DELTA DORE TYMOOV 30FB User manual

EN Wired roller shutter motor pack
Pack TYMOOV 30 FB

EN
2 3
Recommendations
WARNING: Important safety instructions
Incorrect installation can result in serious injuries.
Follow all instructions and retain these installation instructions for
future reference.
-TYMOOV xFB motors are designed solely for the operation of rollers
shutters for home use. For any other use, please contact our technical
department.
- The minimum internal diameter of the rolling tube is 47 mm, however,
the tube must be chosen according to the weight and length of the
apron. Consult the tube manufacturers’ charts.
- Do not operate the roller shutter if people or objects are within the
movement area.
- Moving parts of the motor installed at a height of less than 2.5m must
be protected.
- Before installing the motor, remove all superuous cords and take any
equipment not required for the motor to operate out of service.
- NOTE: Do not operate the shutters or cut off their power supply
when maintenance or cleaning work is being carried out on the
equipment or in close proximity (e.g. window cleaning).
- Monitor the shutter when it is moving and stand clear until it is
completely closed.
-
Do not allow children to play with the xed control devices. Keep
remote control devices out of the reach of children.
- This device can be used by children of at least 8 years of age, and by
persons with reduced physical, sensory, or mental capacities, and also
by persons lacking in experience or knowledge, provided that they are
correctly supervised or that instructions relating to the use of the safe
use of the device have been provided to them, and provided that they
understand the risks involved.
Children must not play with the device. Cleaning and maintenance by
the user must not be performed by children if unsupervised.
- The operating device for a switch without a lock must be in direct
view of the driven part, but away from the moving parts. It must be
installed at a height of at least 1.5m.
- Fixed control devices must be installed so as visible.
- During the use of a switch without a lock, make sure that all other
persons present keep their distance;
- Frequently check the equipment to detect any imbalances or signs of
wear or damage to cables and springs.
- Do not use the device when repairs or adjustments are required.
Preliminary elements
- Sufciently rigid roller shutter slats should be used.
- When the roller shutter is closed, the apron must not overlap the
runners by any more than one 1/2 slat.
- The apron clips or automatic locks used on the shutter must be used
in accordance with their manufacturer’s instructions for use.
It is essential that you adjust the number of locks based on the
model and the number of links.
- If used with upper stops, you should preferably use systems that are
built into the runners.
- Pay attention to the frame rigidity with stop systems on the shutter
slats.
Translation of the
Original Manual

EN
4 5
Recommendations
- Correct operation of the motor is ensured if it is installed and used
according to the following recommendations.
It is essential that peripheral components such as the rolling tube,
the supports, the screws etc. are appropriate and are assembled
in accordance with the latest standards. The specications of
the driven part must be compatible with the assigned load and
operating time.
- Weighted noise pressure level A: LpA ≤ 70 dB(A).
- Cables passing through a metallic wall must be protected and
isolated by a sleeve.
- If the power cable is damaged, the motor must be replaced by the
manufacturer, by the aftersales service, or by similar qualied
personnel, so as to avoid any danger.
- The motor must be chosen according to the requirements of the
load bearing support. See our charts regarding the selection of the
motor according to shutter type. A plate on the motor indicates the
nominal torque and operating time.
- TYMOOV xFB tubular motors are designed to operate
intermittently (4 minutes of continuous operation). They are
electronically protected to prevent overheating. If there is a thermal
shutdown, the motor will operate again after a timeout period of
around 20 minutes. To operate again for a period of 4 minutes, the
motor must have returned to room temperature.
DELTA DORE hereby declares that the motorised drive unit covered by these
instructions is compliant with the essential requirements of the Machinery
Directive 2006/42/EC, and the European directive 2014/30/CE
The EU declaration regarding this device is available on request,
with requests to be submitted to the following address:
«Technical info» department
DELTA DORE – 35270 Bonnemain (France)
Email: [email protected]
DELTA DORE
35270 - BONNEMAIN - France
[email protected]
Because of changes in standards and equipment, the characteristics specied in the text and illustrations
in this document are not binding unless conrmed by our respective departments.

