of the crate
as well and lift the unit off the skid.

500 Series Display Cases Service and Installation Manual
3
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
500 SERIES SPECIFICATIONS
MODEL DELFIELD VOLTS/HERTZ AMPS
NUMBER PART # PHASE (includes lights & fan)
Dry Storage Display Cases
537-CD 078-5371 115/60/1 5.0
549-CD 078-5491 115/60/1 5.0
561-CD 078-5611 115/60/1 5.0
573-CD 078-5731 115/60/1 5.0
MODEL DELFIELD NUMBER OF VOLTS/HERTZ
NUMBER PART # 12 X 20 WELLS PHASE AMPS
Heated Display Cases
549-CH 078-5494 3 120, 208-240V/60/1 19.0/21.0
561-CH 078-5614 4 120, 208-240V/60/1 24.0/27.0
573-CH 078-5734 5 120, 208-240V/60/1 30.0/34.0
MODEL DELFIELD VOLTS/HERTZ EVAPORATOR CAPACITY CABINET LOAD
NUMBER PART # H.P.* PHASE AMPS BTU/°TD BTU/HOUR
Remote Refrigerated Display Cases
537-CRR CONSULT FACTORY 1/2* 115/60/1 5.0 180 1730
549-CRR 078-5493 1/2* 115/60/1 5.0 190 2250
561-CRR 078-5613 3/4* 115/60/1 6.0 190 2770
573-CRR 078-5733 3/4* 115/60/1 6.0 290 3290
*Recommended horsepower
MODEL DELFIELD VOLTS/HERTZ CABINET LOAD SYSTEM CAPACITY REFRIGERATION
NUMBER PART # H.P. PHASE AMPS BTU/HOUR BTU/HOUR CHARGE 404A
Self-Contained Refrigerated Display Cases
537-CR 078-5372 1/2 115/60/1 12.0 1730 3258 32 oz.
549-CR 078-5492 1/2 115/60/1 12.0 2250 3316 32 oz.
561-CR 078-5612 3/4 115/60/1 16.0 2770 4919 48 oz.
573-CR 078-5732 3/4 115/60/1 16.0 3290 5387 48 oz.
MODEL DELFIELD VOLTS/HERTZ CABINET LOAD SYSTEM CAPACITY REFRIGERATION
NUMBER PART# H.P. PHASE AMPS BTU/HOUR BTU/HOUR CHARGE 404A
Open Front Refrigerated Display Cases
549-OR 078-5495 1/2 115/60/1 12.0 2030 3354 32 oz.

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
4
Location
To meet NSF standards, all units must be sealed
to the floor.
Be sure the location chosen has a floor strong enough
to support the total weight of the cabinet and contents.
Contents fully loaded in this product line can weigh as much
as 1500 lbs. Reinforce the floor as necessary to provide for
maximum loading.
For the most efficient refrigeration, be sure to provide good
air circulation inside and out. Do not pack the refrigerator so
full that air cannot circulate. Be sure that the exterior of the
unit has access to ample air. Avoid hot corners and locations
near stoves and ovens.
Leveling
To level unit, simply lower the four adjustable rubber feet
located under the unit to the floor and adjust until unit is
level. A level cabinet will perform better because the drain
will empty properly, the doors will line up with the frames
correctly and the cabinet will not be subject to undue strain.
Plumbing
Self-contained models are standard with a condensate
evaporator. If the evaporator fails, the unit’s drain must have
an outlet to an appropriate drainage area or container.
Moisture collecting from improper drainage
can create a slippery surface on the floor and
a hazard to employees. It is the owner’s and
operator’s responsibility to provide a container or
outlet for drainage.
Electrical connection
Refer to the amperage data on page 3, the serial tag, your
local code or the National Electrical Code to be sure the
unit is connected to the proper power source. A protected
circuit of the correct voltage and amperage must be run for
connection of the line cord, or permanent connection to the
unit.
Self-contained units have an ON/OFF switch located on
the operators side. Simply turn the switch to ON to begin
operation.
The power switch should be turned to OFF and the
unit disconnected from the power source whenever
performing service or maintenance functions.
CAUTION
On self-contained models, after turning the ON/OFF switch
to ON, the unit’s compressor will begin operating. Delfield
display cases are designed to maintain an operational
temperature of 36°F to 40°F.
Do not load the storage area in a way that restricts the air
flow. Overloading will result in the loss of temperature. Do
not throw items into the storage area. The interior of the
cabinet and the blower coil may be damaged by this type of
neglect, which is not covered under your warranty.
These units use HFC-404A refrigerant, and
have a lock-out high pressure limiting device.
Under severe overloading conditions, in the
event of a condenser fan failure or a plugged or
blocked condenser, this device may shut down
the refrigeration system. See page 17 for part number
information if a replacement is required.
INSTALLATION: 500 CD, CR, CRR & OR
OPERATION: 500 CD, CR, CRR & OR

