Dell™7700FullHD SNMP Protocol Document
Control Commands List
Name Feature Oid Value
Type
Read /Write Criteria
RFC1213-system sysDescr .1.3.6.1.2.1.1.1.0 String R Dell 7700FullHD
RFC1213-system sysObjectID .1.3.6.1.2.1.1.2.0 OID R .1.3.6.1.4.1.674.10901.200.12
RFC1213-system sysUpTime .1.3.6.1.2.1.1.3.0 Timetic
ks R * hours * minutes * seconds
RFC1213-system sysContact .1.3.6.1.2.1.1.4.0 String R/W
RFC1213-system sysName .1.3.6.1.2.1.1.5.0 String R/W
RFC1213-system sysLocation .1.3.6.1.2.1.1.6.0 String R/W
RFC1213-system sysServices .1.3.6.1.2.1.1.7.0 Integer R DEFVAL { 72 }
RFC1213-interfac
es ifNumber .1.3.6.1.2.1.2.1.0 Integer R DEFVAL { 1 }
pdmGeneral pdmGeneralProdu
ctName .1.3.6.1.4.1.2699.2.4.1.2.1.0 String R Dell 7700FullHD
pdmGeneral pdmGeneralSerial
Number .1.3.6.1.4.1.2699.2.4.1.2.2.0 String R Check PPID number (the latter 7 yards)
pdmGeneral pdmGereralAssetT
ag .1.3.6.1.4.1.2699.2.4.1.2.3.0 String R/W Range (0~63 byte)
pdmGeneral pdmGereralHardw
areVersion .1.3.6.1.4.1.2699.2.4.1.2.4.0 String R DEFVAL { " " }
pdmGeneral pdmGereralServic
ePerson .1.3.6.1.4.1.2699.2.4.1.2.5.0 String R/W Range (0~255 byte)
pdmGeneral pdmGeneralDevic
eAge .1.3.6.1.4.1.2699.2.4.1.2.6.0 Integer R Check display hours
pdmGeneral pdmGeneralPower
OnCount .1.3.6.1.4.1.2699.2.4.1.2.7.0 Integer R
pdmGeneral pdmGereralManuf
actureDate .1.3.6.1.4.1.2699.2.4.1.2.8.0 String R
pdmGeneral pdmGereralLangu
ageTagSNMP .1.3.6.1.4.1.2699.2.4.1.2.9.0 String R en-US
pdmGeneral pdmGeneralNtpSe
rverAddress .1.3.6.1.4.1.2699.2.4.1.2.10.0 String R DEFVAL { "" }
PdmCtlr pdmCtlrIndex .1.3.6.1.4.1.2699.2.4.1.3.1.1.1.1 Integer not-accessible 1
PdmCtlr pdmCtlrDescripti
on .1.3.6.1.4.1.2699.2.4.1.3.1.1.2.1 String R TI DDP3021
PdmCtlr pdmCtlrHardware
Version .1.3.6.1.4.1.2699.2.4.1.3.1.1.3.1 String R DEFVAL { "" }
PdmCtlr pdmCtlrFirmware
Version .1.3.6.1.4.1.2699.2.4.1.3.1.1.4.1 String R
PdmCtlr pdmCtlrFirmware
Upgradeable .1.3.6.1.4.1.2699.2.4.1.3.1.1.5.1 Integer R DEFVAL { 10 }
PdmCtlr pdmCtlrUpgradeI
nstructions .1.3.6.1.4.1.2699.2.4.1.3.1.1.6.1 String R DEFVAL { " " }
PdmCtlr pdmCtlrPostStatu
s .1.3.6.1.4.1.2699.2.4.1.3.1.1.7.1 Integer R DEFVAL{ 2 }
PdmCtlr pdmCtlrPostCode .1.3.6.1.4.1.2699.2.4.1.3.1.1.8.1 String R DEFVAL { " " }
PdmCtlr pdmCtlrPostStatu
sDefinitions .1.3.6.1.4.1.2699.2.4.1.3.1.1.9.1 String R DEFVAL { " " }
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.1 Integer not-accessible 1
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.2 Integer not-accessible 2
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.3 Integer not-accessible 3
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.4 Integer not-accessible 4
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.5 Integer not-accessible 5
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.6 Integer not-accessible 6