EN
67
• Power supply: 230V - 50 Hz +/- 10%
• Class I insulation
• Operating time: 4 minutes
• Electrical power ratings:
TYMOOV 10FB : 112 W
TYMOOV 20FB : 145 W
TYMOOV 30FB : 191 W
• Weighted noise pressure level A: LpA ≤ 70 dB(A).
• Protection rating: IP44
• Operating temperature: -10°C -> +50°C
• Dimensions:
Model Diameter Total length Length excluding head
30 FB 45 mm 556 mm 537,4 mm
Technical specications
Pack contents
1 wired tubular motor TYMOOV 30 FB
3 telescopic tubes
1 lateral tube mounts
4 fasteners connecting the roller
shutter to the tube
Fastener kit
Bearing lot
1 adjusting tool
Contents
1/ Installation....................................................................................................8
1.1 Installing the tube..................................................................................................... 8
 ............................................................................................................. 10
1.3 Installing the fasteners........................................................................................ 12
2/ Connection ................................................................................................14
3/ Setting stops..............................................................................................15
3.1 Adjusting screw selection table ...................................................................... 16
3.2 Setting the bottom stop...................................................................................... 16
3.3 Setting the top stop............................................................................................... 16
4/ Troubleshooting.......................................................................................17

EN
89
1/ Installation
1.1 Installing the tube
❶Lower the roller shutter completely.
❷Open the roller shutter casing.
❸Mark the exact position of the tube spindle.
In order to position the spindles for the new mounts
in the same locations, mark the exact rotating position
of the old tube.
❹Disconnect the shutter fasteners, disassemble the tube and the old mounts.
If your installation includes brackets, keep them.
❺Attach the new mounts
using the spindle marks.
❻Determine the length of the new tube.
- Measure the distance between the 2 mounts.
- Calculate the length of the tube.
Adapt the length of the tubes according to the dimensions measured
If necessary, cut the tubes to size. Preferably cut the
telescopic assembly to make installation of the new
tube easier.
Leave enough length to ensure that at least 140 mm
(safety dimension) of tube 2 is inserted into tube 1
after nal positioning.
750 mm
1040 mm
x
Support de
roulement
Support moteur
Côté alimentation
Bearing
mount
Motor mount
x :
x = Distance between the 2 mounts
- 5 mm =
Length of the tube
Max. cut
2666 mm max.
11
Tube 1
140 mm mini
Tube 2
Coffre tunnel Coffre menuisé

EN
10 11
1/ Installation
1.2.3 Motor head position
The motor head must be positioned on the support as such that the cable outlet is in
the lower part relative to the horizontal.
1.2.4 Mounting of the motor onto its support
Push the tube/motor assembly (A) onto the support (B) until it engages (click).
Cable
(A)
(B)
“Click”
Always make a kink in the power cable
to avoid the penetration of water into
the motor.
Screwing into the motor
head is strictly prohibited.
1.2 Motor tting
• Never strike the motor head or output shaft to t the motor into the tube.
Never pierce the tube when the motor is installed.
• To attach the apron, use screws that do not protrude into the tube by more
than 1 mm.
1.2.1 Crown and wheel assembly
1.2.2 Mounting in the tube
For mechanical parts and drive and mounting accessories,
consult our catalogue.
Model Length for drilling (L) Total length
TYMOOV 30 FB 525 mm 556 mm
Crown
Motor
head
Wheel
“Click”
Adjusting
screw
Tube
L: length for drilling wheel
attachment using screws or rivets

EN
12 13
1/ Installation
Attach the fasteners to the tubes.
Attach the fasteners using the screws provided.
Use the holes marked 1 and 2.
Check that the fastener springs are correctly
positioned on each side of the links.
Coupling bars
The coupling bars are reversible and can adapt to slats of
thickness 8 mm and 14 mm.
Using the coupling bars, connect the fasteners and the rst slat of the shutter
Dimension to check for optimum operation
Check dimension A to ensure the roller shutter operates
in the optimum manner.
A = Minimum 20 mm/Maximum 70 mm.
If necessary, remove the blade from the apron.
1.2.5 Telescopic assembly
Check that the tube is installed perfectly horizontally.
Check that the motor remains unrestricted on
its axis.
1.3 Installing the fasteners
Position the fasteners on the tubes
11 3
!
2
Drill Ø 4 mm holes
140 mm min.
(safety
dimension)
Tube 2 Tube 1
The 4 blind rivets supplied must be used to assemble each part of the telescopic
tubes
1 mm
!
Motor mount
Crown
Place the fasteners as close as possible to the ends
of the edge of the slats.
The fasteners must be spaced a maximum
of 800 mm apart.
8
mm
14
mm
clic
12
Use the screws provided. The screws must not
be in contact with the motor.
Side adaptable to slats
of thickness 14 mm
Side adaptable to slats of thickness 8 mm
!
1600 mm
800 mm
800 mm
max.
2500 mm
max.
A
The rst blade must be inserted into the lateral
guides when the apron is fully lowered.

