Dell PowerEdge
C6145
Getting Started
With Your System

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
Information in this publication is subject to change without notice.
© 2011 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission
of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, and PowerEdge™ are trademarks of
Dell Inc. AMD®is a registered trademark and AMD Opteron™ is a trademark of
Advanced Micro Devices, Inc. Red Hat Enterprise Linux®and Enterprise Linux®are
registered trademarks of Red Hat, Inc. in the United States and/or other countries.
Novell®is a registered trademark and SUSE™ is a trademark of Novell Inc. in the United
States and other countries. Citrix®and XenServer®are either registered trademarks or
trademarks of Citrix Systems, Inc. in the United States and/or other countries. VMware®
is a registered trademarks or trademarks of VMWare, Inc. in the United States or other
countries.
Other trademarks and trade names may be used in this publication to refer to either the
entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Regulatory Model B05S
January 2011 P/N HR6G0 Rev. A00

Getting Started With Your System | 5
CAUTION: Restricted Access Location
This server is intended for installation only in restricted access locations as
defined in Cl. 1.2.7.3 of IEC 60950-1: 2001 where both these conditions apply:
 Access can only be gained by service persons or by users who have been
instructed about the reasons for the restrictions applied to the location and
about any precautions that shall be taken.
 Access is through the use of a tool or lock and key, or other means of
security, and is controlled by the authority responsible for the location.
Installation and Configuration
WARNING: Before performing the following procedure, review and follow the
safety instructions that came with the system.
Unpacking the System
Unpack your system and identify each item.
Installing the Tool-Less Rail Solution
WARNING: Whenever you need to lift the system, get others to assist you.
To avoid injury, do not attempt to lift the system by yourself.
WARNING: The system is not fixed to the rack or mounted on the rails. To
avoid personal injury or damage to the system, you must adequately
support the system during installation and removal.
WARNING: To avoid a potential electrical shock hazard, a third wire safety
grounding conductor is necessary for the rack installation. The rack
equipment must provide sufficient airflow to the system to maintain proper
cooling.
CAUTION: When installing rails in a square-hole rack it is important to
ensure that the square peg slides through the square holes.

Getting Started With Your System | 6
1 Pull on the latch release buttons on the end piece midpoints to open
the rail latches.
2 Align the end pieces of the rails on the vertical rack flanges to seat
the pegs in the bottom hole of the first U and the top hole of the
second U. Engage the back end of the rails until the latches lock in
place.
NOTE: The rails can be used in both square-hole (item 1 in the following figure)
and round-hole racks (item 2 in the following figure).
3 Repeat Step 1 and Step 2 to position and seat the front end pieces on
the vertical flanges.
NOTE: To remove the rails, pull on the latch release button on the end piece
midpoint and unseat each rail.
4 On each vertical rack flange on the rear, put two screw bases into the
two square holes right above the rail.
5 Install the chassis stabilizer shipping brackets (optional) on the rear
rack flanges and simultaneously fasten the screws.
NOTE: To transport systems already installed in the rack, ensure that the two
chassis stabilizer shipping brackets (optional) are in place.

Getting Started With Your System | 7
6 Slide the system into the rack.
7 Tighten the thumbscrews to secure the ears of the system to the front
of the rack flanges.

Getting Started With Your System | 8
Optional-Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable to
plug into each connector. Be sure to tighten the screws (if any) on the monitor’s
cable connector.

Getting Started With Your System | 9
Connecting the Power Cable(s)
Connect the system’s power cable(s) to the system and, if a monitor is used,
connect the monitor’s power cable to the monitor. Plug the other end of the
power cables into a grounded electrical outlet or a separate power source such as
an uninterrupted power supply or a power distribution unit.

Getting Started With Your System | 10
Turning on the System
Press the power button(s) either on the front or back of the system and on the
monitor. The power indicators should light.

Getting Started With Your System | 11
Complete the Operating System Setup
To install an operating system for the first time, see the installation and
configuration documentation for your operating system. Be sure the operating
system is installed before installing hardware or software not purchased with the
system.
Supported Operating Systems
 Microsoft Windows HPC Server 2008 R2 (64-bit)
 Microsoft Windows Server 2008 Core R2 (64-bit)
 Microsoft Windows Server 2008 R2 Hyper-V
 Microsoft Windows Server 2008 R2 Enterprise (64-bit)
 Red Hat Enterprise Linux 5.5 (64-bit)
 Red Hat Enterprise Linux 6.0 (Certification only)
 SUSE Linux Enterprise Server 11 SP1 (64-bit)
 VMware ESX Server 4.1 U1 and ESXi Embedded
 Citrix XenServer 5.6 Feature Pack 1
NOTE: For the latest information on supported operating systems, see
support.dell.com .