PdmPower pdmPowerImplem
entedState .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.1 Integer R 11
PdmPower pdmPowerImplem
entedState .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.2 Integer R 7
PdmPower pdmPowerImplem
entedState .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.3 Integer R 9
PdmPower pdmPowerImplem
entedState .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.4 Integer R 8
PdmPower pdmPowerImplem .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.5 Integer R 8

entedState
PdmPower pdmPowerImplem
entedState .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.6 Integer R 10
PdmPower pdmPowerDescrip
tion .1.3.6.1.4.1.2699.2.4.1.4.1.1.3.1 String R Power On.-11
PdmPower pdmPowerDescrip
tion .1.3.6.1.4.1.2699.2.4.1.4.1.1.3.2 String R Power Off.-7
PdmPower pdmPowerDescrip
tion .1.3.6.1.4.1.2699.2.4.1.4.1.1.3.3 String R Projector is cooling down.-9
PdmPower pdmPowerDescrip
tion .1.3.6.1.4.1.2699.2.4.1.4.1.1.3.4 String R Low power mode.-8
PdmPower pdmPowerDescrip
tion .1.3.6.1.4.1.2699.2.4.1.4.1.1.3.5 String R Low power mode.-8
PdmPower pdmPowerDescrip
tion .1.3.6.1.4.1.2699.2.4.1.4.1.1.3.6 String R Warming up.-10
PdmPower pdmPowerMfrDes
cription .1.3.6.1.4.1.2699.2.4.1.4.1.1.4.1 String R Full power on, all components active.
PdmPower pdmPowerMfrDes
cription .1.3.6.1.4.1.2699.2.4.1.4.1.1.4.2 String R
Standby State.
Only network electronics remain
on.
PdmPower pdmPowerMfrDes
cription .1.3.6.1.4.1.2699.2.4.1.4.1.1.4.3 String R Going down to standby mode.
PdmPower pdmPowerMfrDes
cription .1.3.6.1.4.1.2699.2.4.1.4.1.1.4.4 String R Lamp off
Fan on.
PdmPower pdmPowerMfrDes
cription .1.3.6.1.4.1.2699.2.4.1.4.1.1.4.5 String R Lamp off Fan on.
PdmPower pdmPowerMfrDes
cription .1.3.6.1.4.1.2699.2.4.1.4.1.1.4.6 String R Lamp warming up
Fan on.
PdmPower pdmPowerTargetSt
ate .1.3.6.1.4.1.2699.2.4.1.4.1.1.5.1 Integer R 7
PdmPower pdmPowerTargetSt
ate .1.3.6.1.4.1.2699.2.4.1.4.1.1.5.2 Integer R 11
PdmPower pdmPowerTargetSt
ate .1.3.6.1.4.1.2699.2.4.1.4.1.1.5.3 Integer R 3
PdmPower pdmPowerTargetSt
ate .1.3.6.1.4.1.2699.2.4.1.4.1.1.5.4 Integer R 7
PdmPower pdmPowerTargetSt
ate .1.3.6.1.4.1.2699.2.4.1.4.1.1.5.5 Integer R 11
PdmPower pdmPowerTargetSt
ate .1.3.6.1.4.1.2699.2.4.1.4.1.1.5.6 Integer R 3
PdmPower pdmPowerTransiti
onTime .1.3.6.1.4.1.2699.2.4.1.4.1.1.6.1 Integer R 120
PdmPower pdmPowerTransiti
onTime .1.3.6.1.4.1.2699.2.4.1.4.1.1.6.2 Integer R 30
PdmPower pdmPowerTransiti
onTime .1.3.6.1.4.1.2699.2.4.1.4.1.1.6.3 Integer R 0
PdmPower pdmPowerTransiti
onTime .1.3.6.1.4.1.2699.2.4.1.4.1.1.6.4 Integer R 120
PdmPower pdmPowerTransiti
onTime .1.3.6.1.4.1.2699.2.4.1.4.1.1.6.5 Integer R 20
PdmPower pdmPowerTransiti
onTime .1.3.6.1.4.1.2699.2.4.1.4.1.1.6.6 Integer R 0
PdmPower pdmPowerComm
