Dell QLogic QL45212 User manual

BC0154503-00 B Third party information brought to
you courtesy of Dell.
User’s Guide
25Gb Intelligent Ethernet Adapter
QL45212

ii BC0154503-00 B
User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
This document is provided for informational purposes only and may contain errors. QLogic reserves the right, without
notice, to make changes to this document or in product design or specifications. QLogic disclaims any warranty of any
kind, expressed or implied, and does not guarantee that any results or performance described in the document will be
achieved by you. All statements regarding QLogic's future direction and intent are subject to change or withdrawal
without notice and represent goals and objectives only.
Document Revision History
Revision A, January 11, 2015
Revision B, April 19, 2016
Changes Sections Affected
Updated the list of features to replace the list of
supported Dell servers with a general reference to
the PowerEdge product line.
Added NPAR and RoCE to the list of features.
Added TSO, LSO, GSO, LOR, RSC, and Microsoft
dynamic VMQ and Linux Multiqueue to the list of
features.
Updated the number of classification filters from
512 to 1,024.
Removed the “Microsoft Windows Server only”
qualification from the virtualization feature.
“Features” on page 1
In Table 2-1, updated the list of supported direct
attach copper cables.
In Table 2-2, updated the supported Windows and
Linux operating system versions; added VMware.
“System Requirements” on page 5
Updated the section titled Installing the Add-In NIC
to Installing the Adapter.“Installing the Adapter” on page 7
Updated the section titled Installing the Linux Driv-
ers and merged it with Removing Linux Drivers
and Network Installations to create two new sec-
tions describing the installation of Linux drivers
with and without RoCE.
“Installing the Linux Drivers without RoCE” on
page 9
“Installing the Linux Drivers with RoCE” on
page 14
Updated the section titled Setting Values for
Optional Properties to Linux Driver Optional
Parameters.
“Linux Driver Optional Parameters” on page 16
Updated the section titled Driver Defaults to Linux
Driver Parameter Defaults. Reorganized the list of
defaults into a table.
“Linux Driver Parameter Defaults” on page 16
Updated the section titled Driver Messages to
Linux Driver Messages.“Linux Driver Messages” on page 17

User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
iii BC0154503-00 B
Updated the Windows driver installation proce-
dure. “Installing the Windows Drivers” on page 17
Updated the Windows driver removal procedure. “Removing the Windows Drivers” on page 25
Updated the section titled Viewing or Changing the
Properties of the Adapter to Managing Adapter
Properties.
“Managing Adapter Properties” on page 26
Added the section VMware Driver Software.“VMware Driver Software” on page 27
Added the chapter Preboot Adapter Configuration.“Preboot Adapter Configuration” on page 36
Added the chapter Configuring RoCE.“Configuring RoCE” on page 44
Added the chapter iSCSI Extensions for RDMA. “iSCSI Extensions for RDMA” on page 62
Updated the firmware versions listed in the exam-
ple to be generic. “Linux” on page 70
Updated the connectivity testing procedures for
Windows and Linux to include information about
how to force the adapter link speed.
“Network Connectivity Testing for Windows” on
page 71
“Network Connectivity Testing for Linux” on
page 72
Updated instances of automatic port speed negoti-
ation to auto-negotiation.“Dell Z9100 Switch Configuration” on page 75
Updated the glossary. “Glossary” on page 78

