About Your Monitor
Setting Up the Monitor
Operating the Monitor
Solving Problems
Appendix
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page

AboutYourMonitor
Dell™ST2320L/ST2321LmonitorUser'sGuide
Package Contents
Product Features
Identifying Parts and Controls
Monitor Specifications
Plug and Play Capability
LCD Monitor Quality & Pixel Policy
Maintenance Guidelines
Package Contents
Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.
NOTE: Some items may be optional and may not ship with your Monitor. Some features or media may not be available in certain countries.
lMonitor with Stand
lPower Cable

lDVI Cable (optional)

lVGA Cable


Product Features
The ST2320L/ST2321L flat panel display has an active matrix, Thin-Film Transistor (TFT), and Liquid Crystal Display (LCD). The monitor's features include:
■ST2320L/ST2321L: 58.42 cm (23 inches) viewable area display.
■1920 x 1080 resolution, plus full-screen support for lower resolutions.
■Tilt adjustment capability.
■Plug and play capability if supported by your system.
■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
■Software and documentation CD which includes an information file (INF), Image Color Matching File (ICM), and product documentation.
■Energy Star compliant.
■Security lock slot.
Identifying Parts and Features
Front View

Back View
lProduct Information Guide
lDrivers and Documentation media
lQuick Setup Guide
Front View
Front Panel Controls
Label
Description
1-2
Shortcut keys
*The default settings are Preset Modes and Brightness/Contrast.
1
Shortcut key: Preset Modes (Default)
2
Shortcut key: Brightness/Contrast (Default)
3
OSD menu select
4
EXIT
5
Power On/Off (light indicator below Dell logo)


Side View
Bottom View

BackView
Label
Description/Use
1
Barcode serial number label
To contact Dell for technical support.
2
Security lock slot
To help secure your monitor.
3
Dell Soundbar mounting brackets
To attach the optional Dell Soundbar.
4
Regulatory rating label
Lists the regulatory approvals.
5
Stand release button
To release stand assembly from monitor.
Left Side

Monitor Specifications
Power Management Modes
IfyouhaveVESA'sDPMS™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotin
use. This is referred to as Power Save Mode. If input from a keyboard, mouse or other input devices is detected by the computer, the monitor will automatically
"wake up". The following table shows the power consumption and signaling of this automatic power-savingfeature:
ST2320L/ST2321L
Pin Assignments
VGA Connector
Bottom view
Label
Description
1
AC power cord connector
2
DVI connector
3
HDMI connector
4
VGA connector
5
Audio Line-in
6
Audio Line out
VESA Modes
Horizontal
Sync
Vertical Sync
Video
Power
Indicator
Power Consumption
Normal operation
Active
Active
Active
White
30 W (maximum)
24 W (typical)
Active-off mode
Inactive
Inactive
Blanked
Amber
Less than 1 W
Switch off
-
-
-
Off
Less than 0.5 W
NOTE: This monitor is ENERGY STAR®-compliant.
NOTE: Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the
monitor.
Pin
Number
15-pin Side of the
Connected Signal Cable
1
Video-Red

DVIConnector
HDMI Connector (for selective models)
2
Video-Green
3
Video-Blue
4
GND
5
Self-test
6
GND-R
7
GND-G
8
GND-B
9
Computer 5 V/3.3 V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Pin
Number
24-pin Side of the Connected Signal
Cable
1
TMDS RX2-
2
TMDS RX2+
3
TMDS Ground
4
Floating
5
Floating
6
DDC Clock
7
DDC Data
8
Floating
9
TMDS RX1-
10
TMDS RX1+
11
TMDS Ground
12
Floating
13
Floating
14
+5 V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-
Pin Number
19-pin Side of the Connected Signal Cable