Available .1.3.6.1.4.1.2699.2.4.1.4.1.1.7.1 Integer R 3
PdmPower pdmPowerComm
Available .1.3.6.1.4.1.2699.2.4.1.4.1.1.7.2 Integer R 4
PdmPower pdmPowerComm
Available .1.3.6.1.4.1.2699.2.4.1.4.1.1.7.3 Integer R 4
PdmPower pdmPowerComm
Available .1.3.6.1.4.1.2699.2.4.1.4.1.1.7.4 Integer R 3
PdmPower pdmPowerComm
Available .1.3.6.1.4.1.2699.2.4.1.4.1.1.7.5 Integer R 3
PdmPower pdmPowerComm
Available .1.3.6.1.4.1.2699.2.4.1.4.1.1.7.6 Integer R 4
PdmPower pdmPowerCurrent
State .1.3.6.1.4.1.2699.2.4.1.4.2.0 Integer R
PdmPower pdmPowerRequest
edState .1.3.6.1.4.1.2699.2.4.1.4.3.0 Integer R/W
pdmDisplayCap pdmDisplayCapRe
solutionH .1.3.6.1.4.1.2699.2.4.1.5.1.0 Integer R 1600
pdmDisplayCap pdmDisplayCapRe
solutionV .1.3.6.1.4.1.2699.2.4.1.5.2.0 Integer R 1200
pdmDisplayCap pdmDisplayCapPh
ysSizeH .1.3.6.1.4.1.2699.2.4.1.5.3.0 String R DEFVAL { "" }
pdmDisplayCap pdmDisplayCapPh .1.3.6.1.4.1.2699.2.4.1.5.4.0 String R DEFVAL { "" }

ysSizeV
pdmDisplaySet pdmDisplaySetInd
ex .1.3.6.1.4.1.2699.2.4.1.6.1.1.1.1 Integer not-accessible 1
pdmDisplaySet pdmDisplaySetAff
ectsAll .1.3.6.1.4.1.2699.2.4.1.6.1.1.2.1 Integer R DEFVAL { 1 }
pdmDisplaySet pdmDisplaySetInp
utSource .1.3.6.1.4.1.2699.2.4.1.6.1.1.3.1 Integer
1. VGA_A
2. VGA_B
3. S-Video
4. Composite Video
5. HDMI
pdmDisplaySet pdmDisplaySetBri
ghtness .1.3.6.1.4.1.2699.2.4.1.6.1.1.4.1 Integer R/W
pdmDisplaySet pdmDisplaySetBrt
Max .1.3.6.1.4.1.2699.2.4.1.6.1.1.5.1 Integer R 100
pdmDisplaySet pdmDisplaySetCo
ntrast .1.3.6.1.4.1.2699.2.4.1.6.1.1.6.1 Integer R/W
pdmDisplaySet pdmDisplaySetCo
nMax .1.3.6.1.4.1.2699.2.4.1.6.1.1.7.1 Integer R 100
pdmDisplaySet pdmDisplaySetRe
d .1.3.6.1.4.1.2699.2.4.1.6.1.1.8.1 Integer R DEFVAL { 0 }
pdmDisplaySet pdmDisplaySetGr
een .1.3.6.1.4.1.2699.2.4.1.6.1.1.9.1 Integer R DEFVAL { 0 }
pdmDisplaySet pdmDisplaySetBlu
e .1.3.6.1.4.1.2699.2.4.1.6.1.1.10.1 Integer R DEFVAL { 0 }
pdmDisplaySet pdmDisplaySetRG
BMax .1.3.6.1.4.1.2699.2.4.1.6.1.1.11.1 Integer R DEFVAL { 100 }
pdmDisplaySet pdmDisplaySetSat
uration .1.3.6.1.4.1.2699.2.4.1.6.1.1.12.1 Integer R/W
pdmDisplaySet pdmDisplaySetSat
Max .1.3.6.1.4.1.2699.2.4.1.6.1.1.13.1 Integer R 100
pdmDisplaySet pdmDisplaySetHu
e (Tint) .1.3.6.1.4.1.2699.2.4.1.6.1.1.14.1 Integer R/W
pdmDisplaySet pdmDisplaySetHu
eMax .1.3.6.1.4.1.2699.2.4.1.6.1.1.15.1 Integer R 100
pdmDisplaySet pdmDisplaySetSh
arpness .1.3.6.1.4.1.2699.2.4.1.6.1.1.16.1 Integer R/W
pdmDisplaySet pdmDisplaySetSh
pMax .1.3.6.1.4.1.2699.2.4.1.6.1.1.17.1 Integer R 31
pdmDisplaySet pdmDisplaySetCol
orTemp .1.3.6.1.4.1.2699.2.4.1.6.1.1.18.1 Integer R/W
3. Custom
4. Low
5. Mid
6. High
pdmDisplaySet pdmDisplaySetRe
dClrTmp .1.3.6.1.4.1.2699.2.4.1.6.1.1.19.1 Integer R/W DEFVAL { 50 }
pdmDisplaySet pdmDisplaySetGr
eenClrTmp .1.3.6.1.4.1.2699.2.4.1.6.1.1.20.1 Integer R/W DEFVAL { 50 }
