Delta Electronics Exhaust Fan GFB Series User manual

Maximum
Air Flow
Watt CFM
Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Pressure
Noise
PART NO.
REV.
FUNCTION VDC VDC Amp R.P.M. mmH
2O IN H2
O dB-A
40 x 40 x 56 MM SERIES
GFB
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
Bearing Type
Ball Bearings
Material
Impeller & Frame: Plastic (UL94V-0)
Lead Wires :UL 1061 AWG #26
OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 84g (2.96 oz)
*
*
*
UNIT: (INCH)
mm
mm
(INCH)
UNIT:
http://www.deltaww.com
*
OUTLET SIDE INLET SIDE
* Function type is optional.
The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
Noise is measured in anechoic chamber in free air, one meter from intake side.
All readings are typical values at rated voltage.
Specifications are subject to change without notice.
*
*
*
*
GFB0412SHS -A -R00 / -F00 12 7.0 to 13.2 1.02 12.24 16200/7800 0.659 23.29 44.41 1.748 58.5
GFB0412EHS -A -R00 / -F00 12 7.0 to 13.2 1.40 16.80 16200/12000 0.762 26.92 45.76 1.802 62.5
Speed
(Front /Rear)
72
Air Direction
Input
Power
Input
Current
