Dell PS-M4110 User manual

Dell EqualLogic PS-M4110 Blade Storage Arrays
Hardware Owner's Manual
Version 1.0

© Copyright 2012 Dell Inc. All rights reserved.
Dell™ and EqualLogic® are trademarks of Dell Inc.
All trademarks and registered trademarks mentioned herein are the property of their respective owners.
Information in this document is subject to change without notice.
Reproduction in any manner whatsoever without the written permission of Dell is strictly forbidden.
Published: July 2012
Part Number: 110-6106-EN-R1

Table of Contents
Preface vi
1 Getting Started 1
About the PS-M4110 Array 1
Front Panel Features and Indicators 2
Shutting Down and Restarting the Array 4
Protecting Hardware 6
Array Networking Considerations 6
Networking Information Resources 6
Network Requirements 7
Network Recommendations 9
Optional Considerations 10
2 Handling the Array 11
About Handling the Array 11
Opening the Array Drawer 12
Closing the Array Drawer 14
Removing the Array from the M1000e Chassis 15
Removing the Blade Drawer From the Upper Chassis 16
Removing the Array Drawer from a Lower Slot 18
Inserting the Array into the M1000e Chassis 19
Install the Array in the M1000e 20
If installing the array into a top slot in the M1000e chassis 21
If installing the array into a bottom slot in the M1000e chassis 21
Verify Proper Installation 24
Releasing the Array Inner Drawer Safety Latch 25
3 Maintaining Drives 27
About Drives 27
About Mixed-Drive Arrays (Rotational and Solid State) 27
Identifying Failed Drives 27
Interpreting Drive LEDs 28
Array Behavior When a Drive Fails 28
Drive Handling Requirements 29
Replacing Drives 29
Drive Installation Guidelines and Restrictions 29
Removing a Drive 30
Installing a Drive 32
4 Maintaining Control Modules 35
Control Module Description 36
About Control Module Configurations 36
Interpreting Control Module LEDs 37
Identifying Control Module Failures 37
Understanding Failover Behavior 38
Maintaining Control Module Firmware 38
Control Module Handling Requirements 39
Replacing a Control Module 39
Control Module Replacement Procedures 40
Removing a Control Module 41
Installing a Control Module 44
Replacing the microSD Card 46
microSD Card Replacement Procedure 46
Removing the microSD Card 47
iv

Inserting the microSD Card 48
5 Troubleshooting Your Array 49
Obtaining Technical Support and Customer Service 49
Express Service Tag Information 49
Obtaining Component Diagnostics 49
Troubleshooting Array Startup Failure 50
Troubleshooting Loss of Communication 50
Troubleshooting Array Connections 50
Troubleshooting External Connections 50
Troubleshooting Control Modules 51
Troubleshooting Array Drives 51
Index 53
v
PS-M4110 Hardware Owner's Manual Table of Contents

Preface
Dell EqualLogic PS Series arrays optimize resources by automating capacity, performance, and network load
balancing. Additionally, PS Series arrays offer all-inclusive array management software and firmware updates.
Dell EqualLogic FS Series appliances, combined with PS Series arrays, offer a high performance, high
availability, scalable NAS solution.
Audience
The information in this guide is intended for hardware administrators. Administrators are not required to have
extensive network or storage system experience, however, it may be helpful to understand:
• Basic networking concepts
• Current network environment
• User disk storage requirements
• RAID configurations
• Disk storage management
Note: This manual provides examples of using PS Series arrays in some common network configurations.
However, detailed information about setting up a network is beyond the scope of this manual. For related
networking information, visit support.dell.com. You can also contact your support provider as described in this
section in Preface on page vi.
Related Documentation
For detailed information about FS Series appliances, PS Series arrays, groups, volumes, array software, and host
software, log in to the Documentation page at the customer support site.
Dell Online Services
You can learn about Dell products and services with this procedure:
1. Visit http://www.dell.com or the URL specified in any Dell product information.
2. Use the locale menu or click on the link that specifies your country or region.
Dell EqualLogic Storage Solutions
To learn more about Dell EqualLogic products and new releases, visit the Dell EqualLogic Tech Center site:
http://delltechcenter.com/page/EqualLogic. Here you can also see articles, demos, online discussions, and more
details about the benefits of our product family.
vi