500 Series Display Cases Service and Installation Manual
5
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
Pressure Control
The temperature is controlled by an adjustable pressure
control located in the machine compartment. An adjustable
control has the word COLDER near the knob, with an arrow
to indicate the adjustment direction. These controls are
field adjustable and do not require a service agent. If you
have any questions, feel free to contact the Delfield Service
Department.
The refrigeration systems on self-contained CR & OR models
were adjusted at the factory to maintain between 36°F and
40°F. No adjustment should be necessary. If adjustment
does become needed however, the factory recommended
settings are:
Low-pressure settings (CR models): 82 psi cut-in,
47 psi cut-out, 35 psi differential.
Low-pressure settings (OR models): 82 psi cut-in,
40 psi cut-out, 42 psi differential.
Operating pressures: High, 170 to 200 psi. Low, 30 to 37
psi.
In attempting to adjust the pressure control, you can
do damage to your unit by accidentally adjusting the
differential. Please make small incremental adjustments
if a temperature adjustment is necessary, please contact
the service department at Delfield [phone] #1,
or your local service agent. Delfield is not responsible
for charges incurred while having the pressure control
adjusted.
CONTROL SETTINGS: 500 CR & OR

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
6
Installation should be done by personnel
certified and licensed to install and maintain
electrical appliances.
Location
Be sure the location chosen has a floor strong enough
to support the total weight of the cabinet and contents.
Contents fully loaded into this product line can weigh as
much as 1500 lbs. Reinforce the floor as necessary to
provide for maximum loading.
Leveling
A level cabinet looks better and will perform better because
the drain pan will drain properly, the doors will line up with
the frames properly, and the cabinet will not be subject to
undue strain.
Electrical connection
Connections must be made in accordance with
all applicable local codes and/or the National
Electrical Code. Refer to the wiring diagrams on
pages 6 and 7.
INSTALLATION: 500 CH
OPERATION: 500 CH
For most efficient operation, keep covered insets empty in
each well during preheating and when the well is not in use.
Dry operation
1) Pre-heat the well on “HIGH” for approximately
15 minutes.
2) After pre-heating, set the control to your
desired serving temperature.
Only 6” (15.2cm) deep insets should be used with a dry
food well. When operated dry, the bottom of the food well
will discolor. Refer to cleaning instructions to remove
discoloration.
Temperature
Product in pans . . . . . . . . . . . . . . . . . . . . . . 140°F to 160°F
ST PE S
NOTE: Intended for DRY OPERATION ONLY.
CLEANING: ALL MODELS
Clean the food wells daily. Wash with non-abrasive cleanser
and non-abrasive pad. If necessary, a mild abrasive may be
used. Do not use steel wool.
For all stainless steel parts, use mild, non-abrasive soap
or detergent and warm water. This may be followed by an
application of stainless steel cleaner or polish which will
eliminate water spotting and fingerprints and will bring out
the finish of the stainless steel.
Do not use a hose or pressure wash on these
units. The water will damage the electrical
components.
Cleaning the condenser (refrigerated units)
In order to maintain proper refrigeration, the condenser
fins must be cleaned of dust, dirt and grease every three
months. If condenser is totally blocked after three months
increase cleaning frequency. Clean the condenser with a
vacuum cleaner or stiff brush. If extremely dirty, use a
commercially available condenser cleaner.
Cleaning the sliding door assembly
All Delfield 500 Series display cases feature a Pike sliding
door assembly. Regular cleaning of door tracks with mild
soap and water will keep them free of foreign matter
insuring many years of use. The glass may be cleaned with
a glass cleaner.
Before the unit is used the first time for serving, turn the
temperature knob to “10” and heat the well for 20 minutes.
Do not be alarmed if smoke appears; this preheat should
burn off any residue or dust on the heating element.
Hot surfaces can cause serious burns. Always
wear some type of protective covering on your
hands and arms when removing lids or pans
from the unit.
Never place food directly into the well. Always use pans.
Always place covers on pans when not serving to prevent
food from drying out and to reduce your operating cost.

