Delfield 549-CD User manual

PROJECT
ITEM #
QUANTITY DATE
APPROVAL
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
Short Form Specifications
Exterior Body: front of unit is provided with curved glass of 0.25”
(0.64 cm) overall thickness tempered glass panes. Each side of glass is
trimmed with black aluminum extrusion formed to match the curvature of
the glass front. Base of cabinet is 18-gauge stainless steel over 14-gauge
galvanized steel bottom structure. Exterior top of display case is con-
structed of 18-gauge stainless steel. Exterior sides are finished with stain-
less steel. Unit is completely insulated with 1.50” (3.8 cm) polyurethane
insulation. Adjustable feet allow for leveling.
Doors: unit is provided with two self-closing, thermopane glass doors
in a thermo-plastic frame/track. Doors are readily removable for clean-
ing and are featured with a hold open mechanism for easy loading,
and a lock for night storage.
Interior Cabinet is constructed of 18-gauge stainless steel top and
bottom. Interior sides are ABS material covered with mirrors. Two
beige epoxy coated shelves are provided and have adjustable shelf
supports located at each end of cabinet. Interior is lighted with three
(120v-60c-1ph) fluorescent lights and two adjust with shelves, with
separate on/off switch.
Unit is supplied with low velocity fans to maintain display temperature
of 6º - 8ºF above ambient room temperature. A louver is installed in
front (server side) of base for air circulation.
Options and Accessories
• Aluminum colored trim strips
• Full height laminate ends and base (customer side only)
• One-way mirrored doors
• Special decorative metal laminates
• Glass shelves
500-CD
Dry Curved Glass Display Cases
Model 549-CD
An AutoCAD® symbols library
is available for all 500-CD models.
See listings on back

MODEL VOLTAGE NEMA SHIP
NUMBER TYPE (60Hz/1ph) AMPS* PLUG WEIGHT
Dry 115 5 5-15P 374 lbs/170 kg
Dry 115 5 5-15P 562 lbs./255 kg
Dry 115 5 5-15P 658 lbs/299 kg
Dry 115 5 5-15P 737 lbs/335 kg
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
DS500CD 10/01
37.25
94.6 cm
35.00
88.9 cm
S/S TOP 15.50
39.4 cm
49.25
125.1 cm
35.00
88.9 cm
S/S TOP
15.50
39.4 cm
73.25"
186 cm
35.00"
88.9 cm
S/S TOP
15.50
39.4 cm
61.25"
155.6 cm
35.00"
88.9cm
S/S TOP
15.50
39.4 cm
EXHAUST AIR GRILL
SLIDING SLIDING
DRY DRY
ACCESS PANEL LIGHT/FAN SWITCH
J-BOX BEHIND
ACCESS PANEL 28.00"
(TYP.)
46.37"
117.7 cm
16.03"
40.7 cm
8.00"
20.3 cm
8.25"
20.9 cm
1.50"
3.8 cm
7.87"
19.9 cm
25.75
65.4 cm
20.75
52.7 cm
26.25
66.7 cm
RADIUS OF CURVED
GLASS (15.75" O.D.)
FAN
35.00
88.9 cm
ACCESS HOLE FOR
ELECT. CONNECTION
PLAN VIEW 537-CD PLAN VIEW 561-CD
PLAN VIEW 549-CD PLAN VIEW 573-CD
TYPICAL FRONT ELEVATION
ALL 500-CD MODELS TYPICAL END ELEVATION
ALL 500-CD MODELS PERSPECTIVE VIEW
Mechanical Data
NOTE: ALL UNITS ARE
115V-60C-1PH
CLEAR DOOR OPENING
DIMENSIONS
MODEL 537 -CD
14” (35.6cm) X 23.5” (59.7cm)
MODEL 549-CD
19.75” (50.2cm) X 23.5” (59.7cm)
MODEL 561-CD
26.65” (67.7cm) X 23.5” (59.7cm)
MODEL 573-CD
31.75” (80.6cm) X 23.5” (59.7cm)
*Includes lights and fan
INTERIOR SHELF LENGTHS
537-CD 33” (83.8CM)
549-CD 45” (114.3CM)
561-CD 57” (144.8CM)
573-CD 69” (175.3CM)
500-CD
Dry Curved Glass Display Cases