Flat Panel Specifications
* Based on estimation
** ST2320L/ST2321L Color Gamut (Typical) is based on CIE1976 (81 %) and CIE1931 (68 %).
Resolution
1
TMDS DATA 2+
2
TMDS DATA 2 SHIELD
3
TMDS DATA 2-
4
TMDS DATA 1+
5
TMDS DATA 1 SHIELD
6
TMDS DATA 1-
7
TMDS DATA 0+
8
TMDS DATA 0 SHIELD
9
TMDS DATA 0-
10
TMDS CLOCK
11
TMDS CLOCK SHIELD
12
TMDS CLOCK-
13
CEC
14
Reserved (N.C. on device)
15
DDC CLOCK (SCL)
16
DDC DATA (SDA)
17
DDC/CEC Ground
18
+5 V POWER
19
HOT PLUG DETECT
Model
ST2320L
ST2321L
Screen type
Active matrix -TFT LCD
Active matrix -TFT LCD
Panel type
TN
TN
Screen dimensions
58.42 cm (23 inches) (23-inch viewable image
size)
58.42 cm (23 inches) (23-inch viewable image
size)
Preset display area: Horizontal
Vertical
509.184 mm (20.05 inches)
286.416 mm (11.28 inches)
509.184 mm (20.05 inches)
286.416 mm (11.28 inches)
Pixel pitch
0,265 mm
0,265 mm
Viewing angle
160°(vertical)typical,170°(horizontal)typical
160°(vertical)typical,170°(horizontal)typical
Luminance output
250 cd/m²(typical)
250 cd/m²(typical)
Contrast Ratio
1,000 to 1 (typical)
1,000 to 1 (typical)
Dynamic Contrast Ratio
8,000,000 to 1 *
7,000,000 to 1 *
Faceplate coating
Antiglare with hard-coating 3H
Antiglare with hard-coating 3H
Backlight
LED light bar system
LED light bar system
Response Time
5 ms typical
5 ms typical
Color Depth
16.7 mil colors
16.7 mil colors
Color Gamut
81 % **
81 % **
Model
ST2320L/ST2321L


Video Supported Modes

Preset Display Modes
ST2320L/ST2321L

Electrical

Physical Characteristics
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
56Hzto76Hz(automatic)
Maximum preset resolution
1920 x 1080 at 60 Hz
Model
ST2320L/ST2321L
Video display capabilities (HDMI playback)
480i/480p/576i/576p/720p/1080i/1080p
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity (Horizontal/Vertical)
VGA, 720 x 400
31.469
70.087
28.3
-/+
VGA, 640 x 480
31.469
59.940
25.2
-/-
VGA, 640 x 480
37.500
75.000
31.5
-/-
VESA, 800 x 600
37.879
60.317
40.0
+/+
VESA, 800 x 600
46.875
75.000
49.5
+/+
VESA, 1024 x 768
48.363
60.004
65.0
-/-
VESA, 1024 x 768
60.023
75.029
78.8
+/+
VESA. 1152 x 864
67.500
75.000
108.0
+/+
VESA, 1280 x 1024
64.000
60.000
108.0
+/+
VESA, 1280 x 1024
79.976
75.025
135.0
+/+
VESA, 1920 x 1080
67.500
60.000
148.5
+/+
Model
ST2320L/ST2321L
Video input signals
Analog RGB, 0.7 Volts +/-5 %, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600 mV for each differential line, positive polarity at 50 ohm input
impedance
HDMI, 600 mV for each differential line, 100 ohm input impedance per differential pair
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage/frequency/current
100 VAC to 240 VAC/50 Hz or 60 Hz +3 Hz/2.0 A (Max.)
Inrush iso surge current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
Model
ST2320L/ST2321L
Connector type
lD-sub: Blue connector
lDVI-D: White connector
lHDMI (for selective models)
Signal cable type
lD-sub: Detachable, Analog, 15 pin, shipped attached to the monitor
lDVI-D
lHDMI (for selective models)