iv BC0154503-00 B
Table of Contents
Preface
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
What Is in This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Documentation Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
License Agreements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
FDA Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Agency Certification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
EMI and EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
KCC: Class A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Product Safety Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
1 Product Overview
Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Adaptive Interrupt Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ASIC with Embedded RISC Processor . . . . . . . . . . . . . . . . . . . . . . . . 3
Adapter Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Standards Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Installing the Hardware
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preinstallation Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Installing Drivers
Linux Driver Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
v BC0154503-00 B
Installing the Linux Drivers without RoCE . . . . . . . . . . . . . . . . . . . . . . 9
Removing the Linux Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing Linux Drivers Using the src RPM Package . . . . . . . . . 12
Installing Linux Drivers Using the kmp/kmod RPM Package . . . 13
Installing Linux Drivers Using the TAR File. . . . . . . . . . . . . . . . . 13
Installing the Linux Drivers with RoCE . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing Linux Drivers for RoCE in an In-box
OFED Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing Linux Drivers for RoCE in an Out-of-box
OFED Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Linux Driver Optional Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Linux Driver Parameter Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Linux Driver Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Windows Driver Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installing the Windows Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Running the Dell Update Package in the GUI . . . . . . . . . . . . . . 17
Running the Dell Update Package from the Command Line . . . 23
Installation Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Removing the Windows Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Managing Adapter Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting Power Management Options. . . . . . . . . . . . . . . . . . . . . . . . . . 26
VMware Driver Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Installing VMware Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
VMware Driver Optional Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . 28
VMware Driver Parameter Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Removing the VMware Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4 Upgrading Firmware
Run by Double-Clicking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Run from the Command Line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5 Preboot Adapter Configuration
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Displaying Firmware Image Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Device Level Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
NIC Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Data Center Bridging Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
NIC Partitioning Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
vi BC0154503-00 B
6 Configuring RoCE
Supported Operating Systems and OFED. . . . . . . . . . . . . . . . . . . . . . . . . . 44
Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Preparing the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Preparing the Ethernet Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Cisco Nexus 6000 Ethernet Switch . . . . . . . . . . . . . . . . . . . . . . 46
Dell Z9100 Ethernet Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configuring RoCE on the Adapter for Windows Server . . . . . . . . . . . . . . . . 51
Configuring RoCE on the Adapter for Linux. . . . . . . . . . . . . . . . . . . . . . . . . 55
RoCE Configuration for RHEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Configuring In-box OFED for RHEL . . . . . . . . . . . . . . . . . . . . . . 55
Installing Out-of-box OFED for RHEL. . . . . . . . . . . . . . . . . . . . . 56
RoCE Configuration for SLES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Configuring In-box OFED for SLES Linux . . . . . . . . . . . . . . . . . 57
Installing Out-of-box OFED for SLES Linux . . . . . . . . . . . . . . . . 57
Verifying the RoCE Configuration on Linux. . . . . . . . . . . . . . . . . . . . . 58
VLAN Interfaces and GID Index Values . . . . . . . . . . . . . . . . . . . . . . . 61
7 iSCSI Extensions for RDMA
Configuring iSER for RHEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Configuring iSER for SLES12 Linux. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Optimizing Linux Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Set CPUs to Maximum Performance Mode. . . . . . . . . . . . . . . . . . . . . 67
Set Kernel sysctl Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
IRQ Affinity Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Block Device Staging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8 Troubleshooting
Troubleshooting Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Verifying that Current Drivers are Loaded . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Testing Network Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Network Connectivity Testing for Windows . . . . . . . . . . . . . . . . . . . . . 71
Network Connectivity Testing for Linux . . . . . . . . . . . . . . . . . . . . . . . . 72
Microsoft Virtualization with Hyper-V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Linux. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
vii BC0154503-00 B
A Adapter LEDS
B Dell Z9100 Switch Configuration
Glossary
Index

User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
viii BC0154503-00 B
List of Figures
Figure Page
3-1 Dell Update Package Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3-2 QLogic InstallShield Wizard: Welcome Window . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3-3 QLogic InstallShield Wizard: License Agreement Window . . . . . . . . . . . . . . . . . . . 19
3-4 InstallShield Wizard: Setup Type Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3-5 InstallShield Wizard: Custom Setup Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3-6 InstallShield Wizard: Ready to Install the Program Window . . . . . . . . . . . . . . . . . . 22
3-7 InstallShield Wizard: Completed Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3-8 Dell Update Package Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3-9 Power Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4-1 Dell Update Package Splash Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4-2 Continue Dell Update Package Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4-3 Loading New Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4-4 Result of Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4-5 Finish Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4-6 Command Line Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5-1 Main Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5-2 Device Level Configuration Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5-3 Global Bandwidth Allocation Page–NPAReP Mode Enabled. . . . . . . . . . . . . . . . . . 43