pdmDisplaySet pdmDisplaySetBlu
eClrTmp .1.3.6.1.4.1.2699.2.4.1.6.1.1.21.1 Integer R/W DEFVAL { 50 }
pdmDisplaySet pdmDisplaySetClr
TmpMax .1.3.6.1.4.1.2699.2.4.1.6.1.1.22.1 Integer R DEFVAL { 0 }
pdmDisplaySet pdmDisplaySetVid
eoMute .1.3.6.1.4.1.2699.2.4.1.6.2.0 Integer R/W
Blank Screen
1. Muted
2. notMuted
pdmDisplaySet pdmDisplaySetDis
playMode .1.3.6.1.4.1.2699.2.4.1.6.3.0 Integer R/W
pdmLightSource pdmLightSourceIn
dex .1.3.6.1.4.1.2699.2.4.1.7.1.1.1.1 Integer not-accessible 1
pdmLightSource pdmLightSourceD
escription .1.3.6.1.4.1.2699.2.4.1.7.1.1.2.1 String R Philips E21.9 400W ARC1.3
pdmLightSource pdmLightSourceSt
atus .1.3.6.1.4.1.2699.2.4.1.7.1.1.3.1 Integer R Standby mode->DEFVAL { 2 } Okay(3) ; Failed(4)
pdmLightSource pdmLightSourceE
coSetting .1.3.6.1.4.1.2699.2.4.1.7.1.1.4.1 Integer R/W
ECO Mode
4. Off -> Normal
5. On -> Low
pdmLightSource pdmLightSourceA
ge .1.3.6.1.4.1.2699.2.4.1.7.1.1.5.1 Integer R
pdmLightSource pdmLightSourceE
rrorCounter .1.3.6.1.4.1.2699.2.4.1.7.1.1.6.1 Integer R
pdmLightSource pdmLightSourceR
eset .1.3.6.1.4.1.2699.2.4.1.7.1.1.7.1 Integer R/W
DEFVAL { 1 }
resetFRU(3) &
resetCountersOnly(4)-->lamp
hour & Error Counter reset to0
pdmLightSource pdmLightSourceR
eplacementCount .1.3.6.1.4.1.2699.2.4.1.7.1.1.8.1 String R DEFVAL { "" }
pdmLightSource pdmLightSourceR .1.3.6.1.4.1.2699.2.4.1.7.1.1.9.1 String R DEFVAL

eplacementTime { "1980-01-01T00:00:00" }
pdmLightSource pdmLightSourceR
eplacemenInterval .1.3.6.1.4.1.2699.2.4.1.7.1.1.10.1 Integer R DEFVAL { 0 }
pdmLightSource pdmLightSourceR
eplacementPN .1.3.6.1.4.1.2699.2.4.1.7.1.1.11.1 String R DEFVAL { "" }
pdmFan pdmFanIndex .1.3.6.1.4.1.2699.2.4.1.8.1.1.1.1 Integer not-accessible 1
pdmFan pdmFanDescriptio
n .1.3.6.1.4.1.2699.2.4.1.8.1.1.2.1 String R System fan
pdmFan pdmFanStatus .1.3.6.1.4.1.2699.2.4.1.8.1.1.3.1 Integer R Standby mode->DEFVAL { 2 }
okay(3) ; warning(4)
pdmFan pdmFanSpeed .1.3.6.1.4.1.2699.2.4.1.8.1.1.4.1 Integer R DEFVAL { 0 }
pdmFan pdmFanErrorCou
nter .1.3.6.1.4.1.2699.2.4.1.8.1.1.5.1 Integer R
pdmFan pdmFanReset .1.3.6.1.4.1.2699.2.4.1.8.1.1.6.1 Integer R/W
DEFVAL { 1 }
resetFRU(3) &
resetCountersOnly(4)-->Error
Counter reset to0
pdmFan pdmFanReplacem
entCount .1.3.6.1.4.1.2699.2.4.1.8.1.1.7.1 String R DEFVAL { "" }
pdmFan pdmFanReplacem
entTime .1.3.6.1.4.1.2699.2.4.1.8.1.1.8.1 String R DEFVAL { "1980-01-01T00:00:00" }
pdmFan pdmFanReplacem
enInterval .1.3.6.1.4.1.2699.2.4.1.8.1.1.9.1 Integer R DEFVAL { 0 }
pdmFan pdmFanReplacem
entPartNumber .1.3.6.1.4.1.2699.2.4.1.8.1.1.10.1 String R DEFVAL { "" }
pdmTempSensor pdmTempSensorI
ndex .1.3.6.1.4.1.2699.2.4.1.10.1.1.1.1 Integer not-accessible 1
pdmTempSensor pdmTempSensorD
escription .1.3.6.1.4.1.2699.2.4.1.10.1.1.2.1 String R Measure system internal temperature.