Technical Support and Customer Service
Dell support service is available to answer your questions about PS Series SAN arrays and FS Series appliances.
Contacting Dell
If you are a customer in the United States or Canada in need of technical support,
call 1-800-945-3355. If you are outside of the United States or Canada, visit Dell EqualLogic Product Support.
If you have an Express Service Code, have it ready. The code helps the Dell automated support telephone
system direct your call more efficiently.
Warranty Information
The MODEL array warranty is included in the shipping box. For information about registering a warranty, visit
http://support.dell.com/support/topics/global.aspx/support/warranty.
Notes, Cautions, and Warnings Symbols
A NOTE symbol indicates important information that helps you make better use of your hardware or
software.
A CAUTION symbol indicates potential damage to hardware or loss of data if instructions are not
followed.
A WARNING symbol indicates a potential for property damage, personal injury, or death.
vii
Dell EqualLogic PS-M4110 Hardware Owner's Manual Preface

1 Getting Started
This chapter includes information about the location and basic operation of the replaceable components in a
storage array, the tools and equipment you will need, protecting hardware from electrostatic discharge, and
power on/off operations.
About the PS-M4110 Array
The PS-M4110 is a double-wide, half-height blade storage array with one or two hot-swappable Type13
control modules and up to 14 drives.
The PS-M4110 blade storage array fits inside and operates only when installed in a Dell EqualLogic Pow-
erEdge M1000e Blade Enclosure. It receives power from, and makes all its network connections through
the PowerEdge M1000e Blade Enclosure.
A fully-populated Dell PowerEdge M1000e Blade Enclosure is shown in Figure 1.
Figure 1: M1000e Enclosure with PS-M4110 Blade Storage and Servers
1

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 1 Getting Started
This PowerEdge M1000e Blade Enclosure contains four PS-M4110 blade storage arrays, two single-wide
full-height blade servers, and four single-wide half-height blade servers.
Front Panel Features and Indicators
The front of a PS-M4110 blade storage array is shown in Figure 2.
• Table 1 describes the features of the front panel.
• Table 2 describes the drive LED indicators.
• Table 3 describes the warnings and critical conditions that are indicated by the Array Status LED.
Figure 2: Front Panel Features and Indicators
Table 1: Front Panel Feature Descriptions
Item Indicator Description
1 Drive Status LEDs Each drive slot is represented by a green element and an amber element on
the front panel. See Table 2 for details.
2 Array Status LED The array status LED has these states:
2

Item Indicator Description
• OFF—Array is in the OFF or Standby state.
• Flashing amber — Array warning condition. See Table 3.
• Steady amber — Array critical condition. See Table 3.
• Steady blue — Normal operating state.
• Flashing blue —System ID engaged.
3 Serial ports Enable you to connect a computer directly to the array.
• The serial port for control module 0 (CM0) is on the left.
• The serial port for control module 1 (CM1) is on the right.
The serial ports are set to 9600 baud, 8 data bits, 1 stop bit, no parity, and no
flow control.
4 Array handle release but-
tons (top and bottom)
Unlocks the array enclosure's handle and use the handle to remove the array
enclosure from the chassis.
5 Express Service Tag Pull this tag to see the unit's Dell Express Service Tag number. This number
is usually required if you need technical support.
Table 2: Drive LED Descriptions1
Green Element Amber Element Description
OFF OFF Drive slot is empty
ON OFF One of these statuses:
• drive is online
• drive is ready
• drive is a spare
• foreign drive
• drive is spun down for removal
• new drive is present but not yet configured
into the RAID set
Flashing OFF Drive slot identification at user's request.
OFF ON One of these statuses:
• drive has failed
• drive is unsupported
Table 3: Warning and Critical Conditions
Condition Level Possible Reasons
Warning • Non-critical hardware component failure
• Control module removed
• Cache syncing
• High or low temperature
1All timing values are +/- 25 msec.
3
Dell EqualLogic PS-M4110 Hardware Owner's Manual Front Panel Features and Indicators

