Delta Light TWEETER X P 30 User manual

1
Last Update 28/11/2014
NORTH AMERICAN EDITION
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Installation instruction TWEETER X P 30
Application
Floor surface mounted
For indoor & outdoor use
Color Finish
N - Dark Grey
Light source
1x POWERLED WHITE 7W / 3000K
Product description
Corrosion protected, powder coated aluminum construction
Electronic power supply included. 120V input, 350 mA current controlled class 2 output.
5’ SJ00W cable included for easy installation
Suitable for wet, damp or dry locations
Dust-tight - Protected against water jets IP65
Weight: 3,1lbs 1,4kg
Accessories not supplied (option)
PIN 11 229 01 11
IP68 CONNECTOR 3P 6 216 12 02
JUNCTION BOX 6 216 12 00
TWEETER X P 30
6 206 43 12
= N
Ø95mm
Ø3”-3/4
177mm
7”
Ø134mm
Ø5”-5/16
350
424mm
16”-11/16
8mm
5/16”
Conforms to ANSI/UL Std. 1598
Cert. to CAN/CSA Std. 22.2 No. 250.0

Installation instruction TWEETER X P 30
2
NORTH AMERICAN EDITION
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Use 1/2” conduit or any
other local code compliant
method!
Use 1/2” conduit or any
other local code compliant
method!
Cable entry
30mm
1”-5/32
38mm
1”-15/32
52mm
2”-1/32
38mm
1”-15/32
39mm
1”-17/32
64mm
2”-1/2
77mm
3”-1/32
Ø5,5mm
Ø3/16”
B (3x)
C
A
EXAMPLE: TWEETER X P 30 / 6 206 43 12
OPTION
JUNCTION BOX
6 216 12 00
Use 1/2” conduit
or any other local
code compliant
method!
A
B
A
B
SAVE!
B
A
Accessories
INSTALLATION LUMINAIRE
4
2 3
350°