User’s Guide—25Gb Intelligent Ethernet Adapter
QL45212
ix BC0154503-00 B
List of Tables
Table Page
2-1 Host Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2-2 Host Operating System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3-1 QLogic QL45212 Linux Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-2 qede Driver Optional Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3-3 Linux Driver Parameter Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3-4 VMware Driver Optional Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3-5 VMware Driver Parameter Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5-1 Adapter Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5-2 Link Speed Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
A-1 Port LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

x BC0154503-00 B
Preface
Overview
This user’s guide describes installation, configuration, and management of the
QLogic®QL45212 25Gb Intelligent Ethernet Adapter.
Intended Audience
This guide is intended for system administrators and other technical staff
members responsible for configuring and managing adapters installed on Dell®
PowerEdge®servers in Windows®, Linux®, or VMware®environments.
What Is in This Guide
This preface specifies the intended audience, explains the typographic
conventions used in this guide, lists related documents, and provides technical
support and contact information. The remainder of this guide is organized into the
following chapters and appendices:
Chapter 1, Product Overview provides a product functional description, a list
of features, a list of supported operating systems, and the adapter
specifications.
Chapter 2, Installing the Hardware describes how to install the adapter
including the list of system requirements and a preinstallation checklist.
Chapter 3, Installing Drivers describes the installation of the adapter drivers.
Chapter 4, Upgrading Firmware describes the use of the Dell firmware
update package to upgrade adapter firmware.
Chapter 5, Preboot Adapter Configuration describes the preboot adapter
configuration tasks using the Human Infrastructure Interface (HII)
application.
Chapter 6, Configuring RoCE describes how to configure the QL45212
adapter, the Ethernet switch, and the host to use RDMA over converged
Ethernet (RoCE).
Chapter 7, iSCSI Extensions for RDMA describes how to configure iSCSI
Extensions for RDMA (iSER) for RHEL and SLES.

Preface
Documentation Conventions
xi BC0154503-00 B
Chapter 8, Troubleshooting describes a variety of troubleshooting methods
and resources.
Appendix A, Adapter LEDS describes the adapter LEDs and their
significance.
Appendix B, Dell Z9100 Switch Configuration describes how to configure the
Dell Z9100 switch port for 25Gbps.
Documentation Conventions
This guide uses the following documentation conventions:
provides additional information.
without an alert symbol indicates the presence of a hazard
that could cause damage to equipment or loss of data.
with an alert symbol indicates the presence of a hazard that
could cause minor or moderate injury.
indicates the presence of a hazard that could cause serious
injury or death.
Text in blue font indicates a hyperlink (jump) to a figure, table, or section in
this guide, and links to Web sites are shown in underlined blue. For
example:
Table 9-2 lists problems related to the user interface and remote agent.
See “Installation Checklist” on page 6.
For more information, visit www.qlogic.com.
Text in bold font indicates user interface elements such as a menu items,
buttons, check boxes, or column headings. For example:
Click the Start button, point to Programs, point to Accessories, and
then click Command Prompt.
Under Notification Options, select the Warning Alarms check box.
Text in Courier font indicates a file name, directory path, or command line
text. For example:
To return to the root directory from anywhere in the file structure:
Type cd /root and press ENTER.
Enter the following command: sh ./install.bin
Key names and key strokes are indicated with UPPERCASE:
NOTE
CAUTION
CAUTION
!
!
WARNING

Preface
License Agreements
xii BC0154503-00 B
Press CTRL+P.
Press the UP ARROW key.
Text in italics indicates terms, emphasis, variables, or document titles. For
example:
For a complete listing of license agreements, refer to the QLogic
Software End User License Agreement.
What are shortcut keys?
To enter the date type mm/dd/yyyy (where mm is the month, dd is the
day, and yyyy is the year).
Topic titles between quotation marks identify related topics either within this
manual or in the online help, which is also referred to as the help system
throughout this document.
License Agreements
Refer to the QLogic Software End User License Agreement for a complete listing
of all license agreements affecting this product.
Technical Support
Dell provides several online and telephone-based support and service options.
Availability varies by country and product, and some services may not be
available in your area. To contact Dell for sales, technical support, or customer
service issues:
1. Go to support.dell.com.
2. Select your support category.
3. Verify your country or region in the Choose a Country/Region drop-down
menu at the bottom of the page.
4. Select the appropriate service or support link on the basis of your
requirement.
Legal Notices
Warranty For warranty details, please check the QLogic Web site:
www.qlogic.com/Support/Pages/Warranty.aspx