pdmTempSensor pdmTempSensorS
tatus .1.3.6.1.4.1.2699.2.4.1.10.1.1.3.1 Integer R DEFVAL { 2 }
pdmTempSensor pdmTempSensorT
emp .1.3.6.1.4.1.2699.2.4.1.10.1.1.4.1 Integer R
Describes the temperature being
measured by the thermal sensor
in 10ths of a degree C.
pdmTempSensor pdmTempSensorE
rrorCounter .1.3.6.1.4.1.2699.2.4.1.10.1.1.5.1 Integer R
pdmTempSensor pdmTempSensorR
eset .1.3.6.1.4.1.2699.2.4.1.10.1.1.6.1 Integer R/W
DEFVAL { 1 }
resetFRU(3) &
resetCountersOnly(4)-->Error
Counter reset to0
pdmTempSensor pdmTempSensorR
eplaceCount .1.3.6.1.4.1.2699.2.4.1.10.1.1.7.1 String R DEFVAL { "" }
pdmTempSensor pdmTempSensorR
eplaceTime .1.3.6.1.4.1.2699.2.4.1.10.1.1.8.1 String R DEFVAL { "1980-01-01T00:00:00" }
pdmTempSensor pdmTempSensorR
eplaceInterval .1.3.6.1.4.1.2699.2.4.1.10.1.1.9.1 Integer R DEFVAL { 0 }
pdmTempSensor pdmTempSensorR
eplacePN .1.3.6.1.4.1.2699.2.4.1.10.1.1.10.1 String R DEFVAL { "" }
pdmTempSwitch pdmTempSwitchI
ndex .1.3.6.1.4.1.2699.2.4.1.11.1.1.1.1 Integer not-accessible 1
pdmTempSwitch pdmTempSwitch
Description .1.3.6.1.4.1.2699.2.4.1.11.1.1.2.1 String R Avertronics INC.
pdmTempSwitch pdmTempSwitchS
tatus .1.3.6.1.4.1.2699.2.4.1.11.1.1.3.1 Integer R Standby mode->DEFVAL { 2 }
okay(3) ; fail(5)
pdmTempSwitch pdmTempSwitchE
rrorCounter .1.3.6.1.4.1.2699.2.4.1.11.1.1.4.1 Integer R
pdmTempSwitch pdmTempSwitchR
eset .1.3.6.1.4.1.2699.2.4.1.11.1.1.5.1 Integer R/W
DEFVAL { 1 }
resetFRU(3) &
resetCountersOnly(4)-->Error
Counter reset to0
pdmTempSwitch pdmTempSwitchR
eplaceCount .1.3.6.1.4.1.2699.2.4.1.11.1.1.6.1 String R DEFVAL { "" }
pdmTempSwitch pdmTempSwitchR
eplaceTime .1.3.6.1.4.1.2699.2.4.1.11.1.1.7.1 String R DEFVAL
{ "1980-01-01T00:00:00" }
pdmTempSwitch pdmTempSwitchR
eplacePN .1.3.6.1.4.1.2699.2.4.1.11.1.1.8.1 String R DEFVAL { "" }
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.1 Integer not-accessible 1
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.2 Integer not-accessible 2
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.3 Integer not-accessible 3
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.4 Integer not-accessible 4
pdmConnector pdmConnectorInd .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.5 Integer not-accessible 5

ex
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.6 Integer not-accessible 6
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.7 Integer not-accessible 7
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.8 Integer not-accessible 8
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.9 Integer not-accessible 9
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.10 Integer not-accessible 10
pdmConnector pdmConnectorInd
ex .1.3.6.1.4.1.2699.2.4.1.12.1.1.1.11 Integer not-accessible 11
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.1 String R VGA-A
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.2 String R VGA-B
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.3 String R S-Video
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.4 String R Composite Video
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.5 String R HDMI-A
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.6 String R Wireless Display
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.7 String R USB Display
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.8 String R USB Viewer
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.9 String R HDMI-B
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.10 String R Component
pdmConnector pdmConnectorDe
scription .1.3.6.1.4.1.2699.2.4.1.12.1.1.2.11 String R Audio
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.1 Integer R 3
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.2 Integer R 3
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.3 Integer R 10
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.4 Integer R 13
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.5 Integer R 6