Environmental

Plug and Play Capability
You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display
Identification Data (EDID) using Display Data Channel (DDC) protocols so that the system can configure itself and optimize the monitor settings. If required,
the user can select different settings, but in most cases monitor installation is automatic.
LCD Monitor Quality & Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more pixels to become fixed in an unchanging state. The visible result is a fixed
pixel that appears as an extremely tiny dark or bright discolored spot. When the pixel remains permanently lit, it is known as a "bright dot." When the pixel
remains black, it is known as a "dark dot."
In almost every case, these fixed pixels are hard to see and do not detract from display quality or usability. A display with 1 to 5 fixed pixels is considered
normalandwithincompetitivestandards.Formoreinformation,seeDellSupportsiteat:support.dell.com.
Maintenance Guidelines
Caring for Your Monitor
Dimensions (with stand)
Height
404.07 mm (15.91 inches)
Width
553.38 mm (21.79 inches)
Depth
203.68 mm (8.02 inches)
Dimensions (without stand)
Height
344.2 mm (13.55 inches)
Width
553.38 mm (21.79 inches)
Depth
59.5 mm (2.34 inches)
Stand dimensions
Height
203.68 mm (8.02 inches)
Width
149.85 mm ( 5.90 inches)
Depth
203.68 mm (8.02 inches)
Weight
Weight with packaging
5.751 kg (12.65 lb)
Weight with stand assembly and
cables
4.417kg(9.72lb)
Weight of stand assembly
0.685 kg (1.51 lb)
Model
ST2320L/ST2321L
Temperature
Operating
0°Cto40°C(32°Fto104°F)
Non-operating
Storage: -20°Cto60°C(-4°Fto140°F)
Shipping: -20°Cto60°C(-4°Fto140°F)
Humidity
Operating
10 % to 80 % (non-condensing)
Non-operating
Storage: 5 % to 90 % (non-condensing)
Shipping: 5 % to 90 % (non-condensing)
Altitude
Operating
4,485 m (14,700 ft) max
Non-operating
12,191 m (40,000 ft) max
Thermal dissipation
102.6 BTU/hour (maximum)
82.08 BTU/hour (typical)

For best practices, follow the instructions in the list below while unpacking, cleaning, or handling your monitor:
lTo clean your antistatic screen, lightly dampen a soft, clean cloth with water. If possible, use a special screen-cleaning tissue or solution suitable for the
antistatic coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed air.
lUse a lightly-dampened,warmclothtocleanthemonitor.Avoidusingdetergentofanykindassomedetergentsleaveamilkyfilmonthemonitor.
lIf you notice a white powder when you unpack your monitor, wipe it off with a cloth.
lHandle your monitor with care as dark-colored monitors may scratch and show white scuff marks more than lighter-coloredmonitors.
lTo help maintain the best image quality on your monitor, use a dynamically changing screen saver and turn off your monitor when not in use.
Back to Contents Page
CAUTION: Read and follow the Safety Instructions before cleaning the
monitor.
CAUTION: Before cleaning the monitor, unplug the monitor from the electrical
outlet.

Back to Contents Page

Appendix
Dell™ST2320L/ST2321LmonitorUser'sGuide
Safety Instructions
FCC Notice (U.S. Only) and Other Regulatory Information
Contacting Dell

CAUTION: Safety Instructions
For information on safety instructions, see the Safety Information that ships with your monitor.
FCC Notice (U.S. Only) and Other Regulatory Information
For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com\regulatory_compliance.
Contacting Dell
For customers in the United States, call 800-WWW-DELL (800-999-3355).
Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be
available in your area. To contact Dell for sales, technical support, or customer service issues:
1. Visit support.dell.com.
2. Verify your country or region in the Choose A Country/Region drop-down menu at the bottom of the page.
3. Click Contact Us on the left side of the page.
4. Select the appropriate service or support link based on your need.
5. Choose the method of contacting Dell that is convenient for you.
Back to Contents Page

CAUTION: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,
electrical hazards, and/or mechanical hazards.
NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or Dell product
catalog.

Back to Contents Page

Setting Up Your Monitor
Dell™ST2320L/ST2321Lmonitor
IfyouhaveaDell™desktoporaDell™ portable computer with internet access
1. Go to http://support.dell.com,enteryourservicetag,anddownloadthelatestdriverforyourgraphicscard.
2. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1920x1080 again.

Back to Contents Page
NOTE: If you are unable to set the resolution to 1920x1080 ,pleasecontactDell™
toinquireaboutaGraphicsAdapterthatsupportstheseresolutions.

Back to Contents Page

Setting Up Your Monitor
Dell™ST2320L/ST2321Lmonitor
IfyouhaveanonDell™desktop,portablecomputer,orgraphicscard
In Windows XP:
1. Right-click on the desktop and click Properties.
2. Select the Settings tab.
3. Select Advanced.
4. Identify your graphics controller supplier from the description at the top of the window (e.g. NVIDIA, ATI, Intel etc.).
5. Please refer to the graphics card provider website for updated driver (for example, http://www.ATI.com OR http://www.NVIDIA.com ).
6. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1920x1080 again.
In Windows Vista®or Windows 7:
1. Right-click on the desktop and click Personalization.
2. Click Change Display Settings.
3. Click Advanced Settings.
4. Identify your graphics controller supplier from the description at the top of the window (e.g. NVIDIA, ATI, Intel etc.).
5. Please refer to the graphics card provider website for updated driver (for example, http://www.ATI.com OR http://www.NVIDIA.com ).
6. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1920x1080 again.