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 1 Getting Started
Condition Level Possible Reasons
• RAID set fault
• RAID set lost blocks
• Internal communication failure
• No progress with replication
• Spare drive too small
• Time of day clock battery low
• Incorrect physical RAM size
• More spare drives than expected
• Spare drive is of wrong type
• Solid-state drive added to RAID set
Critical • Critical hardware component failure
• High or low ambient temperature
• RAID set double fault
• RAID lost cache
• RAID set lost-block table full
• RAID orphan cache
• Multiple RAID sets present
• Incompatible control module
• Enclosure management link failure
• Enclosure open too long
• Degraded parity
• C2F power module failure
• RAID set unresolved
• Fabric mismatch
• No communications with CMC
Shutting Down and Restarting the Array
You can shut down a PS Series array using the Group Manager GUI or the CLI over a telnet or serial
connection, but this does not turn off power to the array or the enclosure.
A PS Series array includes hot-swappable drives and control modules (in a dual redundant module array). You
can remove a faulty component without affecting operation if a functioning component is available. Otherwise, it
is recommended that you cleanly shut down the array and turn power OFF by partially or fully removing the
array before removing a component.
Note: Be aware that the power is still ON while the array is in the chassis.
Note: When an array is shut down, any volumes with data on the array are set offline until the array is restarted.
This may affect initiators that are connected to the volumes.
4

Use Group Manager
In the Group Manager GUI, select the appropriate member name, click the Maintenance tab, and click Shut
down.
Use telnet or a Serial Connection
1. Establish communications with the array. Either:
• Use telnet or SSH to connect to a functioning IP address assigned to a network interface on the array.
Do not connect to the group IP address.
or
• Use the serial cable shipped with the array to connect either serial port on the front of the array to a con-
sole or a computer running a terminal emulator.
Make sure the serial line uses these parameters:
• 9600 baud
• Eight data bits
• One stop bit
• No parity
• No flow control
2. Log in to an account with read/write access, such as the grpadmin account.
3. Execute the shutdown command:
login: grpadmin
Password:
Welcome to Group Manager
Copyright 2001-2012 Dell Inc.
group1> shutdown
• If you are using a network connection, the session will be disconnected before the array is fully shut
down.
• If you are using a serial connection to shut down an array, it is safe to partially or fully remove the array
in order to disconnect power when the “press any key” message is displayed. (Pressing any key will
restart both control modules.)
After performing array maintenance, you can restore power to the array.
When the array restart completes, the member and volumes will be set online.
5
Dell EqualLogic PS-M4110 Hardware Owner's Manual Shutting Down and Restarting the Array

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 1 Getting Started
Protecting Hardware
Protect the PS-M4110 blade storage array from electrostatic discharge at all times.
• When handling array hardware, make sure you use an electrostatic wrist strap or a similar form of pro-
tection. Connect the strap securely to yourself (not clothes) and securely to ground.
• Examples of an appropriate ground are a properly-grounded ESD mat or the metal frame of a grounded piece
of equipment.
• If transporting the array, use the static-protective packaging that the array was shipped in, if possible.
Array Networking Considerations
This section provides requirements and recommendations for PS-M4110 array networking in the M1000e
enclosure.
The PS-M4110 array uses a single 10Gb/s Ethernet port (Ethernet 0 (iSCSI)) for communication on one of two
redundant fabrics, A or B (the default fabric).
• Fabric A is a redundant Ethernet fabric that supports IO module slots A1 and A2. The PS-M4110 requires
10Gb/s Ethernet IO modules in A1 and A2. The M1000e must have a Version 1.1 midplane to support
10Gb/s modules on Fabric A.
Note: If the M1000e has a Version 1.0 midplane, 10 Gb/s Ethernet IO modules are not supported by Fabric
A and the PS-M4110 will not be able to connect.
• Fabric B is a redundant Ethernet fabric supporting IO module slots B1 and B2 at 10Gb/s with a 10GBASE-
KR IO module.
Optionally, Ethernet port 1 on the PS-M4110 array can be set up as a management port and be accessed through
the CMC. See Setting up a Dedicated Management Port in the Dell EqualLogic PS-M4110 Installation Guide.
Networking Information Resources
• Details about network requirements and recommendations are provided in Network Requirements on page 7,
Network Recommendations on page 9 and Optional Considerations on page 10.
• General network, and network configuration of the M1000e is beyond the scope of this manual. Refer to the
Dell PowerEdge M1000e Enclosure Owner's Manual and Dell PowerEdge Configuration Guide for this infor-
mation. Also, refer to the associated Dell IO module documentation.
• Additional documentation can be accessed on the Dell support site (support.dell.com). See the Preface on
page vi for information about accessing the Dell support site.
6