500 Series Display Cases Service and Installation Manual
7
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
WIRING: 500 CR
WIRING: 500 OR
NEUTRAL
NEUTRAL

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
8
WIRING: 500 CD
WIRING: 500 CH
WHT
WHT
WHT
WHT
WHT
WHT
WHT
WHT
WHT WHT WHT WHT WHT WHT
J
P P P P
RED
RED
RED
RED RED RED
RED
HEATED SHELF
120V
P LL
2
1
HH
1 2
208V208V208V 21
P L L
2
H
H1
21 LLP
2
H
H1
2
LL 1 P
H2
1
H
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK BLK BLK
BLK

500 Series Display Cases Service and Installation Manual
9
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
13 12 6
2
4
10
9
11
7
3
5
1
1615
14
8
6
REPLACEMENT PARTS LIST FOR 537-CD
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH, 500-CD
2 1 001-3134 mirror, acrylic, LH, 500-CD
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 001-5285 diffuser, air 537-CD/CR
6 2 XMK00127 fixture, flour. light, 24 remote
7 4 001-5407 support, shelf, 537-CD/CR
8 2 001-5026 clip, air diffuser, 537-CD
9 1 397-8137 shelf, adjustable, 21” x 33”
10 1 397-8138 shelf, adjustable, 26” x 33”
11 1 323-7490 door set, with lock, 537-CD/CR
12 4 932-1095 stud, threaded, s/s, 1/4-20 x .75
13 4 932-1401 nut, 1/4-20, locking
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988
REPLACEMENT PARTS LIST FOR 549-CD
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH, 500-CD
2 1 001-3134 mirror, acrylic, LH, 500-CD
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 XMK00128 fixture, flour. light, 36 remote
6 4 001-5235 shelf support
7 2 397-8122 shelf, top
8 2 397-8123 shelf, bottom
9 1 323-4697 door assembly, with lock
10 1 216-2677 fan, axial
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
10
REPLACEMENT PARTS LIST FOR 561-CD
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH, 500-CD
2 1 001-3134 mirror, acrylic, LH, 500-CD
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 XMK00129 fixture, flour. light, 48 remote
6 4 001-5277 shelf support
7 2 397-8122 shelf, top
8 2 397-8123 shelf, bottom
9 1 323-4698 door assembly, PIKE, with lock
10 1 216-2677 fan, axial
11 1 397-8125 shelf, top center
12 1 397-8126 shelf, bottom center
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988
REPLACEMENT PARTS LIST FOR 573-CD
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH, 500-CD
2 1 001-3134 mirror, acrylic, LH, 500-CD
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 XMK00130 fixture, flour. light, 60 remote
6 4 001-5295 shelf support
7 2 397-8122 shelf, top
8 2 397-8123 shelf, bottom
9 1 323-4699 door assembly, PIKE, with lock
10 1 216-2677 fan, axial
11 1 397-8127 shelf, top center
12 1 397-8128 shelf, bottom center
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & Pike door keys #323-3988