EN
14 15
The electrical wiring must comply with EN, IEC and national institute standards (e.g.
NF C15-100 for France).
In all instances, it must still be possible to switch off the power supply using an
omnipolar device in accordance with the applicable installation requirement. If
the motor is supplied with a H05VVF power cable, this cable cannot be installed
outdoors, unless it is inside a UV-resistant duct.
For outdoor use, the motor must be equipped with a RNF or RRF rubber cable with
at least 2% carbon. Contact the sales department.
Connection with a toggle or biased change-over switch
- A change-over switch prohibiting the simultaneous pressing of
the or buttons must be used.
- In the case where a biased change-over switch is used, the user must press and
hold the button throughout the shutter operating time.
You can wire several motors to the same change-over switch, within the maximum
permissible current capacity, however, the adjustment of the stops must be
performed separately.
2/ Connection
4 x 0.75 mm²
L
L
N
N
Blue Neutral
Brown Phase for rotation or .
Black Phase for rotation or .
Yellow /
Green
Earth
L Phase
N Neutral
Black
Brown Blue
Note: If the raise and lower directions
are reversed, swap the brown and
black wires ( and on the change-
over switch).
Power supply
230 V, 50 Hz
Single-phase
Yellow / Green
3/ Setting stops
You can connect Tyxia 5630 micromodules to the Tymoov xFB motors.
They must be connected after the setting of the stops.
❶Identify the type of roller shutter winding
❷Determine the position of the motor viewed from the outside of the dwelling
❸Setting the stops
To set the stops, use the adjusting tool or a 4 mm hex
screwdriver.
Exterior
housing
Interior
winding
Exterior
winding
Exterior
housing
Interior
housing
Interior
housing
Left
mounted
motor
Right
mounted
motor
White adjusting
screw
Red adjusting
screw
Red adjusting
screw
White adjusting
screw
Left
mounted
motor
Right
mounted
motor

EN
16 17
3/ Setting stops
3.1 Adjusting screw selection table
Interior winding Exterior winding
Left mounted
motor
Right mounted
motor
Left mounted
motor
Right mounted
motor
Setting the top
stop
Red adjusting
screw
White adjusting
screw
White adjusting
screw
Red adjusting
screw
Setting hte
bottom stop
White adjusting
screw
Red adjusting
screw
Red adjusting
screw
White adjusting
screw
3.2 Setting the bottom stop
The skirt of the roller shutter must be detached from the winding spindle.
❶Activate the motor to lower the shutter until its reaches its stop.
❷While still holding the control to lower the shutter, turn the bottom stop (see
table) adjusting screw towards (+) until it reaches the correct position for the
securing of the lock.
❸Attach the roller shutter to the tube using the locks.
3.3 Setting the top stop
❶Activate the motor to raise the shutter.
❷NOTE: if the shutter reaches the stop before the motor stops, switch it off
immediately. In the opposite case (if the motor stops before reaching the top stop),
move on to step ❻.
❸Turn the adjusting screw for the top stop (see table) in the (-) direction.
❹By applying the control to lower the shutter, bring the roller shutter to beneath
the desired position, and stop it there.
❺Repeat operations ❶to ❹until the shutter reaches the top stop (in this case,
move on to step ❻).
❻The motor stops beneath the top stop.
Holding down the control to raise the shutter, turn the top stop adjusting screw
towards (+) until the roller shutter reaches the desired position.
❼The stops have been set.
If the motor is not working:
- Check that the wiring corresponds to the diagrams in the «Connection» chapter.
- Check the power supply within the network.
- Check that the motor is not in thermal protection mode; just wait 20 minutes for it
to cool down.
- Reset the end of travel positions if necessary.
The end of travel points are not adhered to:
- Check the mechanical components of the system
(stabilisation, play, distortion, etc.)
- Reset the end of travel positions if necessary.
Inversion of the direction of rotation.
- Switch the black and brown wires connecting the motor to the change-over switch.
4/ Troubleshooting

www.deltadore.com
04/23