• You can also contact your technical support provider for help and information, as described in the Preface on
page vi.
Network Requirements
Switched 10Gb Ethernet Network
When the PS-M4110 is installed in a M1000e chassis that has the proper M-Series IO Modules (KR-based
blade network switches) or pass-throughs installed, all network connections are 10GbE. The IO modules on
the fabric to which the PS-M4110 is connected must be KR-based 10GbE.
Interconnect All SAN Switches
For increased availability, the Ethernet ports on both PS-M4110 control modules are automatically connected
to each redundant M1000e IO module (IOM) of the configured fabric. (Assuming that both IO modules are
installed.) One port is active and one port is passive.
For example, if a PS-M4110 is configured for Fabric B, and both the B1 IOM and B2 IOM are installed, the
Ethernet ports from each control module are connected to both B1 and B2 IOMs. This provides a total of
four potential Ethernet paths. However, only one Ethernet path is active at any given time.
In the above example, if the B1 IO module fails, both active and passive PS-M4110 ports will automatically
failover to the B2 IO module.
See Figure 3 for an illustration of the above example, showing how the PS-M4110 control modules and
M1000e fabric IOMs are connected.
7
Dell EqualLogic PS-M4110 Hardware Owner's Manual Network Requirements

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 1 Getting Started
Figure 3: Example of Default Fabric B Network Paths
Active 10G path
Network path failover
Passive control module standby network paths
External stack or LAG connection
Stack Switches Together
When using a PS-M4110 inside an M1000e enclosure, the IO modules must be interconnected (stacked or
LAGged together).
For example, if fabric B is configured, the B1 and B2 IOMs must be stacked or LAGged together. The redun-
dant fabric IO modules must be connected using inter-switch links (stack interfaces or link aggregation
groups (LAG)). The links must have sufficient bandwidth to handle the iSCSI traffic.
For ease of management, Dell recommends using stacking configurations wherever possible. Use the Equal-
Logic Group Manager GUI or CLI to assign an IP address and netmask to each interface.
Figure 3 shows an example of stacking B1 and B2 IO modules.
Configure Access to Group IP Address
If a PS-M4110 connects with storage arrays that are outside of the M1000e chassis (external arrays), the net-
work must be configured so that the PS-M4110 has access to the group IP address used by the external
arrays. All of the arrays in the group must be in the same (layer 3) subnet.
8

Network Recommendations
Provide Redundant Network Paths Between Hosts and Arrays
Use a multipathing solution to make sure that no single point of failure exists between hosts and arrays.
Dell recommends using the Dell EqualLogic Host Integration Tools (HIT) solution, available for Microsoft,
VMware and Linux platforms.
Provide Adequately-Sized Reliable Network Link (for replication)
When replicating with groups outside of the M1000e chassis, for effective and predictable replication, make
sure that the network link between the primary and secondary groups is reliable and provides sufficient band-
width for copying the required amount of data within the required time.
Disable STP Functionality on Switch Ports that Connect End Nodes
If possible, do not use Spanning-Tree Protocol (STP) on switch ports that connect directly to iSCSI end
nodes (iSCSI initiators or array network interfaces).
However, if you must use STP or RSTP (preferable to STP), you should enable the port settings (available
on some switches) that let the port transition faster into STP forwarding state upon link-up (i.e. portfast).
This functionality can reduce network interruptions that occur when devices restart, and it should only be ena-
bled on switch ports that connect end nodes.
Some iSCSI BOOT Initiators may not startup reliably when STP is enabled, due to the convergence time.
For further information, refer to the associated specifications for your NIC and Switch.
You can use Spanning-Tree for a single-cable connection between switches, and you can use Link Aggre-
gation Groups (LAG) (or port-channels) for multi-cable connections between switches.
Enable Flow Control on Switches and NICs
Enable Flow Control on each switch port and NIC that handles iSCSI traffic. PS Series arrays will respond
correctly to Flow Control.
Disable Unicast Storm Control on Switches
Disable unicast storm control on each switch that handles iSCSI traffic if the switch provides this feature.
However, the use of broadcast and multicast storm control is encouraged on switches.
Enable Jumbo Frames
Enable Jumbo Frames on each switch and each NIC that handles iSCSI traffic.
PS series arrays support Jumbo Frames, which is enabled by default (MTU 9000). Enable Jumbo Frames on
each switch and iSCSI initiator (NIC) to take advantage of this feature. For further information, refer to the
associated documentation for your switch and NIC.
9
Dell EqualLogic PS-M4110 Hardware Owner's Manual Network Recommendations