500 Series Display Cases Service and Installation Manual
11
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
REPLACEMENT PARTS LIST FOR 549-CR/CRR
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH
2 1 001-3132 mirror, acrylic, LH
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 XMK00128 fixture, flour. light, 36 remote
6 4 001-5235 shelf support
7 2 397-8122 shelf, top
8 2 397-8123 shelf, bottom
9 1 323-4697 door assembly, with lock
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988
13 12 6
2
4
10
9
11
7
3
5
1
1615
14
8
6
REPLACEMENT PARTS LIST FOR 537CR/CRR
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3131 mirror, acrylic, RH, 500-CR
2 1 001-3132 mirror, acrylic, LH, 500-CR
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 001-5285 diffuser, air 537-CD/CR
6 2 XMK00127 fixture, flour. light, 24 remote
7 4 001-5407 support, shelf, 537-CD/CR
8 1 001-5407 divider, air flow, 537-CR
9 1 397-8137 shelf, adjustable, 21” x 33”
10 1 397-8138 shelf, adjustable, 26” x 33”
11 1 323-7490 door set, with lock, 537-CD/CR
12 4 932-1095 stud, threaded, s/s, 1/4-20 x .75
13 4 932-1401 nut, 1/4-20, locking
14 1 001-5422 cover, coil, 537-CR
15 4 001-5252 clip, holding, coil cover
16 4 932-1238 screw, #8 x .75, H/N-P-TR-A
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
12
REPLACEMENT PARTS LIST FOR 573-CR/CRR
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH
2 1 001-3132 mirror, acrylic, LH
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 XMK00130 fixture, flour. light, 60 remote
6 4 001-5295 shelf support
7 2 397-8122 shelf, top
8 2 397-8123 shelf, bottom
9 1 323-4699 door assembly, PIKE, with lock
10 1 397-8127 shelf, top center
11 1 397-8128 shelf, bottom center
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988
REPLACEMENT PARTS LIST FOR 561-CR/CRR
DELFIELD
KEY QUANTITY PART# DESCRIPTION
1 1 001-3133 mirror, acrylic, RH
2 1 001-3132 mirror, acrylic, LH
3 1 397-8121 holder, adj. shelf, RH
4 1 397-8120 holder, adj. shelf, LH
5 2 XMK00129 fixture, flour. light, 48 remote
6 4 001-5277 shelf support
7 2 397-8122 shelf, top
8 2 397-8123 shelf, bottom
9 1 323-4698 door assembly, PIKE, with lock
10 1 397-8125 shelf, top center
11 1 397-8126 shelf, bottom center
Please Note: Items not shown on exploded view are listed on page 17.
Door locks #323-3986 & door keys #323-3988

500 Series Display Cases Service and Installation Manual
13
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
REPLACEMENT PARTS LIST FOR 549-CH
15
7
6
5
3
4
34
10
16
12
2
13
11
1
14
9
8
DELFIELD
KEY PART# DESCRIPTION
1 323-4055 door set, 49” curved glass
2 345-5439 glass, curved, 1” insulated, 47”
3 219-3959 bulb, 25W, Teflon coated, clear
4 219-3960 lamp holder, twin-threaded
5 219-3970 heater, pad, 115V/90W
6 XMK00106 warmer, food, 208V, no drain
7 219-4212 switch, 30A 120/277V
8 219-0154 switch, rocker, 20A/125V, 15A/250V
9 351-6059 thermometer, digital, solar/batt
10 105-0183 extrusion, polyethylene, blk, vertical, RH
11 105-0173 extrusion, polyethylene, blk, vertical, LH
12 105-0184 extrusion, polyethylene, blk, curved, RH
13 105-0174 extrusion, polyethylene, blk, curved, LH
14 001-5414 trim, side, exterior, RH
15 001-5415 trim, side, exterior, LH
16 001-6855 trim, front, laminate
REPLACEMENT PARTS LIST FOR 561-CH
15
7
6
5
3
4
34
10
16
12
2
13
11
1
14
9
8
DELFIELD
KEY PART# DESCRIPTION
1 323-4068 door set, 61” curved glass
2 345-5441 glass, curved, 1” insulated, 59”
3 219-3959 bulb, 25W, Teflon coated, clear
4 219-3960 lamp holder, twin-threaded
5 219-3970 heater, pad, 115V/90W
6 XMK00106 warmer, food, 208V, no drain
7 219-4212 switch, 30A 120/277V
8 219-0154 switch, rocker, 20A/125V, 15A/250V
9 351-6059 thermometer, digital, solar/batt
10 105-0183 extrusion, polyethylene, blk, vertical, RH
11 105-0173 extrusion, polyethylene, blk, vertical, LH
12 105-0184 extrusion, polyethylene, blk, curved, RH
13 105-0174 extrusion, polyethylene, blk, curved, LH
14 001-5414 trim, side, exterior, RH
15 001-5415 trim, side, exterior, LH
16 001-6866 trim, front, laminate