Getting Started With Your System | 12
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with your
system. Warranty information may be included within this document or as a
separate document.
The
Hardware Owner’s Manual provides information about system features and
describes how to troubleshoot the system and install or replace system
components. This document is available at
support.dell.com/manuals .
Dell systems management application documentation provides information
about installing and using the systems management software. This document is
available online at
support.dell.com/manuals .
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.
Información de la NOM (sólo para México)
La información que se proporciona a continuación aparece en el dispositivo
descrito en este documento, en cumplimiento de los requisitos de la Norma
Oficial Mexicana (NOM):
Importador Dell Inc. de México, S.A. de C.V.
Paseo de la Reforma 2620-11° Piso
Col. Lomas Atlas
11950 México, D.F.
Número de modelo B05S
Voltaje de alimentación 100-240 V CA con alimentación de 1 100 W
200-240 V CA con alimentación de 1 400 W
Frecuencia 50/60 Hz
Consumo eléctrico De 12 a 6,7 A con alimentación de 1 100 W
8,6 A con alimentación de 1 400 W

Getting Started With Your System | 13
Technical Specifications
Processor (Per System Board)
Processor type Four AMD Opteron 6100 Series
processors
Expansion Bus (Per System Board)
Bus type PCI Express Generation 2
Expansion slots
PCIe One x16, low profile
Two x16, half-length/half-height
Daughter card PCIe One x16, Mezzanine slot
Memory (Per System Board)
Architecture 32 x DDR3 1066/1333 MHz RDIMM
or UDIMM
Memory module sockets 32 x DDR3 DIMM sockets
Memory module capacities 2 GB, 4 GB, 8 GB, or 16 GB
Minimum RAM 64 GB
Maximum RAM 512 GB
Drives
Hard drives Up to twelve 3.5-inch, hot-swappable
SAS/SATA drives or up to twenty four
2.5-inch, hot-swappable
SAS/SATA/SSD drives
NOTE: SAS hard drives are supported by add-on
card.
Connectors (Per System Board)
Back
NIC Two RJ-45 (10/100/1000 Mbps
Ethernet)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant

Getting Started With Your System | 14
Video 15-pin D-Sub VGA
Management port Dedicated Ethernet port for remote
management access
V
ideo (Per System Board)
Video type On-board AST2050 video controller
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage 1023 W low line/1100 W high line
Voltage 100-240 V CA, 50-60 Hz, maximum
input current: 12.0 Amps
Heat dissipation 4217.063 BTU/hr maximum
Wattage
1400 W
Voltage 200-240 V CA, 50-60 Hz, maximum
input current: 8.6 Amps
Heat dissipation 5724 BTU/hr maximum
Maximum inrush current Initial In-rush Current cannot exceed 55
Amps (peak). Secondary In-rush
Current cannot exceed 35 Amps (peak).
Battery (per system board)
System battery
CR 2032 3.0-V lithium ion coin cell
RAID battery (optional) 3.7-V lithium ion battery pack
Physical
Height 8.76 cm (3.45 in)
Width 44.8 cm (17.6 in)
Depth 79.0 cm (31.1 in)
Weight (maximum
configuration)
42 kg (92.61 lb)
Weight (empty) 16.5 kg (36.38 lb)

Getting Started With Your System | 15
Environmental
NOTE: For additional information about environmental measurements for specific system
configurations, see
www.dell.com/environmental_datasheets .
Temperature
Operating 10° to 35°C (50° to 95°F) with a
maximum temperature gradation of
10°C per hour
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1°F/550 ft.
Storage –40° to 65°C (–40° to 149°F) with a
maximum temperature gradation of
20°C per hour
Relative humidity
Operating 20% to 80% (noncondensing) with a
maximum humidity gradation of 10%
per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 Grms at 5–350 Hz
Storage 1.88 Grms at 10–500 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis
(one pulse on each side of the system)
of 31 G for 2.6 ms in the operational
orientation
Storage Six consecutively executed shock
pulses in the positive and negative x, y,
and z axes (one pulse on each side of
the system) of 71 G for up to 2 ms;
Six consecutively executed shock
pulses in the positive and negative x, y,
and z axes (one pulse on each side of
the system) of 22 G faired square wave
pulse with velocity change at 200
inches/second (508 centimeters/second)