Preface
Legal Notices
xiii BC0154503-00 B
Laser Safety
FDA Notice This product complies with DHHS Rules 21CFR Chapter I, Subchapter J. This
product has been designed and manufactured according to IEC60825-1 on the
safety label of laser product.
Class 1 Laser Product
Appareil laser de classe 1
Produkt der Laser Klasse 1
Luokan 1 Laserlaite
Caution—Class 1 laser radiation when open. Do
not view directly with optical instruments
Attention—Radiation laser de classe 1. Ne pas
regarder directement avec des instruments
optiques.
Vorsicht—Laserstrahlung der Klasse 1 bei
geöffneter Abdeckung. Direktes Ansehen mit
optischen Instrumenten vermeiden.
Varoitus—Luokan 1 lasersäteilyä, kun laite on
auki. Älä katso suoraan laitteeseen käyttämällä
optisia instrumenttej.
CLASS I LASER

Preface
Legal Notices
xiv BC0154503-00 B
Agency Certification
The following sections summarize the EMC and EMI test specifications performed
on the QL45212 Intelligent Ethernet Adapter to comply with emission, immunity,
and product safety standards:
EMI and EMC Requirements
FCC Part 15 compliance: Class A
FCC compliance information statement: This device complies with Part 15 of
the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
ICES-003 Compliance: Class A
This Class A digital apparatus complies with Canadian ICES-003.Cet appareil
numériqué de la classe A est conformé à la norme NMB-003 du Canada.
CE Mark 2004/108/EC EMC Directive Compliance:
EN55022:2010 Class A1:2007/CISPR22:2006: Class A
EN55024:2010
EN61000-3-2: Harmonic Current Emission
EN61000-3-3: Voltage Fluctuation and Flicker
Immunity Standards
EN61000-4-2: ESD
EN61000-4-3: RF Electro Magnetic Field
EN61000-4-4: Fast Transient/Burst
EN61000-4-5: Fast Surge Common/ Differential
EN61000-4-6: RF Conducted Susceptibility
EN61000-4-8: Power Frequency Magnetic Field
EN61000-4-11: Voltage Dips and Interrupt
VCCI: 2010-04 Class A
AS/NZS CISPR22: Class A

Preface
Legal Notices
xv BC0154503-00 B
KCC: Class A
Korea RRA Class A Certified
Product Name/Model: Converged Network
Adapters and Intelligent Ethernet Adapters
Certification holder: QLogic Corporation
Manufactured date: Refer to date code listed on
product
Manufacturer/Country of origin: QLogic
Corporation/USA
Korean Language Format—Class A
Product Safety Compliance
UL, cUL product safety:
UL60950-1 (2nd Edition), 2007-03-3-27
UL CSA C22.2 60950-1-07 (2nd Edition)
Use only with listed ITE or equivalent.
Complies with 21 CFR 1040.10 and 1040.11.
2006/95/EC low voltage directive:
TUV EN60950-1:2006+A11+A1+A12
IEC60950-1 2nd Edition (2005) CB
CB Certified to IEC 60950-1 2nd Edition
A class equipment
(Business purpose info/telecom-
munications equipment)
As this equipment has undergone EMC registration
for business purpose, the seller and/or the buyer is
asked to beware of this point and in case a wrongful
sale or purchase has been made, it is asked that a
change to household use be made.