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
14
REPLACEMENT PARTS LIST FOR 573-CH
11111111
9
8
7
16
12
2
11
13
14
1
6
5
3
4
10
34
15
DELFIELD
KEY PART# DESCRIPTION
1 323-4069 door set, 73” curved glass
2 345-5443 glass, curved, 1” insulated, 71”
3 219-3959 bulb, 25W, Teflon coated, clear
4 219-3960 lamp holder, twin-threaded
5 219-3970 heater, pad, 115V/90W
6 XMK00106 warmer, food, 208V, no drain
7 219-4212 switch, 30A 120/277V
8 219-0154 switch, rocker, 20A/125V, 15A/250V
9 351-6059 thermometer, digital, solar/batt
10 105-0183 extrusion, polyethylene, blk, vertical, RH
11 105-0173 extrusion, polyethylene, blk, vertical, LH
12 105-0184 extrusion, polyethylene, blk, curved, RH
13 105-0174 extrusion, polyethylene, blk, curved, LH
14 001-5414 trim, side, exterior, RH
15 001-5415 trim, side, exterior, LH
16 001-6867 trim, front, laminate
REPLACEMENT PARTS LIST FOR 549-OR
14
13
16
9
8
14
25 23 24 22
21
12
11
15
20
19
9
10
18
17
18
17
10
43
2
1
5
6
7
DELFIELD
KEY PART# DESCRIPTION
1 001-5558 baffle, fan 49”
2 216-2667 motor, fan, morrill
3 351-6075 blade, fan, 7” dia., aluminum
4 397-8070 bracket, fan motor
5 218-2414 harness, fan motor, 78”
6 351-6097 coil, evaporator, custom, 49”
7 351-6273 valve, expansion, 1/4, HI, 404A
8 XMK-00132 fixture, fluorescent light, 36”
9 001-5554 back, interior, louvered
10 001-5555 diffuser, air, LH & RH
11 105-0183 extrusion, polyethylene, blk, vert, RH
12 105-0173 extrusion, polyethylene, blk, vert, LH
13 105-0184 extrusion, polyethylene, blk, curved, RH
14 105-0174 extrusion, polyethylene, blk, curved, LH
15 001-5414 trim, side, exterior, RH
16 001-5415 trim, side, exterior LH
17 001-6855 trim, front, laminate, 549
18 001-5278 louvers, s/s, 15 x 17
19 351-6038 thermometer, dial
20 001-5243 panel, access
21 219-3903 ballast, rapid start, 36” lamp
22 219-3919 switch, 15A/120V
23 351-6247 control, pressure, high
24 509-0025 control, temperature, -30-100
25 352-6731 condensing unit, 1/2 hp, R-404A, med

500 Series Display Cases Service and Installation Manual
15
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
FLUORESCENT LIGHT
2
7
6
4
5
3
9
8
17
DELFIELD
KEY PART# DESCRIPTION
1 SMK00571 cap, end, top mtg, pigtail, -rem.
2 SMK00572 cap, end, top mtg, blank, -rem.
3 170-1045 diffuser, fluor. light, 24”
170-1046 diffuser, fluor. light, 36”
170-1047 diffuser, fluor. light, 48”
170-1054 diffuser, fluor. light, 60”
4 219-3906 lamp, fluorescent, 24”
219-3907 lamp, fluorescent, 36”
219-3908 lamp, fluorescent, 48”
219-3909 lamp, fluorescent, 60”
5 219-3939 lamp holder, left
6 219-3940 lamp holder, right
7 932-1266 screw, #8-32 x .50
8 218-3613 pigtail, male, 3.5”, rem. ballast
218-3595 pigtail, male, 9”, rem. ballast
9 932-1010 nut, hex, starlock, s/s, #6-32
*Refer to the exploded view of unit for a complete assembly part number