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 1 Getting Started
Optional Considerations
Management Network
Optionally, Ethernet 1 on the PS-M4110 array can be set up for a management port and be accessed through
the CMC to keep management traffic separate from iSCSI traffic.
You can do this by using the Dell Chassis Management Console command line interface (CLI), or the Equal-
Logic Group Manager GUI or CLI.See Setting up a Dedicated Management Port in the Dell EqualLogic PS-
M4110 Installation Guide.
10

2 Handling the Array
This section provides information about handling the PS-M4110 array. It describes how to open, remove, and
insert the array inner drawer that holds the array drives and control modules. It also describes how to remove
and insert the entire array from the M1000e enclosure.
About Handling the Array
Be careful when handling the PS-M4110 blade storage array. The PS-M4110 array has an outer shell that houses
an inner drawer (containing the array drives and control modules). The inner drawer can accidentally slide out of
the outer shell if it is not closed.
Warning: If the inner drawer slides open unexpectedly, the sudden weight shift of the heavy inner drawer
could cause the array to fall off the surface it is resting on, or to be dropped by a person holding it. Damage to
the array, or injury to yourself or nearby people, could result.
Before handling a PS-M4110 blade storage array, always check that the array inner drawer is securely closed.
A warning symbol and message that indicates that the drawer is open is printed on the front top edge of the inner
drawer. This message is visible only if the inner drawer is open. Check to make sure that this message is not
visible before handling the array. See Figure 4.
11

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 2 Handling the Array
Figure 4: Drawer Open Indication
Opening the Array Drawer
You must open the array inner drawer to access the drives and control modules. It is designed to open fully to
provide complete access to all the drives and control modules.
Note: If you need to remove the array inner drawer completely from its shell when it is out of the M1000
enclosure, see Releasing the Array Inner Drawer Safety Latch on page 25.
Caution: The front panel is not designed as a handle. It can break if treated roughly. When opening the array
inner drawer, do not pull on the front panel. Grip and pull the drawer by its top, bottom, or sides.
To open the array inner drawer:
1. Push firmly on the array's front panel, releasing it quickly. See Figure 5. This press-and-release motion
releases the array inner drawer from its enclosure. It should spring open enough to provide access to grip the
sides or bottom with your hands.
12

Figure 5: Pressing the Array Drawer to Unlatch It
2. Grip the side or bottom edges of the array drawer (not the plastic front panel) and slowly pull the drawer out,
as shown in Figure 6.
13
Dell EqualLogic PS-M4110 Hardware Owner's Manual Opening the Array Drawer

Dell EqualLogic PS-M4110 Hardware Owner's Manual Chapter 2 Handling the Array
Figure 6: Opening the Array Drawer
3. Continue to pull the drawer open, carefully controlling the speed at which it opens, until you can reach the
drive or control module you need to access.
Caution: Be careful when opening the array drawer -- it is heavy. Open the drawer slowly, so that it does not
have a lot of momentum as it slides open. If the drawer slides out too quickly, it could damage its housing. It
could also break free of its housing and fall on the floor, causing damage to array and injury to nearby people.
Closing the Array Drawer
For proper operation, the array inner drawer must be completely closed and secured within its housing. You can
open the drawer briefly to replace a failed component, but do not leave it open for long periods of time —
leaving it open disrupts the flow of air that cools the drives and could lead to overheating.
When you have finished working on the array components within the array drawer, close it immediately. To
close the array drawer:
1. Press gently on the front panel of the array, pushing the drawer all the way into its enclosure. See Figure 7.
14