Back to Contents Page
NOTE:
If you are unable to set the resolution to 1920x1080 , please contact the manufacturer of your computer or consider purchasing a graphics adapter
thatwillsupportthevideoresolutionof1920x1080.

Back to Contents Page

Operating the Monitor
Dell™ST2320L/ST2321LmonitorUser'sGuide
Using the Front Panel Controls
Using the On-Screen Display (OSD) Menu
Setting the Maximum Resolution
Using the Dell Soundbar (Optional)
Using the Tilt

Using the Front Panel
Use the control buttons on the side of the monitor to adjust the characteristics of the image being displayed. As you use these buttons to adjust the controls,
an OSD shows the numeric values of the characteristics as they change.

Using the On-Screen Display (OSD) Menu
1. Press any key to launch the OSD menu and press to display the main menu.
Main Menu for Analog (VGA) Input

1-2
Shortcut keys
Use this button for direct access to the control menu that you define in the personalize menu.
*The default settings are Preset Modes Select and Brightness/Contrast Select.
1
Preset Modes Select
Use this button for different display preset modes on your monitor.
2
Brightness/Contrast
Use this button to access the "Brightness/Contrast" control menu.
3
OSD Menu
Use this button to open the On-Screen Display (OSD). See Using the OSD Menu.
4
Exit
Use this button to exit the OSD menu.
5
Power button
Usethepowerbuttontoturnthemonitoronandoff.
Thewhitelightindicatesthatthemonitorisonandfullyfunctional.Anamberlightindicatespowersavemode.
NOTE: Ifyouchangethesettingsandtheneitherproceedtoanothermenu,orexittheOSDmenu,themonitorautomaticallysavesthechanges.The
changes are also saved if you change the settings and then wait for the OSD menu to disappear.

Or
Main Menu for non Analog (non VGA) Input



NOTE: Auto Adjust is only available when you are using the analog (VGA) connector.
2.Pressthe and buttons to move between the setting options. As you move from one icon to another, the option name is highlighted. See the table
foracompletelistofalltheoptionsavailableforthemonitor.
3.Press the buttononcetoactivatethehighlightedoption.
4.Press the and buttons to select the desired parameter.
5. Press the buttontoentertheslidebarandthenusethe and buttons,accordingtotheindicatorsonthemenu,tomakeyourchanges.
6. Press the buttontoreturntothemainmenuorexittheOSDmenu.


Icon
Menu and Submenus
Description
Brightness/Contrast
Allows you to adjust the brightness and contrast.










Brightness
Contrast
Back
Brightness adjusts the luminance of the backlight.
Press the buttontoincreasethebrightnessandPress the
button to decrease the brightness (min 0 ~ max 100).
Adjust the Brightness first, and then adjust the Contrast only if further adjustment is necessary.
Press the button to increase contrast and press the
button to decrease contrast (min 0 ~ max 100).
The Contrast function adjusts the degree of difference between the darkest and lightest areas on the monitor screen.
Press the buttonto go back to or exit the main menu.



Auto Adjust


Even though your computer recognizes your monitor on startup, the Auto Adjustment function optimizes the display settings for use with your particular setup.

NOTE:Inmostcases,AutoAdjustproducesthebestimageforyourconfiguration. 

Input Source

Auto Select
The Input Source menu is to used to select between different
video signals that may be connected to your monitor.
Scan for Sources. Push to scan for available input signals.


VGA
DVI-D
HDMI (for selective models)
Back
Select VGA input when you are using the analog (VGA) connector. Push
to select the VGA input source.
Select DVI-D input when you are using the Digital (DVI) connector. Push
to select the DVI input source.
Select HDMI input when you are using the HDMI connector. Push to select the HDMI input source.
Push the buttontogobacktoorexitthemainmenu.



