F5 24” DEEP PASS THROUGH SELF-CONTAINED DROP IN REFRIGERATED DISPLAY CASES
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
F5 Serview Drop In
24” Deep Pass Through Self-Contained Refrigerated Display Cases
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
Approval _________________
Date____________________
F5PC48N
SPECIFICATIONS
Display section exterior sides are made of 18-
gauge stainless steel. Exterior display section top
to be 22-gauge galvanized metal. Interior sides
are made of .095” thick ABS plastic with molded
shelf supports. The interior bottom is constructed
with stainless steel for long lasting durability.
Display section is fully insulated with high density
polyurethane foam between the interior and exte-
rior. Four adjustable epoxy coated wire shelves
are provided for the display section. An on/off
switch for the display section light(s) is located at
the right end of the front facing, above the display
section doors.
Display case refrigeration system consists of a
full-length top mounted coil with multiple fans
circulating the air throughout the cabinet utilizing
a thermostatic control. An ABS plastic drip pan is
placed below the coil with a clear drain hose for running
the condensation to the lower base mechanical section.
Front of the display section is equipped with two sliding
and removable self-closing .50” thick argon lled,
low-e glass doors with a warm edge spacer. The vertical
outsides of each door tuck into an extruded channel
running vertically up each side. Front and rear nosing
to be 20-gauge stainless steel.
Self-contained models have a pre-wired condensing
unit housed in a 16-gauge cage hanging form the units
exterior bottom. Cage also is supplied with an 8’ cord
and plug and electrical junction box. Electrical connec-
tions are 115V-60H-1PH.
Refrigeration system components are HFC-404A. Dis-
play cabinet blower coil assembly shall have a coated
evaporator coil and fans. Interior refrigerated base
cabinet and display section to maintain 36 to 40
degree temperatures at 100-degree ambient room
temperature.
Back has (2) sliding and removable self-closing .50”
thick argon lled, low-e glass doors with a warm
edge spacer.
MODELS:
 F5PC48N 24” Deep Self-Contained Drop In
Display Section
 F5PC72N 24” Deep Self-Contained Drop In
Display Section
STANDARD FEATURES
• Display exterior sides are made of 18-gauge stainless
steel
• ABS plastic interior sides with molded shelf supports
• (4) adjustable epoxy coated wire shelves
• On/off switch for the display section light(s)
• Top mount coil with multiple fans circulating the air
throughout the cabinet
• Display section runs off a thermostatic control
• Sliding and removable self-closing .50” thick argon
filled, low-E, warm edge insert, thermopane glass doors
with left and right vertical gasket
• High density polyurethane foam throughout unit
• Three adjustable epoxy coated shelves for each door
• Single service display section with mirrored back
• Environmentally friendly HFC-404A refrigerant
OPTIONS AND ACCESSORIES
 48” shelf (48” long units only)
 72” shelf (72” long units only)
 Mirrored interior on pass-through doors (48”)
 Mirrored interior on pass-through doors (72”)
 220 volt/50 cycle - inclusion of this option will
alter specications

F5 24” Deep Pass Through Self-Contained Refrigerated Display Cases
Model #__________
CSI Section 11400
Printed in the USA.
01/04
DSF5PCN
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
PLAN VIEW F5PC48N PLAN VIEW F5PC72N
ELEVATION VIEW F5PC48N
48”
121.9cm
31.9”
81.0cm
22.8”
57.9cm
72”
182.9cm
28”
71.1cm
CUTOUT DIMENSIONS:
• 48" LONG MODELS
23.62" x 18.62" (60.0cm x 47.3cm)
• 72" LONG MODELS
32.62" x 18.62" (82.9cm x 47.3cm)
J
MECHANICAL ACCESS
PLAN VIEW ALL MODELS
INSTALLATION NOTE:
Refrigeration system is designed so air will ow
front to rear on 48” models and right to left on 72”
models, using the supplied louvered panels. Louver
cut-out dimensions are 24” by 15.5” (60.1cm x
39.4cm). Unobstructed airow must be maintained
to insure unit performance and maintain warranty.
28”
71.1cm
28”
71.12cm
6.5”
16.5cm
56.90”
144.5cm
42.0”
106.7cm
18”
45.7cm
24”
60.7cm
28”
71.1cm
6.5”
16.5cm
56.90”
144.5cm
42.0”
106.7cm
18”
45.7cm
24”
60.7cm
14.9”
37.8cm
14.9”
37.8cm
RIGHT END VIEW
48” MODELS
ELEVATION VIEW F5PC72N
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
F5SC48N 20.8 14.3 1/2 3160 1802 115/60/1 12.0 5-15P 423/192
F5SC72N 32.8 22.2 3/4 5758 2801 115/60/1 16.0 5-20P 578/262
Mechanical Data–Standard Unit
RIGHT END VIEW
72” MODELS