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
16
4
6
4
3
1
1
1
1
5
2
2
Door Assembly
DELFIELD
KEY PART# DESCRIPTION
323-7490 complete assembly, 537-CD/CR/CRR
323-4697 complete assembly, 549-CD/CR/CRR
323-4055 complete assembly, 549-CH
323-4698 complete assembly, 561-CD
323-4699 complete assembly, 573-CD
1 323-4636 single roller, 537, 549 & 561
323-4637 double roller, 573
2 order by size bumper gasket, 241/8 & 537
323-3936 bumper gasket, 245/32, 549, 561 & 573
3 order by size wiper gasket, 537
323-3936 wiper gasket, 2223/32, 549, 561 & 573
4 323-3947 spring 12”, green, 537
323-3949 spring 12”, 549
323-3945 spring 23”, gold, 561
323-3946 spring 30”, gold, 573
5 order by size bottom track, 34 3/16, 537, black
323-3904 bottom track, 46 3/16, 549, black
order by size bottom track, 46 3/16, 549-CH, black
323-3909 bottom track, 58 3/16, 561, black
323-3912 bottom track, 70 3/16, 573, black
6 order by size top track, 34 3/16, 537, black
323-3904 top track, 46 3/16, 549, black
323-3922 top track, 58 3/16, 561
order by size Alum. top track, 46 3/16, 549-CH
323-3925 top track, 70 3/16, 573
Please Note: Gaskets & tracks order by dimensions • Plastic door glides order by
description reference #323-4055, 549-CH

500 Series Display Cases Service and Installation Manual
17
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
17
COMPRESSOR/COIL ASSEMBLY 537/549/561-CR/CRR
DELFIELD
KEY PART# DESCRIPTION
1 010-1916 coil pan assembly
2 001-5251 bracket, fan mounting
001-5417 bracket, fan mounting (537-CR)
3 219-3919 switch, toggle, SPST
4 219-3903 ballast, rapid start (549 & 537-CR)
219-3904 ballast, rapid start (561)
5 219-3942 control, SPST
219-3927 control, SPST (537-CR)
6 351-6231 evaporator coil, 404A
351-6072 evaporator coil, 404A (537-CR)
7 216-2667 motor, fan, 1450 rpm, CW (537, 549 & 561)
8 351-6184 blade, fan, 7” plastic, CW
9 352-6729 condensing unit, 1/2 h.p., 404A
(549-CR)
352-6746 condensing unit, 1/3 h.p., 404A (537-CR)
352-6732 condensing unit, 3/4 h.p., 404A (561-CR)
10 351-6084 valve, expansion, 1/2”, 404A
11 218-3445 harness, evaporator fan
COMPRESSOR/COIL ASSEMBLY 573-CR/CRR
DELFIELD
KEY PART# DESCRIPTION
1 010-1926 coil pan assembly
2 001-5292 bracket, fan mounting
3 219-3919 switch, toggle, SPST
4 219-3905 ballast, rapid start
5 219-3942 control, SPST
6 351-6246 evaporator coil, 404A
7 216-2667 motor, fan, 1450 rpm, CW
8 351-6184 blade, fan, 7” plastic, CW
9 352-6732 condensing unit, 3/4 h.p., 404A
(573-CR only)
10 351-6084 valve, expansion, 1/2”, 404A
11 218-3445 harness, evaporator fan

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
18
DELFIELD FOOD WELL (DFW) ASSEMBLY: WITH INFINITE CONTROL
3
11
8
6
1
5
9
10
4
7
2
12
14
13
INFINITE
CONTROL
KNOB
NOTE: If you need four or more component parts,
you must buy a complete assembly.
DELFIELD
KEY PART# DESCRIPTION
XMK00106 Complete assembly, infinite w/o drain
1 GMK00061 Deflector plate
2 GMK00062 Bottom cover
3 016-0014 Food well, with drain
4 932-1353 Screw
5 219-4007 Element
6 932-1379 Screws (2)
7 343-4663 Insulation
8 219-4335 Thermostat non-adjustable
9 932-1007 Screw
10 GMK00063 Drain cover
11 932-1007 Screws (2)
12 219-4110 Infinite control, 240V
13 323-4557 Infinite control knob
14 219-4095 Pilot light, amber
For 500-CH Heated Units