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.6 Integer R 12
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.7 Integer R 12
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.8 Integer R 12
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.9 Integer R 6
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.10 Integer R 11
pdmConnector pdmConnectorTyp
e .1.3.6.1.4.1.2699.2.4.1.12.1.1.3.11 Integer R 16
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.1 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.2 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.3 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.4 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.5 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.6 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.7 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.8 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.9 Integer R DEFVAL { 1 }

pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.10 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorEn
abled .1.3.6.1.4.1.2699.2.4.1.12.1.1.4.11 Integer R DEFVAL { 1 }
pdmConnector pdmConnectorAu
dioAdjust.1 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.1 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.2 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.2 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.3 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.3 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.4 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.4 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.5 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.5 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.6 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.6 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.7 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.7 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.8 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.8 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.9 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.9 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.10 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.10 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioAdjust.11 .1.3.6.1.4.1.2699.2.4.1.12.1.1.5.11 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.1 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.1 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.2 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.2 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.3 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.3 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.4 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.4 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.5 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.5 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.6 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.6 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.7 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.7 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.8 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.8 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.9 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.9 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.10 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.10 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoAdjust.11 .1.3.6.1.4.1.2699.2.4.1.12.1.1.6.11 Integer R DEFVAL { 0 }
pdmConnector pdmConnectorVid
eoCurrInput .1.3.6.1.4.1.2699.2.4.1.12.2.0 Integer R/W DEFVAL { 0 }
pdmConnector pdmConnectorAu
dioCurrInput .1.3.6.1.4.1.2699.2.4.1.12.3.0 Integer R/W DEFVAL { 0 }
pdmInterlockTable pdmInterlockInde
x .1.3.6.1.4.1.2699.2.4.1.13.1.1.1.1 Integer not-accessible 1
pdmInterlockTable pdmInterlockDesc