Getting Started With Your System | 16
Environmental
Altitude
Operating –16 to 3,048 m (–50 to 10,000 ft)
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1°F/550 ft.
Storage –16 to 10,600 m (–50 to 35,000 ft)
Airborne contaminant level
Class G2 or lower as defined by
ISA-S71.04-1985

Dell PowerEdge
C6145
系统使用入门

注、小心和警告
注： "注"表示可以帮助您更好地使用计算机的重要信息。
小心："小心"表示如果不遵循说明，就有可能损坏硬件或导致数据丢失。
警告："警告"表示可能会导致财产损失、人身伤害甚至死亡。
______________
本出版物中的信息如有更改，恕不另行通知。
© 2011 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书面许可，严禁以任何形式复制这些材料。
本文中使用的商标： Dell™ 、 DELL 徽标和 PowerEdge™ 是 Dell Inc. 的商
标。
AMD
®
和 AMD Opteron™ 是 Advanced Micro Devices, Inc. 的注册商标
和商标。
Red Hat Enterprise Linux
®
和 Enterprise Linux
®
是 Red Hat, Inc. 在美
国和/或其它国家/地区的注册商标。
Novell
®
和 SUSE™ 是 Novell Inc. 在美
国和其它国家/地区的注册商标和商标。
Citrix
®
和 XenServer
®
是 Citrix
Systems, Inc.
在美国和/或其它国家/地区的注册商标或商标。 VMware
®
是
VMWare, Inc.
在美国或其它国家/地区的注册商标或商标。
本出版物中述及的其它商标和商品名称是指拥有相应商标和商品名称的公司
或其产品。
Dell Inc. 对本公司的商标和产品名称之外的其它商标和产品名称
不拥有任何专有权。
管制型号 B05S
2011 年1 月P/N HR6G0 Rev. A00

系统使用入门 | 19
小心：受限访问位置
此服务器仅适用于安装在 IEC 60950-1:2001 的 Cl. 1.2.7.3 中定义的受限访
问位置，并遵循以下两个条件 :
 仅维修人员或对该位置施加限制的理由以及应当采取的防备措施已
完全领会的用户，方可对此服务器进行访问。
 访问是通过使用工具或锁和钥匙，或其它安全手段来实现，并且由
负责该位置的管理机构来控制。
安装和配置
警告：执行下列步骤之前，请阅读并遵循系统随附的安全说明。
打开系统包装
打开系统包装并识别每项物品。
安装免工具拆装导轨解决方案
警告：需要提起系统时，请让别人帮您。为避免受伤，请勿尝试独自提起系
统。
警告：系统未固定到机架上或未安装在导轨上。为避免人身伤害或损坏系统，
必须在安装和拆卸过程中对系统进行充分支撑。
警告：为避免可能的电击伤害，机架安装需要第三根导线安全接地连接器。机
架设备必须为系统提供足够的气流以保持适当冷却。
小心：在方孔机架中安装导轨时，请确保方形连接销滑过方孔。

系统使用入门 | 20
1 拔起尾段正中央的闩锁释放按钮以打开导轨闩锁。
2 对齐垂直机架边缘上的导轨尾段，将连接销按入第一个 U 底部
的孔和第二个
U 顶部的孔中。接合导轨后端直到闩锁锁定到位。
注： 导轨可同时用于方孔（下图中的项目 1 ）和圆孔机架
（下图中的项目 2 ）。
3 重复步骤 1 和步骤 2 定位前端段并将其固定在垂直边缘。
注： 要卸下导轨，请拔起尾段正中央的闩锁释放按钮并取出每个导轨。
4 在背面的每个垂直机架边缘，将两个螺钉座放入导轨正上方的
两个方孔。
5 在背面机架边缘安装运输时稳固机箱的支架（可选）并同时拧
紧螺钉。
注： 要运输已经安装在机架上的系统，请确保两个运输时稳固机箱的支架
到位（可选）。
正面视图
后视图