500 Series Display Cases Service and Installation Manual
19
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
REPLACEMENT PARTS LIST — NOT SHOWN ON EXPLODED VIEWS
DELFIELD DESCRIPTION
PART#
CR & CRR MODELS (MISC. PARTS)
Harness, wiring-female, 84” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218-3596
Glass, curved, 1”, insulated, 35” (537). . . . . . . . . . . . . . . . . . . . . . . . . . . 345-5319
Glass, curved, 1”, insulated, 47” (549). . . . . . . . . . . . . . . . . . . . . . . . . . . 345-5439
Glass, curved, 1”, insulated, 59” (561). . . . . . . . . . . . . . . . . . . . . . . . . . . 345-5441
Glass, curved, 1”, insulated, 71” (573). . . . . . . . . . . . . . . . . . . . . . . . . . . 345-5443
Foot, leveler, adj., 1/2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323-4696
Fixture, fluorescent light, 24” remote, top light (537) . . . . . . . . . . . . . .XMKOO131
Fixture, fluorescent light, 36” remote, top light (549) . . . . . . . . . . . . . .XMKOO132
Fixture, fluorescent light, 48” remote, top light (561) . . . . . . . . . . . . . .XMKOO133
Fixture, fluorescent light, 60” remote, top light (573) . . . . . . . . . . . . . .XMKOO134
Louver,s/s,15x17 ......................................... 001-5278
Louver,s/s,15x23 ......................................... 001-5279
Harness, light/fan motor, 78” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218-3414
Switch, 15A/120V, SPST, ivory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-3919
Holder, adj. shelf, beige, RH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8121
Holder, adj. shelf, beige, LH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8120
Control,pressure,dual....................................... 219-3942
Bracket,fanmotor .......................................... 397-8070
Blade, fan, 7” dia., Lexan, clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351-6184
Harness,evaporatorfan...................................... 218-3445
Support,shelf,(549-CR) ..................................... 001-5235
Shelf, top/end, adj., 21 x 22.5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8122
Shelf, bottom/end, adj., 26 x 22.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8123
Door set, 49” disp. case, with lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323-4697
Door set, 61” disp. case, with lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323-4698
Shelf, top/center, adj., 21 x 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8125
Shelf, bottom/center, adj., 26 x 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8126
CD MODELS (MISC. PARTS)
Harness, wiring-female, 84” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218-3596
Glass, curved, .25”, insulated, 35” (537) . . . . . . . . . . . . . . . . . . . . . . . . . 345-5400
Glass, curved, .25”, insulated, 47” (549) . . . . . . . . . . . . . . . . . . . . . . . . . 345-5440
Glass, curved, .25”, insulated, 59” (561) . . . . . . . . . . . . . . . . . . . . . . . . . 345-5442
Glass, curved, .25”, insulated, 71” (573) . . . . . . . . . . . . . . . . . . . . . . . . . 345-5444
Fixture, fluorescent light, 24” remote, top light (537) . . . . . . . . . . . . . . XMKOO131
Fixture, fluorescent light, 36” remote, top light (549) . . . . . . . . . . . . . . XMKOO132
Fixture, fluorescent light, 48” remote, top light (561) . . . . . . . . . . . . . . XMKOO133
Fixture, fluorescent light, 60” remote, top light (573) . . . . . . . . . . . . . . XMKOO134
Foot, leveler, adj., 1/2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323-4696
Switch, 15A/120V, (2) SPST, ivory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-3918
Holder, adj. shelf, beige, RH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8121
Holder, adj. shelf, beige, LH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8120
Pigtail, male, 9”, rem. ballast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218-3595
Support,shelf,(549) ........................................ 001-5235
Shelf, bottom/end, adj., 21 x 22.5 (549 & 561) . . . . . . . . . . . . . . . . . . . . 397-8122
Shelf, adjustable, 21 x 33 (537) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8137
Shelf, top, center, adj. 21 x 24 (573) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8127
Shelf, bottom/end, adj., 26 x 22.5 (549 & 561) . . . . . . . . . . . . . . . . . . . . 397-8123
Shelf, adjustable, 26 x 33 (537) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 397-8138
Shelf, bottom, center, adj. 26 x 24 (573) . . . . . . . . . . . . . . . . . . . . . . . . . 397-8128
DELFIELD DESCRIPTION
PART#
OR MODELS (MISC. PARTS)
Motor,evaporator........................................... 216-2667
Blade, fan, 7” dia., CW, 20 deg, alum . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351-6075
Harness, light/fan motor, 78’ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218-3414
Coil,evap.,customer,49”..................................... 351-6097
Cond. unit, 1/2 h.p., R-404A, med . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 352-6731
Control, temperature, -30-100%D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 509-0025
Valve, Expansion, 1/4, R-404A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351-6273
Ballast, rapid start, 36” lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-3903
Switch, 15A/120V, SPST, ivory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-3919
Timer, 24 hours, clock face. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-4345
Harness,evaporatorfan...................................... 218-3445
Bracket,fanmotor .......................................... 397-8070
Louver,s/s,15x17 ......................................... 001-5278
Shelf, Lexan, .5” x 10” x 45.5” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354-5339
Dial,Thermometer .......................................... 351-6038
CH Models (misc. parts)
Lamp holder, twin-threaded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-3960
Bulb, 25W, Teflon coating, clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-3959
Heater,pad,115V/90W....................................... 219-3970
Thermostat, nonadjustable, 480°F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-4335
Thermometer/digital, solar/batt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351-6059
Switch, rocker, 20A/125V, 15A/250V . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219-0154
Switch,30A,120/277V....................................... 219-4212
BALLASTS
120Vballast(537) .......................................... 219-3902
120Vballast(549) .......................................... 219-3903
120Vballast(561) .......................................... 219-3904
120Vballast(573) .......................................... 219-3905
220Vballast .............................................specialorder