Color Settings
Input Color Format
Mode Selection
Preset Modes
VGA input
Standard
Multimedia
Game
Warm
Cool
Custom (RGB)
Video input
Use the color settings to adjust the Image mode and color format.
Allows you to set the color format.
Allows you to set the display mode to Graphics or Video. If your computer is connected to your monitor, choose Graphics. If a DVD, STB, or VCR is connected to your monitor, choose Video.

Mode suitable for desktop applications.
Mode for multimedia applications, e.g., video playback.
Mode suitable for gaming applications.
Select warm mode to obtain a red tint. This color setting is typically used for color-
intensive applications (photograph image editing, multimedia, movies, etc.).
Select cool mode to obtain a bluish tint. This color setting is typically used for text based applications (spreadsheets, programming, text editors, etc.).
Use the or
buttons to increase or decrease each of the three colors (R, G, B) independently, in single


Movie
Game
Sports
Nature
Hue
Saturation
Demo Mode
Reset Color Settings
Back
Mode suitable for movie playback.
Mode suitable for game applications.
Mode suitable for sports scenes.
Mode suitable for nature scenes.
This feature can make the video image color shift from green to purple. Use this feature to adjust the skin tone. Use
increases the green hue in the image
increases the purple hue in the image
NOTE: Hue adjustment is only available for video input.
Allows you to adjust the color saturation of the video image. Use or
buttons to adjust the saturation from '0' to '100'
makes video image looks monochrome
makes video image looks colorful
NOTE: Saturation adjustment is only available for video input.
Vertically splits the screen into two segments. The left half of the screen in the normal mode and the right half of the screen is displayed in the color enhanced mode.
NOTE: Demo Mode is only available for video input.
Returns your monitor color settings to the factory default settings.
Press the button to go back to or exit the main menu.
Display Settings








Wide Mode
Horizontal Position
Vertical Position
Sharpness
Pixel Clock
Phase
Dynamic Contrast
Reset Display Setting
Back
Adjusts the image ratio as 4:3 or full screen.
NOTE: Wide Mode adjustment is not required at maximum preset resolution 1920 x 1080.
Use the and buttons to adjust image left and right. Minimum is '0' (-). Maximum is '100' (+).
Use the and buttons to adjust image up and down. Minimum is '0' (-). Maximum is '100' (+).
This feature can make the image look sharper or softer. Use or
to adjust the sharpness from '0' to '100' .
The Phase and Pixel Clock adjustments allow you to adjust your monitor to your preference. These settings are accessed through the main OSD menu, by selecting 'Display Settings'.
Use the and buttons to adjust for best image quality.
IfsatisfactoryresultsarenotobtainedusingthePhaseadjustment,usethePixelClock(coarse)adjustmentandthenusePhase(fine),again.

Allowsyoutoincreasethelevelofcontrasttoprovidesharperandmoredetailedimagequality.
Resets the display settings to the factory default settings.
Press the buttontogobacktoorexitthemainmenu.
Audio Settings



Line Out Source
PowerSave
Audio
Reset Audio Settings
Back
Selectthesourceoftheaudio
Turns the Audio Power on or off during power save mode.
Resets the audio settings to the original factory settings.
Push togobacktoorexitthemainmenu.

Other Settings

Language
Menu Transparency
Menu Timer
Menu Lock
DDC/CI

Language option to set the OSD display to one of 6 languages (English, Espanol, Francais, Deutsch, Simplified Chinese, Japanese).
Allows you to adjust the OSD background from opaque to transparent.
OSD Hold Time: Sets the amount of time the OSD will remain active after the last time you pressed a button.
Use the and buttons to adjust the slider in 5 second increments, from 5 to 60 seconds.
Controls user access to adjustments. When selected, no user adjustments are allowed. All buttons are locked except the

NOTE: Lock function –
Either soft lock (through OSD menu) or hard lock (Press and hold the button above power button for 10 sec)
Unlock function–Only hard unlock (Press and hold the button above power button for 10 sec)
DDC/CI(DisplayDataChannel/CommandInterface)allowsyourmonitorparameters(brightness,colorbalance,etc.)tobeadjustableusingsoftwareonyourcomputer.Youcandisablethisfeaturebyselecting"Disable".
Enable this feature for best user experience and optimum performance of your monitor.