ription .1.3.6.1.4.1.2699.2.4.1.13.1.1.2.1 String R DEFVAL { "" }
pdmInterlockTable pdmInterlockStatu
s .1.3.6.1.4.1.2699.2.4.1.13.1.1.3.1 Integer R DEFVAL { 3 }
pdmLocaleCharset pdmLocaleCharset
Index .1.3.6.1.4.1.2699.2.4.1.14.1.1.1.1 Integer not-accessible 1
pdmLocaleCharset pdmLocaleCharset
Enum .1.3.6.1.4.1.2699.2.4.1.14.1.1.2.1 Integer R DEFVAL { 4 }
pdmLocaleCharset pdmLocaleCharset
EnumEWS .1.3.6.1.4.1.2699.2.4.1.14.2.0 Integer R DEFVAL { 4 }
pdmLocaleLangua
ge
pdmLocaleLangua
geIndex .1.3.6.1.4.1.2699.2.4.1.15.1.1.1.1 Integer not-accessible 1
pdmLocaleLangua
ge
pdmLocaleLangua
geTag .1.3.6.1.4.1.2699.2.4.1.15.1.1.2.1 String R DEFVAL { en-US }
pdmLocaleLangua
ge
pdmLocaleLangua
geTagEWS .1.3.6.1.4.1.2699.2.4.1.15.2.0 String R DEFVAL { en-US }
pdmLocaleLangua
ge
pdmLocaleLangua
geTagOSD .1.3.6.1.4.1.2699.2.4.1.15.3.0 String R DEFVAL { en-US }
pdmLocaleLangua
ge
pdmLocaleLangua
geTagWSM .1.3.6.1.4.1.2699.2.4.1.15.4.0 String R DEFVAL { en-US }
pdmAudio pdmAudioDescrip .1.3.6.1.4.1.2699.2.4.1.16.1.0 String R DEFVAL { "" }

tion
pdmAudio pdmAudioVolume .1.3.6.1.4.1.2699.2.4.1.16.2.0 Integer R/W
pdmAudio pdmAudioMute .1.3.6.1.4.1.2699.2.4.1.16.3.0 Integer R/W
pdmAudio pdmAudioTreble .1.3.6.1.4.1.2699.2.4.1.16.4.0 Integer R DEFVAL { 0 }
pdmAudio pdmAudioBass .1.3.6.1.4.1.2699.2.4.1.16.5.0 Integer R DEFVAL { 0 }
pdmAudio pdmAudioBalance .1.3.6.1.4.1.2699.2.4.1.16.6.0 Integer R DEFVAL { 0 }
pdmAlert pdmAlertIndex 1.3.6.1.4.1.2699.2.4.1.18.1.1.1.1 Integer not-accessible 1
pdmAlert pdmAlertGroupTy
pe 1.3.6.1.4.1.2699.2.4.1.18.1.1.2.1 String R See Note 1
pdmAlert pdmAlertGroupId 1.3.6.1.4.1.2699.2.4.1.18.1.1.3.1 String R See Note 1
pdmAlert pdmAlertCode 1.3.6.1.4.1.2699.2.4.1.18.1.1.4.1 String R DEFVAL { "" }
pdmAlert pdmAlertDescripti
on 1.3.6.1.4.1.2699.2.4.1.18.1.1.5.1 String R
Alert's condition has lamp Fail,
Lamp hours running out,
Projector Overheating, Lamp
Overheating and Fan Error.
pdmAlert pdmAlertSeverityL
evel 1.3.6.1.4.1.2699.2.4.1.18.1.1.6.1 Integer R See Note 1
pdmAlert pdmAlertTraining
Level 1.3.6.1.4.1.2699.2.4.1.18.1.1.7.1 Integer R DEFVAL { 2 }
pdmAlert pdmAlertDateTim
e 1.3.6.1.4.1.2699.2.4.1.18.1.1.8.1 String R DEFVAL
{ "1980-01-01T00:00:00" }
pdmAlert pdmAlertPowerOn
Count 1.3.6.1.4.1.2699.2.4.1.18.1.1.9.1 String R DEFVAL { "" }
pdmAlert pdmAlertSysUpti
me 1.3.6.1.4.1.2699.2.4.1.18.1.1.10.1 String R DEFVAL { "" }
pdmAlert pdmAlertCriticalA
lertsCount 1.3.6.1.4.1.2699.2.4.1.18.2.0 Integer R
pdmAlert pdmAlertAllAlerts
Count 1.3.6.1.4.1.2699.2.4.1.18.3.0 Integer R
Note 1:
a) If there is no any current alert, all of OID in alert table will respond default value.
pdmAlertGroupType =” “
pdmAlertGroupID=0
pdmAlertSeverity = other (1)
The reset Object will respond default.
b) If there is FAN alert happen, the tables is shown below.
pdmAlertGroupType =” Fan”
pdmAlertGroupID= “FanError”
pdmAlertSeverity = Critical (3)
TherestObjectwillresponddefault.
c) If there is Lamp fail alert happen, the tables is shown below.
pdmAlertGroupType = “Lamp”
pdmAlertGroupID= LampFail
pdmAlertSeverity = Critical (3)
TherestObjectwillresponddefault.
d) If there is Lamp hours running out alert happen, the tables is shown below.
pdmAlertGroupType = “Lamp”
pdmAlertGroupID= Lamp hours running out
pdmAlertSeverity=warning(4)
TherestObjectwillresponddefault.
e) If there is Projector Over-heating alert, the tables is shown below.
pdmAlertGroupType = “ThermalSensor”
pdmAlertGroupID= “Projector Overheating”
pdmAlertSeverity=warning(4)
TherestObjectwillresponddefault.
f) If there is Lamp Over-heating alert, the tables is shown below.
pdmAlertGroupType = “ThermalSwitch”
pdmAlertGroupID= “Lamp Overheating”
pdmAlertSeverity = Critical (3)
TherestObjectwillresponddefault.
Information in this document is subject to change without notice.
© 2012 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or
their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

March 2012 Rev. A00