500 Series Display Cases Service and Installation Manual
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
20
STANDARD LABOR GUIDELINES TO REPAIR OR REPLACE PARTS ON DELFIELD EQUIPMENT
Advice and recommendations given by Delfield Service Technicians do not constitute or guarantee any special coverage.
• A maximum of 1-hour is allowed to diagnose a defective component.
• A maximum of 1-hour is allowed for retrieval of parts not in stock.
• A maximum travel distance of 100 miles round trip and 2-hours will be reimbursed.
• Overtime, installation/start-up, normal control adjustments, general maintenance, glass breakage, freight damage, and/or
correcting and end-user installation error will not be reimbursed under warranty unless pre-approved with a Service Work
Authorization from Delfield. You must submit the number with the service claim.
LABOR OF 1-HOUR IS ALLOWED TO REPLACE:
• Thermostat • Contactor/Relay
• Infinite Switch • Transformer
• Door Jamb Switch • Evaporator/Condenser Fan Motor and Blade
• Solenoid Coil • Circulating Fan Motor and Blade
• Hi-limit/Thermal Protector Switch • Microprocessor Control
• Fan Delay/Defrost Termination Switch • Water Level Sensor/Probe
• Compressor Start Components and Overload Protector • Door Hinges, Locks, and Gaskets
• Defrost Timer • Condensate Element
• Thermometer • Springs/Lowerator
• Gear Box
LABOR OF 2 HOURS TO REPLACE:
• Drawer Tracks/Cartridges • Defrost Element
• Pressure Control • Heating Element
• Solenoid Valve • Locate/Repair Leak
LABOR OF 3 HOURS TO REPLACE:
• EPR or CPR Valve • Condenser or Evaporator Coil
• Expansion Valve
LABOR OF 4 HOURS TO REPLACE
• Compressor
This includes recovery of refrigerant and leak check.
$55.00 maximum reimbursement for refrigerant recovery (includes recovery machine, pump, torch, oil, flux, minor fittings,
solder, brazing rod, nitrogen, or similar fees.)
REFRIGERANTS
• R22 A maximum of $4.00/lb. or 25¢/oz. will be reimbursed.
• R134A A maximum of $5.00/lb. or 31¢/oz. will be reimbursed.
• R404A A maximum of $15.00/lb. or $1.00/oz. will be reimbursed.
