SAFE OPERATING INSTRUCTIONS
•The charger contains up to 25 selectable charging algorithms stored in its internal memory to charge
batteries. These algorithms are specific to each manufacturer and model of battery. Your equipment
supplier or charger distributor is responsible for ensuring the active charge algorithm matches the battery
pack charging requirements. Contact them
withanyquestions aboutwhichalgorithmtoselectforeach
batterypack.
•
The charger may become hot during charging. Use hand protection tosafely handle the charger when
charging.
•
Tomaintain safe operations, the unit automatically reduces its output power if the temperature rises
above set thresholds, orif the ACinput voltage is too low.
•
If power is interrupted, and then returns, the charger restarts and continues to operate without hazard to
the user, ordamagetothebatteries.
•
Unplug the charger from bothAC and DC sources when cleaning, moving, or conducting any maintenance
or repair onthecharger.Nouser serviceable parts are inside. Donot remove the cover due totherisk of
electricalshock.
•
Do not expose the charger to oil, dirt, mud, or direct heavy water spray when cleaning the vehicle or
machine.
•
If the detachable AC input power cord set or DC output cord is damaged, do not use the charger until they
are
replaced with cord sets appropriate to your region and application.
•
When mated with a Delta-Q Technologies sealed AC cord, the charger meets IP66 specifications, making
it dust-tight and protected against powerful water jets. Ifacord set with anunsealed connectorisused,the
plug and connector must beperiodically inspectedtoensurethecontacts arecleananddry.
o
If this charger is provided with an AC cord set and the power plug does not match the power outlet,
contact the equipment manufacturer, distributor,
or Delta-Q Technologies for the correct
ACcordset
terminatingwitha3-prong
plug suitable for your region’s grounded power outlet.
o
In North America (and other 120V AC regions),
the AC cord must be a 3-conductor ULListed/
CSAapproved detachable cord setatleast1.8m
in
length (≥ 6 feet), minimum 16 AWG and rated
SJT; rated 105˚C min, and terminated with 125V,
13A, or greater connector.
o
In Japan, the AC cord must be a 3-conductor PSE
approved detachable AC cord set, rated 105˚C,
and terminated with 100V,
15A, or greater
connector.
o
In 220-240VAC regions, the AC cord must be a 3-conductor safety-approved cord set, with
1.5mm² conductors (min.), rated appropriately for industrial use. Thecord must beterminated on one
end with a grounding type input plug appropriate for useinthecountryofdestination; both plug and
connector should berated 250V, 10A, orgreater.
•
Extension cords must be 3-wire cords no longer than 30m (100’) at 10 AWG or 7.5m (25’) at 16 AWG, per
UL guidelines.
