18PTB/18PTL/F18 Series
Pizza Prep Tables

18PTB Series
You need a production center that keeps
your costs low, productivity high and delivers
a quality product. Delfield’s pizza prep
tables meet those needs with an integrated
production center that promotes efficiency
and production quality. In addition to our
standard features, we provide a wide offering
of options that allow you to configure your
pizza prep table to meet your specific needs.
Features & Benefits
Configure your pizza
prep table to meet the
needs of your operation.
Stainless steel back
for that finished look
Laminate facing
to fit your decor
Cheese grates with
removable catch pans
to make clean-up a
breeze
Cutting boards to aid
production
Overshelves for
additional storage and
staging
Tray racks for easy
access storage
Door/drawer locks for
security
Legs instead of casters
1Tough, easy to clean ABS interiors: They stand up to wear and tear in a busy kitchen and
are easy to keep clean and sanitary.
2
3
4
5
Long life door gasket: Durable vinyl material, magnetic snap in type design for assured
door seal and easy removal for cleaning or replacement. Protected from tearing by
thermoformed ABS door liner that comes out past the gasket to keep pans, boxes and other
items from coming into contact with the gasket as they are loaded and unloaded.
6
7
Mounted on casters: Casters make the unit easy to move for cleaning or reorganization.
8
9
10
Tough, good looking stainless steel exterior: Stands up to the demand of your busy
operation.
Self closing doors: Hinges are concealed in the door to avoid damage. Cam lift system
assures that the doors self-close past 90˚, while staying open for convenient access at 120˚.
Efficient, energy saving polyurethane foam insulation: A full 2” thick polyurethane foam
insulation keeps the heat out and the cold in for efficient operation.
Large capacity interiors: Lots of storage space and easy shelf adjustment.
Wide work surface: 14” width provides assembly area for large pizzas.
Ergonomic design: 36” high to the work surface - just the right height for easy pizza
assembly. Rail, at 42” high, is easy to get to for quick topping access.
Recessed door handle: Easy to access, but it doesn’t get in the way.
12
3
4
5
6
7
8
9
10
11
12
13

All the benefits found with our 18PTB pizza
prep tables plus the added performance of
LiquiTec®pan cooling technology. LiquiTec®
has the ability to hold product in the pans
at or below 41˚F even in the harshest
conditions. The pans can be mounted flush
with the rail surface, making them easy to
work out of, keeping productivity high.
• Superior temperature maintenance.
• Ergonomic flush mount pan placement.
Delfield’s Deluxe 18PTL
Series Pizza Prep Tables.
18PTB series units available with doors or drawers.
Delfield’s drawers are designed to hold up in busy kitchens.
• Full extension for easy access
• Heavy-duty construction for long life reliability
• 11-gauge stainless steel drawer box
• 11-gauge stainless steel prole
• 12-gauge stainless steel general construction
• Self lubricating Delrin rollers
10 Year
Warranty!
11
12
13
8’ cord and plug attached: Plug & play, long enough to allow movement for cleaning
behind the unit.
High performance mechanically cooled rail: Stands up to the demand of your busy
operation.
Dual controls: Control the rail and the interior storage individually.
Patented LiquiTec®uses eutectic fluid
permanently sealed in a jacket surrounding
the pan opening as the cooling medium.
Refrigerant lines cool the eutectic
fluid, which in turn, cools the pan. This
fluid remains a liquid at extremely cold
temperatures, providing consistent, even
super cooling, keeping food fresh and safe.
Eutectic fluid surrounds the sides and bottom
of the pan providing 100% more surface
contact than a traditional mechanically
cooled pan.
12
3
4
5
6
7
8
9
10
11
12
13

To your pizza preparation needs? Delfield
can deliver with one of our F18 series
pizza prep table products.
Need a Truely Custom
Solution...
REACH-INS / PREP TABLES / SHELLEY® SERVING COUNTERS / DROP-INS / COMPONENT CRAFTED EQUIPMENT
PHONE: [phone] / FAX: [phone] / WEB:WWW.DELFIELD.COM
DBPIZZAPREP
09/07
F18RC - Reduced height raised rail model.
Rail is 42” high for convenient pass-thru
to serving area.
F18DC - Quick glance rail units.
Rail is angled to give easy access to pans.
The F18 series pizza table offering
has tough construction with 16-gauge
stainless steel tops and mechanically
cooled pan rails. They are designed
to be customizable to meet specific
customer needs and to be combined with
other fabrication to create integrated
production systems. Contact your
Delfield representative to explore the
capabilities this line offers.
MODEL DESCRIPTION L D H AMP PAN
CAPACITY 1/3 SIZE
18648PTB PIZZA PREP TABLE 48” 31.5” 42” 10 6
18660PTB PIZZA PREP TABLE 60” 31.5” 42” 12 7
18672PTB PIZZA PREP TABLE 72” 31.5” 42” 14 9
18691PTB PIZZA PREP TABLE 91” 31.5” 42” 14 11
18699PTB PIZZA PREP TABLE 99” 31.5” 42” 14 12
186114PTB PIZZA PREP TABLE 114” 31.5” 42” 16 14
18648PTL PIZZA PREP TABLE 48” 31.5” 42” 10 6
18672PTL PIZZA PREP TABLE 72” 31.5” 42” 14 9
18699PTL PIZZA PREP TABLE 99” 31.5” 42” 14 12
F18RC52 PIZZA PREP TABLE 52” 31.5” 42” 10 6
F18RC60 PIZZA PREP TABLE 60” 31.5” 42” 12 7
F18RC68 PIZZA PREP TABLE 68” 31.5” 42” 12 9
F18RC82 PIZZA PREP TABLE 82” 31.5” 42” 14 10
F18RC91 PIZZA PREP TABLE 91” 31.5” 42” 14 11
F18RC99 PIZZA PREP TABLE 99” 31.5” 42” 16 12
F18DC52 PIZZA PREP TABLE 52” 31.5” 43.75” 10 6
F18DC60 PIZZA PREP TABLE 60” 31.5” 43.75” 12 7
F18DC68 PIZZA PREP TABLE 68” 31.5” 43.75” 12 9
F18DC82 PIZZA PREP TABLE 82” 31.5” 43.75” 14 10
F18DC91 PIZZA PREP TABLE 91” 31.5” 43.75” 14 11
F18DC99 PIZZA PREP TABLE 99” 31.5” 43.75” 16 12
18PTB SERIES
18PTL SERIES
F18RC SERIES
F18DC SERIES
The right size to fit your needs with work area and pan capacities.