1 BC0154503-00 B
1Product Overview
This chapter provides information about the following topics:
Functional Description
Features
Adapter Specifications
Functional Description
The QL45212 Adapter is a 25Gb Intelligent Ethernet Adapter that is designed to
perform accelerated data networking for Dell PowerEdge systems. The QL45212
Adapter includes a 25Gb Ethernet MAC with full-duplex capability.
Features
The QL45212 Adapter provides the following features:
NIC partitioning (NPAR)
Remote direct memory access over converged Ethernet (RoCE)
Single-chip solution
25Gb MAC
SerDes interface for direct attach copper (DAC) transceiver connection
PCI Express Gen3 x8
Zero copy capable hardware
Performance features
TCP, IP, UDP checksum offloads
TCP segmentation offload (TSO)
Large segment offload (LSO)
Generic segment offload (GSO)
Large receive offload (LRO)
Receive segment coalescing (RSC)

1–Product Overview
Features
2 BC0154503-00 B
Microsoft®dynamic VMQ and Linux multiqueue
Adaptive interrupts
Receive side scaling (RSS)
Transmit side scaling (TSS)
Stateless offloads for NVGRE/VXLAN tunneled traffic1.
Manageability
System management bus (SMB) controller
Advanced Configuration and Power Interface (ACPI) 1.1a compliant
(multiple power modes)
Network controller-sideband interface (NC-SI) support
Advanced network features
Jumbo frames (up to 9600 bytes). The OS and the link partner must
support jumbo frames.
Virtual LANs (VLANs)
Flow control (IEEE Std 802.3x)
Logical Link Control (IEEE Std 802.2)
High-speed on-chip reduced instruction set computer (RISC) processor
Integrated 96 KB frame buffer memory
1,024 classification filters
Support for multicast addresses through 128-bit hashing hardware function
Serial flash NVRAM memory
PCI Power Management Interface (v1.1)
64-bit base address register (BAR) support
EM64T processor support
Virtualization
1This feature requires support for Hypervisor to use the offloads.

1–Product Overview
Adapter Specifications
3 BC0154503-00 B
Adaptive Interrupt Frequency
The adapter driver intelligently adjusts host interrupt frequency based on traffic
conditions to increase overall application throughput. When traffic is light, the
adapter driver interrupts the host for each received packet, minimizing latency.
When traffic is heavy, the adapter issues one host interrupt for multiple,
back-to-back incoming packets, preserving host CPU cycles.
ASIC with Embedded RISC Processor
The core control for the QL45212 Adapter resides in a tightly integrated,
high-performance ASIC. The ASIC includes a RISC processor, which provides the
flexibility to add new features to the card and adapts it to future network
requirements through software downloads. The RISC processor also enables the
adapter drivers to exploit the built-in host offload functions on the adapter as host
operating systems are enhanced to take advantage of these functions.
Adapter Specifications
Physical Characteristics
The QL45212 Adapter is a standard PCI Express®card and ships with either a
full-height or a low-profile bracket for use in a standard PCIe®slot.
Standards Specifications
PCI Express Base Specification, rev. 3.0
PCI Express Card Electromechanical Specification, rev. 3.0
PCI Bus Power Management Interface Specification, rev. 1.2
802.1q (VLAN)
802.1AX (Link Aggregation)
802.1ad (QinQ)
802.1p (Priority Encoding)
IPv4 (RFQ 791)
IPv6 (RFC 2460)

4 BC0154503-00 B
2Installing the Hardware
System Requirements
Safety Precautions
Preinstallation Checklist
Installing the Adapter

2–Installing the Hardware
System Requirements
5 BC0154503-00 B
System Requirements
Before you install a QLogic QL45212 Adapter, verify that your system meets the
following hardware (Table 2-1) and operating system (Table 2-2) requirements:
Table 2-1. Host Hardware Requirements
Hardware Requirement
Architecture IA-32 or EMT64 processor that meets operating system
requirements
PCIe PCIe Gen2 x8
PCIe Gen3 x8
Full dual-port 25Gb bandwidth is supported on PCIe
Gen3 x8 or faster slots.
Memory 8GB RAM (minimum)
Direct Attach Cables (DAC) Amphenol®NDDCCGF-0001
Amphenol NDAQGF-0003
Amphenol NDCCGF-0005
Leoni®ParaLink®LA0SF064-SD-R
Table 2-2. Host Operating System Requirements
Operating
System Requirement
Windows Server 2012 and later
Linux RHEL 6.6, 6.7; 7.1 and later
SLES 11 SP4, 12 U1 and later
VMware ESXi 6.0 U2 and later
